DXi4500 Installation and
Configuration Guide
Contents
DXi4500 Configurations......................... 2
Choosing a Location .............................. 2
Installation Requirements.................. 2
Rack Space Requirements .................. 3
Environmental Conditions ................. 3
Preparing for the Installation ................ 3
Taking ESD Precautions ...................... 3
Taking ESD Precautions ...................... 3
Unpacking the DXi4500 ......................... 4
Installing the DXi4500 System............... 6
Locating the Mounting Position ........ 6
Installing the DXi4500 ....................... 7
Cabling the DXi4500 ........................ 11
Initial Configuration............................. 11
Accessing the DXi4500, Remote
Management Interface .................... 12
Completing the Setup Wizard ......... 15
Connecting the Ethernet Cables ...... 19
Creating a Typical Backup
Configuration................................... 20
DXi4500 Installation and
Configuration Guide
This guide provides basic installation and configuration instructions for the
DXi4500 system (see Figure 1). Make sure to read the DXi4500 Site
Planning Guide before starting your installation. The Site Planning Guide is
included on the documentation CD provided with your DXi4500 system.
Note: Make sure to take the online training for the DXi4500 in order to
make the best use of your product. The online training is available
at www.quantum.com/ServiceandSupport/StorageCareLearning/
Index.aspx
This instruction uses the following conventions:
Note: Notes emphasize important information related to the main topic.
Caution: Cautions indicate potential hazards to equipment and are
included to prevent damage to equipment.
WARNING: Warnings indicate potential hazards to personal safety and
are included to prevent injury.
Figure 1 DXi4500 System

2DXi4500 Configurations
DXi4500 Installation and Configuration Guide
DXi4500 Configurations
The DXi4500 is available in the following configurations (see Ta b l e 1 ):
Table 1 DXi4500
Configurations
Configuration Number of Hard Drives Hard Drive Capacity
DXi4510 (2.2 TB Usable Capacity) 8500 GB
DXi4520 (4.4 TB Usable Capacity) 81 TB
Choosing a Location
Quantum recommends installing the DXi4500 system in a controlled or restricted area
to prevent access by untrained personnel. In addition, Quantum recommends that
system installation be performed only by qualified IT personnel.
When choosing an installation site for the DXi4500 system, consider the following
requirements:
•Installation Requirements
•Rack Space Requirements
•Environmental Conditions
Installation
Requirements
Review the DXi4500 Site Planning Guide (PN 6-66909) to ensure that your site meets the
installation requirements for the DXi4500.

Preparing for the Installation 3
DXi4500 Installation and Configuration Guide
Rack Space
Requirements
Tabl e 2 contains the rack requirements for the DXi4500 components.
Table 2 Rack Requirements
DXi4500
Height 2U, 3.40 in (8 6 cm)
Width (side to side) 17.19 in (43.6 cm)
Depth (front to back) 24.09 in (61 cm)
Weight (stand alone) 49.5 lbs (22.5 Kg)
Air Clearance Open 4 in (10.2 cm) behind unit for proper air flow
Environmental
Conditions
The installation site must have the following environmental conditions:
• Humidity: 20% to 80% (non-condensing)
• Temperature: 10 to 35 °C (50 to 95 °F) 35 °C Max, Altitude = 900 m or 2952.75 ft
(28 °C Max, Altitude = 3048 m or 10,000 ft)
These environmental conditions apply when the DXi4500 system is in operation.
Note: For additional specifications, refer to the Quantum DXi4500 User’s Guide (PN 6-
66904) located on the documentation CD.
Preparing for the Installation
Before you begin the installation procedure in this section, make the following
preparations as described in this section:
•Taking ESD Precautions on page 3
Taking ESD Precautions Some components within the DXi4500 system contain static-sensitive parts. To avoid
damaging these parts while performing installation procedures, always observe the
following precautions:
• Keep the DXi4500 system turned off during all installation procedures.
• Keep static-sensitive parts in their original shipping containers until ready for
installation.
• Do not place static-sensitive parts on a metal surface. Place them inside their
protective shipping bag or on an antistatic mat.

4Unpacking the DXi4500
DXi4500 Installation and Configuration Guide
• Avoid touching connectors and other components.
Note: Dry climates and cold-weather heating environments have lower relative
humidity and are more likely to produce static electricity.
Unpacking the DXi4500
By following these instructions, you help ensure that the system will continue to be
safeguarded after it arrives at the installation site.
Unpack and remove the following components from the packing materials (see
Figure 2):
• DXi4500 chassis
• Front bezel with key
• (4) power cords, 2 U.S. and 2 international cables
• Ethernet cables
• Left and right slide assemblies
• Cable-management arm
• Left and right cable-management arm ramp assemblies
• DXi4500 Quick Reference and Documentation CD
• DXi4500 Installation and Configuration Instructions
• Accessory kit
Caution: Do NOT discard the packing materials after the system is unpacked. The
packaging materials must be used if the system is relocated.
WARNING: The DXi4500 weighs 49.5 lbs (22.5 Kg). Two people are required to lift the
chassis.

