Quickie Pulse 6BC User manual

O w n e r ’s M a n u a l
Quickie®Pulse
6BC, 6SC, 6CC, 5BC, 5CC, 6MPC
Supplier: This manual must be given to the rider of
this wheelchair.
User: Before using this wheelchair read this entire manual and save
for future reference.
SECTION ENGLISH
PULSE
M a n u a l d e I n s t r u c c i o n e s
Quickie®Pulse
6BC, 6SC, 6CC, 5BC, 5CC, 6MPC
istribuidor: Este manual debe ser entregado al pasajero de esta silla de
ruedas.
Pasajero: Antes de usar esta silla de ruedas, lea este manual en su
totalidad y guárdelo para futura referencia.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español
o francés está disponible en formato P F en nuestra página en Internet:
www.SunriseMedical.com. Ingrese a la página del producto específico para descargar el manu-
al, o comuníquese con el proveedor autorizado de Sunrise Medical.
Mode d’emploi
Quickie®Pulse
6BC, 6SC, 6CC, 5BC, 5CC, 6MPC
Fournisseur: Ce manuel doit être remis à l’utilisateur / utilisatrice de ce
fauteuil roulant.
Utilisateur / Utilisatrice: Avant d’utiliser ce fauteuil roulant, lisez entière-
ment ce manuel et conservez le pour le consul-
ter ultérieurement.
Chaque fauteuil est livré avec un manuel d’instructions en anglais. Les versions en espagnol et
en francais sont à ançais est à votre disposition en format P F sur le site:
www.SunriseMedical.com. Veuillez vous rendre à la page de votre produit pour télécharger le
manuel dans la langue souhaitée, ou contactez un fournisseur agréé Sunrise Medical.

SUNRISE LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear
your questions or comments about this manual, the safety and
reliability of your chair, and the service you receive from your
Sunrise supplier. Please feel free to write or call us at the address
and telephone number below:
Sunrise Medical
Customer Service epartment
2842 Business Park Ave
Fresno, CA 93727
[phone]
FOR ANSWERS TO YOUR QUESTIONS
Your authorized supplier knows your wheelchair best, and can
answer most of your questions about chair safety, use and mainte-
nance. For future reference, fill in the following:
Supplier: _______________________________________________________________
Address: _______________________________________________________________
______________________________________________________________________
Telephone: _____________________________________________________________
Serial #: _________________________________________ ate/Purchased:_________
USER WARNING
WARNING
Attention wheelchair users, do not operate this wheelchair with-
out first reading the owner’s manual. If you do not understand the
instructions and warnings of this owner’s manual please contact
your dealer or qualified technician before operating this Quickie
wheelchair. Failure to do so may result in damage and/or injury.
EALER/TECHNICIAN WARNING
WARNING
Attention dealers and qualified technicians, do not operate or serv-
ice this wheelchair without first reading this owners manual. If you
do not understand the instructions and warnings of this owners
manual please contact the Quickie Technical Service epartment
before operating and/or servicing this Quickie wheelchair. Failure to
do so may result in damage and/or injury.
WARNING
In addition, power wheelchairs may contain printed circuit boards.
Careful attention should be given to the Printed Circuit Board
Handling Techniques insert supplied with the chair.
Related ocuments
Listed below are additional documents which are referenced in this
owners manual.
• RNET Owners Manual
• RNET OBP Owners Manual
• RNET Omni Owners Manual
• PULSE Service Manual
I. INTRODUCTION
QUICKIE PULSE
2
119832Rev.

II. TABLE OF CONTENTS
QUICKIE PULSE
3119832 Rev.
I. INTRO UCTION..........................................................................2
III. YOUR CHAIR AN ITS PARTS ................................................4
IV. NOTICE– REA BEFORE USE...................................................5
V. EMI (ELECTROMAGNETIC INTERFERENCE).......................5
A.WHAT IS EMI? ............................................................................5
B. WHAT EFFECT CAN EMI HAVE?.........................................5
C.SOURCES OF EMI .................................................................5-6
. ISTANCE FROM THE SOURCE..........................................6
E. IMMUNITY LEVEL .....................................................................6
F. REPORT ALL SUSPECTE EMI INCI ENTS .....................6
G.EMI FROM CHAIR.....................................................................6
H. HEA ARRAY SAFETY AN RFI
VI. GENERAL WARNINGS................................................................7
A.NOTICE TO USER AN ATTEN ANTS.............................7
B. WEIGHT LIMIT ..........................................................................7
C.CONTROLLER SETTINGS......................................................7
. SAFETY CHECK-LIST...............................................................7
E. CHANGES & A JUSTMENTS ................................................7
F. ACCESSORIES ............................................................................7
G.WHEN SEATE IN A PARKE WHEELCHAIR ................8
H.ENVIRONMENTAL CON ITIONS......................................8
I. TERRAIN......................................................................................8
J. STREET USE ................................................................................8
K.MOTOR VEHICLE SAFETY......................................................8
L. CENTER OF BALANCE...........................................................8
M. TRANSFERS ................................................................................9
N.REACHING OR LEANING .....................................................9
O. RESSING OR CHANGING CLOTHES.............................9
P. OBSTACLES.................................................................................9
Q. RIVING IN REVERSE .............................................................9
R. RAMPS, SLOPES & SI EHILLS................................................9
S. TO RE UCE THE RISK OF A FALL, TIP-OVER
OR LOSS OF CONTROL ....................................................10
T. RAMPS AT HOME & WORK ................................................10
U.WHEELCHAIR LIFTS..............................................................10
V. CURBS & SINGLE STEPS.......................................................10
W. STAIRS.......................................................................................10
X.ESCALATORS ...........................................................................10
VII. WARNINGS: COMPONENTS AN OPTIONS.................11
A.ARMRESTS.................................................................................11
B. BATTERIES.................................................................................11
C.CUSHIONS................................................................................11
.FASTENERS ...............................................................................11
E. FOOTPLATE, & FOOTRESTS ...............................................11
F. MOTOR LOCKS ......................................................................11
G.ON/OFF SWITCH...................................................................11
H.POSITIONING BELTS ............................................................11
I. SEATING SYSTEMS ...........................................................11-12
J. UPHOLSTERY FABRIC...........................................................12
K.SUSPENSION............................................................................12
L. WIRING .....................................................................................12
M.POWER SEATING (SC & MPC)...........................................12
N.S.P.O.T. POWER ACCESSORY ..............................................12
O.POWER RECLINE ...................................................................12
P. POWER LEGREST ACCESSORY AN USE.......................12
Q.TRANSIT OPTION AN USE.......................................13-15
VIII. SET-UP, A JUSTMENT AN USE..........................................16
A.A JUSTMENT NOTES...........................................................16
B. TOOLS YOU WILL NEE .....................................................16
C.BATTERY REMOVAL...............................................................16
. FOL ING BACKREST ...........................................................17
E. SWING-AWAY FOOTRESTS................................................17
F ELEVATING LEGREST ............................................................17
G.CENTER MOUNT HANGER A JUSTMENT ..................18
H. UAL-POST HEIGHT-A JUSTABLE ARMRESTS,
FIXE HEIGHT STAN AR ..............................................18
I. SINGLE POST HEIGHT-A JUSTABLE ARMRESTS.........19
J. SEAT EPTH A JUSTMENT................................................19
K.CAPTAIN’S SEAT...............................................................19-21
L. MANUAL RECLINE OPERATION.....................................21
M. ASAP II SEATING A JUSTMENTS ...................................21
N. SEAT REMOVAL......................................................................21
O. SEAT HEIGHT A JUSTMENTS ..........................................21
P. SEAT TO FLOOR HEIGHT/PRE-TILT POSITIONING...22
Q.SEAT PAN AN BACK SIZE A JUSTMENTS .................22
R. JOYSTICK...................................................................................22
S. POWER RECLINE, TILT AN LIFT OPERATION...........22
T. JOYSTICK RETRACTABLE MOUNT..................................23
U.SHROU REMOVAL ..............................................................23
V. CONTROLLER POSITION ...................................................23
W. CHECK-OUT..........................................................................24
IX. OPERATING GUI E...................................................................25
A.PERFORMANCE CONTROL SETTINGS..........................25
B. THERMAL ROLLBACK..........................................................25
C.JOYSTICK STATIONARY.......................................................25
. VR2 JOYSTICK ASSEMBLY ....................................................25
E. LE JOYSTICK .........................................................................26
F. COLOR LC SCREEN ...........................................................27
G.BRAKE LEVER .........................................................................28
X. BATTERIES.....................................................................................28
A.INTRO UCTION ..................................................................28
B. BATTERY CHARGER ............................................................28
C.CONNECTING BATTERIES IN BATTERY BOX.............29
. CHARGING BATTERIES .......................................................29
XI. MAINTENANCE...........................................................................30
A.NOTES ......................................................................................30
B. CLEANING ..............................................................................30
C. STORAGE TIPS .......................................................................30
. TO REPAIR OR REPLACE A TIRE.......................................30
E. MOTOR BRUSHES ..................................................................30
F. ISPOSING OF BATTERIES.................................................30
G.OR ERING PARTS ................................................................30
H.MAINTENANCE CHART......................................................30
I. WIRING IAGRAM ..............................................................31
XII. SUNRISE LIMITE WARRANTY.............................................31
ESPAÑOL .......................................................................................33
FRANÇAIS......................................................................................64

