QDI Vision-1 User manual

VISION-1
AGP
3D Graphics Card

VISION-1 AGP
User’s Guide
Version 1.1
Copyright1997 LEGEND.QDI
All rights reserved
No part of this manual may be reproduced or transferred to other
media without permission from QDI.
Notice
QDIbelieves the information contained in this document are accurate and
reliable. However, QDIreserves the right to make corrections, improvements, or
changes to this document at any given time without notice.
Please refer to README file in the driver diskette for operating instructions and
other information updates.
Trademarks Acknowledgment
•MS-DOS, Windows, and DirectX are trademarks of Microsoft Corporation.
•Pentium is a trademark of Intel Corporation.
•OS/2, VGA are trademarks of IBM Corporation.
All other brand and product names are trademarks of their respective companies.

Contents
Introduction
1 ............................................................................................................1
 ............................................................................................................3
Deutsch...........................................................................................................5
Francais......................................................................................................... 7
Italiano............................................................................................................9
Español........................................................................................................ 11
Portugese..................................................................................................... 13
English.............................................................................................................. 15
Features............................................................................................................. 15
System Requirements ..................................................................................... 16
Package Contents............................................................................................. 16
Software Upgrade............................................................................................ 16
Hardware Installation 17
Drivers for Windows 95 19
Before You Begin............................................................................................ 19
Operating System Requirements ................................................................... 19
Windows 95 Driver Installation..................................................................... 20
Configuring the Windows 95 Driver............................................................. 22
Drivers for Windows NT 26
Windows NT 4.0 Driver Installation............................................................. 26
Configuring the Windows NT 4.0 Driver..................................................... 27
BIOS Upgrade 27
~

User’s Manual
1
Introduction

  
    
     
 

•  
•   
•
•   
• 
 
•    
• 
• 
• 

Introduction
2
• 
  
• 

   
    

  

  
    
     
 


User’s Manual
3
•  
•   
•
•   
• 
 
•    
• 
• 
• 
• 
  
• 

   
    

  

Introduction
4
Deutsch
Wir danken lhnen für den Kauf der VISION-1 AGP 3D Grafikkarte. Mit
dem eingebauten Rendition V2200 True Media Accelerator verbindet lhre
VISION-1 eine hervorragende 3D Beschleunigung mit 2D Grafiken und
ausgezeichneter Videoqualität auf einer einzigen Platine. Es bietet lhnen
eine sowohl hohe Performance-Leistung aus als auch eine
zufriedenstellende Qualität für einen 3D Spiel-und Multimediaeinsatz.
Technische Daten:
•AGP Bus, AGP V1.0 Interface angepasst
•Rendition V2200 Accelerator gekoppelt mit einem Hochleistungs
RISC Prozessor
•4MB 100MHz SGRAM auf der Platine
•Eine 230MHz RAMDAC für eine hohe Bildauflösung,gute
Farbsättigung und eine hohe Bilderneuerungsrate bis zu
1600 x 1200 bei 85Hz
•Hardware “Triangle” Funktion, Pixel Funktion und Füllfunktion, die
lhnen hochentwickelte 3D Funktionen und 3D Specialeffekte liefern
•Video Abspielfunktion von überzeugender Qualität,
MPEG-2/DVD Beschleunigung
•voll VGA kompartibel

User’s Manual
5
•DPMS für Power Management Unterstützung
DDC2B für den Monitoranschluß und Abspielunterstützung
•Driver für die wichtigsten Operationssysteme und APIs
Windows 95 (OSR2.1), Windows NT 4.0
DirectX 5.0. OpenGL, etc. Unterstützung mit 3D
Beschleunigung für die bekannntesten Spiele
Systemanforderungen:
Computer : Benutzung der Hauptplatine mit einem AGP Bus slot
Monitor : Standard VGA Monitor. Um alle Vorteile der
Grafikkarte auszuschöpfen, benötigen Sie einen
hochauflösenden Multifrequenzmonitor.
Software : Windows 95; Windows NT, etc.

