Quick XR Series User manual

XRSeries
XR7 4024 DC - 4000 AC - 5500 AC - HYDRO
XR8 5500 AC - 7500 AC - HYDRO
XR9 15000 AC - HYDRO
REV 000A
VERTICAL WINDLASSES
*EN - INSTALLATION AND USER'S MANUAL *Other languages available by scanning the QR
code on the back of this manual or on the label
on the product.

XRSeries EN
INDEX
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
1 - Information about the product 5
1.0 - Model code 5
1.1 - XR7 Technical Data 5
1.2 - XR8 Technical Data 6
1.3 - XR9 Technical Data 6
1.4 - Chains and tightening torques 7
2 - Supply and equipment 7
2.0 - Standard supply and material included in the package 7
2.1 - Quick®accessories required, not included in standard supply 7
2.2 - Tools required for installation 7
2.3 - Recommended Quick®accessories not included 7
3 - Introduction 8
3.0 - Important notes 8
3.1 - Precautions 8
3.2- Precautions for the installer 8
4 - Installation 9
4.0 - Installation requirements 9
4.1 - Installation procedures 9
5 - Wiring diagram 11
5.0 - Example of connection XR7 4000W DC 11
5.1 - Example of connection XR7 (4000-5000) XR8 (5500) EC-BOX 12
5.2 - Example of connection Inverter XR7 XR8 13
5.3 - Example of connection XR9 14
6 - Cautions & Use 15
6.0 - Important cautions 15
6.1 Use 15
7 - Maintenance 17
8 - Product disposal 17
9 - XR7 spare parts 19
9.0 - XR7 spare parts 19
9.1 - XR7 spare parts - Accessories not included as standard 19
10 - XR8 spare parts 21
10.0 - XR8 spare parts 21
10.1 - XR8 spare parts - Accessories not included as standard 21
11 - XR9 spare parts 23
11.0 - XR9 spare parts 23
11.1 - XR9 spare parts - Accessories not included as standard 23
12 - XR7 dimensions 24
13 - XR8 dimensions 26
14 - XR9 dimensions 29

XRSeries EN
XR7 40 24 D
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
5
1 - Information about the product
1.0 - Model code
VOLTAGE (V)
SERIES NAME
POWER
(W)
DRUM
(D)
1.1 - XR7 Technical Data
ELECTRIC MODEL XR7 4000 X/Y
MODEL POWER 4000 W
Motor voltage 24 V
Maximum instantaneous pull 4000 kg (8818 lb)
Maximum work load 1500 kg (3307 lb)
Work load 700 kg (1543 lb)
Current consumption at work load (1) 190 A
Maximum recovery speed (2) 31 m/min (10 1.7 ft/min)
Minimum motor cable cross section (3) 35 mm (AWG 2)
Circuit breaker (4) 150 A
Deck thickness (5) 30 ÷ 60 mm (1” 3/16 ÷ 2” 23/64)
Weight 181.6 kg 400 lb
ELECTRIC MODELS XR7 AC 4000 X/Y XR7 AC 5500 X/Y
MOTOR POWER 4000 W AC 5500 W AC
Motor voltage (5) 230/400 V 230/400 V
Maximum instantaneous pull 4500 kg (9921 lb) 5000 kg (11000 lb)
Maximum work load 2000 kg (4409 lb) 2350 kg (5181 lb)
Maximum recovery speed (2) 10 m/min (32.8 ft/min) 11.6 m/min (393.7 ft/min)
Deck thickness (6) 30 ÷ 60 mm (1” 3/16 ÷ 2” 23/64)
Weight 173 kg (381.4 lb) 178.6 kg (393.7 lb)
• (1) After an initial period of use. • (2) Measurements carried out with gypsy for 16 mm STUD-LINK chain. • (3) Minimum recommended value for total length L= <20m. Calculate the cable cross
section according to the connection length. • (4) With specic circuit breaker for direct current (DC) and delayed (thermal-magnetic or hydraulic-magnetic) circuit breaker. • (5) Three-phase
motor • (6) Studs for greater deck thickness can be supplied upon request.
HYDRAULIC MODEL XR7 HYDRO X/Y
Motor type Reversible gear type
Displacement 43 cc 2.62 in3
Lifting capacity 2500 kg @ 150 bar 5511 lb @ 2175 psi
Recovery speed at work load (1) 50 l/min @ 12.5 m/min 11.4 USG/min @ 41 ft/min
Deck thickness (2) 30 ÷ 60 mm (1” 3/16 ÷ 2” 5/16)
Weight 165 kg 363.8 lb
ADJUSTMENT VALUES (recommended by Quick)
Flow rate 70 l/min 18.5 USG/min
Maximum pressure 150 bar 2175 psi
(1) Measurements carried out with gypsy for 16 mm stud-link chain.
(2) Studs for greater deck thickness can be supplied upon request.
QUICK®RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT
PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED VERSION AND THE ORIGINAL TEXT IN THE ITALIAN
LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.

