QuantoLux Quick Guide
Setup Instructions for Installation
1 2 3
Unboxing
Shipment box contains the QLX3 instrument ①,
the controller box ②, and an accessories box ③.
Attached documents are a packing list and this
quick guide sheet ④.
Unpack all items and check for completeness and
possible damage.
If the Controller is missing, please check if this
was included in the purchase order !
①
②
③
④
UnpackingAccessories
Open the accessories box and take out the service
kit ①, the power cord ②, and the teflon tube ③.
①
②
③
ConnectingPower & USB
Place the instrument on a stable workbench or
table. Take the power cord and connect to a
power outlet. Position the controller near or above
the instrument. Connect the power supply to the
computer and socket. Link computer and
instrument with the USB cable.
4
Prepare gas accessories
Remove the two protective red caps from the
teflon tube ends ①. Unplug the cap at the back
of the instrument: push in the plastic ring and
remove the tube piece ②. Put all in the service
kit. Push the filter ③into the exhaust pipe right
from the argon inlet.
6
Power-upthe instrument
Use the switch on the backside to power-up the
instrument. Make sure the instrument is at least 5
min on to warm-up the laser, before you start the
first measurement !
Also switch on the computer. Use Windows PIN:
(user) and „qlx00000“ (password). Double-click
the QuantoLux icon to start the software.
5 min
Need help?
Windows licencing
Computer missing?
QLX 4.0 Software
If the instrument was ordered without controller,
this item is missing in your shipment. In that
case you need to provide your own computer and
Windows licence.
In this case the USB thumb drive contains the
setup routine for the QLX software as well as the
calibration data of your instrument.
Please refer to the installation guide provided on
the USB drive.
The software and calibration data are licenced to
work on this instrument only!
The controller comes with a Windows 10
licence. During production, Windows was
setup and used in offline mode. Please
register and activate Microsoft Windows
to make full use of the system!
If you have any questions or queries about
installation, please check the user manual, write
QuantoLux service partner.
Connectingto Argon
Have a cylinder of argon 4.8 (99.998%)
available. Mount a pressure regulator. The
fitting from the Service Kit is screwed to the
outlet ①of the regulator. Then the end of the
teflon tube can easily be pushed in. Push in the
other end to the argon inlet at the backside of
the instrument. Set the right gauge of the
regulator to 1.5 bar pressure!
51.5 bar
①
②
③
①The QLX software is easy to use. Please refer to the
user manual for more details. Please customize your
software. The default users and their passwords are:
•Supervisor – 193027
•User – 12345
Part No. QL00188
www.quantolux.com
Deliver Results !
QuantoLux 1 Unboxing your shipment
①② ③ ④
Unboxing
Shipment box contains the QLX3 instrument , the controller box , and an
accessories box . Attached documents are a packing list and the „Quick
Guide“ sheet .
Unpack all items and check for completeness and possible damage.
If the Controller is missing, please check if this was included in the purchase
order !
www.quantolux.com
Deliver Results !
QuantoLux 2 Unboxing the accessories package
Unpacking Accessories
Open the accessories box and take out the service kit , the power cord ,
and the teflon tube .
① ② ③
www.quantolux.com
Deliver Results !
QuantoLux 3 Connecting Power & USB
Connecting Power & USB
Place the instrument on a stable workbench or table. Take the power cord and
connect to a power outlet. Position the controller near or above the instrument.
Connect the power supply to the computer and socket. Link computer and
instrument with the USB cable.
www.quantolux.com
Deliver Results !
QuantoLux 4 Prepare Gas Accessories
Prepare gas accessories
Remove the two protective red caps from the teflon tube ends . Unplug the
cap at the back of the instrument: push in the plastic ring and remove the tube
piece . Put all in the service kit. Push the filter into the exhaust pipe right
from the argon inlet.
① ② ③
www.quantolux.com
Deliver Results !
QuantoLux 5 Connecting to Argon
Connecting to Argon
Have a cylinder of argon 4.8 (99.998%) available. Mount a pressure regulator.
The fitting from the Service Kit is screwed to the outlet of the regulator. Then
the end of the teflon tube can easily be pushed in. Push in the other end to the
argon inlet at the backside of the instrument. Set the right gauge of the regulator
to 1.5 bar pressure!
1.5 bar
①
www.quantolux.com
Deliver Results !
QuantoLux 6 Power-up the Instrument
Power-up the instrument
Use the switch on the backside to power-up the instrument. Make sure the
instrument is at least 5 min on to warm-up the laser, before you start the first
measurement !
Also switch on the computer. Windows will start. Use Windows PIN: 010101; or
the Windows user [email protected] (user) and „qlx00000“ (password). Double-
click the QuantoLux icon to start the software.
5 min
www.quantolux.com
Deliver Results !
QuantoLux Computer Hardware & Software
Need help?
Windows licencing
Computer missing?
QLX 4.0 Software
If the instrument was ordered without controller, this
item is missing in your shipment. In that case you need
to provide your own computer and Windows licence.
In this case the USB thumb drive contains the setup
routine for the QLX software as well as the calibration
data of your instrument.
Please refer to the installation guide provided on the USB
drive.
The software and calibration data are licenced to work
on this instrument only!
The controller comes with a Windows 10 licence.
During production, Windows was setup and used in
offline mode. Please register and activate Microsoft
Windows to make full use of the system!
If you have any questions or queries about installation,
please check the user manual, write to
support@quantolux.de or contact your local QuantoLux
service partner.
The QLX software is easy to use. Please refer to the
user manual for more details. Please customize your
software. The default users and their passwords are:
•Supervisor – 193027
•User – 12345
Thank you for your Attention !
For more information, please contact
sales@quantolux.de
or your local QuantoLux Partner!
© 2018 QuantoLux GmbH all rights reserved
QuantoLux GmbH | Boschstrasse 16 | D-47533 Kleve | Germany
T: +49 2821 894-4870 | E: [email protected] | W: quantolux.de
