Queclink GL505 User manual

GL505 User Manual
TRACGL505UM001 - 1 -
GL505 User Manual
GSM/GPRS/GPS Tracker
TRACGL505UM001
Revision: 1.00

GL505 User Manual
TRACGL505UM001 - 2 -
Document Title
GL505 User Manual
Version
1.00
Date
2016-06-14
Status
Release
Document Control ID
TRACGL505UM001
General Notes
Queclink offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by Queclink. The information provided is
based upon requirements specifically provided to Queclink by the customers. Queclink has not
undertaken any independent search for additional relevant information, including any
information that may be in the customer’s possession. Furthermore, system validation of this
product designed by Queclink within a larger electronic system remains the responsibility of the
customer or the customer’s system integrator. All specifications supplied herein are subject to
change.
Copyright
This document contains proprietary technical information which is the property of Queclink
Wireless Solutions Co., Ltd. The copying of this document and giving it to others and the using
or communication of the contents thereof, are forbidden without express authority. Offenders
are liable to the payment of damages. All rights reserved in the event of grant of a patent or the
registration of a utility model or design. All specification supplied herein are subject to change
without notice at any time.
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 3 -
Contents
Contents ............................................................................................................................................3
Table Index ........................................................................................................................................4
Figure Index.......................................................................................................................................5
0. Revision History.............................................................................................................................6
1. Introduction ..................................................................................................................................7
1.1. Reference.............................................................................................................................7
1.2. Terms and Abbreviations.....................................................................................................7
2. Product Overview..........................................................................................................................8
2.1. Check Parts List....................................................................................................................8
2.2. Parts List ..............................................................................................................................8
2.3. Interface Definition .............................................................................................................9
3. Getting Started ............................................................................................................................10
3.1. Opening the Case ..............................................................................................................10
3.2. Closing the Case ................................................................................................................10
3.3. Installing a SIM Card..........................................................................................................11
3.4. Installing the Internal Backup Battery ...............................................................................11
3.5. Power on the Device .........................................................................................................12
3.6. Device Placement..............................................................................................................12
3.7. Device Status LED ..............................................................................................................13
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 4 -
Table Index
Table 1. GL505 Protocol Reference.........................................................................................7
Table 2. Terms and Abbreviations...........................................................................................7
Table 3. Parts List ....................................................................................................................8
Table 4. Description of 8 PIN Connections..............................................................................9
Table 5. Definition of Device Status and LED ........................................................................13
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 5 -
Figure Index
Figure 1. Appearance of GL505 ........................................................................................8
Figure 2. The 8 PIN connector on the GL505 ...................................................................9
Figure 3. Opening the Case ............................................................................................10
Figure 4. Closing the Case ..............................................................................................10
Figure 5. SIM Card Installation .......................................................................................11
Figure 6. Backup Battery Installation .............................................................................12
Figure 7. GL505 Status LED.............................................................................................12
Figure 8. Label on GL505................................................................................................13
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 6 -
0. Revision History
Revision
Date
Author
Description of Change
R1.00
2016-06-14
Hazard Zhang
Initial
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 7 -
1. Introduction
The GL505 is a powerful GPS tracker designed for fixed asset tracking applications. It is powered
by user replaceable CR123A lithium battery pack. Configuration allows it to wake up on a preset
schedule to check if it needs to shift from dormant to active status and/or send update of its
current location, and then return to a dormant state. Optimally configured, it will operate
autonomously for 1800 days. Its built-in 3-axis accelerometer allows the GL505 to detect asset
movement and transmit an alert message. The integrated @Track interface protocol allows the
GL505 to communicate with a customer mobile phone or a backend server via GPRS/SMS and
transfer reports like GPS position. System integrators can easily incorporate the GL505 into
existing tracking systems based on this full featured protocol.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
1.1. Reference
Table 1. GL505 Protocol Reference
SN
Document name
Remark
[1]
GL505 @SMS & @Track Interface Protocol
The @SMS & @Track protocol
interface between GL505 and
backend server.
1.2. Terms and Abbreviations
Table 2. Terms and Abbreviations
Abbreviation
Description
AGND
Analog Ground
AIN
Analog Input
DIN
Digital Input
DOUT
Digital Output
GND
Ground
MIC
Microphone
RXD
Receive Data
TXD
Transmit Data
SPKN
Speaker Negative
SPKP
Speaker Positive
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 8 -
2. Product Overview
2.1. Check Parts List
Before starting, check all the following items have been included with your GL505. If anything is
missing, please contact your supplier.
Figure 1. Appearance of GL505
2.2. Parts List
Table 3. Parts List
Name
GL505 Locator
80*58*26.8 mm
GL505 Data Cable (Optional)
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 9 -
GL505 MCU Download Kit (Optional)
2.3. Interface Definition
The GL505 has an 8 PIN interface connector. It contains the connections for power, RS232, MCU
Interface, etc. The sequence and definition of the 8PIN connector are shown in following figure:
Figure 2. The 8 PIN connector on the GL505
Table 4. Description of 8 PIN Connections
Index
Description
Comment
1
VDD_5V
External DC power input 5V
only for debug use
2
NC
Not connected
3
BB_RXD
BB UART RXD
4
BB_TXD
BB UART TXD
5
MCU_RESET
MCU CHIP RESET SIGNAL
6
BKGD
MCU CHIP BKGD SIGNAL
7
VDD_MCU_2V8
MCU POWER INPUT，2.8V
8
GND
Power and digital ground
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 10 -
3. Getting Started
3.1. Opening the Case
Figure 3. Opening the Case
Use the Screwdriver to remove the screws, and then open the case.
3.2. Closing the Case
Figure 4. Closing the Case
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 11 -
Place the cover in the correct position and then tighten the screws with a Screwdriver.
3.3. Installing a SIM Card
Open the case and ensure the unit is not powered (unplug the internal battery). Slide the holder
right to open the SIM card. Insert the SIM card into the holder as shown below with the
gold-colour contact area facing down taking care to align the cut mark. Close the SIM card holder.
Close the case.
Figure 5. SIM Card Installation
3.4. Installing the Internal Backup Battery
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 12 -
Figure 6. Backup Battery Installation
Note: Make sure the battery is switched OFF before installation.
3.5. Power on the Device
After inserted the Battery, GL505 will power on automatically, the Status LED will start work,
detail description in the next section.
Figure 7. GL505 Status LED
3.6. Device Placement
The side with label should towards sky to ensure there is good GPS signal can be recieved.
Blue GPS
Red PWR
Green GSM
Queclink
Confidential

GL505 User Manual
TRACGL505UM001 - 13 -
Figure 8. Label on GL505
3.7. Device Status LED
Table 5. Definition of Device Status and LED
LED
Device status
LED status
GSM
(Green)
Device is searching GSM network.
Fast flashing
(Note1)
Device has registered to GSM network.
Slow flashing
(Note2)
SIM card needs pin code to unlock.
ON
GPS
(Blue)
GPS chip is powered off.
OFF
GPS sends no data or data format error.
Slow flashing
GPS chip is searching GPS info.
Fast flashing
GPS chip has gotten GPS info.
ON
PWR
(Red)
Battery voltage is lower than 0%.
OFF
Battery voltage is below 10%.
Slow flashing
Battery voltage is more than 10%.
ON
Note:
1. Fast flashing is about 60ms ON/ 780ms OFF.
2. Slow flashing is about 60ms ON/ 1940ms OFF.
3. In Battery mode, all LEDs are only enabled during the first 5 minutes after the device is
powered on, and then will be shut down all the time.