XRSeries
EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
6
1 - Information about the product
1.2 - XR8 Technical Data
ELECTRIC MODELS XR8 AC 5500 X/Y XR8 AC 7500 X/Y
MOTOR POWER 5500 W AC 7500 W AC
Motor voltage (1) 230/400 V 400/690 V
Maximum instantaneous pull 4500 kg (9921 lb) 6500 kg (14330 lb)
Maximum work load 2500 kg (5511 lb) 3500 kg (7716 lb)
Maximum recovery speed (2) 14.5 m/min (47.5 ft/min) 14 m/min (46 ft/min)
Deck thickness (3) 30 ÷ 60 mm (1” 3/16 ÷ 2” 5/16)
Weight 297 kg (654 lb) 303 kg (668 lb)
(1) Three-phase motor• (2) Measurements carried out with gypsy for 20.5 mm STUD-LINK chain. • (3) Studs for greater deck thickness can be supplied upon request.
HYDRAULIC MODEL XR8 HYDRO X/Y
Motor type Reversible gear type
Displacement 43 cc 2.62 in3
Lifting capacity 3000 kg @ 170 bar 6613 lb @ 2465 psi
Recovery speed at work load (1) 14 m/min 46 ft/min
Deck thickness (2) 30 ÷ 60 mm 1” 3/16 ÷ 2” 23/64 inch
Weight 280.5 kg 618 lb
ADJUSTMENT VALUES (recommended by Quick)
Flow rate 70 l/min 18.5 USG/min
Maximum pressure 170 bar 2175 psi
(1) Measurements carried out with gypsy for 20.5 mm STUD-LINK chain. • (2) Studs for greater deck thickness can be supplied upon request.
1.3 - XR9 Technical Data
ELECTRIC MODELS XR9 AC 15000 X/Y
MOTOR POWER 15000 W AC
Motor voltage (1) 400/690 V
Maximum instantaneous pull 17637 Kg (38882 lb)
Maximum work load 13227 Kg (29160 lb)
Maximum recovery speed (2) 15 m/min (49 ft/min)
Deck thickness (3) 30 ÷ 60 mm (1” 3/16 ÷ 2” 23/64)
Weight 580 kg (654 lb)
(1) Three-phase motor- (2) Measurements carried out with gypsy for 26 mm STUD-LINK chain. - (3) Studs for greater deck thickness can be supplied upon request.
HYDRAULIC MODEL XR9 HYDRO X/Y
Motor type Reversible gear type
Displacement 43 cc 2,62 in3
Lifting capacity 6000 kg @ 180 bar 6613 lb @ 456 bar
Recovery speed at work load (1) 15 m/min 49 ft/min
Deck thickness (2) 30 ÷ 60 mm 1” 3/16 ÷ 2” 23/64 inch
Weight 565 kg 1245 lb
ADJUSTMENT VALUES (recommended by Quick)
Flow rate 70 l/min 18.5 USG/min
Maximum pressure 170 bar 2175 psi
(1) Measurements carried out with gypsy for 26 mm STUD-LINK chain. - (2) Studs for greater deck thickness can be supplied upon request.

