QMobile E950 User manual

1
Contents
1. For your Safety………………………….5
2. Mobile Phone Profile…………………8
3. Preparation before Use……………10
Install SIM Card........................10
Install Memory card .................11
Install Battery ..........................12
Charge Battery.........................13
Notices on using the battery ....14
PIN code ..................................16
4. Use of Menu Functions……………17
Phonebook……………………………..17
Messaging……………………………...20

2
Call center………………………………26
Services....................................33
User profiles.............................35
Organizer…………………………….….36
Settings……………………………….….39
Music……………………………….…….48
Games……………………………….……50
Camera………………………….……….50
File manager…………………….…….51
Email…………………………….………..52
MSN.........................................53
Yahoo messenger………….……….54
Opera mini…………………….……….54
Twitter……………….…………………..54
Google talk………….………………….55
Face book…………….…………………55

3
WIFI………………………………………..55
Java………………………………………..56
Image viewer……………………….…58
Video player…………………………...59
Calculator…………………………….…60
FM radio………………………………...60
Sound recorder………………….……62
Video recorder………………….….…62
Calendar………………………………...63
Alarm………………………………….….64
Photo editor…………………….…….65
Tasks………………………………….…..65
Ebook reader…………………….……65
Slide Show………………………..…….66
5. Use of USB……………………………….67
6. Maintenance & Safety……………67

4
After sales service ....................68
Charger and Adapter Safety .....68
Battery Information and Care...68
General Notice.........................69
Troubleshooting.......................70
7. Abbreviations………………………….73

5
1. For your Safety
For your safety and proper use of the
mobile phone, please read the following
guidelines carefully: Do not switch the mobile
phone on when close to chemical factory, gas
station or other explosive objects.
During driving, please use headset for safety
purpose; unless otherwise in emergency,
always stop the car on roadside to have a call
conversation.
Because the use of the mobile phone can
cause interference in the aircraft, never use
the mobile phone in aircraft. The use of the
mobile phone is dangerous and illegal; do
switch off the mobile phone before boarding.
Pay special attention to the use of the mobile
phone near heart pacemaker, deaf-aid and
some other medical equipment, because the
mobile phone can cause interference with
them.
None-original factory’s accessories and parts
will lose guarantee.
Do not dismantle the mobile phone without
permission. In case of failure, please contact

6
the supplier as soon as possible.
Do not plug the charger into the mobile
phone and charge without battery. Always
power off the mobile phone when taking out
the battery; otherwise the memory of the
phone may be damaged.
When charging the mobile phone, always
keep it in the place with good ventilation,
heat sink and away from flammable and
explosive objects.
In order to avoid demagnetization, always
keep the mobile phone away from magnetic
objects such as CD, credit card etc.
Ensure the mobile phone not to contact any
liquid; once such case occurs, remove the
battery and contact the supplier
immediately.
Do not use the mobile phone in the
environment at too high or too low
temperature, never expose the mobile
phone under strong sunshine or too wet
environment. The suitable temperature for
the phone and accessories is 0℃-40℃. The
height to use the phone shall be less than
2,000m.
Do not use liquid or wet cloth with strong

7
cleanser to clean the mobile phone.
This mobile phone has shooting, videoing
and audio recording functions, which shall be
used as per the related laws and regulations.
Always keep the mobile phone out of
children’s reach. Do not throw or vibrate the
mobile phone because violent treatment to
the mobile phone may damage the inner
circuits and precise structures.
Please do not discard the waste battery into
general household garbage. Please deal with
the waste battery according to provisions
where they are definitely made.
Tip: This user manual is based on simplified
Chinese operation mode; so it may vary in English
operation mode.
Warning: We will not be bear any responsibility
for any incompliance with the above guidelines
or improper use of the mobile phone. Our
company keeps the right to make modifications
to any of the content here in this user guide
without public announcement in advance. The
content of this manual may vary from the actual
content displayed in the mobile phone. In such
case, the latter shall govern.

8
2. Mobile Phone Profile
This phone is the finger touch function, you’re
your finger slide on the screen you can choose
the related function. Below is the front of the
mobile phone.
1
2
3

9
7
6
1.
Receiver
5
Speaker
2.
LCD
6
Charger
3.
OK/back Keys
7
7.
Power key
4
Camera
9
5
4
6
7

10
3. Preparation before Use
Install SIM Card
When registering mobile phone number, you
can apply for two different phone numbers, two
different mobile phone network service providers
and thus obtain two SIM (Subscriber
Identification Module) cards.
With these two SIM cards, you can use all
functions of your mobile phone. The SIM cards
save the parameters needed for communications
and personal data, including PIN (Personal
Identification Number) code, phonebook, short
message and other extra system services.
Warning: Do not distort or scratch the SIM card
nor let it contact static, dust or moisture. If it is
lost, please contact immediately your network
operator for help.
Before SIM card installation, please switch off
the mobile phone. The SIM card is installed on
the back of the mobile phone.
Follow the following diagram to install the
SIM card. Please insert the host SIM card into the
SIM1 slot and the slave SIM card into the SIM2

11
slot.
Note: If SIM card is inserted only into the
SIM1 slot, then only the host works; likely, If SIM
card is inserted only into the SIM2 slot, then only
the slave works. When two SIM cards are
inserted into the SIM1 slot and SIM2 slot
respectively, you can choose work mode freely as
you wish.
Note: As the SIM card is small object, keep it out
of children’s touch or prevent children gulping it!
Install Memory card
As the mobile phone does not have enough
storage space, to use some functions, you need
to install a memory card (This mobile phone use
SIM 1
SIM 2

