Qilive Q1530 User manual

FR
ES
IT
UA
6
7
2
1
3
4
5
FCC ID: N7KQ12
Model Name: Q12
User Manual

EN CONTENT OVERVIEW :
Read the safety advice carefully and keep it for future reference.
1. SAFETY INSTRUCTIONS
1.
can be placed on or near the device.
2. The ventilation openings of the device should not be obstructed
by objects such as newspapers, tablecloths, curtains, etc. To ensure
good ventilation, there should be 10 centimetres of free space around
the device.
3. The electrical and electronic equipment are part of a
separate collection. Do not throw electrical or electronic
equipment away with unsorted municipal waste, but ensure
that it is collected separately. Collection systems and
locations (sorting centres, rubbish dumps) are provided for you by
local councils and retailers. By entrusting your end-of-life product to
the proper recycling process, you are helping to protect the environment
and your health.
4. Use this device in temperate climates only.
5. This device may be used by children aged 8 years or older
and by those with reduced physical, sensory or mental abilities, or
those lacking experience or knowledge, provided they are correctly
supervised, or if the instructions related to the use of the device have
been adequately given and if the risks involved have been understood.
Children must not play with this device. Children should not clean or
maintain the device without supervision.
6. This device cannot be exposed to damp, splashes or run-off. Do not
place objects containing liquid nearby (such as vases, glasses, etc.).
7. The electrical socket must remain easily accessible if it serves as
the means of disconnection.
8. The exclamation point in the equilateral triangle alerts the
user to the presence of important operational and
P. 4
P. 5
P. 6
P. 6
P. 7
1. SAFETY INSTRUCTIONS
2. TECHNICAL SPECIFICATIONS
3. PRODUCT DESCRIPTION
4. OPERATION
5. WARRANTY AND LIMITATION OF LIABILITY

EN
maintenance instructions for the device (maintenance and repair) that
are included with the device.
9. Always unplug the device before cleaning it.
10. Clean the device with a soft dry cloth only. Never use solvents.
11. Attention should be drawn to the environmental aspects of battery
disposal.
12. The battery (batteries or battery pack) shall not be exposed to
13. Use the apparatus in moderate climate only.
2. TECHNICAL SPECIFICATIONS
A2DP, AVRCP, HFP, HSP
Maximum range Up to 10 m
Bluetooth version V 4.2
Output 18 W
SNR (signal-to-noise ratio) >75dB
Frequency band 2402-2480 MHz
Power Rating Input DC 5V/1A
Wireless range up to 10 m
Music playtime 9 to 10 hours (60% volume)
Charging time 2 to 3 hours
Battery capacity 3.7V / 2500mAh, Li-ion battery
Size 73mm (Dia.) x 185mm (H)

EN 3. PRODUCT DESCRIPTION
1. Power on / off - Play /
Pause - Answer / End
phone call
2. Volume Up / Next Track
3. Volume Down / Previous
Track
4. TWS (True Wireless
Stereo)
5. Bluetooth/ Reset button
6. Power LED
7. Status LED
4. OPERATION
Charging your speaker
1. Connect one end of the USB charging cable to the charging port
on your speaker. Plug the other end of the cable into a suitable
USB port on your computer.
Note: A full charge takes approximately three hours.
2. A white LED light will turn on to indicate that the unit is charging.
The white light will turn off when the battery is fully charged.
Turning the speaker on/off
Power on: Press and hold the button for 3 seconds to power on
Power off: Press and hold the button for 3 seconds to power off
the speaker. The white LED will turn off.
Pairing Bluetooth devices with your speaker
In order to pair your Bluetooth audio device with your Bluetooth
1. Make sure your Bluetooth audio source is close to the speaker.
2. Press the button for 3 seconds to power on the speaker. The
3. Enable Bluetooth on your device (phone or audio device). Refer
to the manufacturer’s instructions for details.
4. Search for Bluetooth devices and select “Q12P”.
the pairing process.
5. The speaker will beep when the devices are paired. The white
LED will switch on and your portable device will disp