XRSeries EN
XRSeries
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
7
1 - Information about the product
1.4 - Chains and tightening torques
XR7
GYPSY 14 mm 16 mm 18 mm 12.5 mm 14 mm 16 mm
SUPPORTED
CHAIN
14 mm 14 mm 16 mm 16 mm 18 mm 18mm 12.5 mm 14 mm 16 mm
DIN 766 ISO(**) DIN 766 ISO(**) DIN 766 ISO(**) STUD-LINK STUD-LINK STUD-LINK
(**) ISO EN 818-3.
XR8
GYPSY 16 mm 19 mm 20.5 mm 22 mm
SUPPORTED
CHAIN
16 mm 17.5 mm 19 mm 20.5 mm 22 mm
STUD-LINK STUD-LINK STUD-LINK STUD-LINK
XR9
GYPSY 22 mm 24 mm 26 mm
SUPPORTED
CHAIN
22 mm 24 mm 26 mm
STUDLINK STUDLINK STUDLINK
XR7 XR8 XR9
TIGHTENING TORQUE
Nm
M6 6.5
M8 16
M10 31
M12 55
M14 87
M16 135
Indicative values for stainless steel screws, consider tightening by
evaluating the material of the surface where it will be fastened.
2 - Supply and equipment
2.0 - Standard supply and material included in the package
• Windlass (top + gearmotor)
• Contactor or reversing contactor box (DC model only)
• Lever
• Screws for assembly
• Installation and user’s manual, Warranty
• Drilling template
2.1 - Quick®accessories required, not included in standard supply
• RH/LH chain pipe
• Band brake handwheel
2.2 - Tools required for installation
XR7 • Drill with bit: Ø 15 mm (19/32”) • Hole saw Ø 200 mm (7” 7/8) • Hex wrench: 17 and 19 mm
XR8 • Drill with bit: Ø 15 mm (19/32”) • Hole saw Ø 250 mm (9” 27/32) • Hex wrench: 17 and 19 mm
XR9 • Drill with bit: Ø 18 mm (45/64”) • Hole saw Ø 340 mm (13” 25/64) • Hex wrench: 24 mm
2.3 - Recommended Quick®accessories not included
• EC - BOX Electrical connection box for AC motors (XR7/XR8)
• Inverter
• Control from control board
• Waterproof push-button panel
• Foot-operated switch
• Control system via RRC radio
• Chain stopper

XRSeries
EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
8
3 - Introduction
BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK®DEALER.
3.0 - Important notes
This manual features Warning and/or Caution symbols that are important for safety.
Please follow the instructions provided.
Warning symbol for dangerous
situations.
Caution symbol to prevent direct or
indirect damage to the product.
This document provides boat manufacturers and nautical equipment installers with instructions on how to assemble the Quick®
product and operate it correctly.
3.1 - Precautions
Quick® windlasses have been designed and manufactured to weigh the anchor
• Do not use these products for any other type of operation.
• Quick®shall not be held liable for direct or indirect damage caused by improper use of the product.
• The windlass is not designed to support loads generated in particular weather conditions (storm).
• Operate the product from a position where it is possible to supervise the work area.
• Always deactivate the windlass when not being used.
• Make sure that there are no bathers nearby before dropping the anchor.
• For improved safety, we recommend installing at least two controls to operate the windlass in case one is
damaged.
• We recommend the use of Quick®switch as motor safety device.
• Secure the chain with a retainer before sailing off.
• 24 V MODEL ONLY: The reversing contactor box must be installed in a position protected from any water entry.
• After completing the anchorage, secure the chain to xed points such as chain stopper or bollard.
• To prevent accidental releases, the anchor must be secured. The windlass must not be used as sole securing
device.
• Isolate the windlass from the electrical system during navigation and secure the rope to a xed point of the boat.
• This equipment is not intended for use by people (including children) with reduced physical, sensory or mental
capabilities. Quick®SpA shall not be held liable for direct or indirect damage caused by improper use of the
equipment.
3.2- Precautions for the installer
CARRY OUT THE INSTALLATION IN GOOD LIGHTING CONDITIONS.
It is advisable to wear suitable clothing and personal protective equipment (PPE).
The product is not suitable for installation in potentially explosive environments and/or atmospheres.
Installation and subsequent inspection or repair work must only be carried out by qualied personnel.
CARRY OUT INSTALLATION/MAINTENANCE WORK MAKING SURE THAT THE PRODUCT IS DISCONNECTED
FROM THE ELECTRICAL SYSTEM.
Quick accepts no responsibility for inadequate connection of users to the electrical system and inadequate safety
of the electrical system.

XRSeries EN
B
45°
A
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
9
4 - Installation
4.0 - Installation requirements
The windlass must be positioned by aligning the gypsy with the bow roller.
Check that the upper and lower surfaces of the deck are as parallel as possible; if this is not the case, properly compensate for
the difference (lack of parallelism could result in motor power loss).
The deck thickness must be between the values shown in the table (Sect.1). In case of different thickness, please contact your
Quick®dealer.
There must be no obstacles below deck for chain passage, the shallow depth of the locker could cause jams.
4.1 - Installation procedures
A) Identify the ideal position and drill the holes using the drilling template supplied.
B) Remove the excess material from the chain passage hole, nish it and smooth it with a specic product (marine paint, epoxy
resin gel) ensuring the free passage of the chain.
max 5 mm
(3/16")
minimum
1.5m (59”1/16)