1
2
9
4
11
10
5
8
7
3
119832Rev. 4
QUICKIE PULSE
III. OUR CHAIR AND ITS PARTS
1. Flip-back, height adjustable armrest
2. VR2 controller joystick (RNET option)
3. Captain’s seat
4. Front Caster 7”
5. Rear stabilizing caster 6”
6. Single plate foot platform (shown)
Optional:
Swing-away 65° hangers
Swing-away ELR hangers
Swing-away 70° hangers
Swing-away 75° hangers (tapered)
Swing-away 90° hangers
7. rive wheels
8. Brake release
9. Caster fork (front)
10. Caster fork (rear)
11. Front shroud
Models
Pulse 6 BC, SC, and CC (shown)
Pulse 5 BC,CC
Pulse 6 MPC
III. OUR CHAIR AND ITS PARTS
QUICKIE PULSE
Weight (lbs)
Chair with Batteries
SC -260, BC -235, CC -250, MPC -350
Chair without Batteries
SC -182, BC -157, CC -172, MPC -272
rive Wheels
13" Mag: Std. airless insert
Joystick
Standard – VR2 (right-hand or
left-hand mount)
Option - VR2 w/actuator control
(SC only)
Option - RNET, LE , or Color
Batteries
(2 deep cycle batteries required to
operate chair)
Standard - Group 22
Battery Charger
Off board 8 AMP
Shroud Colors
Red, Black, Blue, Silver, Copper, Green
Apple, Yellow, Pearl Pink, Candy
Purple, Matte Black, Midnight Blue,
Pearl white, igital camo, Woodland
Camo, Carbon fiber print.
Seats, Upholstery and Style
Standard- BC & SC: A.S.A.P. II Seat Frame
CC: Captain’s Seat
Sizes: 12" - 22" wide, 12" - 22" deep
MPC: 14" - 22" wide, 16” -20” deep
Footrest:
CC: Center Mount SC & BC: Standard-
SA Swing away footrests w/heel loops
Option-Foot platform, Manual elevat-
ing legrests, Power Articulating
Legrest (ALR), Power Center Mount,
Center mount
Backrest
SC & BC: Standard Canes Angle Adjust
Option- 8° Bend, Semi Recline,
Folding
CC: standard- Captain’s Seat Back
MPC: Recline
Casters front
Standard- 7” solid
Casters rear
Standard- 6” solid
Armrest
SC & BC: Standard- 14" Cantilever, height
adjustable 14" arm pad
Option- Locking, two-point arm, ual
post Arm, Single Post arm
MPC: Reclining/Otto Bock
Suspension
Standard- all wheel
All features may not be available with some chair
setups or in conjunction with another chair feature.
Please consult your supplier for more information.
Your authorized supplier can also provide you with
more information on accessories.
6

119832 Rev.
5
QUICKIE PULSE
IV. NOTICE– READ BEFORE USE
A. CHOOSE THE RIGHT CHAIR & SAFETY
OPTIONS
Sunrise provides a choice of many power wheelchair styles, sizes and
adjustments to meet the needs of the user. However, final selection
of a wheelchair rests solely with you and your health care profes-
sional. Choosing the best chair for you depends on such things as:
1. Your size, disability, strength, balance and coordination.
2. Your intended use, and your level of activity.
3. The types of hazards you must overcome in daily use (in
areas where you are likely to use your chair).
4. The need for options for your safety and comfort (such as
positioning belts or special seat systems).
INTEN E USE: The Quickie PULSE is a battery operated device
with wheels that is intended for medical purposes to provide
mobility to persons restricted to a sitting position.
B. A JUST CHAIR TO YOUR ABILITY
You need to work with your doctor, nurse or therapist, and your
supplier, to fit this chair and adjust the controller settings for your
level of function and ability.
C. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you,
should read this entire Manual and make sure to follow all instruc-
tions. Review the warnings often, until they are second nature to you.
. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that
may cause severe injury or death to you or to other persons. The
“Warnings” are in four main sections, as follows:
1. V — EMI
Here you will learn about electromagnetic interference and
how it can affect your chair.
2. VI — GENERAL WARNINGS
Here you will find a safety checklist and a summary of risks
you need to be aware of before you ride this chair.
3. VII — WARNINGS — COMPONENTS & OPTIONS
Here you will learn about your chair. Consult your supplier
and your health care professional to help you choose the
best set-up and options for your safety.
4. X — BATTERIES
Here you will learn about battery and charger safety, and
how to avoid injury.
Throughout this owner’s manual and on the wheelchair you will
see the icons listed below to identify warnings and potential haz-
ards.
WARNING! These warnings must be followed, failure to
do so may cause personal injury or may dam-
age the wheelchair.
ES : Electrostatic ischarge can damage printed
circuit boards.
V. EMI (ELECTROMAGNETIC INTERFERENCE)
WARNING
Heed all warnings to reduce the risk of unintended brake release
or chair movement:
1. Beware of the danger from hand-held transceivers. Never
turn on or use a hand-held transceiver while power to your
chair is on. Use extra care if you believe that such a device
may be in use near your chair.
2. Be aware of nearby radio or TV stations, and avoid coming
close to them.
3. If unintended movement occurs, turn your chair off as soon
as it is safe to do so.
A. WHAT IS EMI?
WARNING
1. EMI means: electromagnetic (EM) interference (I). EMI comes
from radio wave sources such as radio transmitters and
transceivers. (A “transceiver” is a device that both sends and
receives radio wave signals).
2. There are a number of sources of intense EMI in your daily
environment. Some of these are obvious and easy to avoid.
Others are not, and you may not be able to avoid them.
3. Powered wheelchairs may be susceptible to electromagnetic
interference (EMI) emitted from sources such as radio sta-
tions, TV stations, amateur radio (HAM) transmitters, two
way radios, and cellular phones.
4. EMI can also be produced by conducted sources or electro-
static discharge (ES ).
B. WHAT EFFECT CAN EMI HAVE?
WARNING
1. EMI can cause your chair, without warning, to:
• Release its brakes
• Move by itself
• Move in unintended directions
If any of these occur, it could result in severe injury to you
or others.
2. EMI can damage the control system of your chair. This could
create a safety hazard, and lead to costly repairs.
C. SOURCES OF EMI
WARNING
The sources of EMI fall into three broad types:
1. Hand-Held Transceivers:
The antenna is usually mounted directly on the unit. These include:
• Citizens band (CB) radios
• “Walkie-talkies”
• Security, fire and police radios
• Mobile phones
• Lap-top computers with phone or fax
• Other personal communication devices
NOTE– These devices can transmit signals while they are on, even if not in
use.

