Pyle PSWLE56 User manual

TV Size Range: 23
Maximum Weight Capacity: 30kg/66lbs
Locked by safety bolt on the bottom
"～ "46
Balance adjust system is included
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.
CAUTION
-8-
Thank you for choosing our productThank you for choosing our product
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
!
.
Warning
Item No.:PSWLE56Item No.:PSWLE56
INSTALLATION GUIDE
www pyleaudio com..
Pyle Audio
1600 63rd st , Brooklyn, NY, 11204
[phone]

-2- -7-
2
ID Description
1
2
3
1
1Left bracket
Bubble level
Safety bolt
Qty
5
2
1
4
1
Hardware Kit:Hardware Kit:
A-H LI K
JM
3
1
Wall plate
1
2,3
Wall Wall
6
6
6
4
I
J
K
L
M
Square washer
Long bolt
Wall anchor
Long bolt washer
Spacer
B
C
4
4
M4 mm×16 bolt
M5× mm16 bolt
M6× mm16 bolt
M ×36mm5 bolt
M6×36mm bolt
M ×36mm8 bolt
D4
4
4
4
4
F
G
H
ID Description
Qty
M8×16mm bolt
4
E
A4M4 mm×12 bolt
Right bracket
4
NOTE: Always use an assistant or mechanical lifting equipment to safely lift
and position heavy equipment.
NOTE:
Part 3-Mounting the flat panel screen
Hook the top of brackets onto the top flange of wall plate(1). Then
swing the screen down. Tighten the safety screw on each bracket to lock
the screen into place.
(2,3)
(4)
Part 3-Mounting the flat panel screen
54

-6-
I
M
F-H
Part 2b-Attaching brackets to screen with recessed back
Center brackets vertically on back of screen. Select the medium(F or G) or
large(H) screws. Attach brackets to screen using four selected screws,four
square washers(I) and four spacers(M) at the top and bottom of each bracket.
Tighten screws firmly. Do not overtighten.
Part 2b-Attaching brackets to screen with recessed back
Square washer(I)
Medium hole for
M5andM6screws
Large hole for
M8 screws
-3-
Part 1a-Wood Stud Mounting
.
Use wall plate as a template, make sure it is level, and mark mounting holes
along the center lines of the wood studs. Drill 3/16
)
)..
””(5mm)dia holes 2
(50mm) deep. Level wall plate and attach to wall with long bolts(J and
washers(L . Tighten screws firmly Do not overtighten
Part 1a-Wood Stud Mounting
Wood stud
J
L
Bubble level
2 50mm)”(
Φ3/16 (5mm)”

-5-
.
Part 2a-Attaching Brackets To Screen With Flat Back
Center brackets vertically on back of screen. Select the small(A or B),medium
(C or D) or large(E) screws. Attach brackets to screen using four selected
screws and four square washers(I) at the top and bottomof each bracket.
Tighten screws firmly. Do not overtighten
Part 2a-Attaching Brackets To Screen With Flat Back
A-E
I
Square washer(I)
Small hole for
M4 screws
Medium hole for
M5 and M6 screws
Large hole for
M8 screws
-4-
Part 1b-Concrete Wall Mounting
.
Level wall plate and use it as a template to mark holes. Drill 3/8 (10mm) dia.
holes 2 (50mm) deep. Insert anchors(K) into holes and secure wall plate
with long bolts(J) and washers(L). Tighten screws firmly. Do not overtighten
”
”
Part 1b-Concrete Wall Mounting
Concrete Wall
2(”50mm)
Φ3/8 (10mm)”
Bubble level
K
J
L