XRSeries
EN
90°
HYDRO
90°
90°
90°
45°
D
E
F
H
G
45°
AC
I
L
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
10
4 - Installation
XR7/XR8 • C) Position the upper part of the windlass. D) Secure it by screwing the nuts on the locking studs.
E) Insert the O-ring into the ange. F) Secure the ange to the base insert with 6 screws. G) Insert the gearmotor into the
windlass shaft. H) Tighten with screws.
XR9 • C) Position the upper part of the windlass. D) Secure it by screwing the nuts on the locking studs. I)
Insert the gearmotor into the windlass shaft. L) Tighten with screws.
WASHER
SCREW
Nm
Nm
O-RING
WASHER
STUD
GROWER
NUT
FLANGE
SCREW
BASE INSERT
C
WASHER
SCREW
GROWER
Tighten screws and nuts following a cross pattern with reference to the tightening values shown in the table (page
7). Apply threadlocker on the screws supplied. Periodically check proper tightening of screws.
ELECTRIC MOTOR Connect the power cables coming from the windlass to the mains (AC).
HYDRAULIC MOTOR Connect the pipes coming from the distribution valve to the two hydraulic motor anges
(see wiring diagram on page --).
WARNING: before connecting the equipment, make sure that cables are not live.
HORIZONTAL POSITION OF GEARMOTOR AND HYDRAULIC MOTOR
ELECTRIC Depending on the type of gearmotor, a rotation every 45° or 90° is possible.
HYDRAULIC Depending on the type of motor, a rotation every 90° is possible.
The entire XR series features the
band brake with movable xing
block that allows to aim the
handwheel in several positions
on the deck plan.

XRSeries EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
11
5 - Wiring diagram
A1
A2
D1
D2
MULTI-PURPOSE
PUSH-BUTTON PANEL
HRC 1002
WINDLASS
MOTOR
BATTERY
HYDRAULIC MAGNETIC
SWITCH
(SEE TABLE ON PAGE.5)
REVERSING
CONTACTOR BOX
MOD. T6415-24 (24V)
C
A2
FOOT-OPERATED SWITCHES MOD. 915C
BLACK
BROWN
BLUE
BROWN
BLACK
BLUE
A1
FUSE
2A (24V)
4A (12V)
L5
L2
L3
L1
L6
L4
L = L1 + L2 + L3 + L4 + L5 + L6
5.0 - Example of connection XR7 4000W DC

XRSeries
EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
12
5 - Wiring diagram
5.1 - Example of connection XR7 (4000-5000) XR8 (5500) EC-BOX
W2 U2 V2
U1 W1
AC
IN
AC
OUT
24V
IN
CONTROLLER
U1 V1 W1
XP XP XP
R S T
L1 XP R
L2 XP S
L3 XP T
M
3
～
V1
MULTI-PURPOSE
PUSH-BUTTON
PANEL
MOD. HRC 1002
WINDLASS
SENSORE
TERMINAL BOX
MOTOR
SENSOR
CABLE
EC BOX
FOOT-OPERATED SWITCHES MOD.
915C
BATTERY 24V
BROWN
MARRONE
BLACK
NERO
BLUE
BLU
FUSE
2A (24V) 4A (12V)

XRSeries EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
13
5 - Wiring diagram
M
3 200...690 Vac
WINDLASS
INVERTER
THREE-PHASE
SUPPLY
FUSE
MOTOR TERMINAL BOX
MULTI-PURPOSE
PUSH-BUTTON
PANEL
HRC 1002
FOOT-OPERATED SWITCHES
MOD. 915C
5.2 - Example of connection Inverter XR7 XR8

XRSeries
EN
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
14
5 - Wiring diagram
WINDLASS
BATTERY 12/24
CONTACTORS
12/24
THREE-PHASE SUPPLY
FUSE
5.3 - Example of connection XR9
M
3 200...690 Vac
INVERTER
MOTOR BRAKE
CONTACTS
BRAKING
RESISTOR
MULTI-PURPOSE
PUSH-BUTTON
PANEL
MOD. HRC 1002
FOOT-OPERATED
SWITCHES MOD. 915C

