Quickie 2 User manual

Quickie® 2,2HD
with transit option without transit option
Supplier:
Rider:
This manual must be given to the rider of this wheelchair.
Before using this wheelchair read this entire manual and
save it for future reference.
QUICKIE 2, 2HD
Manual del Propietario
Pasajero:
ruedas.
Antes de usar esta silla de ruedas, lea este manual en su
totalidad y guárdelo para futura referencia.
Manuel du Propriétaire
ment ce manuel et conservez le pour le
consulter ultérieurement.
Chaque fauteuil est livré avec un manuel d’instructions en anglais. Les versions en espagnol
et en francais sont à ançais est à votre disposition en format PDF sur le site:
www.SunriseMedical.com. Veuillez vous rendre à la page de votre produit pour télécharger
le manuel dans la langue souhaitée, ou contactez un fournisseur agréé Sunrise Medical.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español o
francés está disponible en formato PDF en nuestra página en Internet: www.SunriseMedical.com.
Ingrese a la página del producto específico para descargar el manual, o comuníquese con el
proveedor autorizado de Sunrise Medical.
Quickie® 2,2HD
 avec option pour transport  sans option pour transport
Fournisseur: Ce manuel doit être remis à l’utilisateur / utilisatrice de ce fau-
teuil roulant.
Utilisateur / Utilisatrice: Avant d’utiliser ce fauteuil roulant, lisez entière-
Quickie® 2,2HD
 con opción de tránsito 
sin opción de tránsito
Distribuidor:
Este manual debe ser entregado al pasajero de esta silla de
Owner's Manual

QUICKIE 2
I. INTRODUCTION
SUNRISE MEDICAL LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your questions or
comments about this manual, the safety and reliability of your chair, and the service
you receive from your Sunrise supplier. Please feel free to write or call us at the
address and telephone number below:
Sunrise Medical (US) LLC
Customer Service Department
2842 N. Business Park Ave
Fresno, CA 93727 USA
[phone]
Be sure to register your wheelchair and let us know if you change your address.
This will allow us to keep you up to date with information about safety, new
products, and options to increase your use and enjoyment of this wheelchair.
You can also register your wheelchair at:
www.sunrisemedical.com/register
FOR ANSWERS TO YOUR QUESTIONS
Your authorized supplier knows your wheelchair best, and can answer most of your
questions about chair safety, use and maintenance. For future reference, fill in the
following:
Supplier:________________________________________________
Address: _______________________________________________
_______________________________________________________
Telephone:______________________________________________
Serial #: __________________ Date/Purchased: _______________
ADDITIONAL INFORMATION YOU SHOULD KNOW
No component of this chair was made with Natural Rubber Latex.
Disposal and recycling information:
When this product reaches the end of its life, please take it to an approved
collection or recycling point designated by your local or state government. This
wheelchair is manufactured using a variety of materials. Your product should not
be disposed of as ordinary household waste. You should dispose of your
wheelchair properly, according to local laws and regulations. Most materials that
are used in the construction of this product are fully recyclable. The separate
collection and recycling of your product at the time of disposal will help conserve
natural resources and ensure that it is disposed in a manner that protects the
environment.
Ensure you are the legal owner of the product prior to arranging for the product
disposal in accordance with the above recommendations.
www.sunrisemedical.com/register
MK-100070 Rev. E
2

QUICKIE 2
I. INTRODUCTION ............................................................... 2
II. TABLE OF CONTENTS ...................................................... 3
III. YOUR CHAIR AND ITS PARTS ....................................... 4
IV. NOTICE - READ BEFORE USE ......................................... 4
A.Choose the Right Chair & Safety Options ................ 4
B. Review This Manual Often ............................................. 4
C.Warnings.............................................................................. 4
V. GENERAL WARNINGS....................................................... 5
A.Weight Limits .................................................................... 5
B. Intended Use....................................................................... 5
C.Attendants and Caregivers.............................................. 5
D.Accessories ......................................................................... 5
E. Know Your Chair ............................................................ 5
F. Reduce The Risk of an Accident .................................. 5
G.Safety Checklist ................................................................. 5
H.Changes & Adjustments ................................................. 5
I. Environmental Conditions .............................................. 6
J. Terrain ................................................................................ 6
K.Street Use .......................................................................... 6
L. Motor Vehicle Safety ....................................................... 6
M.When You Need Help .................................................... 6
VI. SAFETY WARNINGS: FALLS & TIP-OVERS.................. 8
A.Center of Balance ............................................................
B. Dressing or Changing Clothes ......................................
C.Obstacles ............................................................................
D.Front Caster Lift................................................................
E. Reaching or Leaning..........................................................
F. Moving Backward...............................................................
G.Escalators.............................................................................
H.Ramps, Slopes & Sidehills ...............................................
I. Transfer................................................................................
J. Curbs & Single Steps.........................................................
K.Climbing a Curb or Single Step...................................... 11
L. Descending a Curb or Single Step................................. 11
M.Stairs ..................................................................................... 11
N.Climbing Stairs .................................................................. 11
O.Descending Stairs ............................................................. 11
VII. WARNINGS: COMPONENTS & OPTIONS ................. 12
A.Anti-Tip Tubes .................................................................. 12
B. Armrests ............................................................................. 12
C.Caster Pin Locks................................................................ 12
D.Cushion & Sling Seats ...................................................... 12
E. Fasteners ............................................................................ 12
F. Footrests.............................................................................. 12
G.Pneumatic Tires ................................................................ 13
H.Positioning Belts Option.................................................. 13
I. Push Handles Option........................................................ 13
J. Quick-Release Axles ........................................................ 13
K.Rear Wheels ...................................................................... 13
L. Rear Wheel Locks ........................................................... 14
M.Modified Seat Systems ..................................................... 14
N.Seat and Back Upholstery .............................................. 14
VIII. USE AND MAINTENANCE .............................................. 15
A.Introduction ........................................................................ 15
B. Critical Maintenance Tips ................................................ 15
C.Maintenance Chart ........................................................... 15
D.Cleaning Tips ...................................................................... 15
E. Troubleshooting Chart..................................................... 15
F. To Mount and Remove Rear Wheels .......................... 16
G.Wheel Locks....................................................................... 16
H.Anti-tips................................................................................ 16
I. Armrests.............................................................................. 17
J. Flip-Back Height Adjustable Armrests.......................... 17
K.Padded Swing-away Armrests ........................................ 17
L. Footrests, Legrests, & Footplates ................................ 18
N.Backrests and Back Upholstery...................................... 20
O.Swing-away adjustable stroller handles ........................
P. Seating and Seat Sling Upholstery ................................. 20
Q.Side Guards.........................................................................
R. Folding and Unfolding....................................................... 21
S. Storage Tips ........................................................................ 21
T. Inspect ................................................................................
IX DEALER SERVICE AND ADJUSTMENT ......................... 22
A.Dealer Service Introduction............................................ 22
B. Critical Maintenance tips ................................................. 22
C.Cleaning................................................................................ 22
D.Rear Axles & Axle Plates................................................. 22
E. Rear Wheel Axle Nut Adjustment ............................... 23
F. Wheel Locks....................................................................... 23
G.Caster Forks ....................................................................... 24
H.Casters ................................................................................. 24
I. Anti-tip Receivers.............................................................. 24
J. Armrest Receiver Attachment ...................................... 25
K.Adjustable Locking Flip-up Armrests .......................... 25
L. Padded Swing-away Armrests ........................................ 26
M.Fixed Front Footrests....................................................... 26
N.Swing-in, Swing-out Hangers and Footrests .............. 26
O.Angle Adjustable Footplates ........................................... 26
Q.Backrest ...............................................................................
R. Angle Adjustable Backrest............................................... 28
T.Removing Seat Rails .......................................................... 29
U.
Seat Saddle Adjustment.................................................... 29
V.Sideguard Hardware ......................................................... 29
X. SUNRISE LIMITED WARRANTY ..................................... 31
II. TABLE OF CONTENTS
S. Backrest Tension Adjustable ........................................... 28
M.Z-Finity™ Footrest System ............................................ 19
P. Z-Finity™ Footrest System ............................................ 27
N.Choking Hazard ............................................................... 7
O.Pinch Point ........................................................................ 7
8
8
8
8
8
8
10
10
9
9
20
21
21
28
3
MK-100070 Rev. E