Unpacking the DXi4500 5
DXi4500 Installation and Configuration Guide
Figure 2 Unpacking the
DXi4500
DXi4500
Slide rails
Tie bands
Chassis rails Front bezel

6Installing the DXi4500 System
DXi4500 Installation and Configuration Guide
Installing the DXi4500 System
Installing the DXi4500 in a rack consists of the following steps:
1Locating the Mounting Position on page 6
2Installing the DXi4500 on page 7
3Cabling the DXi4500 on page 11
Locating the Mounting
Position
The DXi4500 systems is designed to fit in a standard 19 inch wide rack. It is important
for the chassis installation to locate the hole pattern in the rack rails. You must allow 2U
(3.5 in (8.9 cm)) of vertical space for the DXi4500 system. Rack cabinets that meet EIA-
310 standards have an alternating pattern of three holes per rack unit with center-to-
center hole spacing (beginning at the top hole of a 1-U space) of 15.9 mm, 15.9 mm,
and 12.7 mm (0.625 inch, 0.625 inch, and 0.5 inch) for the front and back vertical rails
(see Figure 3). Rack cabinets may have round or square holes.
Figure 3 Rail Hole Pattern
1 U (44 mm [1.75 inches])
12.7 mm (0.5 inch)
15.9 mm (0.625 inch)
15.9 mm (0.625 inch)
12.7 mm (0.5 inch)
1 U (44 mm [1.75 inches])
WARNING: If the rack is empty at the time of installation, do NOT install the DXi4500
chassis too high in the rack. The weight of the chassis may cause the rack
to become “top heavy” and unstable if installed in the top of an empty
rack.
To mark the rack, perform the following step:
1Place a mark (or tape) on the rack's front vertical rails where you want to locate the
bottom of the system you are installing in the rack. The bottom of each 1-U space is
at the middle of the narrowest metal area between holes (marked with a horizontal
line on some rack cabinets).

Installing the DXi4500 System 7
DXi4500 Installation and Configuration Guide
Installing the DXi4500 Installing the DXi4500 consists of the following steps:
•Installing the DXi4500 Rack Mounting Rails
•Installing the DXi4500 Chassis
Installing the DXi4500 Rack Mounting Rails
1Install the rack mounting rails (see Figure 4 for square holes and Figure 5 for Round
holes):
aPosition the left and right rail end pieces of the rail module labeled FRONT
facing inward and orient each end piece to seat in the square holes on the front
side of the vertical rack flanges. Align each end piece to seat the pegs in the
bottom hole of the first U space and the top hole of the second U space.
bEngage the back end of the rail until it fully seats on the vertical rack flange and
the second tooth on the latch locks in place.
Note: To remove the rack mounting rails, pull the Release latch located on the
front of the rail.
Figure 4 Installing the Rack
Mounting Rails (Square Holes)
Front side of rack rails
Front of rack
Back of rack
Rail teeth
Rail pegs
Second tooth
engaged
Release
button
Release
button

8Installing the DXi4500 System
DXi4500 Installation and Configuration Guide
Figure 5 Installing the Rack
Mounting Rails (Round Holes)
2Place the DXi4500 on a level surface and align the four keyhole slots on the chassis
rails with the corresponding pins on the system. Slide the chassis rails towards the
back of the system until each one locks into place (see Figure 6).
WARNING: The DXi4500 weighs 49.5 lbs (22.5 Kg). Two people are required to lift the
chassis.
Note: To disengage the chassis rails, pull the latch and push the rails toward the front
of the chassis.
Front side of rack rails
Front of rack
Back of rack
Rail teeth
Rail pegs
Second tooth
engaged
Release
button
Release
button

Installing the DXi4500 System 9
DXi4500 Installation and Configuration Guide
Figure 6 Installing the Chassis
Rails
Front
Back
Chassis rails
Latch