12
T-FLASH card.)
Install T-FLASH card: Open the back cover to
take out the battery, release the T-Flash card lock,
insert the T-Flash card into its slot, and restore
the lock and the battery before restarting the
mobile phone.
Note: As the T-FLASH card is small object, keep it
out of children’s touch or prevent children
gulping it!
Install Battery
The mobile phone is suitable for original
battery and accessories. When the battery is idle,
it is recommended to put it into the protection
box.
Follow the following diagram to install the
battery.
Memory Card

13
Note: Do install the battery as per the diagram so
as prevent the battery contact patch being
damaged.
Charge Battery
The new battery cannot reach the optimal
efficiency unless it has undergone several
continuous complete charges and discharges.
When the battery is used up, charge it in
time. Over-discharge can damage the battery.
After the battery is charged full, cut off the
connection of charger with the AC power supply
and the connection with the mobile phone.
Follow the following diagram to connect the
charger.
Battery

14
During charging, the battery capacity icon
on the screen flickers from the right to the left.
After the battery is charged full, the icon is full of
bars. Slight heat during charging is normal.
Warning: When a travel charger and its
accessories are used to charge the battery, please
firstly check if they are original or recognized by
the original manufacturer. The use of other
accessories may damage your mobile phone and
cause risks! Always use them indoor and dry
places.
Notices on using the battery
The performance of the battery is affected
by many factors, including radio barrier network
settings, signal strength, signal strength, work
temperature, chosen and used functions or
settings as well as phone accessories, tone, data
or other applications.
Earphone Charger Port

15
For optimal performances, please follow the
rules below:
New battery or the battery having been idle
for long need charging for long. The standard
voltage scope for the battery is 3.6V-4.2V.
During charging, keep the battery at room
temperature or similar temperature.
With time passing by, the battery will
gradually be worn and thus need longer time
to charge. This is normal. However, after
normal charging, if call duration decreases
but charging time increases, you need to buy
another battery from the original
manufacturer or authorized by the original
manufacturer. The battery of interior quality
can damage your mobile phone and cause
danger!
If the phone is overused at low battery when
charging, there might need a longer time for
the charge indicator to be shown on the
screen.
Note: Please dispose the battery according to the
local regulations. Try to recycle the battery as
possible. Do not treat the waste battery as
common waste.
Warning: Do not throw the battery into fire so as

16
to prevent fire. The broken battery may cause
explosion.
Warning
Charging the mobile phone by
improper means can cause to explosion.
Always refer to the related regulations for
the disposal of the battery.
PIN code
PIN1 Code: It is the personal identification
number used to enter SIM and able to prevent
others using SIM1 without permission. If the
mobile phone has activated the PIN1 code
protection, when the mobile phone is switched
on, the screen will display “Input PIN”. In the
process of inputting PIN1 code, the screen will
use “*” to represent the input content. While
obtaining SIM, you can obtain its PIN1 code.
PIN2 Code: It is the personal identification
number used for some special functions such as
paid call etc.
PUK Code and PUK2 Code(8-digit)
To change the locked PIN code, you need to
use PUK (Personal Unblocking Key) code. To
change the locked PIN2 code, you need to use

17
PUK2 code. If these two codes are not provided
together with the SIM cards, ask the local service
provider for them.
Warning: If the PIN code is input wrongly for
successively three times, the SIM card will be
locked. Please contact the network operator
immediately for help. Attempt to unlock the code
may make the SIM card ineffective forever!
4. Use of Menu Functions
Phonebook
The mobile phone is provided with the
business card folder type phonebook. The
information of every contact saved on the mobile
phone include three phone numbers (mobile
phone, home phone and company phone),
company name, e-mail, fax, birthday, big-head
sticker, tone, callers’ group (five types: family,
friends, VIPs, colleagues and others). Every
contact saved into SIM1 and SIM2 can only
include name and number. The mobile phone
supports 1,000 groups of numbers.

18
View
You can browse the details of the contract.
Send message
Input the message, and you can sent to the
contract.
Call
You can make a phone call of the contract by
pressing this option
Edit
You can edit the name and the number of the
contract.
Delete
You can have four modes regarding deletion:
from SIM1, from SIM2, from phone and one by
one.
Copy
You can copy all contacts from SIM1 to
phone, from phone to SIM1, from SIM2 to phone,
from phone to SIM2, from SIM1 to SIM2 and
from SIM2 to SIM1.

19
Move
You can move the contract from the phone
to SIM Card 1 or to SIM card 2
Send contract
You can send the contract as the phone
guides, as text message, as multimedia message,
as email and via Bluetooth.
Add to Blacklist
You can add the contract into blacklist.
Mark several
With this choice, you can select several
contracts, and continue the corresponding
choice.
Caller Groups
You can set call tone, photo and members
for five callers’ groups. Callers’ group member
can only come from the number saved on phone.
Phonebook settings
Preferred Storage: You can choose the
storage path for the current number.
Speed dial: On or Off

20
My number: You can edit and send my
business card.
vCard version: View the version here.
Extra numbers: Have the related choice to
have the option.
Memory Status: You can view the current use
status of the phonebook, including SIM1,
SIM2 and phone memory. The display format
is “Used/Total”.
Copy contacts: You can copy the contract
from SIM1 to phone, from phone to SIM1,
from SIM2 to phone, from phone to SIM2,
from SIM1 to SIM2 and from SIM2 to SIM1.
Move contacts: You can move the contract
from the phone to SIM Card or to SIM card 2
Delete all contacts: You can have four modes
regarding deletion: from SIM1, from SIM2,
from phone and one by one.
Messaging
SMS is a kind of network service that cannot
be used to send and receive short messages until
you apply to the network operator.
Both SIM cards of the mobile phone can
send and receive SMS. The SMS is sent to the
SMS center of the network and then sent by the
network to the target user (GSM user). If the user