IV. NOTICE- READ BEFORE USE
QUICKIE 2
A. CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
Sunrise provides a choice of many wheelchair styles to meet your
needs. This product is intended for single person use only. Final
selection of the type of wheelchair, options and adjustments rests
solely with you and your health care professional. Choosing the best
chair for your unique mobility needs, will depend on such things as:
1. Your disability, strength, balance and coordination.
2. The types of hazards you must overcome in daily use (where you
live and work, and other places you are likely to use your chair).
3. The need for options that will improve your positioning, safety and
comfort (such as anti-tip tubes, positioning belts, or special
seating systems).
B. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you,
should read this entire manual and make sure to follow all
instructions. Review the warnings often, until they are second nature
to you.
C. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that may
cause severe injury or death to you or to other persons. The “Warnings”
are in three main sections, as follows:
1. V — GENERAL WARNINGS
Here you will find a safety checklist and a summary of risks
you need to be aware of before you ride this chair.
2.VI– SAFETY WARNINGS: FALLS & TIP-OVERS
Here you will learnabout practices for the safe use of your
chair, and how to avoid a fall or tip-over while you perform
daily activi-ties in your chair.
3. VII — WARNINGS — COMPONENTS & OPTIONS
Here you will learn about the components of your chair and
options you can select for safety. Consult your authorized supplier
and your health care advisor to help you choose the best set-up
and options for safe use.
NOTE– Where they apply, you will also find “Warnings” in other sec-
tions of this manual. Heed all warnings in these sections. If
you fail to do so a fall, tip-over or loss of control may occur
and cause severe injury to the rider or others.
1. Push Handle/Backcane
2. Backrest
3. Pneumatic Tire
4. Aluminum Handrim
5. Aluminum Wheel Rim
6. Quick-Release Axle
7. Anti-tip
8. Caster Wheel
9. Caster Fork
10. Caster Housing
11. Footrest
12. Swing-Away latch release
13. X-Hinge
14. Wheel lock
15. Seat Sling
16. Armrest
QUICKIE 2 1
3
4
6
10
9
11
15
16
8
13
12
14
2
5
7
All features may not be available
with some device setups or in
conjunction with other device
features. Please consult your
supplier for more information.
Your authorized supplier can also
provide you with informa-tion on
accessories.
III. YOUR CHAIR AND IT'S PARTS
MK-100070 Rev. E
4

A. WEIGHT LIMITS
WARNING
NEVER exceed the weight limit specified by Sunrise Medical. The
weight capacity provided by your manufacturer is for the combined
weight of a rider and items carried using on-board storage. If you do
exceed the weight limit, damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
Weight Capacities
Quickie 2 - 300lbs / (136kg)
Quickie 2HD - 350lbs / (159kg)
Option Specific Weight Capacities:
Topolino Rear Wheels – 265 lbs / (120 kg)
Xtender Power Assist – 265 lbs / (120 kg)
Z-Finity™ Footrest – 165 lbs / (75 Kg)
B. INTENDED USE
The Quickie 2 Series of wheelchair's intended use is to provide mobility
to persons limited to a sitting position.
WARNING
DO NOT use this device for purposes other than what is intended by
the manufacturer
1. The wheelchair is not designed for weight training and is unsafe
for use as a seat while weight training. Weight training from the
wheelchair substantially changes the stability of the chair and
may cause tipping.
2. DO NOT stand on the frame of the wheelchair.
3. NEVER allow someone to stand on your chair or use it as a step
ladder.
4. This chair is designed for a single rider only.
5. Unauthorized modifications and use of parts or accessories not
supplied or approved by Sunrise Medical may change the chair
struc-ture. This will void the warranty and may cause a safety
hazard. If the warning is ignored, damage to your chair, and the
potential severe injury of the person using the chair for
unintended purposes can occur.
C. ATTENDANTS AND CAREGIVERS
WARNING
Before you assist a rider, be sure to read all warnings contained in this
manual, and follow all instructions that apply. Be aware that after
consulting a healthcare advisor, you will need to learn safe and proven
body mechan-ics to use and create assistive methods best suited to
your abilities.
D. ACCESSORIES WARNING
Unauthorized modifications or use of parts, or accessories not supplied
or approved by Sunrise Medical may change the chair structure. This
will void the warranty and may cause a safety hazard.
Some problems that may occur, but are not limited to:
1. Incorrect Wheels and/or tires that put the rider at risk of a fall or
tip-over.
2. Adding a component to the frame, changing the structural
integrity of the chair.
3. Any modification or disassembly can potentially create an unsafe
situ-ation where rider and/or attendant are put at risk.
E. KNOW YOUR CHAIR
WARNING
Every wheelchair is different. Take the time to learn the feel of this chair
before you begin riding. Start slowly, with easy, smooth strokes. If you
are used to a different chair, you may use too much force and tip over.
If you use too much force, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
F. REDUCE THE RISK OF AN ACCIDENT
WARNING
1. BEFORE you begin riding, you should be trained in the safe use
of this chair by your health care advisor.
2. Practice bending, reaching and transfers until you know the limit
of your ability. Have someone help you until you know what can
cause a fall or tip-over and how to avoid doing so.
3. Be aware that you must develop your own methods for safe use
best suited to your level of function and ability.
4. NEVER try a new maneuver on your own. Ask the advice of your
health care provider to lower the risk of a fall or tip-over.
5. Get to know the areas where you plan to use your chair. Look
for hazards and learn how to avoid them.
G. SAFETY CHECKLIST
WARNING
Before Each Use Of Your Chair:
1. Make sure the chair rolls easily and that all parts work smoothly.
Check for noise, vibration, or a change in ease of use. (This may
indicate low tire pressure, loose fasteners, or damage to your
chair).
2. Immediately repair any problem. Your authorized supplier can
help you find and correct the problem.
3. Check to see that both quick-release rear axles are locked.
When locked, the axle button will “pop out” fully. If not locked,
the wheel may come off and cause you to fall.
4. If your chair has anti-tip tubes, lock them in place.
H. CHANGES & ADJUSTMENTS
WARNING
1. If you modify or adjust this chair, it may increase the risk of a
tip-over UNLESS you make other adjustments as well.
2. Consult your authorized supplier BEFORE you modify or
adjust your chair.
3. We recommend that you use anti-tip tubes until you adapt to
the change, and are sure you are not at risk to tip over.
4. Unauthorized modifications by the end-user, dealer or any
other individual, including the use of parts not supplied or
approved by Sunrise may change the chair structure. This will
void the warranty and may cause a safety hazard.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
QUICKIE 2
V. GENERAL WARNINGS
5
MK-100070 Rev. E