2. Medium-Range Mobile Transceivers:
These include two-way radios used in police cars, fire trucks,
ambulances and taxi cabs. The antenna is usually mounted on the
outside of the vehicle.
3. Long-Range Transceivers:
These include commercial radio and TV broadcast antenna towers
and amateur (HAM) radios.
NOTE– The following are not likely to cause EMI problems: Lap-
top computers (without phone or fax), Cordless phones, TV sets
or AM/FM radios, C or tape players.
. ISTANCE FROM THE SOURCE
WARNING
Electro-magnetic energy rapidly becomes more intense as you get
closer to the source. For this reason, EMI from hand-held devices
is of special concern. (See C.1 above) A person using one of these
devices can bring high levels of EM energy very close to your chair
without you knowing it.
E. IMMUNITY LEVEL
WARNING
1. The level of EM is measured in volts per meter (V/m). Every
power wheelchair can resist EMI up to a certain level. This is
called its “immunity level”.
2. The higher the immunity level, the less the risk of EMI. It is
believed that a 20 V/m immunity level will protect the power
wheelchair user from the more common sources of radio
waves.
3. The configuration tested and found to be immune to at least
20 V/m is: Quickie Pulse power wheelchair with a right-hand
mounted RNET remote joystick system, 18" seat width, 18"
seat depth, dual post height adjustable armrests, fixed
tapered legrests with a two piece footplate, and Gp 22 gel
cell batteries.
4. All After Market input device options, classified as breath con-
trols, Proportional controls, and/or Switched controls that can
be used with this powerchair, have an unknown effect on their
immunity level to different types of EMI. They have not been
specifically tested with the Pulse 5/6 and RNET control system.
WARNING
Individuals with physical limitations requiring the use of a specialty
control input device known not to be immune to 20V/m, or not
known, should exercise extra care around known sources of EMI.
WARNING
There is no way to know the effect on EMI if you add accessories
or modify this chair. Any change to your chair may increase the risk
of EMI. Parts not specifically tested or parts from other suppliers
have unknown EMI properties.
F. REPORT ALL SUSPECTE EMI
INCI ENTS
WARNING
You should promptly report any unintended movement or brake
release. Be sure to indicate whether there was a radio wave source
near your chair at the time. Contact:
Sunrise Medical, Customer Service epartment at [phone].
G. EMI FROM CHAIR
WARNING
The chair itself can disturb the performance of electromagnetic
fields such as emitted by alarm systems of shops.
H. HEA ARRAY SAFETY AN RFI
WARNING
If you have a Head-array, the sensors used in the product have the
potential to operate unintentionally if moisture or any substance
that is electrically conductive is present in sufficient quantities.
Electro magnetic interference from electrical power lines and cer-
tain types of phones can cause the sensors to activate.
These sensors are capacitive in nature, and can generate an elec-
tronic field, which can be affected by liquids and/or a source of
radio frequency Interferance (RFI). Any material that is conductive
has the potential to activate the Head-array unintentionally.
Avoid use under high power lines and around cell phones.
Avoid the use of a Head Array in rain or snow and protect against
the potential of spilled liquids on the sensors.
Avoid cell phones and electronic devices in proximity to the array.
Avoid any source that has the potential of (RFI).
Warn the user of this chair that the chair controls have the poten-
tial of acting erractically or making sudden stops, if (RFI) is not
avoided.
If any (RFI) causes erratic behavior, immediately cut off the power
to the wheelchair, and wait until the interference passes.
V. EMI (ELECTROMAGNETIC INTERFERENCE)
QUICKIE PULSE
6
119832Rev.

4. Propel this chair by the push handles only. They provide
secure points for you to hold the rear of the chair to pre-
vent a fall or tip-over.
5. Check to make sure push handle grips will not rotate or slip off.
B. WEIGHT LIMIT
WARNING
1. The user plus items carried should never exceed the total
weight capacity identified on your chair.
2. Never use this chair for weight training.
3. Exceeding the weight limit is likely to damage the seat, frame,
or fasteners, and may cause severe injury to you or others
from chair failure.
4. Exceeding the weight limit will void the warranty.
C. CONTROLLER SETTINGS
WARNING
Be aware that you may need to adjust the controller settings of
your chair.
1. Check and adjust the settings every six to twelve months.
2. Consult your supplier to adjust the control settings immedi-
ately if you notice any change in your ability to:
• Control the joystick
• Hold your torso erect
• Avoid running into objects.
. SAFETY CHECK-LIST
WARNING
Before each use of this chair:
1. Make sure the chair operates smoothly. Check for noise,
vibration, or a change in ease of use. (They may indicate low
tire pressure, loose fasteners, or damage to your chair).
• If you detect a problem, make sure to repair or adjust the
chair right away, do not wait. Your supplier can help you
find and correct the problem.
2. Make sure batteries are charged. Green lights on charge indi-
cator will light up when charge is full. Yellow lights indicate
battery charge level is getting low. Red lights indicate batter-
ies are in immediate need of charging.
E. CHANGES & A JUSTMENTS
WARNING
Never use non-Quickie parts to replace Quickie provided parts or
make changes to your chair unless authorized by Sunrise. ( oing so
will void the warranty and may create a safety hazard.)
F. ACCESSORIES
WARNING
Accessories designed by manufacturers other than Sunrise, not avail-
able through Sunrise order process have not been tested or
approved for use by Sunrise.
1. If you modify or adjust this chair it may increase the risk of a
fall or tip-over.
2. Modifications unauthorized by Sunrise constitutes remanufac-
turing of the wheelchair. This voids the warranty. The user
then assumes all future liability for the wheelchair.
WARNING
Heed all warnings in this section. If you fail to do so, a fall, tip-over
or loss of control may occur and cause severe injury to you or
others.
A. NOTICE TO USER AN ATTEN ANTS
WARNING
User:
1. Before using this chair, you should be trained in its safe use
by your health care professional.
2. Every wheelchair is different. Take the time to learn the feel
of this chair before you begin riding.
3. Be aware that you must develop your own methods for the
safe use of this chair that are best suited to your level of
function and ability.
4. Have someone help you practice bending, reaching and trans-
fers until you learn how to do them safely.
5. Never try a new maneuver on your own unless you are sure
it is safe.
6. Get to know the areas where you plan to use your chair.
Look for hazards and learn how to avoid them.
7. Always wear a positioning strap.
8. o not use a wheelchair if the joystick does not spring back
to the neutral position.
9. o not use your wheelchair if the joystick boot is ripped or
damaged.
10. o not try to tip this wheelchair without an attendant present.
11. o not allow additional riders, the chair may become unstable.
User and Attendants:
1. When transferring the user in or out of the wheelchair
never use the footplate as a platform.
2. o not lift this wheelchair by any parts that are removable,
doing so may result in damage to the wheelchair or injury to
the user.
3. Never try to stop or slow this wheelchair with the wheel
locks (if applicable). Wheel locks are designed to prevent the
chair from moving when stopped. They are not brakes.
4. Always keep your hands and body parts clear of moving
parts to help prevent injuries.
Attendants:
WARNING
Make sure you heed all warnings and follow all instructions in each
section of this manual. Warnings that apply to the user also apply
to you.
1. o not stand or sit on any portion of this wheelchair.
2. You need to work with the user, and the user’s doctor, nurse
or therapist, to develop safe methods best suited to your
abilities and those of the user.
3. To manually push the chair you must release the motor brakes.
• o not engage or disengage motor brakes unless power to
the chair is off.
• Make sure you have full control over the chair when you
release the motor brakes. When you do so the chair will
not have brakes.
• Make sure the chair is on level ground before you release
the motor brakes.
VI. GENERAL WARNINGS
QUICKIE PULSE
7119832 Rev.

