Qtus DuetPro User manual

DuetPro

2
Index:
EN ............................................................ pag. 04
DE ............................................................ pag. 24
FR ............................................................ pag. 44
NL ............................................................ pag. 64
Index

3
Congratulations on the purchase of your Qtus product.
We wish you and your child a lot of fun discovering the world.
If you would like to share something with us or if you have any
questions, please contact us at: [email protected]
Herzlichen Glückwunsch zum Kauf Ihres Qtus-Produkts.
Wir wünschen Ihnen und Ihrem Kind viel Spaß beim
Entdecken der Welt.
Wenn Sie etwas mit uns teilen möchten oder Fragen haben,
kontaktieren Sie uns bitte unter: [email protected]
Félicitations pour l'achat de votre produit Qtus.
Nous vous souhaitons, à vous et votre enfant, beaucoup de
plaisir à découvrir le monde.
Si vous souhaitez partager quelque chose avec nous ou si
vous avez des questions, s'il vous plaît contactez-nous au:
[email protected]
Gefeliciteerd met de aankoop van uw Qtus product.
Wij wensen u en uw kindje veel plezier met het ontdekken van
de wereld.
Als u iets met ons wilt delen of als u vragen hebt, kunt u
contact met ons opnemen via: [email protected]
The Qtus team
Welcome

4
IMPORTANT!
KEEP THE MANUAL FOR FUTURE REFERENCE.
Read the instructions carefully before use and keep them for
future reference. Your child’s safety may be affected if you do
not follow these instructions.
• A CHILD’S SAFETY IS YOUR RESPONSIBILITY. Children
should be harnessed in at all times and should never be
left unattended. The child should be clear of moving parts
while making adjustments. This vehicle requires regular
maintenance by the user. Overloading, incorrect folding and
the use of non-approved accessories may damage or break
this vehicle. Read the instructions.
• This product is only suitable for children from 6 months up
to 4 years up to a maximum weight of 15 kg / 33 lbs
• Never leave your child unattended.
• Ensure that all the locking devices are engaged before use.
• The parking device shall be engaged during the loading and
unloading of your child.
• The maximum load that can be stored in the storage basket
is: 5 kg / 11 lbs.
• This product is only suitable for one child.
• Accessories or replacement parts which are not approved
by the manufacturer shall not be used.
• Any load attached to the handle bar may affect the stability
of the product.
• Always use the restraint system.
• Always use the crotch strap in combination with the waist
belt when carrying your child in the seat.
• Check that the carrycot or seat unit attachment devices are
correctly engaged before use.
WARNING

5
• This product is not suitable for running or skating.
• Carelessness causes re.
• Incorrect folding/overloading and the use of non approved
accessories may break or damage this product.
• Keep this plastic cover away from children to avoid
suffocation.
• Do not let your child play with the Qtus DuetPro.
• To avoid injury ensure that your child is kept away when
unfolding and folding this product.
• Never place more than 13kg in any car seat when attached
to the stroller.
• The car seat does not replace a cot or bed. Should your
child need to sleep, then it should be placed in a suitable
bassinet/carrycot, cot or bed.
• TIP: If the instructions say left or right, this is always meant
when looking from behind the Qtus DuetPro handles.
• When assembling the DuetPro there should not be a child in
the seat or carrycot.
• Avoid dangerous situations. Take your child out of the Qtus
DuetPro if you go up or down stairs, escalators or steep
hills.
• The Qtus DuetPro should only be used with the
accompanying seat and accessories. Only use the parts
and accessories approved for use by Qtus.
• Do not use the Qtus DuetPro if any part is broken, torn,
incomplete or does not seem to be functioning correctly.
• Never carry more than one child per place in this stroller.
• Never allow a child to step on the footrest to get in or out of
the stroller.
WARNING

6
• Always make sure the bumper bar is correctly installed
before using the seat unit.
• Always adjust the handle bar to the highest position when
using in double-seat mode.
• Avoid serious injury from falling or sliding out.
• Always install carrycot facing the stroller handle bar.
WARNING