XRSeries EN
1
9
14
3
1
9
14
3
FIG. B
REF. A1
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
15
6 - Cautions & Use
6.0 - Important cautions
DO NOT place any part of your body or objects near the chain and gypsy sliding area.
Operate the windlass from a position where it is possible to supervise the work area.
Make sure the electric motor is not powered when the windlass is operated manually (also when using the lever
to lift the drum). In fact, people with windlass remote control (remote push-button panel or radio control) may
accidentally activate it.
Secure the chain with a retainer before sailing off.
DO NOT electrically activate the windlass with the lever inserted in the drum or gypsy cover.
Quick®recommends using a suitable power fuse/thermal-magnetic/hydraulic-magnetic protection depending on
the motor used, to protect the motor from overheating or short circuit.
The circuit breaker can be used to isolate the windlass control circuit, thus avoiding accidental activation.
6.1 Use
POWER TRANSMISSION
The central axis is connected to the reduction gear and the drum.
The gypsy is dragged by the drum through front couplings on the
gypsy.
When the drum (9) is up (Fig. A) and the bushing (3) is fully
unscrewed, the gypsy (14) is free.
When the drum (9) is down (Fig. B) and the bushing (3) is fully
screwed, the gypsy (14) is connected to the axis through the drum
and it is possible to weigh the anchor.
GYPSY COUPLING
1) Use the lever (1) to screw the bushing 3) clockwise; the drum
(9) lowers and engages the gypsy (14).
Make sure that the notches (image ref.A1) on the drum and
the gypsy are aligned.
The bushing must not be too tight, in this way the drum can
rotate on the gypsy and engage the front couplings through the
springs (8).
2) Use the lever (1) to unscrew the bushing by rotating it counter-
clockwise by 1/4 of a turn.
3) Remove the lever.
4) Operate the motor. The springs (8) in the bushing allow to
engage the front couplings between drum and gypsy.
5) Visually check that the coupling has been carried out (Fig. B)
and screw the bushing clockwise.
6) Remove the lever.
7) Release the band brake (25) if the windlass must be used.
ANCHOR WEIGHING WITH MOTOR
1) Make sure that the drum is coupled to the gypsy (Fig. B).
2) Use Quick®controls to weigh or release the anchor.
FIG. A
DO NOT STRAIN THE LIMIT SWITCH

XRSeries
EN
A
1
B
1
A = B
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
16
6 - Cautions & Use
FREE FALL
1) Make sure that Quick®chain stopper is in a position that does NOT lock the chain (Fig. C).
2) Make sure that the band brake is completely tight.
3) Unscrew the bushing counter-clockwise until its end of stroke and make sure that the drum is up, disengaged from the
gypsy (Fig. A).
4) Use the handwheel to loosen the band brake and adjust the anchor free fall.
USING THE DRUM (GYPSY LOCKED)
1) Make sure that Quick®chain stopper is in a position that locks the chain (Fig. D).
2) Make sure that the band brake is completely tight.
3) Unscrew the bushing counter-clockwise until its end of stroke and make sure that the drum is up, disengaged from the
gypsy (Fig. A).
4) Use Quick®controls to rotate the drum in either direction (Fig. E). Wrap the rope counter-clockwise around the drum (at least
3 turns - Fig. F). It is possible to adjust speed reduction and recovery force by sliding the rope on the drum cylinder.
WARNING: during recovery, keep a suitable safety distance between your hands and the windlass drum.
FIG. C
FIG. D
FIG. E FIG. F
QUICK®CONTROLS

XRSeries EN
XRSeries
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
17
7 - Maintenance
8 - Product disposal
WARNING: make sure that the electric motor is not powered when manually working on the windlass.
Remove with care the chain or rope from the gypsy or the rope from the drum.
Quick®windlasses are made of materials resistant to the marine environment: it is essential, in any case, to periodically remove
salt deposits that form on the external surfaces to avoid corrosion and consequently damage to the device.
• Thoroughly wash the surfaces and parts where salt can deposit with fresh water.
• Once a year, disassemble the gypsy and the drum according to the following sequence:
Clean every disassembled part to prevent corrosion, and grease (with marine grease) the shaft thread and the gypsy.
As with installation, at the end of this product life, dismantling must be carried out by qualied personnel.
This product is made up of various materials, some can be recycled and others must be suitably disposed of; enquire about the
recycling or disposal systems provided for by local regulations for this product category.
Some parts of the product may contain pollutants or hazardous substances that, if dispersed, may be harmful to the environment
and human health.
As indicated by the symbol on the side, it is forbidden to dispose of this product as domestic waste.
Separate the products for disposal in accordance with the regulations in force in your area or return the product to
the seller when purchasing a new equivalent product. Local regulations may impose severe penalties for the improper
disposal of this product.