G. WHEN SEATE IN A PARKE
WHEELCHAIR
WARNING
1. Always turn off all power to your chair when you are
parked, even for a moment. This will prevent:
• Accidental movement from contact with the joystick by you
or others.
• Unintended brake release or movement from EMI sources.
(See Section V)
2. Make sure that persons who help you (for example, store
clerks) are aware of the joystick and do not touch it. If they
do, your chair may move suddenly when you do not expect
it.
H. ENVIRONMENTAL CON ITIONS
WARNING
Your chair is not designed for use in a heavy rain storm, or in
snowy or icy conditions.
1. Contact with water or excessive moisture can cause an elec-
trical malfunction. The frame, motors and other chair parts
are not water-tight and may rust or corrode from the inside.
To avoid a chair failure:
• Minimize exposure of your chair to rain or very
wet conditions.
•Never take your chair into a shower, tub, pool or sauna.
• o not use your chair in fresh or salt water (such as at the
edge of a stream, lake, or ocean).
• Make sure battery cover is secure.
• Replace joystick boot if it becomes torn or cracked.
• Make sure all electrical connections are secure.
• ry the chair as soon as you can if it gets wet, or if you use
water to clean it.
2. Proceed slowly and use extra care if you must operate your
chair on a wet or slick surface.
• Stop if one or both main wheels lose traction. If this
occurs, you may lose control of your chair or fall.
•Never operate your chair on a slope or ramp if there is
snow, ice, water or oil film present.
• When in doubt, have someone help you.
3. When not in use, keep your chair in a clean, dry place.
WARNING
Extra caution should be used when employing the disc switch or
the proximity head array as control devices. These two devices are
susceptible to malfunction when wet.
I. TERRAIN
WARNING
1. This chair will perform at it’s best on firm, even surfaces
such as concrete, asphalt and indoor flooring.
2. Although equipped with suspension, the performance can be
substantially reduced on uneven surfaces and rough terrain.
3. o not operate the chair on sand, loose gravel or soil. oing
so may damage wheels, bearings, axles, motors or loosen fas-
teners.
J. STREET USE
WARNING
1. This product is not intended for street use. Avoid streets
whenever possible.
2. Obey and follow all legal pedestrian pathways, and laws that
apply to pedestrians.
3. Be alert to the danger of motor vehicles in parking lots, or if
you must cross a road.
4. It may be hard for drivers to see you. Make eye contact with
drivers before you proceed. When in doubt, yield until you
are sure it is safe.
K. MOTOR VEHICLE SAFETY
WARNING
Identify whether or not your chair has been manufactured with the
Transit Option installed.
If your chair is not equipped with the Transit Option: The wheel-
chair does not meet federal standards for seating while travelling
in a motor vehicle.
1. NEVER let anyone sit in this chair while in a moving vehicle.
2. ALWAYS secure the rider with OEM motor vehicle
restraints. In an accident or sudden stop the rider may be
thrown from the chair. Wheelchair seat belts will not pre-
vent this, and further injury may result from the belts or
straps.
3. NEVER transport this chair in the front seat of a vehicle. It
may shift and interfere with the driver.
4. ALWAYS secure this chair so that it cannot roll or shift.
5. O NOT use any chair that has been involved in a motor
vehicle accident. It may have changed the structure of the
chair, and damaged, or broken components. This could lead
to a risk of injury or damage to your chair. If the wheelchair
has been involved in an accident, discontinue use and contact
your supplier for a thorough inspection.
If your chair is equipped with the Transit Option: See section VII-
Q: “Transit Option and use”.
L. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back, or to the side
depends on its center of balance and stability.
The Center Of Balance Is Affected By:
1. The seat height and seat angle.
2. A change in your body position, posture or weight distribu-
tion.
3. Using this chair on a ramp or slope.
4. The use of a back pack or other options, and the amount of
added weight.
5. Center or rear rive wheel positioning.
To Reduce The Risk Of A Fall Or Tip-Over:
1. Whenever a condition exists that may change the center of
balance, reduce speed, proceed cautiously.
2. When in doubt, always have someone help you.
VI. GENERAL WARNINGS
QUICKIE PULSE
8
119832Rev.

NOTE–To do this: Move your chair past the object you want to reach, then
back up alongside it. Backing up will rotate the casters forward.
3. Turn off all power to your chair. If you fail to do so, you may
touch the joystick and cause your chair to move when you
do not expect it.
O. RESSING OR CHANGING CLOTHES
WARNING
Be aware that your weight will shift if you dress or change clothes
while seated in this chair. To make the chair more stable, rotate the
front casters until they are forward.
P. OBSTACLES
WARNING
Riding over curbs or obstacles can cause tipping and serious bodily
harm. If you have any doubt that you can safely cross any curb or
obstacle, ALWAYS ASK FOR HELP. Be aware of your riding skills
and personal limitations. evelop new skills only with the help of
a companion.
1. Be aware that thresholds are very dangerous. (Even a small
change in height may stop a caster wheel and cause your
chair to tip). You may need to:
• Remove or cover threshold strips between rooms.
• Install a ramp at entry or exit doors.
2. Keep your eyes moving when you ride; scan the area well
ahead of your chair.
3. Make sure the floor areas where you use this chair are level
and free of obstacles.
Q. RIVING IN REVERSE
WARNING
Use extra care when you drive your chair in reverse. You may lose
control or fall if one of the rear wheels hits an object.
1. Operate your chair slowly and at an even speed.
2. Stop often and check to make sure your path is clear of
obstacles.
R. RAMPS, SLOPES & SI EHILLS
WARNING
Your center of balance changes when you are on a slope.
NOTE– “Slope” includes a ramp or sidehill. Your chair is less stable
when it is at an angle. Never use this chair on a slope
unless your are sure it is safe. When in doubt, have some-
one help you.
Beware Of:
1. Steep slopes. o Not use this chair on a slope steeper than
10%. (A 10% slope means: One foot in elevation for every
ten feet of slope length).
2. Wet or slippery surfaces (such as when ice, snow, water or
oil film is present). A loss of traction may cause a fall or tip-
over.
3. A change in grade on a slope (or a lip, bump or depression).
These may cause a fall or tip-over.
4. A drop-off at the bottom of a slope. (A drop-off of as small
as 3/4 inch (19 mm) can stop a front caster and cause the
chair to tip forward).
M. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires good balance
and agility. Be aware that there is a point during every transfer
when the wheelchair seat is not below you. To prevent a fall:
1. Always turn off power before you transfer to or from your
chair. If you fail to do so you may touch the joystick and
cause your chair to move when you do not expect it.
2. Make sure motor brakes are engaged. This keeps the chair
from moving when you transfer.
3. Work with your health care professional to learn all safe
methods for transfers.
• Learn how to position your body and how to support
yourself during a transfer.
• Have someone help you until you are sure you can do a
safe transfer on your own.
4. Move your chair as close as you can to the seat you are
transferring to. If possible, use a transfer board.
5. Rotate the front casters until they are as far forward as possi-
ble.
6. Be careful of the footrests. If you can, remove or swing them
out of the way.
• Never stand on footrests when you transfer. oing so may
damage them or cause your chair to tip.
• Make sure your feet do not “hang up” or get caught in the
space between the footrests.
7. Make sure armrests do not interfere.
8. Transfer as far back onto the seat surface as you can. This
will reduce the risk that you will miss the seat or fall.
N. REACHING OR LEANING
WARNING
Reaching or leaning affects the center of balance of your chair. If
done improperly, a fall or tip-over is likely. When in doubt, ask for
help or use a device to extend your reach.
To Reduce the Risk of injury and/or amage to the Chair:
1. Never reach or lean if you must shift your weight sideways or
rise up off the seat.
2. Never reach or lean if you must move forward in your seat
to do so. Always keep your buttocks in contact with the
backrest.
3. Never reach with both hands (you may not be able to catch
yourself to prevent a fall if you lose your balance).
4. Never try to pick up an object from the floor by reaching down
between your knees.
5. Never put pressure on the footrests while reaching.
6. Never reach or lean over the top of the seat back. This may
damage the backrest and cause you to fall.
WARNING
IF YOU MUST REACH OR LEAN, O SO AT YOUR OWN RISK.
Remember to:
1. Move your chair as close as you can to the object you wish
to reach.
2. Rotate the front casters until they are as far forward as pos-
sible. This makes the chair more stable.
VI. GENERAL WARNINGS
QUICKIE PULSE
9119832 Rev.