QUICKIE 2
WARNING
If your chair is NOT equipped with the Transit Option:
1. NEVER let anyone sit in this chair while in a moving vehicle.
a. ALWAYS move the rider to an approved vehicle seat.
b. ALWAYS secure the rider with proper motor vehicle restraints.
2. In an accident or sudden stop the rider may be thrown from the
chair. Wheelchair seat belts will not prevent this, and further injury
may result from the belts or straps.
3. NEVER transport this chair in the front seat of a vehicle. It may shift
and interfere with the driver.
4. ALWAYS secure this chair so that it cannot roll or shift.
5. Do not use any chair that has been involved in a motor vehicle acci-
dent. The frame and/or components may have been changed due to
the accident. Such items could be, but are not limited to: bent, loos-
ened, and/or broken components that were subjected to an impact.
Failure to heed these warnings puts you and others that may assist you
at a high risk of injury.
M. WHEN YOU NEED HELP
WARNING
For The Rider: Make sure that each person who helps you reads and
fol-lows all warnings and instructions that apply.
For Attendants:
1. Work with the rider’s doctor, nurse or therapist to learn safe methods
best suited to your abilities and those of the rider.
2. Tell the rider what you plan to do, and explain what you expect the
rider to do. This will put the rider at ease and reduce the risk of an
accident.
3. Make sure the chair has push handles. They provide secure points for
you to hold the rear of the chair to prevent a fall or tip-over. Check to
make sure push handle grips will not rotate or slip off.
4. To prevent injury to your back, use good posture and proper body
mechanics. When you lift or support the rider or tilt the chair, bend
your knees slightly and keep your back as upright and straight as you
can.
5. Remind the rider to lean back when you tilt the chair backward.
6. When you descend a curb or single step, slowly lower the chair in one
easy movement. Do not let the chair drop the last few inches to the
ground. This may damage the chair or injure the rider.
7. To avoid tripping, unlock and rotate anti-tip tubes up, out of the way.
8. Whenever you aren’t attending the wheelchair, ALWAYS use the
wheel-lock to secure the rear wheels, and lock the anti-tip tubes in
place.
If you fail to ask for help when in doubt, you run a high risk of a fall, tip-over or
loss of control that may occur and cause severe injury to the rider or others.
I. ENVIRONMENTAL CONDITIONS
WARNING
1.
2.
Use extra care if you must ride your chair on a wet
or slick surface. If you are in doubt, ask for help.
Contact with water or excess moisture may cause your chair to
rust or corrode. Avoid all extreme weather situations if possible.
a. Do not use your chair in a shower, pool or other body of
water. The chair tubing and parts are not water-tight and
may rust or corrode from the inside.
b. Avoid excess moisture (for example, do not leave your chair
in a damp bathroom while taking a shower).
c.
d.
Dry your chair as soon as you can if it gets wet, or if you use
water to clean it.
Avoid contact with salt or salty conditions as this may cause
damage to the chair
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
J. TERRAIN
WARNING
1. Based on ANSI/RESNA testing, Sunrise Medical recommends the
use of a caster wheel with a minimum diameter of 5”, if the wheel-
chair will be overcoming obstacles up to 1/2” on a regular basis.
2. Your chair is designed for use on firm, even surfaces such as con-
crete, asphalt, indoor flooring, and carpets.
3. Do not operate your chair in sand, loose soil, or over rocky terrain.
4. If you use your chair on terrain that is rougher than described
above there is a danger that screws and bolts will loosen prema-
turely, and that damage to wheels or axles could put the rider at
risk of a fall, tip-over, or loss of control.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
WARNING
1. This product is not intended for street use.
K. STREET USE
2. Avoid streets whenever possible.
3. Obey and follow all legal pedestrian pathways, and laws that
apply to pedestrians.
4. Be alert to the danger of motor vehicles in parking lots, or if you
must cross a road.
If you fail to heed this warning, damage to your chair, and a possible
colli-sion may occur and cause severe injury to the rider or others.
L. MOTOR VEHICLE SAFETY
If possible and feasible, the rider should transfer to the Original
Equipment Manufacturer vehicle seat and use the OEM vehicle
restraint.
Sunrise Medical does provide a WC-19 Wheelchair Tie-Down and
Occupant Restraint System, otherwise called a Transit Option. To
Identify whether your wheelchair has been manufactured with the
Transit Option installed, look for four points of securement. Two Front
points (A), and two rear points (B). These points are recognized by the
securement point decal which can be found on or near the securement
points.
If your wheelchair is equipped with the Transit Option, please review the
Transit Securement supplement that was provided with the wheelchair
for additional information and instructions. You can request a copy from
your authorized supplier, or call Sunrise medical at 1-800-333-4000 if
you don’t have it.
21
Look for this symbol on your wheelchair. It indicates wheel-
chair securement points which conform to ANSI/RESNA
(1998) V.1 - Section 19 and/or ANSI/RESNA (2012) V.4
WC-19. For more Transit related information, see the
“Transit Securement Supplement” included with your chair.
12
B
Front Transit hook Rear Transit hook
A
V. GENERAL WARNINGS
MK-100070 Rev. E
6

QUICKIE 2 V. GENERAL WARNINGS
O. PINCH POINT
NOTE- Your wheelchair has many moving parts that can create pinch points
and possible finger traps. Be aware when making any adjustments, when
folding and unfolding, when moving, and any other situation that could
cause a pinch point situation.
WARNING
N. CHOKING HAZARD
NOTE- Your chair consists of many small parts that could present a choking
hazard to young children. Take care to put parts out of reach when doing
any work on the chair.
WARNING
7
MK-100070 Rev. E

