Quantum 600 XL User manual

Quantum®600 XL
SERIES POWER CHAIRS
The Quantum®600 XL features our patent
pending Mid-Wheel 6 design platform, an
increased weight capacity of 400 lbs., and
enhanced seating available up to 24” x 24”.
The 600 XL is the perfect heavy-duty choice
for those who demand maximum stability
and true all-around performance.
Maximum stability.
Q600 XL shown with Synergy®Seating System
and Flight controller

14” solid
Front: 5” solid Rear: 6” solid
ATX Suspension
(Active-Trac®with extra stability)
Up to 4.5 mph
Intelligent Braking
(electronic, regenerative disc brakes)
3”
20”
Length: 37.5” (without front riggings)
Width: 23”
Synergy®Seat
Adjustable Width: 10”-24”
Adjustable Depth: 10”-24”
TRU-Balance®2 Power Positioning System
Adjustable Width: 14”-24”
Adjustable Depth: 14”-24”
High-back Seat (24” x 24” max. dim.)
2-motor, GLIDE, Mid-Wheel 6®
Two 12 volt, NF-22
Up to 15 miles
5A, off-board
75A Flight
70A PG VSI
400 lbs. maximum (user weight)
129 lbs.
38 lbs. (each)
Lifetime limited warranty on frame
2-year warranty on electronics
18-month warranty on drive motor
DRIVE WHEELS
OMNI-CASTERS
SUSPENSION
MAXIMUM SPEED 1
BRAKES
GROUND CLEARANCE 2
TURNING RADIUS 2
OVERALL SIZE 2
SEATING
DRIVE TRAIN
BATTERIES
RANGE PER CHARGE 1
BATTERY CHARGER
AVAILABLE
ELECTRONICS
WEIGHT CAPACITY
BASE WEIGHT
BATTERY WEIGHT
WARRANTY
.Mid-Wheel 6®allows six wheels on the ground
for maximum stability
.OMNI-Casters (nylon, spherical-shaped casters)
on front and rear prevent wheel hang-ups
.Side-mounted, easily accessible freewheel levers
.ATX Suspension (Active-Trac®with extra stability)
incorporates front OMNI-Casters for enhanced
performance over more varied terrain
.5-amp, off-board charger
.2-pole, GLIDE motors
.400 lbs. weight capacity
.Swing-away joystick
.Multi-axis joystick mount
.Elevating leg rests
.Oxygen tank holder
.Neoprene leg rest sleeves
.Gel adductor buttons
.Angle-adjustable footplates
.Contoured seating
.High-mount foot platform
.Residual limb supports
.Contoured seating with solid seat pan
Specifications Features
FOOTNOTES:
1) Range and speed vary with user weight, terrain type, battery
charge, battery condition and tire pressure.
2) Due to manufacturing tolerances, this specification can be
subject to variance of + or - 3%.
Options
(US) 866-800-2002
(Canada) 888-570-1113
www.quantumrehab.com
Q600XL-7-19-07
Q600 2HD - SS (Code: K0824)
Q600 2HD - C (Code: K0825)
Q600 2SPHD - SS (Code: K0837)
Q600 2MPHD - SS (Code: K0843)
Q600 3HD - SS (Code: K0850)
Q600 3HD - C (Code: K0851)
Q600 3SPHD - SS (Code: K0858)
Q600 3SPHD - C (Code: K0859)
Q600 3MPHD - SS (Code: K0862)
Code Coverage
70A PG Remote Plus
Shroud Colors
Candy
Apple Red
Viper
Blue
Onyx
Black
Champagne Sunburst
Orange
Emerald
Green
Pewter
Silver
Kelly
Green
Graphite
Blue
Sapphire
Blue
Tangerine
Mariner
Blue
Cardinal
Red
Spring
Green
Violet Solar
Yellow
Pearl
Pink
METALLIC COLORS
SOLID COLORS