S. TO RE UCE THE RISK OF A FALL, TIP-OVER
OR LOSS OF CONTROL
WARNING
1. Never use your chair on a slope unless you are sure you can
do so without losing traction.
2. Always go as straight up and as straight down as you can.
•o not “cut the corner” on a slope or ramp.
•o not turn or change direction on a slope.
3. Always stay in the center of the ramp. The ramp needs to be
wide enough so that the wheel won’t roll off of the side of
the ramp.
4. Keep your chair moving at a slow, steady speed. Keep con-
trol over the chair at all times.
• On a descent, do not let your chair accelerate beyond its
normal speed.
• If the chair picks up speed, center the joystick to slow
down or stop.
T. RAMPS AT HOME & WORK
WARNING
Before driving on a ramp, survey the condition of the ramp. On
slippery ramps traction may be reduced causing your wheelchair to
slide.
WARNING
NOTE– Make sure ramps meet all Building Codes for your area.
1. For your safety, have a licensed contractor build or remodel
ramp to meet all local codes and standards.
2. The proper design will vary, depending on such things as: the
length and height of the ramp; the need for an intermediate
platform; landing size; doors, and the direction of swing, and;
whether the ramp includes a turn or angle.
At A Minimum:
1. Open sides of ramp must have side rails to prevent your
chair from going over the edge.
2. Slope must not be steeper than one inch in height for every
one foot of slope length (approximately 10º).
3. Ramp surface must be even, and have a non-skid surface.
4. You may need to add a section at the top or bottom to
avoid a lip or drop-off.
5. Ramp must be sturdy. Add bracing if needed, so ramp does
not “bow” when you ride on it.
U. WHEELCHAIR LIFTS
WARNING
Wheelchair lifts are used in vans, buses, and buildings to help you
move from one level to another.
1. Always turn off all power to your chair when you are on a
lift. If you fail to do so, you may touch the joystick by acci-
dent and cause your chair to drive off the platform. (Be
aware that a “roll-stop” at the end of the platform may not
prevent this).
2. Make sure there is not a lip or drop-off at the top or bot-
tom of the platform. These may cause a fall or tip-over. When
in doubt, have someone help you.
3. Always position the user securely in the chair to help prevent
falls while on a lift.
4. Avoid moving forward if a wheel is “hung up” on the lip of
the ramp. Backup, reposition the caster for a more direct
approach. And slowly try again.
V. CURBS & SINGLE STEPS
WARNING
1. Sunrise recommends that you avoid climbing and/or descending
a curb, single step, or other obstacle, and that a ramp or curb
cutout is always used.
2. If you must climb or descend a curb, single step, or other
obstacle that is greater than 2.5", it is recommended to have
a person assist you in doing so.
3. O NOT try to climb a curb, single step, or other obstacle
greater than 4" high.
4. If you must climb or descend a curb or step alone do so at your
own risk using extreme care and follow the following procedure:
• Proceed slowly, at a steady speed
• Go as straight up or down as you can over the obstacle.
Never turn when trying to climb or descend and obstacle,
doing so may result in a fall or tip-over.
5. Failure to follow the above recommendations may cause:
• A Fall or Tip Over
• amage to the frame, wheels, axles or other parts, or
loose fasteners.
W. STAIRS
WARNING
Never use this chair to go up or down stairs, even with an atten-
dant. oing so is likely to cause a fall or tip-over.
X. ESCALATORS
WARNING
Never take this chair on an escalator, even with an attendant.
oing so is likely to cause a fall or tip-over.
VI. GENERAL WARNINGS
QUICKIE PULSE
10
119832Rev.

4. Never lift this chair by the footrests. Footrests detach and
will not bear the weight of this chair. Lift this chair only by
non-detachable parts of the main frame.
F. MOTOR LOCKS
WARNING
1. o not engage or disengage motor brakes unless power to
the chair is off.
2. Be aware that the chair will not have brakes when motor
brakes are in the free-wheel position.
3. Make sure that the person pushing the chair has full control
when motor brakes are disengaged.
4. Make sure that the chair is on level ground when motor
brakes are disengaged.
G. ON/OFF SWITCH
WARNING
1. Never use the ON/OFF switch to stop the chair except in
an emergency. This will result in an abrupt stop, and may
cause you to fall.
2. To slow your chair to a stop, return the joystick to neutral.
H. POSITIONING BELTS (OPTIONAL)
WARNING
Use a positioning belt only to help support your posture. Improper
use of such belts may cause severe injury or death.
1. Make sure you are not at risk to slide down in the wheelchair
seat. If this occurs, you may suffer chest compression or suf-
focate due to pressure from the belt.
2. A pelvic wedge or a similar device can help keep you from
sliding down in the seat. Consult your health care profession-
al to find out if you need such a device.
3. The belt must be snug, but must not be so tight that it inter-
feres with breathing. You should be able to slide your open
hand, flat, between the belt and your stomach.
4. Make sure you can easily remove the belt in an emergency.
WARNING
Never use a positioning belt:
• In place of a motor vehicle seat belt. In an accident or sud-
den stop you may be thrown from the chair. A positioning
belt will not prevent this, and further injury may result from
the belt.
• As a restraint. A restraint requires a doctor’s order.
• On a user who is comatose or agitated.
I. SEATING SYSTEMS
WARNING
1. Use of a seating system not approved by Sunrise may alter
the center of balance of this chair. This may cause a fall or
tip-over.
2. Never change the seating system of your chair unless you
consult your supplier first.
3. Never raise your seating system to a height of more than
22" (measuring from the front of the seat pan to the floor)
with all actuators in their home position.
WARNING
If you use parts or make changes not authorized by Sunrise it may
create a safety hazard and will void the Warranty.
A. ARMRESTS
WARNING
1. Armrests will not bear the weight of this chair.
2. Never lift this chair by its armrests. They may come loose or
break.
B. BATTERIES
WARNING
1. Always wear rubber gloves and safety glasses when you han-
dle batteries.
2. Never smoke or hold an open flame near batteries. They are
a known explosion hazard.
3. Only deep cycle sealed case construction batteries should be
used in this device.
4. Read all of section X. Batteries before attempting to change,
or charge batteries.
C. CUSHIONS
WARNING
1. Standard foam cushions and other body supports are not
designed for the relief of pressure.
2. If you suffer from pressure sores, or if you are at risk that
they will occur, you may need a special seat system or a
device to control your posture.
• Consult your doctor, nurse or therapist to find out if you
need such a device for your well-being.
. FASTENERS
WARNING
Many of the screws, bolts and nuts on this chair are special high-
strength fasteners. Use of improper fasteners may cause your chair
to fail.
1. Only use fasteners provided by Sunrise.
2. If fasteners become loose, tighten them immediately.
3. Over- or under-tightened fasteners can cause damage to
your chair or it’s components.
E. FOOTPLATE & FOOTRESTS
WARNING
1. At the lowest point, footrests should be at least 2 1/2 inches
(65 mm) off the ground. If set too LOW, they may “hang up”
on obstacles you can expect to find in normal use. This may
cause the chair to stop suddenly and tip forward.
2. To avoid a trip or fall when you transfer:
• Make sure your feet do not “hang up” or get caught in the
space between the footrests.
• Avoid putting weight on the footrests, as the chair may tip
forward.
• Remove or swing the footrests out of the way, if possible.
3. The footrest should always be in the down position when
operating the chair.
VII. WARNINGS: COMPONENTS AND OPTIONS
QUICKIE PULSE
11 119832 Rev.