QUICKIE 2
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
A. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back or to the side depends
on its center of balance and stability. How your chair is set up, the
options you select and the changes you make may affect the risk of a
fall or tip-over.
1. The Most Important Adjustment Is:
The position of the rear wheels. The more you move the rear
wheels forward, the more likely your chair will tip over backward.
2. The Center Of Balance Is Also Affected By:
a. A change in the set-up of your chair, including:
•The distance between the rear wheels.
•The amount of rear wheel camber.
•The seat height and seat angle.
•Backrest angle.
b. A change in your body position, posture or weight distribution.
c. Riding your chair on a ramp or slope.
d. A back pack or other options and the amount of added weight.
3. To Reduce The Risk Of An Accident:
a. Consult your doctor, nurse or therapist to find out what axle
and caster position is best for you.
b. Consult your authorized supplier BEFORE you modify or adjust
this chair. Be aware that you may need to make other changes
to correct the center of balance.
c. Have someone help you until you know the balance points of
your chair and how to avoid a tip-over.
d. Use anti-tip tubes.
If you fail to heed these warnings, you are at a high risk of a fall, tip-
over or loss of control that could cause severe injury to the rider or
others.
B. DRESSING OR CHANGING CLOTHES
WARNING
Your weight may shift if you dress or change clothes while seated in
this chair.
To reduce the risk of a fall or tip-over:
1. Rotate the front casters until they are as far forward as
possible. This makes the chair more stable.
2. Lock anti-tip tubes in place. (If your chair does not have anti-
tip tubes, back it up against a wall and lock both rear wheels).
If you fail to heed this warning, damage to your chair, a fall, tip-over or
loss of control may occur and cause severe injury to the rider or others.
C. OBSTACLES
WARNING
Riding over curbs or obstacles can cause tipping and serious bodily harm.
If you have any doubt that you can safely cross any curb or obstacle,
ALWAYS ASK FOR HELP. Be aware of your riding skills and personal lim-
itations. Develop new skills only with the help of a companion.
To avoid the risk of traversing obstacles:
1. Keep a lookout for danger – scan the area well ahead of your
chair as you ride.
2. Make sure the floor areas where you live and work are level and
free of obstructions.
3. Remove or cover threshold strips between rooms.
4. Install a ramp at entry or exit doors. Make sure there is not a
drop off at the bottom of the ramp.
5. To Help Correct Your Center Of Balance:
a. Lean your upper body FORWARD slightly as you go UP over
an obstacle.
b. Press your upper body BACKWARD as you go DOWN from a
higher to a lower level.
6. If your chair has anti-tip tubes, do not go over an obstacle
without help.
7. Keep both of your hands on the handrims as you go over an
obsta-cle.
8. Never push or pull on an object (such as furniture or a
doorjamb) to propel your chair.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
D. FRONT CASTER LIFT
WARNING
Front caster lift can occur when the front wheels, ordinarily in contact
with the ground, are either intentionally, or unintentionally caused to
lift from the ground while the rear wheels remain in contact. Pitch
control (partial or full) should NEVER be attempted without
consulting your healthcare advisor and making sure that anti-tips are
installed.
If you fail to heed this warning, you are at a high risk of damage to
your chair, a fall, tip-over or loss of control that may occur and cause
severe injury to the rider or others.
E. REACHING OR LEANING
WARNING
If you reach or lean it will affect the center of balance of your chair.
This may cause you to fall or tip over. When in doubt, ask for help or
use a device to extend your reach.
1. NEVER reach or lean if you must shift your weight sideways or rise
up off the seat.
2. NEVER reach or lean if you must move forward in your seat to do
so. Always keep your buttocks in contact with the backrest.
3. NEVER reach with both hands (you may not be able to catch your-
self to prevent a fall if the chair tips).
4. NEVER reach or lean to the rear unless your chair has anti-tip tubes
locked in place.
5. DO NOT reach or lean over the top of the seat back. This may
damage one or both backrest tubes and cause you to fall.
6. If You Must Reach Or Lean:
a. Do not lock the rear wheels. This creates a tip point and
makes a fall or tip-over more likely.
b. Do not put pressure on the footrests.
c. Move your chair as close as you can to the object you wish to
reach.
d. Do not try to pick up an object from the floor by reaching
down between your knees. You are less likely to tip if you
reach to the side of your chair.
e. Rotate the front casters until they are as far forward as
possi-ble. This makes the chair more stable.
f. Firmly grasp a rear wheel or an armrest with one hand. This
will help to prevent a fall if the chair tips.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
F. MOVING BACKWARD
WARNING
Use extra care when you move your chair backward. Your chair is most
stable when you propel yourself forward. You may lose control or tip
over if one of the rear wheels hits an object and stops rolling.
1. Propel your chair slowly and smoothly.
2. If your chair has anti-tip tubes, make sure to lock them in place.
3. Stop often and check to be sure your path is clear.
If you fail to heed this warning, you are at a high risk of damage to
your chair, a fall, tip-over or loss of control that may occur and cause
severe injury to the rider or others.
MK-100070 Rev. E
8

QUICKIE 2
H. RAMPS, SLOPES & SIDEHILLS
WARNING
Whenever possible, avoid riding on a slope, which includes a ramp or sidehill. This will change
the center of balance of your chair. Your chair is less stable and more difficult to manuever
when it is at an angle. When moving up a hill, anti-tip tubes may not prevent a fall or tip-over.
3 4 5 6
3
4
5
6
IF you need to go up a hill:
a. The Upslope should be less than 6°
b. ALWAYS Go Straight up
c. DON'T STOP
d. NEVER turn on a hill
e. ALWAYS lean forward
IF you need to traverse a Sidehill:
a. The side hill must be Less than 6° or
you are at risk of a tip over
b. DON’T STOP
c. NEVER turn on a hill
If you need to traverse a Ramp:
a. Go Slowly.
b. Watch out for Drop-offs.
c. ALWAYS go straight up or straight down.
d. Stay centered on the Ramp.
IF you need to go down a hill:
a. The Downslope should be less than 6°
b. GO SLOW Control your speed
c. ALWAYS Go Straight down
d. NEVER turn on a hill
e. ALWAYS lean backward
Whenever possible, avoid riding on a slope, which includes a ramp or sidehill. This will change the
cen-ter of balance of your chair. Your chair is less stable and more difficult to manuever. when it
is at an angle. When moving up a hill, anti-tip tubes may not prevent a fall or tip-over.
1. DO NOT use your chair on a slope steeper than 6°.
2. ALWAYS go as straight up and as straight down as you can. (Do not “cut the corner”
on a slope or ramp.)
3. DO NOT turn or change direction on a slope.
4. When you have to use a ramp, always stay in the CENTER of the ramp. Make sure
ramp is wide enough that you have no risk of going off the edge.
5. DO NOT stop on a steep slope. If you stop, you may lose control of your chair.
6. NEVER use rear wheel locks to try to slow or stop your chair. This is likely to cause
your chair to veer out of control.
7. ALWAYS be aware of:
a. Wet or slippery surfaces.
b. A change in grade on a slope (or a lip, bump or depression). These may cause
a fall or tip- over.
c. A drop-off at the bottom of a slope or ramp. A drop-off as small as 3/4 inch can
stop a front caster and cause the chair to tip forward.
8. To Reduce The Risk Of A Fall Or Tip-Over:
a.
b.
Lean or press your body UPHILL. This will help adjust for the change in the center of
bal-ance caused by the slope or sidehill.
Keep pressure on the handrims to control your speed on a down slope. If you go too
fast you may lose control.
c. ASK FOR HELP any time you are in doubt.
9. Ramps At Home & Work– For your safety, ramps at home and work must meet all
legal requirements for your area:
a. AVOID A DROP-OFF
Make sure there is a section at the top or bottom to smooth out the transition.
b. ALWAYS stay in the center of the ramp and control your speed.
G. ESCALATORS
WARNING
NEVER use this chair on an escalator, even with an attendant. If you do, a fall or tip-over is likely.
If you fail to heed this warning you and others that may be assisting you, are at a high risk of
severe injury.
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and
can possibly cause severe injury to the rider or others.
For Attendants:
Follow these steps to help the rider go up or down a ramp:
1. Stay behind the chair.
2. Firmly grasp the handles.
3. For going up or down a ramp, the chair should always be facing forward.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may
occur and cause severe injury to the rider or others
9
MK-100070 Rev. E