XRSeries
EN
14
15
16
17
18
19
22
24
25
26
30
28 29
32
31
33
34
36
37
41
40
38
39
35
23
27
21
2
1
3
71
4
5
6
12
12
7
8
9
10
11
11
11
42
43
43
44
44
44
44
45
46
47
49
52
53
51
48
57
51
54
55
56
12
13
20
18
19
20
18
19
50
65
64
63
66
62
63
60/61
70
63
69 67
68
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
18
9 - XR7 spare parts

XRSeries EN
5958
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
19
9 - XR7 spare parts
9.0 - XR7 spare parts
Refer to the exploded view on page 20
CODE DESCRIPTION PART NO.
FVSSBXR71250A00 12.5MM GYPSY OSP, XR7 STUD-LINK 14
FVSSBXR71400A00 14MM GYPSY OSP, XR7 STUD-LINK 14
FVSSBXR71600A00 16MM GYPSY OSP, XR7 STUD-LINK 14
FVSSMSEXR700A00 XR7 WINDLASS BUSHING AND DRUM OSP 3 - 4 - 5 - 6 - 7 - 8 - 9
9.1 - XR7 spare parts - Accessories not included as standard
CODE DESCRIPTION PART NO.
FSRBXR700000A00 XR7 STAINLESS STEEL REMOTE BRAKE
HANDWHEEL
18 - 19 - 20 - 23 - 25 - 26 - 27 - 28 - 29 - 30
FSPSXR7SX0R1A00 XR7 COMPL LH STAINLESS STEEL CHAIN PIPE 58
FSPSXR7DX0R1A00 XR7 COMPL RH STAINLESS STEEL CHAIN PIPE 59
NO. NAME
1 LEVER
2 SCREW
3 XR7 DRUM BUSHING
4 XR7 DRUM DISC
5 ANTI-ROTATION RING
6 EXTERNAL SNAP RING
7 SPRING
8XR7 WINDLASS DRUM
9 DRUM DISC SPACER
10 SCREW
11 OIL SEAL
13 ANTI-ROTATION RING
14 GYPSY
15 SCREW
16 XR7 SERIES WINDLASS BASE
17 STUD
18 GROWER
19 NUT
20 WASHER
21 SENSOR
22 STUD
23 STUD
24 BAND BRAKE LOCK
25 UPPER WASHER
26 LOWER WASHER
27 REMOTE BRAKE ROD
28 UNIVERSAL JOINT
29 ELASTIC PIN
30 REMOTE BRAKE HANDWHEEL
31 BAND BRAKE SHAFT
32 EXTERNAL SNAP RING
33 EXTERNAL SNAP RING
34 XR8 SERIES BAND BRAKE
35 FLAT WASHER
36 SCREW
37 XR7 CHAIN STRIPPER SUPPORT
38 XR7 SERIES CHAIN STRIPPER
39 COUNTERSUNK SCREW
40 SCREW
41 XR7 BRASS PIN
42 7000W REINFORCING WASHER
43 INTERNAL SNAP RING
44 BEARING
45 XR7 BASE INSERT
46 XR7 SERIES WINDLASS SHAFT
47 KEY
48 PINS
49 SCREW
50 GROWER
51 O-RING
52 HUB FLANGE
53 SCREW
54 O-RING
55 REDUCTION GEAR CLOSING
FLANGE
56 SCREW
57 REDUCTION GEAR
58 RH CHAIN PIPE
59 LH CHAIN PIPE
60 5.5KW MOTOR
61 7.5KW MOTOR
62 HYDRAULIC MOTOR
63 KEY
64 ADAPTER
65 HYDRAULIC MOTOR FLANGE
66 90° G3/4 FEMALE FLANGE
67 3000 W MOTOR
68 KEY
69 3000 W MOTOR FLANGE
70 ADAPTER

XRSeries
EN
15
16
17
18
19
20
21
23
24
25
26
30
28 29
32
31
33
34
36
37
41
40
38
39
35
23
27
22
2
3
1
4
5
6
7
8
8
8
9
10
11
12
13
13
13
42
43
43
44
44
44
44
45
46
47
48
49
50
51
52
53
54
57
50
50
50
55
56
8
14
19
20
21
19
20
21
63 60
65
64
63
66
62
63
61
QUICK XRSeries INSTALLATION AND USER’S MANUAL - REV000A
20
10 - XR8 spare parts