J. UPHOLSTERY FABRIC
WARNING
1. Replace worn or torn fabric of seat sling and seat back as
soon as you can. If you fail to do so, the seat may fail and
cause you to fall. Worn fabrics may increase the potential for
a fire hazard.
2. Sling fabric will deteriorate with age and use. Look for fray-
ing, thin spots, or stretching of fabric at rivet holes. Replace
fabric as required.
3. Be aware that washing may reduce flame retardation qualities
of the fabric.
K. SUSPENSION
WARNING
The suspension system does contain ry Natural Rubber. The sus-
pension, or any other component on the chair, does not contain
any latex based product. The suspension components are enclosed
and inaccessible to the user.
L. WIRING
WARNING
Never pull on cables directly. This can result in wires breaking
inside the connector or harness. To remove a plug or connector,
always grasp the plug or connector itself. (See section XI (H)for
wiring diagram).
M. POWER SEATING (SC,MPC)
WARNING
1. Operation
• While driving this wheelchair in the reclined, elevated, or
tilted position use caution.
• o Not attempt to operate any power seating option
while positioned on an incline.
• o Not attempt to operate any power seating option
while this wheelchair is in motion.
• o not attempt to operate the lift or tilt power seating
options around children.
• Through programming it is possible to reverse the direction
of all powered seating functions, ensure you know which
direction your seat is going to move before operating.
2. Reduced Speed riving (Creep)
This power chair is designed to automatically reduce the
maximum driving speed to a creep mode when certain
power seating limits are reached.
3. Pinch points
Pinch points may occur when operating the powered seating
options on this chair. Ensure all hands and body parts are
clear of all power seating components that may result in
pinch points before operating them.
4. Tilting Power Base with Push Handles
o not attempt to tilt power wheelchairs by pulling down on
the push handles. Power wheelchairs have heavy bases. As such,
attempting to tilt a power wheelchair to traverse obstacles can
damage components in the seating system and/or modular
actuators.
5. Remain Clear uring Power Accessory Operation
Please stay clear of any powered actuator while the compo-
nent is in motion. Sunrise power mechanisms move over
large ranges of travel. Users should be aware of their sur-
roundings while components are in motion.
6. Maximum User Weight
o not exceed the weight capacity for your specific
chair/seating system configuration. oing so could result in
premature failure or injury.
7. Latch Mode
While operating any power seating function in latched mode
use caution. In latch mode, powered seating will not stop until
a reverse command is performed or the end of travel is met.
N. S.P.O.T. (Single Power Option Tilt)
POWER ACCESSORY (SC only)
WARNING
The powered S.P.O.T. accessory for this chair has a maximum user
weight capacity of up to 300 lbs. Never exceed this capacity while
operating the powered actuator.
WARNING
The powered S.P.O.T. should not be operated for more than three
minutes of continuous use. oing so may shorten the life of the
powered S.P.O.T.
O. POWER RECLINE
WARNING
Pinch Point
Avoid putting hands or fingers near the power recline mechanism
while in operation.
Weight Capacity
The maximum user weight capacity for the power recline is 250lbs
if the seat depth is less than 17 inches, and up to 300 lbs for any
seat depth over 17 inches. Exceeding this weight capacity could
lead to injury and/or permanent damage to the equipment.
P. POWER LEGREST ACCESSORY AN USE
The power legrest accessory has a maximum user weight capaci-
ty of up to 300 lbs depending on your chair configuration. Never
exceed this capacity while operating the powered actuator.
VII. WARNINGS: COMPONENTS AND OPTIONS
QUICKIE PULSE
12
119832Rev.

Q. TRANSIT OPTION AN USE
Refer also to sections VI-K: “Motor Vehicle Safety” for additional
transit option and motor vehicle warnings.
WARNING
Contact Sunrise Medical customer service (800-333-4000) with
any questions about using this power wheelchair for seating in a
motor vehicle, or if your chair is a candidate for the transit option.
Whenever possible, wheelchair occupants should transfer into the
vehicle seat and use the OEM (Original Equipment Manufacturer)
vehicle-installed restraint system.
This wheelchair has been dynamically tested in a forward-facing
mode with a specified crash test dummy restrained by both pelvic
and upper-torso belt(s) (shoulder belts). It has been determined
that both the pelvic and upper-torso belt(s) should be used to
reduce the possibility of head and chest impacts with vehicle com-
ponents. When travelling in a motor vehicle, use only Wheelchair
Tie-down and Occupant Restraint Systems (WTORS) which meet
the requirements of the SAE (Society of Automotive Engineers)
J2249 Recommended Practice.
This wheelchair has been tested for seating in a motor vehicle with
the factory-installed seating system only. This wheelchair must be
in a forward facing position during travel in a motor vehicle.
This wheelchair is equipped with wheelchair-anchored pelvic belts.
It has been dynamically tested to rely on wheelchair-anchored
pelvic belts. If desired, vehicle-anchored pelvic belts may also be
used. It is strongly recommended that the combination of both
pelvic and upper-torso belt(s) be used to reduce the risk of injury
if a sudden stop and/or collision were to occur.
To reduce the potential of injury to vehicle occupants, wheelchair-
mounted accessories, including but not limited to IV poles, trays,
respiratory equipment, backpacks, and other personal items should
be removed from the wheelchair and secured separately. Postural
supports, positioning devices, and/or strap(s) should not be relied
on for occupant restraint. These items may be used in addition to
the wheelchair anchored, or vehicle-anchored belts.
Wheelchairs with adjustable seat angles must be set to 10°. o
not alter or substitute wheelchair frame parts, components, or
seating systems.
A sudden stop and/or collision may structurally damage your
wheelchair. Wheelchairs involved in such incidents should be
replaced.
Spill proof batteries, such as “gel cells”, should be installed on
wheelchairs that will experience travel in a motor vehicle.
WARNING
NOTE– Only use the transit brackets included with the Quickie
Pulse for the purposes described in this manual.
ABOUT TRANSPORT REA Y PACKAGES
The Quickie Pulse Transit System includes four factory-installed
transport brackets and an optional wheelchair anchored pelvic
belt. The Quickie Pulse 6 has been crash-tested in accordance
with ANSI-Resna WC Vol 1 Section 19 Frontal Impact Test require-
ments for wheelchairs with a 170 lb crash dummy. As of this date,
the epartment of Transportation has not approved any tie-down
systems for transportation of a user while in a wheelchair, in a
moving vehicle of any type. It is Sunrise Medical’s position that
users of wheelchairs should be transferred into the vehicle seating
when transport is necessary and that the restraints made available
by the auto industry be used.
VII. WARNINGS: COMPONENTS AND OPTIONS
QUICKIE PULSE
13 119832 Rev.
Sunrise Medical does not recommend any wheelchair transporta-
tion systems
COMPLIANCE INFORMATION
This wheelchair conforms to the requirements of the ANSI-Resna
WC Vol 1 Section 19.
NOTE– ANSI stands for: American National Standards Institute.
Resna: Rehabilitation Engineering and Assistive Technology
Society of North America.
This wheelchair has been dynamically tested in a forward-facing
mode with a specified crash test dummy, restrained by both pelvic
and upper-torso belts in accordance with ANSI-Resna WC Vol 1
Section 19. Both pelvic and upper-torso belts should be used to
reduce the possibility of head and chest impacts with vehicle com-
ponents in the event of a sudden stop and/or collision.
SECURING THE WHEELCHAIR TO THE VEHICLE
(See Figures 1 & 2 below)
WARNING
This wheelchair must be in a forward facing position during travel
in a motor vehicle. The recommended clear zones for wheelchair
seated occupants restrained by both pelvic and upper-torso belt(s)
and only by a pelvic belt are shown in the diagrams and described
below. Frontal Clear Zones (FCZ) need to be larger when upper
torso belt(s) are not used.
The Rear Clear Zone of 16in is measured from the rearmost point
on an occupant’s head.
The Frontal Clear zone is measured from the front most point of
an occupant’s head and is 26-inches with pelvic and upper-torso
belt(s) and 37 inches with only a pelvic belt. The frontal clear zone
may not be achievable for wheelchair- seated drivers.
The estimated seated height (HHT) from the ground or floor to
the top of the wheelchair-seated occupant’s head ranges from
approximately 47 inches for a small adult female to about 61inches
for a tall adult male.
HHT
1
2