QUICKIE 2
I. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires good balance and agility. Be aware that there
is a point during every transfer when the wheelchair seat is not below you. To avoid a fall:
1. Work with your health care advisor to learn safe methods for transfers.
a. Learn how to position your body and how to support yourself during a transfer.
b. Have someone help you until you learn safe transfer methods.
2. Lock the rear wheels before you transfer.
3. Be aware that the chair can still slide and/or tip. The wheel lock keeps the rear wheels
from rolling while you are perforrming the transfer.
4. Make sure that the pneumatic tires are properly inflated. Low tire pressure may allow
the rear wheel locks to slip. (see table in Section G “Pneumatic Tires”
5. Move your chair as close as you can to the seat you are transferring to.
If possible, use a transfer board.
6. Rotate the front casters until they are as far forward as possible.
7. If you can, remove the footrests, or swing them out of the way.
a. Make sure your feet do not catch in the space between the footrests.
b. Avoid putting weight on the footrests as this may cause the chair to tip.
8. Make sure armrests are removed, or out of the way and do not interfere with the
transfer.
9. Transfer as far back onto the seat surface as you can. This will reduce the risk that the
chair will tip or move away from you.
87
7
J. CURBS & SINGLE STEPS
WARNING
Before riding over curbs, and negotiating even a single step, ALWAYS ask for assistance first.
Curbs and steps can cause tipping and serious bodily harm. When in doubt as to your ability to
avoid, or traverse any obstacle, always ask for help. Be aware of your riding skills and personal
limitations. Develop new skills only with the help of a companion.
For Attendant: Each person who assists the rider with curbs and steps should read and follow all
instructions and warnings pertaining to attendants, and caregivers.
1. Do not try to climb a high curb or step (more than 4 inches high) UNLESS you have help.
Doing so may cause your chair to exceed its balance point and tip over.
2. Go straight up and straight down a curb or step. If you climb or descend at an angle, a fall
or tip-over is likely.
3. Be aware that the impact of dropping down from a curb or step can damage your chair or
loosen fasteners.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may
occur and can possibly cause severe injury to the rider or others.
9
GET READY TRANSFER ADJUST
8
1. 2. 3.
Before transferring:
1. Flip-back or remove the armrests.
2. Swing-away or remove the footrests.
3. Make sure the wheel lock is set.
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
Optimum Transfer position
MK-100070 Rev. E
10

QUICKIE 2
K. CLIMBING A CURB OR SINGLE STEP
WARNING
For Attendant: follow these steps to help the rider climb a curb or single step going BACKWARD:
1. Stay behind the chair.
2. Continue backward until the rear wheels contact the face of the curb or step. Lift and roll
the rear wheels to the top of the curb.
3. Pull the chair backwards until the caster wheels have cleared the edge of the curb and
return the chair to its rolling position.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may
occur and cause severe injury to the rider or others.
L. DESCENDING A CURB OR SINGLE STEP
WARNING
For Attendant:: Follow these steps to help a rider descend a curb or single step going FORWARD:
1. Stay at the rear of the chair.
2. Several feet before your reach the edge of the curb or step, tip the chair slightly and pull it backward.
3. When the chair is at it’s balance point, carefully step forwards until the rear wheels reach the edge
of the curb or step. Then allow the rear wheels to slowly roll down onto the lower level.
4. Push the chair forward until you are standing on the lower level.
5. When the rear wheels are safely on the lower level, tilt the chair back to its balance point.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may
occur and cause severe injury to the rider or others.
M. STAIRS
WARNING
1. NEVER use this chair on stairs UNLESS you have someone to help you. Doing so is likely to
cause a fall or tip-over.
2. Negotiating stairs with a wheelchair always requires at least 2 attendants for safety.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur
and cause severe injury to the rider or others.
N. CLIMBING STAIRS
WARNING
1. Use at least two attendants to move a chair and rider up stairs.
2. Move the chair and rider BACKWARD up the stairs.
3. The person at the rear is in control. He or she tilts the chair back to its balance point.
4. A second attendant at the front firmly grasps a non-detachable part of the front frame and
lifts the chair up and over one stair at a time.
5. The attendants move to the next stair up. Repeat for each stair, until you reach the landing.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur
and cause severe injury to the rider or others.
O. DESCENDING STAIRS
WARNING
1. Use at least two attendants to move a chair and rider down stairs.
2. Move the chair and rider FORWARD down the stairs.
3. The person at the rear is in control. He or she tilts the chair to the balance point of the rear
wheels and rolls it to the edge of the top step.
4. A second attendant stands on the third step from the top and grasps the chair frame. He or she
low-ers the chair one step at a time by letting the rear wheels roll over the stair edge.
5. The attendants move to the next stair down. Repeat for each stair, until you reach the landing.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur
and cause severe injury to the rider or others.
9
9
10
10
10
10
9
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
11
MK-100070 Rev. E

QUICKIE 2
A. ANTI-TIP TUBES
WARNING
Anti-tip tubes can help keep your chair from tipping over backward
in normal conditions.
1. Sunrise recommends the use of anti-tip tubes:
2. When locked in place (in the “down” position) anti-tip tubes
should be BETWEEN 1-1/2 to 2 inches off the ground.
a. If set higher than 2 inches, they may not prevent a tip-over.
b. If set lower than 1-1/2 inches, they may “hang up” on
obstacles and cause a fall or tip over.
3. If you have to climb or descend a curb, or overcome an obstacle
it may be necessary to have an attendant make sure the anti-tip
tubes are rotated up, and out of the way, so that the chair and
rider do not get stuck and/or become unstable.
If you fail to heed these warnings damage to your chair, a fall, tip-over or
loss of control may occur and cause severe injury to the rider or others.
B. ARMRESTS
WARNING
Armrests detach and will not bear the weight of this chair.
1. NEVER lift this chair by its armrests. They may come loose or
break.
2. Lift this chair only by non-detachable parts of the main frame.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
C. CASTER PIN LOCKS
WARNING
Always use both pin locks when transferring in and out of the chair.
Caster pin locks only keep the front caster wheels from changing
direction, they do not lock-out the front wheels from rotation. To prevent
the wheel-chair from rolling, you must engage the rear wheel locks.
If you propel your wheelchair with the caster pin locks engaged, the chair
will be prevented from turning.
If you fail to heed these warnings damage to your chair, a fall, tip-over or
loss of control may occur and cause severe injury to the rider or others.
D. CUSHIONS & SLING SEATS
WARNING
1. Quickie sling seats and standard foam cushions are not designed
for the relief of pressure.
2. If you suffer from pressure sores or if you are at risk that they will
occur, you may need a special seat system or a device to control
your posture. Consult your doctor, nurse or therapist to find out if
you need such a device for your well-being.
3. Seat slings are not intended to be used as a direct seating
surface. A cushion or other seating surface should be placed on
the sling before use.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
E. FASTENERS WARNING
Many of the screws, bolts and nuts on this chair are special high-
strength fasteners. Use of improper fasteners may cause your chair
to fail.
1. ONLY use fasteners provided by an authorized supplier (or ones of
the same type and strength, as indicated by the markings on
the heads).
2. Over- or under-tightened fasteners may fail or cause damage to
chair parts.
3. If bolts or screws become loose, tighten them as soon as you can.
NOTE- For safety and optimum performance it is best to not reuse
fasteners.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
F. FOOTRESTS
WARNING
1. At the lowest point, footrests should be AT LEAST 2 inches off
the ground. If set too LOW, they may “hang up” on obstacles
you can expect to find in normal use. This may cause the chair
to stop sud-denly and tip forward.
2. To Avoid A Trip Or Fall When You Transfer:
a. Make sure your feet do not “hang up” or get caught in the
space between the footrests.
b. Avoid putting weight on the footrests, as the chair may tip
for-ward.
c. Footrests should be swung out of the way or removed
whenever entering or exiting the wheelchair.
3. NEVER lift this chair by the footrests. Footrests detach and will
not bear the weight of this chair. Lift this chair only by non-
detachable parts of the main frame.
4. Never use the footrests of the chair to open doors, this may
cause them to fail prematurely, and create an unsafe situation.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
VII. WARNINGS: COMPONENTS AND OPTIONS
MK-100070 Rev. E
12