7
Parts list
Front Wheel x2
Seat
Front Bar
Frame
Rear Wheel x2 Front Seat
Adapter
Rear Seat
Adapter

8
Introducing your new stroller
To ensure safe operation of your stroller, please follow
these instruction carefully.

9
1. Handle height adjuster
2. Handle
3. Canopy latch
4. Seat adjustment button
5. Seat release button
6. Brake
7. Rear wheel (2)
8. Rear wheel release button
9. Canopy
10. Sun shield
11. Front bar release button
12. Front bar
13. Shoulder pad
14. 5-point safety harness
15. Folding button
16. Basket
17. Front swivel wheel lock
18. Front wheel release button
19. Front wheel (2)
20. Footrest adjustment button
Introducing your new stroller

10
Frame with two seats
21
23
22
ATTENTION: DuetPro 2nd Seat is not included.
If you would like to use this product in double
seat mode, please purchase it separately.
21. Rear seat adapter
22. Front seat adapter
23. Seats (2)

11
Assembling and using your stroller
Unfolding the frame
1- Hold the handle and lift
the frame. 2- Lift the handle until the frame is fully opened.
Install / remove the front wheels
1- Insert the front wheel into
the tube of the frame. 2- Press the release button and pull the front wheel out.

12
1- Slide both seat moldings
down until they click into
position.
2- Pull the seat to make sure
it is fully engaged.
3- Press the release buttons
on both sides at the same
time, lift the seat to remove
it from the frame.
Install / remove the seat
3- Insert the rear wheel into
the tube of the frame until it
is fully engaged.
4- Press the release button
and pull the rear wheels out.
Install / remove the rear wheels

13
Install the canopy
1- Clip each side of the
canopy.
1- To attach the bumper bar,
insert the bumper bar into
the openings on the seat
until you hear “click”
2- Zip up the canopy.
2- To remove the bumper
bar, press the release button
on both sides and remove
the bumper bar.
Install / remove the bumper barr

14
Folding the stroller
1- Apply the brake before
folding the stroller.
3- Press the release
button on both sides, pull
the seat to remove it.
2- Squeeze the handle
adjustment button and slide
the handle to the lowest
height.
4- Slide at the front of the
stroller. Slide the button
in the direction of the
arrows and lift it to fold
the stroller.

15
5- Push the stroller down in
the direction of the arrow.
WARNING: Always remove your child from the stroller prior to
folding of stroller.
TIP: You do not need to remove the seat for folding the stroller
when it is in one seat mode.
6- Push down as far as
possible.

16
Using your stroller
1- To lock the front wheel,
push the swivel wheel lock
downwards.
2- To Unlock the front wheel,
push the swivel wheel lock
upwards.
4- To unlock the rear wheel,
push the brake pedal up.
3- To Lock the rear wheel,
push the brake pedal down,
push the stroller until the
real wheel is locked.
5- Squeeze the adjustment
button and slide the handle
bar to the desired height.
6- The handle bar will click
into place.

17
7- To adjust seat recline,
Press the buttons on both
sides and tilt the seat to the
desired position.
9- Place your child in the
stroller, with the crotch
strap (Figure 3) between
the child’s leg. Tighten the
waist strap (Figure 1) and
shoulder strap (Figure 2).
8- To adjust the footrest,
press the buttons on both
sides and tilt the footrest to
the desired position.
10- Fit clips together. Slide
the right clip into right buckle
until you hear “click”.
TIP: Lock the swivel wheel when using the stroller in a straight
direction for a long period.

18
11- Fit clips together. Slide
the left clip into left buckle
until you hear “click”. Pull the
harness to make sure it is
secured.
13- To open the canopy, pull
the front forwards until it is
fully opened.
To close the canopy, push
it backward until it is fully
closed.
14- According to the needs
of your child, adjust the
shoulder strap. Insert the
shoulder strap into the
correct position (in cloth
layer)(1/2/3)
12- To release the 5-point
harness, press the 5-point
harness release button.

19
15- For safety, the shoulder strap should also go through the
plastic backrest.

20
Two seats world
facing
Sitting position
Two seats facing
different directions
Semi-reclining
position
Two seats parent-
facing
Reclining position
Single seat mode
Double seat mode