10 Installing the DXi4500 System
DXi4500 Installation and Configuration Guide
Installing the DXi4500 Chassis
WARNING: Ensure that the system is properly supported until the chassis rails are
locked into the slide rails on both sides.
1To install the DXi4500 chassis (see Figure 7):
WARNING: The DXi4500 weighs 49.5 lbs (22.5 Kg). Two people are required to lift the
chassis.
aPull the slide rails out of the rack until they lock into place.
bAlign and insert the ends of the chassis rails into the ends of the slide rails. Push
the system inward until the chassis rails lock into place.
cPush or pull the blue tab located near the front of the system and slide the
system into the rack.
Figure 7 Installing the
DXi4500 Chassis
Slide rails extended
DXi4500 chassis
Blue tab
Chassis rails

Initial Configuration 11
DXi4500 Installation and Configuration Guide
Cabling the DXi4500 To cable the DXi4500 (see Figure 8):
1Connect a power cable to each power supply (two).
Note: It is recommended that you connect each power cord to a separate AC
circuit to ensure system availability in case of a power failure.
2 Do NOT connect Ethernet cables at this time.
Figure 8 Cabling the DXi4500
ST
1
3
2
1
2
Gb 2
Gb 1
2345
Power cables
Service ports (not
for customer use)
Not used
Back
Not used
Initial Configuration
Before the DXi4500 is operational, you must configure the system through the remote
management setup pages. You must also configure your backup software.
Configuring the DXi4500 consists of four major steps. See the following subsections for
detailed instructions for completing each step:
1Accessing the DXi4500, Remote Management Interface on page 12
2Completing the Setup Wizard on page 15
3Connecting the Ethernet Cables on page 19
4Creating a Typical Backup Configuration on page 20
Note: You will need a computer and an Ethernet cable to complete the initial setup.

12 Initial Configuration
DXi4500 Installation and Configuration Guide
Note: If you attempt to install multiple DXi4500 systems at the same time, an IP
address conflict can occur because each system is configured with the same
default IP address (10.1.1.1). To avoid this problem, install one system and
configure it to use a different IP address before you connect another system to
the network.
Accessing the DXi4500,
Remote Management
Interface
To access the DXi4500 remote management interface:
1Turn on the DXi4500 system by pressing the power button located on the front of
each chassis (see Figure 9).
Note: Wait 10 minutes for the system to boot before continuing with the
procedure.
Figure 9 Power Buttons
Power button
The NMI button is recessed to prevent it
from being pressed accidently. Press only
when instructed by technical support
Front
2Using an Ethernet cable, connect the Ethernet port on the computer to Ethernet
port 2 on the back of the DXi4500. Ethernet port 2 is in the far left-hand Ethernet
port in the middle PCI slot (slot 2) as you face the back of the system (see Figure 10).

Initial Configuration 13
DXi4500 Installation and Configuration Guide
Figure 10 Ethernet Ports
ST
1
3
2
1
2
Gb 2
Gb 1
2345
Service port (not
for customer use)
Not used
Back
Ethernet port 2
Not used
3Configure the network settings on the computer:
Note: This procedure assumes you are running Windows XP on the computer. The
steps might be different if you are using another operating system.
aOn the Windows Start menu, click Connect To > Show all connections.
bRight-click the network connection that corresponds to the Ethernet port on the
computer (for example, Local Area Connection), and click Properties.
cSelect Internet Protocol (TCP/IP) in the list of connections, and then click
Properties.
The Internet Protocol (TCP/IP) Properties window displays (see Figure 11).

14 Initial Configuration
DXi4500 Installation and Configuration Guide
Figure 11 Internet Protocol
(TCP/IP) Properties Window
dSelect Use the following IP Address and then enter the following information:
Caution: Before changing the IP address information, write down the
original settings. This will be used later to reset the network
configuration.
•IP address - 10.1.1.2
•Subnet mask - 255.255.0.0
eClick OK.
fWait at least two minutes for the computer to set the IP addresses on the local
computer.
4On the computer, open a supported Web browser, type 10.1.1.1 in the Address
box, and press <Enter>.
The Log In page displays (see Figure 12).
Note: For Web browsers, the DXi4500 supports either Internet Explorer 6 or
higher, or Firefox 1.5 or higher.
Note: If the Log In page does not display, verify that you entered the correct IP
address (10.1.1.1) and that the network settings on the computer are
correct. Wait five minutes, then try again. If the Log In page still does not
display, contact Quantum Customer Support. (Contact information is
located on the last page of this document.)
Continue with the next section to log on to the system and complete the Setup
Wizard.

Initial Configuration 15
DXi4500 Installation and Configuration Guide
Figure 12 Log In Screen
Completing the Setup
Wizard
To complete the DXi4500 setup wizard:
1On the Log In page, select Administrator, type password for the password, and
click Login.
The License Agreement page displays (see Figure 13).
Figure 13 License Agreement
2Read the license agreement and click I Accept at the bottom to continue.