QUICKIE 2
G. PNEUMATIC TIRES
WARNING
Proper inflation extends the life of your tires and makes your chair
easier to use.
1.
2.
Do not use this chair if any of the tires are under- or over-
inflated. Check weekly for proper inflation level, as listed on the
tire side-wall.
Low pressure in a rear tire may cause the wheel lock on that
side to slip and allow the wheel to turn when you do not expect
it.
3. Low pressure in any of the tires may cause the chair to veer to
one side and result in a loss of control.
4. Over-inflated tires may burst.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
H. POSITIONING BELTS (OPTIONAL)
WARNING
The positioning belt is predominately used to support your posture. It
can also be used to limit slipping and/or sliding that you might
experience when the chair is in motion. The positioning belt is not a
transit rated safety belt and should not be used in the place of a seat
belt while being transported in a motor vehicle. Improper use of
Positioning belts may cause severe injury or death. If you use a
positioning belt, be sure to follow the recom-mendations in this section:
1. Make sure the rider does not slide down in the wheelchair seat. If
this occurs, the rider may suffer chest compression or suffocate
due to pressure from the belts.
2. The belts must be snug, but must not be so tight that they
interfere with breathing. You should be able to slide your open
hand, flat, between the belt and the rider.
3. A pelvic wedge or a similar device can help keep the rider from
slid-ing down in the seat. Consult with the rider’s doctor, nurse or
therapist to find out if the rider needs such a device.
4. Use positioning belts only with a rider who can cooperate. Make
sure the rider can easily remove the belts in an emergency.
5. NEVER Use Positioning Belts:
a. As a patient restraint. A restraint requires a doctor’s order.
b. On a rider who is comatose or agitated.
c. As a motor vehicle restraint. In an accident or sudden stop
the rider may be thrown from the chair. Wheelchair seat
belts will not prevent this, and further injury may result from
the belts or straps.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
I. PUSH HANDLES (OPTIONAL)
WARNING
When you have an attendant, make sure that this chair has push handles.
1. Push handles provide secure points for an attendant to hold the
rear of this chair, to prevent a fall or tip-over.
2. Check to make sure push handle grips will not rotate or slip off.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
J. QUICK-RELEASE AXLES
WARNING
1. Do not use this chair UNLESS you are sure that both quick-release
rear axles are locked.
2. An axle is not locked until the quick-release button pops out fully.
3. An unlocked axle may come off during use, resulting in a fall, tip-
over or loss of control and cause severe injury to the rider or oth-
ers.
•Quick-Release Axles should be periodically cleaned and
inspected for function and signs of wear or bending. Replace as
necessary.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
K. REAR WHEELS
WARNING
A change in set-up of the rear wheels will affect the center of
balance of your chair.
1. The farther you move the rear axles FORWARD, the more likely it
is that your chair will tip over backward.
2. Consult your healthcare advisor to find the best rear axle set-up
for your chair. Do not change the set-up UNLESS you consult your
healthcare advisor first.
3. Adjust the rear wheel locks after you make any change to the
rear axles.
a. If you fail to do so, the wheel locks may not work.
b. Make sure lock arms embed in the tires at least 1/8 inch
when locked.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
11
A
11
Recommended Tire Pressures
VII. WARNINGS: COMPONENTS AND OPTIONS
13
MK-100070 Rev. E

QUICKIE 2
L. REAR WHEEL LOCKS
WARNING
Rear wheel locks are NOT designed to slow or stop a moving
wheelchair. Use them only to keep the rear wheels from rolling when
your chair is at a complete stop.
1. NEVER use rear wheel locks to try to slow or stop your chair when it
is moving. Doing so may cause a fall or tip-over
2. To keep the rear wheels from rolling, always set both rear wheel
locks when you transfer to or from your chair.
3. Low pressure in a rear tire may cause the wheel lock on that side to
slip and may allow the wheel to turn when you do not expect it.
4. Make sure lock arms embed in tires at least 1/8 inch when locked.
If you fail to do so, the locks may not work.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
M. MODIFIED SEAT SYSTEMS
WARNING
Use of a seat system not approved by Sunrise may alter the center of
bal-ance of this chair. This may cause the chair to tip over.
1. Do not change the seat system of your chair UNLESS you
consult your authorized supplier first.
2. Use of a seating system not approved by Sunrise may affect
the folding mechanism of this chair.
3. Use of a seating system not provided by Sunrise is prohibited
for transit use.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
N. SEAT AND BACK UPHOLSTERY
WARNING
1. Replace worn or torn fabric of seat and seat back as soon as
you can. If you fail to do so, the seat or seat back may fail.
2. Sling fabric will weaken with age and use. Look for fraying, thin
spots, or stretching of fabrics especially at edges and seams.
3. “Dropping down” into your chair will weaken fabric and result in
the need to inspect and replace the seat more often.
4. Be aware that laundering or excess moisture will reduce the
flame retardation qualities of the fabric.
5. If Tension Adjustable upholstery is present, loosen straps or
remove upholstery prior to folding or unfolding the chair.
If you fail to heed these warnings damage to your chair, a fall, tip-over
or loss of control may occur and cause severe injury to the rider or
others.
VII. WARNINGS: COMPONENTS AND OPTIONS
MK-100070 Rev. E
14