Introduction
6
Francais
Nous vous remercions d’avoir choisi la carte de graphiques VISION-1
AGP 3D. Munie de l’accélérateur de traduction incorporé “V2200 True
Media Accelerator”, votre VISION-1 réunit sur une seule carte
l’accélération exceptionnelle 3D avec d’excellents graphiques 2D et une
qualité supérieure de vidéo. Elle fournit également une performance
remarquable aussi bien qu’une qualité de choix dans les jeux 3D et les
applications multimédia.
CARACTERISTIQUES:
•Bus AGP, accomodant interface AGP V1.0.
•Processeur RISC de haute performance avec Accélérateur de
Traduction V2200 intégré.
•4MB 100MHz SGRAM sur monocarte.
•Un écran RAMDAC 230MHz à haute résolution, grande intensité
de couleur et à grande vitesse de rafraîchissement allant jusqu’à
1600 x 1200 avec 85 Hz.
•Les mécanismes triangle hardware, pixel et d’insertion fournissent
des caractéristiques perfectionnées 3D et des effets exceptionnels
3D.
•Reproduction vidéo de haute qualité, accélération
MPEG-2/DVD.
•Compatibilité VGA entière.
•DPMS pour soutien de gestion de puissance
DDC2B pour fiche de moniteur et soutien de reproduction.
•Gestionnaires pour les principaux systèmes de fonctionnement et les
APIs.
Windows 95 (OSR2.1), Windows NT 4.0
DirectX 5.0, OpenGL, ect.
Soutien des jeux en vogue avec accélération 3D.
~

User’s Manual
7
CONDITIONS DU SYSTEME:
Ordinateur : Utilise carte principale avec logement de Bus AGP.
Moniteur : Moniteur standard VGA. En vue d’obtenir tous les
avantages de la carte des graphiques, vous devez
utiliser un moniteur multifréquence à haute résolution.
Logiciel : Windows 95; Windows NT, etc.
Italiano
Grazie per aver scelto la scheda grafica VISION-1 3D.
Con il Rendition V2200 True Media Accelerator incorporato, la Vs.
scheda grafica VISION-1 combina una accelerazione 3D (a 3 dimensioni),
una grafica 2D (a 2 dimensioni) e una qualità video superiori su una
scheda singola, fornendo Vi elevate prestazioni ed una qualità
soddisfacente nelle applicazioni dei giochi a 3 dimensioni e nelle
applicazioni multimediali.
Caratteristiche:
•Bus AGP, conforme all’interfaccia AGP V1.0
•Processore ad alte prestazioni RISC con Rendition V2200
Accelerator inserito
•4MB 100MHz SGRAM on board

Introduction
8
•230MHz RAMDAC ad alta risoluzionc, profondità ad alti colori ed
un display ad alta velocità di ripristino costante (refresh) fino a
1600 x 1200 con 85 Hz
•Meccanismo triangolare hardware, meccanismo pixel e meccanismo
di riempimento (fill engine), che fornisce prestazioni avanzate ed
effetti speciali a 3 dimensioni
•Playback video di alta qualità, con accelerazione
MPEG-2/DVD
•Completamente compatibile VGA
•DPMS per supporto di gestione dell’energia
DDC2B per supporto monitor plug & play
•Driver per I più importanti sistemi operativi APIs Windows 95
(OSR2.1), Windows NT4.0, DirectX 5.0, OpenGL ecc.
l giochi più comuni sono supportati con l’accelerazione a 3
dimensioni
Requisiti del sistema:
Computer : scheda principale con uno slot per un Bus AGP
Schermo : Standard VGA. Per utilizzare appieno tutte le
caratteristiche della scheda grafica, è necessario uno
schermo multifrequenza ad alta risoluzione.
Software : Windows 95, Windows NT ecc.

User’s Manual
9
Español
Gracias por adquirir la nueva Tarjeta Gráfica VISION-1 AGP 3D.
Incorporando la nueva Rendition V2200 True Media Accelerator, su
VISION-1 combina una inmejorable aceleración 3D, y gráficos 2D con
superior calidad de video en una sola tarjeta, ofreciendole en ambos
aspectos mayor rendimiento; calidad garantizada en juegos 3D y en
aplicaciones multimedia.
Características:
•Bus AGP V1.0 interface compatible
•Procesador Rendition V2200 Accelerator RISC alto rendimiento
incorporado.
•4MB 100MHz SGRAM en placa.
•230MHz RAMDAC para alta resolución, color de alta intensidad y
mayor refresco de pantalla hasta 1600 x 1200 a 85 Hz
•Hardware triangle, pixel y función de relleno le ofrccen
caracteristicas avanzadas en 3D y efectos especiales.
•Reproducción de Video de alta calidad, acelerador
MPEG-2/DVD
•VGA compatible
•DPMS para control de power management
DDC2B para soporte de monitores Plug and play.
•Drivers para los sistemas operativos más utilizados
Windows 95 (OSR2.1), Windows NT 4.0, DirectX 5.0,
OpenGL, etc. Soporte de los juegos más utilizados con
acelerador 3D
Requerimientos de Sistema
Ordenador : Placa base con Bus AGP incorporado