119832Rev. 14
QUICKIE PULSE
SECUREMENT POINTS
Rear securement points(A), front securement points(B), Pelvic Belt
Securement point(C)
SECURING THE WHEELCHAIR
This wheelchair is to be used only with Wheelchair Tie-down and
Occupant Restraint Systems (WTORS) that have been installed in
accordance with the manufacturer’s instructions and SAE J2249.
NOTE–A copy of SAE J2249 Wheelchair Tie-down and Occupant
Restraint Systems (WTORS) for use in Motor Vehicles can
be obtained from:
SAE International
400 Commonwealth rive.
Warrendale, PA. 15096-0001
[phone] or [phone]
Attach WTORS to the tie-down brackets in accordance with the
manufacturer’s instructions and SAE j2249.
SECURING THE OCCUPANT:
WHEELCHAIR-ANCHORE BELTS
WARNING
Only use a pelvic belt system that meets the requirements of
ANSI-Resna WC Vol 1 Section 19 and SAE J2249, and has been
specified to work in conjunction with the Quickie Pulse 6 transit
system.
1. Installation
a. Install the pelvic belt ( ) onto the pelvic belt securement
point anchored to the seating frame of the Quickie Pulse 5
or 6. Using a 10mm Hex key, torque the screw to 144in-lbs
securing the pelvic belt to the mounting anchor (C).
b. Repeat step 1 for the opposite side.
c. Upper torso attachment point(E) shown.
VEHICLE-ANCHORE BELTS
This wheelchair has an overall rating of “A” with regard to accom-
modating the use and fit of vehicle-anchored belts. This rating is
scored as follows: A = Excellent, B = Good, C = Fair, = poor.
The test for Lateral Stability isplacement for Point (P) is shown in
the figure at right. The average test result for point (P) is:
• Quickie Pulse 6 - 0.547inches (13.9mm)
• Quickie Pulse 5 - 0.547inches (13.9mm)
NOTE–Figure 5 shows the rear view of the wheelchair and human
surrogate secured on test platform and tilted to 45°.
34
45
VII. WARNINGS: COMPONENTS AND OPTIONS
3
4
5
A
B
C
C
E

119832 Rev.
15
QUICKIE PULSE
SEATING SYSTEM
WARNING
This wheelchair has been tested for seating in a motor vehicle with the
factory installed seating system only. Ensure that the factory installed
seating system is secured to the wheelchair frame before operation. Refer
to the seating system owner’s manual for further information.
CAPTAIN’S SEAT OPTION
LOCKING PIN ACTIVATION
WARNING
Captains seat must be used in conjunction with WC-19 Tie-down brackets
1. Configuration for standard use ( riving the Chair)
• Locking Pin Lever (A) should be disengaged. (Figure 6)
• Backrest can be reclined or folded as needed.
2. Transit Configuration (Captains seat used in a vehicle)
• Locking Pin Lever (B) should be engaged. (Figure 7)
• Backrest is now in locked position (99°)
MAKE SURE TO ENGAGE LOCKING PIN FOR TRANSIT USE.
POSITIONING BELTS
WARNING
The angle of the pelvic belt should be within the preferred zone of 45 to
75 degrees to the horizontal or within the optional zone of 30 to 45
degrees to the horizontal.
Steeper side-view pelvic belt angles are especially important if the pelvic
belt is intended to be used for postural support in addition to occupant
restraint in a frontal crash. Steeper angles will reduce the tendency for a
vertical gap to develop between the user and the belt due to compliance
of seat cushions and belt movement, thereby reducing the tendency for
the user to slip under the belt and for the belt to ride up on the soft
abdomen during normal use. Steeper belt angles also reduce the tendency
for upper-torso belts to pull the pelvic belt onto the abdomen during
frontal impact loading.
NOTE– For this procedure, refer to figure 9.
a. The pelvic belt should be worn low across the front
of the pelvis.
b. Position the upper torso belts over the shoulders.
c. The belt(s) should not be held away from the body
by the wheelchair components or parts, including
but not limited to the armrests or wheels.
d. Ensure the belt(s) are not twisted.
e. Adjust belts as firmly as possible being mindful of
user comfort.
67
89
VII. WARNINGS: COMPONENTS AND OPTIONS
6
7
8
9
A
B

119832Rev. 16
QUICKIE PULSE
VIII. SET-UP, ADJUSTMENT AND USE
C. BATTERY REMOVAL
1. To remove the batteries before transporting or servicing:
a. Carefully remove seat (see Section O Seat removal)
b. Remove the shroud by first removing the six fasteners
(Figure 10), then lift up and remove the shroud.
c. Unplug the main power connect (A) (figure 11)
d. Lift the batteries out of the frame using the battery strap as
a lifting handle.
2. Battery installation
• See section X. (Batteries) for installation
WARNING
Batteries may weigh up to 39 lbs. Care must be taken to avoid
injury when lifting up on battery straps.
1110
A. A JUSTMENT NOTES
1. Work Surface For Set-Up:
Use a flat surface, such as a table, to assemble, adjust and check your
chair. This makes the steps easier and helps ensure a correct set-up.
2. Fasteners:
• Many of the screws and bolts on this chair are special high-
strength fasteners and may have special coatings.
• Many nuts are of the Nylock type. They have a plastic insert
to help prevent loosening.
• Only use screws, bolts and nuts provided by Sunrise.
WARNING
1. Use of improper fasteners may cause the chair to fail.
2. Over- or under-tightened fasteners may fail or cause damage
to chair parts.
3. If bolts or screws become loose, tighten them as soon as
you can. Loose bolts or screws can cause damage to other
chair parts causing them to fail.
4. Washers & Spacers:
• Note the position of washers and spacers before disassem-
bly.
• To avoid damage to the frame, replace all washers and spac-
ers when you reassemble parts.
5. Torque Settings:
• A torque setting is the optimal tightening for a particular fas-
tener. Use a torque wrench that measures inch-pounds to
secure screws, nuts and bolts on this chair.
NOTE– Unless otherwise noted, use a torque setting of 120 in-lbs
for all fasteners.
B. TOOLS YOU MIGHT NEE
1. Basic Tool Kit:
To set-up, adjust and maintain your chair you may need the
following tools:
• Combined Phillips and flat screw driver
• Standard metric wrenches from 10mm - 19mm
• Metric Hex wrenches from 5mm - 8mm
• Metric socket set 10mm - 19mm
• Imperial Allen wrenches from 5/64" to 1/4"
• Wire cutters, and Needle nose plyers
• Torque wrench that can measure up to 120in-lbs
You can obtain a multi-purpose tool kit from Sunrise, or buy the
tools you need from a hardware store.
A
10
11