16 Initial Configuration
DXi4500 Installation and Configuration Guide
Note: If you do not accept the license agreement, the DXi4500 will not function.
The Segmentation and Bonding page displays (see Figure 14).
Caution: Configuring network segmentation requires advanced networking
knowledge. When selecting network segmentation options other than
than the options recommended in the following procedures, contact
your network administrator for assistance.
If you choose to use network segmentation or CIFS, refer to the
DXi4500 User’s Guide for details.
Caution: The DXi4500 bonding settings must match the switch settings. If the
switch settings and the DXi4500 settings do not match, your system
may become inaccessible.
Figure 14 Network
Configuration (Segmentation
and Bonding)
3Under Segmentation, select BOND ALL (Not segmented). BOND ALL (Not
segmented) is the default setting.
Note: Refer to the Quantum DXi4500 User’s Guide (PN 6-66904) located on the
documentation CD for information about additional segmentation options.
4Under Bonding, select Round Robin (Mode 0). Round Robin (Mode 0) is the
default setting.
Note: Refer to the Quantum DXi4500 User’s Guide (PN 6-66904) located on the
documentation CD for information about additional bonding options.

Initial Configuration 17
DXi4500 Installation and Configuration Guide
5Click Next.
The General page displays (see Figure 15).
Figure 15 Network
Configuration (General)
6On the General page:
aEnter the Hostname used to identify the DXi4500 system.
bIf your site uses Domain Search Path (DNS), enter the DNS. DNS may be either a
single domain name or a comma-separated list (no spaces) of up to 6 domain
names. The first domain name listed is used as the local domain. Domain names
must only contain letters [A-Z a-z], numbers[0-9], dots [.] and hyphens [-].
7Click Next.
The Network Configuration (IP) page displays (see Figure 16).

18 Initial Configuration
DXi4500 Installation and Configuration Guide
Figure 16 Network
Configuration (IP)
8On the IP page:
Your network administrator will provide you with the IP address information.
Caution: Make sure you enter the correct IP address information and that you
write this information down. If you enter the incorrect IP address
information and reboot, you will not be able to access the system.
aUnder System, enter the IP Address, the Netmask, and the Default Gateway
you want to use to join the DXi4500 to your network.
bIf your site uses DNS, under DNS, enter the Primary, Secondary, and Te r t i a r y
DNS IP Address.
9Click Apply to confirm the changes, then click Yes to continue. A message displays
stating that the Network configuration has been saved.
10 Click OK to continue.
The Date/Time Settings page displays (see Figure 17).

Initial Configuration 19
DXi4500 Installation and Configuration Guide
Figure 17 Date/Time Settings
11 If necessary, select Manual to manually set the system date and time.
Click Edit to specify the system date. Use the drop down boxes to specify the system
time.
Note: You can also choose to synchronize the system time with an NTP time
server. For more information, refer to the
Quantum DXi4500 User’s Guide
(PN 6-66904) located on the documentation CD.
12 Select the Timezone.
13 Select the desired time format (24 hours or 12 hours).
14 Click Apply.
A message appears stating that completing the setup will restart the system.
15 Click Yesto restart the system.
16 Disconnect the computer from the DXi4500 from Ethernet port 2 on the DXi4500.
Reset the computer network settings back to its default values.
17 Wait 15 minutes for the system to fully restart.
Connecting the
Ethernet Cables
Connect the Ethernet cables to the DXi4500 as follows (see figure 18).
Note: The Ethernet cables are used for remote management and NAS connectivity.
Review the
DXi4500 Site Planning Guide (PN 6-66638) located on the
documentation CD to determine the number of Ethernet cables to attach.
1Connect up to four Ethernet cables to the Quad port NIC (ports 2, 3, 4, and 5).

20 Initial Configuration
DXi4500 Installation and Configuration Guide
Figure 18 Connecting the
Ethernet Cables
ST
1
3
2
1
2
Gb 2
Gb 1
2345
Ethernet ports
Service port (not
for customer use)
Not used
Not used
Creating a Typical
Backup Configuration
Before you can begin using the DXi4500 for backups, you must configure the system for
NAS or Symantec™ NetBackup OST. See the following sections for detailed instructions
for completing each type of configuration:
•Installed System Licenses on page 21
Refer to this section for information on installed system licenses.
•OST Configuration on page 21
See this section to configure the DXi4500 to use OST (OpenStorage) and Symantec
Veritas NetBackup to perform backups and Optimized Duplication.
•NAS Configuration on page 22
See this section to configure the DXi4500 to use NAS (network attached storage) for
backups.