VIII. USE AND MAINTENANCE
When checking axles and axle sleeves every six months, make sure
they are clean and tight.
Loose sleeves will damage the axle plate and will affect
performance.
D. CLEANING TIPS
1. Paint Finish
a. Clean the painted surfaces with mild soap or detergent at least
once a month.
b. Protect the paint with a coat of non-abrasive auto wax every
three months.
2. Axles and Moving Parts
a. Clean around axles and moving parts WEEKLY with a slightly
damp (not wet) cloth.
b. Wipe off or blow away any fluff, dust or dirt on axles or moving
parts.
3. Upholstery
a. Hand-wash (machine washing may damage fabric).
b. Drip-dry only. DO NOT machine dry as heat will damage fabric.
4. Basic Maintenance Materials available at local store
a. Tire Pump
b. Tire pressure gauge.
c. Clean rags or cotton cloth.
d. Teflon-based Lubricant
e. Mild Detergent.
NOTE– You do not need to grease or oil the chair.
QUICKIE 2
WARNING
The owner of this chair is responsible for making sure that it has
been setup and adjusted by a trained service professional under
the advice of a healthcare advisor. The chair may require periodic
safety and function checks or certain tool free adjustments that
can be performed by the owner, caregiver or authorized dealer if
desired. Always use parts and/or accessories that have been
recommended or approved by Sunrise Medical when servicing this
chair.
1. Tire Air Pressure:
Check air pressure in pneumatic tires at least ONCE PER WEEK.
The wheel locks will not grip properly if you fail to maintain the
air pressure shown on tire sidewall.
2. Axles & Axle Sleeves:
    Make sure tire pressure is correct and
equal in both rear tires and front
caster tires, if pneumatic.
    Make sure all nuts and bolts are tight.
  Make sure all spokes and nipples are
tight on radial spoke wheels.
Use Tri-Flow Lubricant (Teflon®-based)
between frame connections and parts.
    Check for proper caster fork
adjustment. See instructions for
caster fork adjustment.
Symptom
Left turn in chair Right Turn in chair
Looseness in chair
Sluggish turning
Squeaks and rattles
Caster flutter
Solution
E. TROUBLESHOOTING CHART
A. INTRODUCTION
1. Proper maintenance will improve performance and extend the
use-ful life of your chair.
2. Clean your chair regularly. This will help you find loose or worn
parts and make your chair easier to use. You will need a mild
detergent solution and plenty of cleaning rags.
3. If discovered, repair or replace loose, worn, bent or damaged
parts before using the chair. ALWAYS be sure to use Parts and/
or acces-sories that have been recommended or approved by
Sunrise Medical.
4. To protect your investment, have all major maintenance and
repair work done by your authorized dealer.
5. Inspect and maintain this chair strictly per the maintenance chart.
6. If you detect a problem, make sure to order parts, or have service,
and repair work done at your authorized dealer before use.
7. At least once per year, have a complete inspection, safety check,
and service of your chair made by an authorized dealer.
B. SAFETY CHECKLIST
C. CRITICAL SAFETY CHECKS
NOTE - The user or caregiver should perform these weekly and
monthly checks to maintain the safety of their chair. If an item
is not working properly, please contact your authorized dealer.
Weekly
3 Months 6 Months Annually
Tire inflation level
Wheel locks
Visually check for loose hardware
Armrests
Axle and axle sleeves
Quick-release axles
Wheels, tires and spokes
Casters
Anti-tip tubes

Frame, camber tubes, and crossbrace
Upholstery

Service by Authorized Dealer
Safety & Function Check
Monthly
15
MK-100070 Rev. E

QUICKIE 2
F. TO MOUNT & REMOVE REAR WHEELS
WARNING
Do not use this chair UNLESS you are sure both quick-release axles are locked. An unlocked axle may
come off during use and cause a fall.
1. To Install Wheel
a. Depress quick-release button (A) fully. This will release tension on ball bearings at other end.
b. Insert axle (B) through hub of rear wheel.
c. Keep button (A) depressed as you slide axle (B) into axle sleeve (C).
d. Release button to lock axle in axle sleeve. Adjust axle if it does not lock. See Section B.
e. Repeat steps on other side.
NOTE– The axle is not locked until the quick-release button pops out fully (A). Check that the axle is
locked by pulling on the wheel in the direction of the axle.
2. To Remove Wheel
a. Depress quick-release button (A) fully.
b. Remove wheel by sliding axle (B) completely out of axle sleeve (C).
c. Repeat steps on other side.
WARNING
Wheel locks are installed at Sunrise and should be adjusted by your qualified service person.
Inspect wheel locks weekly per the maintenance chart. Do not use your chair UNLESS you are sure both
wheel-locks can fully engage. A wheel-lock that is not correctly adjusted may allow your chair to roll, or
turn unexpectedly.
Wheel-locks must be adjusted after making sure the tires have the correct air pressure. When fully
engaged, the arm should be imbedded into the tire at least 1/8” to be effective.
If you find the wheel locks have slipped or are not working correctly contact your service provider for
proper adjustment.
1. Inserting Anti-Tip Tubes Into Receiver
a. Press the rear anti-tip release pin (D) on the anti-tip tube so that both release pins are drawn
inside.
b. Insert into the anti-tip tube into the receiver (E).
c. Turn the anti-tip tube down until release pin is positioned through the receiver mounting hole.
d. Insert second anti-tip tube the same way.
2. Adjusting Anti-Tip Tube Wheel
The anti-tip tube wheels may have to be raised or lowered to achieve proper clearance 1 1/2" to 2".
a. Press the anti-tip wheel release pin(F) so that the release pin is drawn inside.
b. Raise or lower to one of the three predrilled holes.
c. Release pin.
d. Adjust the second anti-tip tube wheel the same way. Both wheels should be at exactly the same
height.
3. Turning Anti-Tip Tubes Up
Turn anti-tip tubes up when being pushed by attendant, overcoming obstacles or climbing curbs.
a. Press the rear anti-tip tube release pin.
b. Hold pin in and turn anti-tip tube up.
c. Release pin, and make sure the anti-tip is locked in place.
d. Repeat these steps with second anti-tip tube.
1312
H. ANTI-TIPS 14 15 16
Sunrise Medical recommends anti-tip tubes for all wheelchairs.
12
13
15
C
A
B
F
16
14
E
D
G. WHEEL LOCKS
VIII. USE AND MAINTENANCE
MK-100070 Rev. E
16