EN
Bluetooth music playback
1. Open the music player and select a song to play. Press the
button to pause the music and press it again to play music.
2. Press the button to increase the volume or press and hold to
skip to the next song.
3. Press the button to decrease the volume or press and hold to
skip to the previous song.
Bluetooth phone calls
1. Press the button to answer an incoming call. Press again to
end the call.
Aux-in mode
1. Use the aux-in cable provided to connect the speaker to your
mobile phone or computer.
2. Press the button to play music and press again to pause the
music.
TWS Function
If you have two Q12P speakers, you can use TWS to play music in
stereo.
1. Make sure the two Q12P speakers are not connected over
Bluetooth.
2. Power on both speakers and press the button on each
speakers will automatically connect to each other. You will hear a
indicate that the TWS connection was successful.
3. Search for Bluetooth devices and select “Q12P” on your
Bluetooth device.
Reset
Press the button to reset the speaker.
5. WARRANTY ANDLIMITATION OF LIABILITY
This product is guaranteed for a period of 12 to 24 months (as
from the date of purchase, against any fault resulting from a defect in
materials or manufacturing.
This warranty does not cover damages caused by improper use or
normal wear and tear of the product.

EN ■Damage or problems caused by improper use, an accident, an
alteration or power supply of unsuitable current or voltage.
■
is damaged, altered, removed or oxidised.
■Replaceable batteries and accessories are guaranteed for a
6-month period.
■Battery failure, caused by excessively lengthy charging or by the
failure to observe the safety precautions explained in the manual.
■Visual damage, including scratches, dents or any other elements.
■Damage caused by any intervention conducted by a non-
accredited person.
■Defects caused by normal wear and tear or due to normal ageing
of the product.
■Software updates, due to a change in network settings.
■Product failures due to the use of third-party software to modify,
change or adapt the existing software.
■Product failures due to the use of accessories that have not been
approved by the manufacturer.
■Oxidised products.
The manufacturer cannot, under any circumstances, be held
responsible for the loss of data stored on the disc. Likewise, the
manufacturer is not obliged to verify that SIM/SD cards are properly
removed from returned products.
Repaired or replaced products may include new and/or reconditioned
components and equipment.
METHODS FOR INVOKING THE WARRANTY
To obtain a warranty service, please bring your product to your point
of sale’s welcome desk along with your proof of purchase (till receipt,
bill, etc.), the product and the accessories provided, along with its
original packaging.
It is important to have the following information: date of purchase,
model, and serial or IMEI number (this information generally appears
on the product, packaging or your proof of purchase).
Failing that, you must bring back the product along with the
accessories required for it to operate properly (power supply, adapter,
etc.).
In the event that your claim is covered by the warranty, the customer
service department may, within the limits of local legislation, either:
■Repair or replace the defective components.

■Exchange the returned product for a product that has at least the
same functions and that is equivalent in terms of performance.
■Reimburse the product at the price of purchase of the product as
indicated on the proof of purchase.
If one of these 3 solutions is used, this does not entitle the purchaser
to an extension or renewal of the warranty period.

Made in China
897807 897808 897809 / Q12
FR - Service Clients Auchan France - 200 rue de la Recherche
59650 Villeneuve d’Ascq - 03 59 30 59 30 - www.auchan.fr
ES - Alcampo, S.A. - Supermercados Sabeco, S.A. C/ Santiago de
Compostela Sur, s/n - 28029 Madrid - e-mail: [email protected]
IT - Servizio clienti Auchan - Strada 8 Palazzo N - 20089 Rozzano (MI) -
Linea diretta 800-896996- www.auchan.it
PT - Serviço Auchan- Auchan Portugal Hipermercados, S.A.,
Travessa Teixeira Júnior, n.º 1, 1300 – 553 Lisboa,
E-mail : [email protected]
PL - Dystrybutor : Auchan Polska Sp. z o.o., ul. Puławska 46,
05-500 Piaseczno - www.auchan.pl
HU - Importálja és forgalmazza: Auchan Magyarország Kft, 2040 Budaörs,
Sport u. 2-4. - www.auchan.hu
RO - Importator Auchan România SA, Str. Brașov nr.25, Sector 6,
Cod poștal 061444, București, România - www.auchan.ro

FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
