Pyle PWLB003 User manual

Fig 3
2
1
Plasma LCD bracket
Thinnest design: Distance to the wall is only 37mm
Easy installing: just glide and embed to finish
installing of panel
Max load capacity:15kg/33lbs
According VESA standard to design
IMPORTANT: If don’t understand about right install ways, please
consult to normal installing specialist.
-4-
Item No.:PWLB003Item No.:PWLB003
INSTALLATION GUIDE
Ideal for Flat Panels from 10 to 24""
Caution :This Product LCD /Plasma Wall Mount Bracket is
intended for use only with the maximum weights indicated .See apparatus
instructions .Use with products heavier than the maximum weights
indicated may result in instability causing possible injury .
Caution :

No Name
A
B
D
C
E
F
1
1
4
4
4
LCD panel
Wall mount
M4x8 bolt
M4x12 bolt
Long bolt
Wall anchor
Parts:
Fig2
Qty
G2
2
B
ACDE
Fig 1
Step 1:
Choose fitting position on the wall.
Important: Make sure there is
enough space to spread LCD,
considering show size.
This product offers two installing
parts: wooden wall and cement
wall.
Step 1:
Choose fitting position on the wall.
Important:
Installing ways of batten wall.
Use a electronic detector in lay position to detect the position of batten,
then making a mark. Put the wall mount in the installing position flatly,
using it as template, lining out a hole in the center of batten. Using a
aiguille of dia.3mm to drill two 50mm deep holes. Using long bolt to
install wall mount carefully.
Step2: Installing wall mount
Step2: Installing wall mount
Installing ways of cement and beton wall
Put the wall mount flatly in the installing position, using it as template,
lining out the hole on the wall. Use a aiguille of dia.8mm to drill a 50mm
hole, embedding the wall anchor to hole, and knocking it into wall lightly.
wall anchor is just fit for cement and beton wall. Don't use
wall anchor in drywall to install bracket.。
Carefully:
According LCD hole's size, deep, position
to choose bolt. Using M5 washer and
chose bolts to install the LCD on the
panel. Showing as Fig 2.
Don't force the bolt to LCD
hole, avoiding damage to people and
instrument. Don't use electronics drill
to fasten screw.
Step 3: Installing LCD
Carefully:
Step 3: Installing LCD
Carefully:
Step 4: Button the LCD to wall
Warning:
Firstly put up the panel and TV, making the small trough on the
panel fit to the big trough on the wall mount, according trough to
embed the LCD panel into the wall mount, As shown in Fig 3.
It needs 2 people to put up some TV! Our company will not
responsible for any damage by man-made.
Step 4: Button the LCD to wall
Warning:
M5x8 bolt
M5x12 bolt
M5 washer
4
2
4
1
2
FG
1
-3-
-2-
F
G
E
A-D