119832 Rev.
17
QUICKIE PULSE VIII. SET-UP, ADJUSTMENT, AND USE
. FOL ING BACKREST
Quickie Pulse wheelchairs are shipped with backrest in folded position. (optional)
1. Upright Positioning
a. Lift backrest to upright position so that latch handles (A) lock into place.
b. Backrest is ready for use.
2. Folding Backrest
a. Lift and turn backrest latch handles (A) inward
or outward.
b. Fold backrest forward.
WARNING
Backrest latches must be locked into place before operating wheelchair.
E. SWING-AWAY FOOTRESTS
1. Installation
a. Place swing-away pivot pin (B) into the locating hole (C) on top of the hanger mount
with the footrest facing outward from frame.
b. Rotate the footrest inward until latch plate locks ( ) into place on locking bolt.
2. Removal
a. To remove footrest, press quick-release lever (E).
b. Rotate footrest outward and lift.
3. Height Adjustment
a. Remove both bolts (F) in the hanger frame tube.
b. Reposition footrest height.
c. Re-tighten all bolts (F).
F. ELEVATING LEGREST (Optional)
1. Installation
To install or remove Elevating Legrest (ELR) see instructions for Swing-away Footrest installa-
tion.
2. Adjustment
a. To raise legrest, lift to desired position. Legrest will automatically lock in place.
b. To lower legrest, while seated in chair, first lift slightly then press release lever (G)
down and lower legrest to desired position.
12
1413
15
12
13
14
15
A
B
C
E
F
G

119832Rev. 18
QUICKIE PULSE VIII. SET-UP, ADJUSTMENT, AND USE
G. CENTER MOUNT HANGER A JUSTMENT
(ASAP Seating only)
1. Removal
a. Remove the four screws (A) and slide the footrest out.
2. Height Adjustment
a. Remove the six securing screws (B).
b. Move footplate to desired height.
c. Re-install screws (B) through desired holes.
3. Calf pad Adjustment
a. Remove the two securing screws (C).
b. Move Calf Pads to desired height.
c. Re-install screws (C) through adjusted holes.
H. UAL-POST HEIGHT-A JUSTABLE ARMRESTS (Option),
FIXE HEIGHT STAN AR
The dual-post flip-back armrest can be used as either a flip-back armrest or a removable
armrest.
1. Installing Armrest
a. Insert front and rear posts into armrest receivers.
b. Engage levers ( and E) to secure armrest.
2. Set-up for Flip-back Operation
a. isengage lever ( ) so front post is able to come free.
b. Armrest now has the ability to be flipped back without removal.
3. Set-up for Removal
a. isengage levers ( and E) so front and rear posts are able to come free.
b. Armrest can now be easily removed for transferring.
4. Height-Adjustment (option)
a. Release the upper securing lever (F).
b. Set at desired height
c. Return securing lever to locked position.
d. Move armrest up or down to allow armrest to snap into place
181716
16
17
18
19
16
17
18
19
A
B
C
E
F

119832 Rev.
19
QUICKIE PULSE VIII. SET-UP, ADJUSTMENT, AND USE
I. SINGLE POST HEIGHT-A JUSTABLE ARMRESTS (optional)
1. Installation
a. Slide the outer armpost into the receiver mounted to the wheel chair frame.
b. The armrest will automatically lock into place.
2. Height Adjustment
a. Rotate release lever to stop.
b. Slide armrest pad up or down to desired height.
c. Return lever to locked position.
d. Push arm pad until upper armpost locks firmly into place.
3. Removing Armrest
a. Rotate release lever and remove the armrest.
4. Replacing Armrest
a. Slide armrest back into receiver.
b. Return release lever to locked position against armpost.
5. Adjusting Armrest Receiver Fit (tighten or loosen fit)
To tighten or loosen the fit of the outer armpost in the receiver:
a. Loosen the four bolts on the sides of the receiver.
b. With the armrest in the receiver, squeeze the receiver to achieve the desired fit.
c. Tighten the four bolts.
6. Adjusting Inner Armpost Fit
a. Two set screws are installed in the outer armpost.
b. Turn the set screws in or out until the desired fit is achieved.
J. SEAT EPTH A JUSTMENT 14" - 16", 20" - 22" only
The seat depth can be adjusted in one inch increments on standard rehab seating.
1. Seat Frame epth Adjustment
a. To adjust, remove the two bolts (A & B) from each side of the backrest pivot plate.
b. Reposition the backrest to the desired position.
c. Replace and retighten bolts on each side of the backrest pivot plate.
2. Back Angle Adjustment on Seat Frame
a. Remove the front securing bolt (A) on the side of the backrest hinge plate.
b. Loosen the lower rear bolt (B)
c. Set at desired angle. There are five holes (in 4º increments) to choose from.
d. Reinstall the front bolt and tighten both bolts securely.
K. CAPTAINS SEAT
The Captains seat back can be manually reclined, folded, or angle adjusted.
1. Adjusting the recline angle
a. To adjust, pull up on the release lever(C) located on the right side of the backrest.
b. Reposition the backrest forward or backward to the desired position.
c. Release the lever (C) and wiggle the backrest to make sure it locks in place.
2. Folding the Back (unoccupied)
a. To fold, Pull up on the release lever(C) located on the right side of the backrest.
b. The backrest should spring forward into the folded position as shown.
c. Release the lever.
d. To unfold the back, pull up on the release lever (C) and adjust the back to an upright
position.
20
21
2322
9
2
6
71
4
3
5
8
Height-Adjustable Armrest Key
1. Inner Arm Post
2. Receiver
3. Release Lever, Locked Position
4. Armrest Pad
5. Transfer Bar
6. Side Panel
7. Tension Adjustment Set Screw
8. Outer Arm Post
9. Receiver Adjustment Bolts
20
21
22
23
A
B
C
C

119832Rev. 20
QUICKIE PULSE VIII. SET-UP, ADJUSTMENT, AND USE
3. Seat depth adjustments with 1” increments
a. Using a 5mm Hex Key, remove the M8 Flat head screws(A), (3 on each side)
b. Using a 5mm Hex Key, remove the M8 Flat head screws (B), (1 on each side)
c. Using a 5mm Hex Key, loosen the M8 Flat head screws (C), (1 on each side)
d. While holding the backrest on each side, slide it front or back to achieve the desired
position.
NOTE– Changing the seat depth can effect the balance of your chair. Test the chair carefully
before regular use if a seat depth adjustment has been made.
4. Seat depth mounting positions
a. Using the Seat depth mounting positions table, and the hole number callouts, reference
the correct hole positions to achiever the desired width and depth.
5. Back height adjustments with 1” increments
NOTE– There are 3 positions of adjustment in 1” increments for the back. Position 2 (+2)
( ), Position 1 (+1) (E), and position 0 (default) (F).
a. Using a 5mm Hex key, remove the M8 flat head screws (3) on each side.
b. Position the backrest at the desired height. The top screw should be mounted as
shown (figure 26).
c. Holding the backrest in place, tighten the screws.
d. Repeat the steps on the other side, and ensure that the left and right sides are posi-
tioned at the same height.
6. Armrest width adjustment
NOTE– You can change the armrest widths independantly, remember that this adjustment
will increase the overall width of the wheelchair.
a. Locate the 2 armrest fasteners (G) on each side of the armrest receiver bracket.
b. Loosen the fasteners.
c. Slide the armrests in or out to the desired width.
d. Re-tighten the fasteners.
7. Armrest height adjustment
a. Using a 4mm Hex key, loosen the two M5 set screws(H) located on the armrest
receiver.
b. Raise or lower the armrest to the desired height.
c. Tighten the set screws to secure the armrest.
24 25
26
27
28
24
1
2
4
3
5
6
8
7
9
5
6
8
7
9
1
2
4
3
25
26
27
28
H
G
E
F
C
A
B