Introduction
10
Monitor : monitor estándar VGA. Para conseguir un
rendimiento óptimo de la tarjeta gráfica, necesita un
monitor de alta resolución.
Software : Windows 95; Windows NT, etc.
Portugese
Obrigado por comprar nossa placa grafica, a VISION-1 AGP.
Com acelerador Rendition V2200 True Media ja instalado, sua placa
combina: excelente aceleracao em 3D e graficos em 2D. A qualidade do
video e superior as placas ja existentes, proporcionando um desempenho
elevado e qualidade satisfatoria nos jogos de 3D e aplicacoes de
multimedia.
Caracteristicas:
•Bus AGP, AGP interface complacente
•Acelerador Rendition V2200 embutido, processador de alto
desempenho RISC
•4MB 100MHz SGRAM na placa

User’s Manual
11
•Um RAMDAC de 230MHz para elevadas resolucoes, alta
tonalidade de cores e alta velocidade de refrescamento da tela de
1600 X 1200 com 85 Hz
•Hardware com motor triangular, motor pixel e motor de
abastecimento, com a finalidade de transmitir caracteristicas
avancadas e efeitos especias em 3D
•Capacidade de repeticao do video de alta qualidade. Aceleracao
MPEG-2/DVD
•Completamente compativel com VGA
•DPMS para suporte no gerenciamento de forca da placa
DDC2B para supporte no plug-e-play do monitor
•Drivers para os sistemas de operacao principais e API’s
Windows 95 (OSR2.1), Windows NT4.0, DirectX5.0,
OpenGL, etc.
Suporte para jogos com aceleracao 3D
Pre-requisitos do Sistema:
Computador : Contendo placa-mae com slots bus AGP
Monitor : Monitor padrao VGA. Para obter todos os
beneficios da placa grafica, voce vai precisar de
um monitor de multifrequencia e de alta resolucao.
Software : Windows 95; Windows NT, etc.

Introduction
12
English
Thank you for purchasing the VISION-1 AGP 3D Graphic Card.
With the Rendition V2200 True Media Accelerator built in, your VISION-
1 combines outstanding 3D acceleration, excellent 2D graphics and
superior video quality on a single board, providing you with both high
performance and satisfied quality in 3D game and multimedia applications.
Features:
•AGP Bus, AGP V1.0 interface compliant.
•Rendition V2200 Accelerator embedded high performance
RISC processor.
•4MB 100MHz SGRAM on board.
•A 230 MHz RAMDAC for high resolution, high color depth
and high refresh rate display up to 1600x1200.
•Hardware triangle engine, pixel engine and fill engine,
delivering advanced 3D features and 3D special effects.
•High quality video playback, MPEG-2/DVD acceleration.
•Full VGA compatible.
•DPMS for power management support.
DDC2B for monitor plug and play support.
•Drivers for major operation systems and APIs
Windows 95 (OSR2.1), Windows NT4.0
DirectX 5.0 , OpenGL, etc.
Popular games support with 3D acceleration.
System Requirements:
Computer :Using mainboard with an AGP Bus slot

User’s Manual
13
Monitor :Standard VGA monitor. To receive all the
benefits from the graphics card, you need a
high resolution multi-frequency monitor.
Operating :Windows 95; Windows NT, etc.
System
Package Contents:
Before installing your VISION-1 graphic card, please check to make
sure your VISION-1 package is complete.
þVISION-1 AGP graphic card.
þCD-ROM Disk Driver.
þUser's manual.
Contact your dealer if you find anything missing or damaged.
Note! Graphic cards are sensitive to static charge. To avoid
damage that may occur by static charge, leave the graphic card
in its antistatic packaging until installation. Keep the package for
possible future transportation.
Software Upgrade
You can visit our web-site: http: // www.qdigrp.com / for BIOS, driver
updates and other release information .

User’s Manual
17
Hardware Installation
Follow the detailed procedures described in this section for easy
installation of VISION-1 Graphic card into your computer system. A
screwdriver is the only tool needed for installation.
Note! Before installing the VISION-1 AGP card, touch a metal
surface of your computer to discharge yourself of static charge,
hold the graphic card by the edges and do not touch the IC chips,
leads or circuits.
1. Before opening the computer cover , be sure that the
power to the computer system unit and all devices
connected to it are turned off. Disconnect the computer
from the power supply.
2. In a typical PC computer all cover mounting screws are
located on the back of the computer. Remove these screws

Hardware Installation
18
and save them. Carefully remove the cover.
3. Remove an existing VGA card or disable the mainboard
VGA.
4. Remove the AGP slot shield at the back of the computer by
removing its retaining screw and lifting it out. Save the screw.
5. Carefully insert the graphic card into the AGP slot by
holding the card at the top and gently push both ends of
the slot at the same time. Do not force the card into the
slot! If the card does not fit easily, pull it back, and try
again.
1. Secure the card with the screw that you removed in the
step above.
2. Replace and secure the system cover.
3. Connect a VGA compatible or multi-frequency monitor
with the 15 pin video connector at the back of the
VISION-1 card.
4. Connect the computer to the power supply.
