Quadra-Fire FireBrick qvi25fb User manual

qvi25fb
Gas FireBrick®Insert

Quadra-Fire is a registered trademark of Hearth & Home Technologies. Product specications and pric-
ing subject to change without notice. The Quadra-Fire qvi25 direct vent gas replace heater is listed
by Underwriters Laboratories and is approved for Canada and USA to ANSI Z21.88-2002/CSA 2.33-
2002, Vented Gas Fireplace Heaters, and UL307B.
QDF-1012U-1108
Dimensions
Clearances
Width (front)................29 1/8”
Width (back).................20 3/8”
Height (front)...........18 15/16”
Height (back) ...............14 5/8”
Depth ..........................14 7/16”
Shipping Weight...........99 lbs.
Flue Size. Dual 3” Direct Vent
Chimney Liner
Bedroom Approved .......... Yes
Technical Data
Performance
Heating Capacity.................Up to 1,500 sq. .*
BTU Input NG .....................21,800 - 29,650
BTU Input LP.......................16,000 - 27,000
Eciency ..............................up to 80% NG / 81% LP
IMPORTANT - READ BEFORE YOU INSTALL!
Refer to the Owner/Installation Manual for complete clearance requirements and
specications. The images and descriptions in this brochure are provided to assist you
in product selection only.
*Heating capacity rating is to be used as a guideline only and may dier slightly due to
climate, building construction and condition, amount and quality of insulation, location
of the heater, and air movement in the room.
Visit our Website at www.quadrafire.com
qvi25fb
Standard Features
Options
Available From:
The strongest in the industry, Quadra-Fire provides
a limited lifetime warranty on gas-burning prod-
ucts for their most important aspects: rebox and
heat exchanger.
For full warranty details go to www.quadrare.com
Available Fronts
GAS INLET
14 5/8
18-15/16
20-3/8
9-11/16
14-7/16
29-1/8
TOP OF UNIT
MANTEL
12”
MAX.
12” MIN.
• 331 sq. in. of Viewing Glass
• High Eciency FireBrickTM Firebox
• Six Piece Glowing Log Set
• Inviting Fire with Glowing Coals
• Tapered Firebox
• Decorative Andirons
• Adjustable Flame
• Quiet Operation
• Limited Lifetime Warranty
• 3 Available Fronts:
Screen Only, Bi-fold Glass Door, Sun Prairie with Cabinet Doors
• 2 Panel Sizes
• Adjustable Hearth Support
• Variable Speed Blower (160 cfm)
IMPORTANT: Not to be used with Bi-fold Glass Door
• 3 Available Remote Controls including On/O with Digital
Thermostat Control
• 2 Wall Thermostats
Screen Only shown
Sun Prairie with Cabinet
Doors shown in Hammered
Pewter. Also available in
Black.
FireBrick®Technology from Quadra-Fire oers you a stunning new
alternative for upgrading your existing replace. Utilizing a new
patented process, the rebox and interior brick lining are molded from
Firebrick material to capture that traditional wood replace look. This
seamless rebox construction also allows us
to use larger glass, giving you a beer view
into those soothing ames and logs. This quiet
and durable material is extremely ecient.
FireBrick pushes the heat into the room instead
of absorbing and losing heat into the replace itself. Three front options
are available in several nishes to help you complement your original
replace and room décor. The model qvi25 will operate during an
electrical power outage and is the best choice for high eciency and
heat output in smaller replaces.
Bi-fold Glass Doors
MINIMUM FIREPLACE SIZE
PANEL SIZES
Standard ...............40” x 28”
Large .....................40” x 32”
Canadian P4 Eciencies: NG 58.67% / LP 55.8%
Location Inches Millimeters
Front Width 30 7/8” 784
Rear Width 25 5/8” 651
Depth 15” 381
Height* 19 1/2” 495
*NOTE: If exhaust collar on insert and fireplace damper do
not line up, add 4 inches (102mm) to minimum fireplace
height for bends in vent pipe.