I. ARMRESTS
Sunrise medical offers several different types of armrests. Fixed, swing-away, and Flip-back armrests.
Flip-back armrests can be detached or can flip back to allow lateral transfers. They are height
adjustable (1" increments) by flipping the adjustment lever and moving the armrest pad (1) up or down
to the desired height.
1. Basic Installation
a. Slide the outer armpost (4) into the receiver mounted to the wheelchair frame.
b. The armrest should lock into place.
2. Height Adjustment
a. Release the upper securing lever (2) .
b. Slide armpad up or down to desired height.
c. Return lever to locked position.
3. Removing Armrest
a. To remove, grasp the unlocking lever (3) and pull up on the Armrest..
4. Replacing Armrest
a. Slide armrest back into receiver.
b. Make sure that the unlocking lever (3) returns to the locked position against
armpost
J. FLIP-BACK HEIGHT-ADJUSTABLE ARMRESTS
1. Installation
a. Slide the outer armpost into the receiver mounted to the wheelchair frame.
b. The armrest will automatically lock into place.
2. Height Adjustment
a. Rotate height release lever (2) to second stop.
b. Slide armrest pad (1) up or down to desired height.
c. Return lever (2) to locked position against armpost.
3. Flipping Armrest Back
a. Depress the release latch (3) and pull the armrest toward the back of the wheelchair.
b. To return armrest to operating position, push armpad down until it locks firmly into
place.
4. Removing Armrest
a. Rotate height release lever (2) to first stop and remove the armrest.
5. Replacing Armrest
a. Slide armrest back into receiver.
b. Return release lever (2) to locked position against armpost.
K. PADDED SWING-AWAY ARMRESTS
1. Installation
Slide armrest into receiver tube (A) on rear of frame.
2. Swinging Away
Lift armrest out of locked position and rotate to the side.
3. Removing Armrest
19
17
18
VIII. USE AND MAINTENANCE
QUICKIE 2
1. Armrest pad
2. Height Release Lever
3. Release lever
4. Outer armpost
5. Transfer bar
6. Side panel
7. Receiver
8. Receiver adjustment
hardware
17
1. Armrest Pad
2. Upper Securing Lever
3. Release Latch
4. Armrest Panel
5. Rear Receiver
6. Armrest Release Pin
1
2
4
5
3
6
18
19
A
WARNING
Armrest should not be used for lifting or carrying the wheelchair. Always
check that the armrests are correctly engaged.
There is a risk of trapping fingers when adjusting the armrests.
Pull armrest straight out of receiver.
The Padded Swing Away Armrest is primarily use for resting the forearms of the chair's occupant.
It is not designed to be a transfer arm for the wheelchair. You should always remove the the
armrests or swing them out of the way during transfers. The armrests are not designed to be used
for any activity that puts full body weight on them, such as transferring using this armrest.
Failure to follow these instructions can result in severe injury, decreased chair integrity and may
void the warranty.
WARNING
Padded swing away armrests are not transfer devices and must be rotated out of the way prior
to transferring. Failure to do this on a regular basis can result in decreased chair integrity and
may void the warranty.
17
MK-100070 Rev. E

QUICKIE 2
L. FOOTRESTS, LEGRESTS, & FOOTPLATES
Make sure that your Sunrise dealer has correctly adjusted your footrests and/or legrests with the advice
of a healthcare professional. The original setup should not be changed without first checking with that
advisor. The footrest position is key to keeping your body in the proper alignment, and providing a stable
support for your legs and torso. Legrests and footrests should be swung out of the way, or removed for
transfers.
Swing-in-Swing-out Hangers and Footrests (60°, 70º, 80°)
1. Basic Footrest Installation
a. Place swing-in/swing-out pivot saddle into the receiver (A) on front frame tube with the
footrest facing inward or outward from the frame.
b. Rotate the footrest inward until it locks into place on locking plate.
2. Removal
a. To remove footrest, release latch (B) by pulling lever upward or pushing lever downward.
b. Rotate footrest inward or outward and lift.
5. ELR Installation or Removal
To install or remove Elevating Legrest (ELR) see instructions for Swing-away
Footrest installation.
6. Elevation Adjustment
a. To raise legrest, lift to desired position. Legrest will automatically lock in place.
b. To lower legrest, while seated in chair, press release lever (D) down and lower legrest to
desired position. Legrest will automatically lock in place.
Flip-up the Footplate when transferring from your wheelchair.
20
3. ALR Installation or Removal 21
To install or remove Articulating Legrest (ALR) see instructions for Swing-away Footrest installation.
4. Elevation Adjustment
a. To raise legrest, lift to desired position. Legrest will automatically lock in place.
b. To lower legrest, while seated in chair, press release lever (C) down and lower Legrest to
desired position. Legrest will automatically lock in place.
22
7. Flipping up the Platform Footplate 23
VIII. USE AND MAINTENANCE
20
23
B
A
Elevating
legrest
22
D
Articulating
legrest
21
C
MK-100070 Rev. E
18

M. Z-FINITY™ FOOTREST SYSTEM
CAUTION– The Z-Finity™Footrest system is rated to 165lbs (75kg)
With the footrest system, Sunrise Medical offers either a single Flip-up Footplate (B), or dual footplates (C)
that are able to accomodate all of the possible heights and adjustment angles that the rider may require
for their comfort and support.
1. Basic Footrest Installation
a. From the side, place the pivot (E) into the top of the frame tube which guides the hanger into the
cor-rect alignment with the locking plate (F) on front frame tube.
b. Rotate the footrest towards the front of the chair until it locks into place on locking plate.
2. Removal
a. To remove footrest, release latch (G) by pulling lever upward or pushing lever downward.
b. Rotate footrest inward or outward and lift.
24 25
Z-FINITY™ SWING-AWAY FOOTREST 25 26
The footrest system can also accomodate a swing-away hanger(D) with dual footplates (C) that are both
height adjustable and angle adjustable.
Swing-in-Swing-out Hangers and Footrests (80°) 25
D
24
B
C
26
E
G
F
QUICKIE 2
VIII. USE AND MAINTENANCE
19
MK-100070 Rev. E

N.BACKRESTS AND BACK UPHOLSTERY
1. Backrest/Stroller Handles
Quickie 2 wheelchairs with depth adjustable backs are shipped with the backrest/stroller handles
(A) in a folded position. To secure backrest/stroller handles, lift backrest/stroller handles to upright
position. When secured, backrest release pin will lock into place.
2. Backrest Upholstery
Check monthly for excessive stretching of the upholstery, or loose attaching hardware. If you deter-
mine the upholstery is no longer tight, contact your service representative for a replacement.
3. Solid Back Insert
Place the solid back hook clamps (B) on the stroller handles (A). Insert the quick release pins (C)
through the mounting holes on the top two hook clamps.
O.SWING-AWAY ADJUSTABLE STROLLER HANDLES
Positioning Swing-Away Adjustable Stroller Handles (option)
Loosen push handle (D) by turning knob (E) counter-clockwise. Raise or lower push handle (A) to
desired height. While holding push handle (D) in one hand, raise retaining ring (F) with knob (E) upward
into locking slot with other hand.
NOTE: Locking slot is hidden under retaining ring . When knob is raised into locking slot (D) push handle
cannot rotate. Dropping into lower slot ( E ) allows push handle to swing in. To secure push
han-dle, turn knob clockwise.
NOTE: For easy storage and portability, push handles will swing in and stroller handles fold flat.
1. Adjustment
a. Remove seat rail end caps at the front of the chair (F).
b. Slide the seat sling, plastic retaining rods, and spacers (if present) from the channels in the seat
rails.
c. Readjust hook and loop material to obtain the desired tension in the seat sling.
d. Reinsert the seat sling and plastic retaining rods into the channels in the seat rails.
e. Replace the end caps.
2. Seat sling Upholstery
a. Check monthly for excessive stretching of the upholstery, or loose attaching hardware. If you
determine the upholstery can no longer be adjusted tight, contact your service representative for
a replacement.
3. Cushion Installation
a. Place cushion on the seat sling with hook material side down. The beveled edge of the cushion
should be facing toward the front of your chair.
b. Press firmly into place.
2928
P.SEATING AND SEAT SLING UPHOLSTERY 30
The seat sling can be adjusted through the use of hook and loop material beneath the seat. Seat
sling also includes a folding strap on the seat to assist in folding the chair.
NOTE– The seat sling folding strap is not intended as a carrying strap.
27
QUICKIE 2
27
28
B
A
C
D
E
F
G
H
I
29
30
VIII. USE AND MAINTENANCE
MK-100070 Rev. E
20
