INSTALLATION GUIDE
SPECIALTY SERIES FANS

2QUIETCOOLSYSTEMS.COMQUIETCOOLSYSTEMS.COM
GENERAL SAFETY INSTRUCTIONS
1. Read Instructions - All safety and operation instructions must be read. Failure to read and follow
instructions as stated in this guide may void applicable warranty.
2. Retain Instructions - The safety and operating instructions should be kept for future reference.
3. Heed Warnings - All warnings should be followed.
4. Follow Instructions - All installing and operating instructions should be followed.
5. Heat - The QuietCool system should be situated away from heat sources.
6. Damage Requiring Service - Only qualified service personnel should service the QuietCool system.
The user should not attempt to service the product.
7. Building Codes - Always follow Local Building Codes when installing appliances
CONTENTS
1. SYSTEM OVERVIEW......................................................1
1.1 Introduction.......................................................1
1.2 Features ..........................................................1
1.3 Benefits...........................................................2
1.4 System Venting Requirements .....................................2
2. INSTALLATION ..........................................................3
2.1 Installing AFG Model Fans..........................................3
2.2 Installing GA Model Fans...........................................4
2.3 Installing GX Model Fans ...........................................5
2.4 Installing RM Model Fans ..........................................6
3. WIRING .................................................................8
3.1 Wiring with a Thermostat ..........................................8
3.2 Wiring with a Timer ...............................................10
4. SYSTEM OPERATING INSTRUCTIONS ................................... 11
4.1 QuietCool Attic Fans .............................................. 11
4.2 QuietCool Garage Fans ............................................ 11
4.3 QuietCool Roof Mount Fans ....................................... 11
SPECIALTY SERIES OVERVIEW ............................................12
WARRANTY ...............................................................13
QC Manufacturing, Inc.
43352 Business Park Drive
Temecula, CA 92590
PH 951.325.6340
FX 951.325.6351
QuietCoolSystems.com

3
1-888-QUIETCOOL 11-888-QUIETCOOL
1. SYSTEM OVERVIEW
1.1 Introduction
Congratulations on the purchase of your new QuietCool Specialty Series Fan!
The QuietCool Specialty Series was designed for almost every application imaginable. QuietCool Specialty
Series fans dominate the market in energy efficiency. Our Specialty Series fans work great in practically all
climate zones and most homes, mobile homes, and even warehouse buildings!
QuietCool Attic Fans: The QuietCool Attic Fans help cool your attic, and keep your home from heating up
as quickly on very hot days. We offer two great models: the AFG ES-1500, the most energy efficient attic fan,
and the AFG CON-3.0, the most powerful residential attic fan. Both fans have stellar energy efficiency and
astounding airflow.
QuietCool Garage Fans: The QuietCool Garage Fans offer great ventilation options for your garage, man cave,
or workshop. We offer the GA ES-1500 to ventilate both your garage and attic, and the GX ES-1100 to ventilate
your garage only, with a wall mount design.
QuietCool Roof Mount Fans: The QuietCool Roof Mount Fans offer great versatility for most applications.
QuietCool Roof Mount Fans can be used as an attic fan, as a whole house fan with a duct, or as a whole house
fan that pulls air through air intake grilles in multiple rooms.
1.2 Series Features
• High Efficiency Design
• Designed and Built in California
• 10 Year Warranty
• Attic Gable Fans
• Garage Fans
• Roof Mount Fans

2QUIETCOOLSYSTEMS.COM
1.3 Benefits
1.4 System Venting Requirements
VERY IMPORTANT - Be sure to install enough inlet and outlet venting as described in the
following table:
Fan Model Required Inlet Venting* Required Outlet Venting** Airflow
AFG CON-3.0 4 SQ. FT. 4 SQ. FT. 3013 CFM
AFG ES-1500 2 SQ. FT. 2 SQ. FT. 1560 CFM
GA ES-1500 2 SQ. FT. 2 SQ. FT. 1452 CFM
GX ES-1100 1.5 SQ. FT. N/A
(Exhausts Directly to Outside) 1103 CFM
RM ES-1100 1.5 SQ. FT. N/A
(Exhausts Directly to Outside) 1130 CFM
RM ES-2200 3 SQ. FT. N/A
(Exhausts Directly to Outside) 2245 CFM
* Inlet Venting includes openings such as windows, door, gable vents, ridge vents, eaves vents, etc. to allow air
to be pulled from the outside.
** Outlet Venting includes openings such as gable vents, ridge vents, eaves vents, etc. to allow air to be
exhausted from the attic.

3
1-888-QUIETCOOL
2. INSTALLATION
2.1 Installing AFG Model Fans
NOTE: The AFG model fans are designed to mount behind existing gable vent louvers. If no
louver exists, one must be installed. Louver should be installed in the upper center section
of the gable. For maximum efficiency, the area of the louver should be greater than the size
of the ventilator. Any louver area not covered by the ventilator should be sealed off to
prevent any possible air leakage.
Installing the QuietCool AFG is very easy. The mounting tabs on the AFG should be attached to the Attic
Gable Fan. Use the mounting hardware included in the box to fasten the gable fan to the boards that frame
the gable vents. To install the AFG, simply mount the gable fan to your gable vents as shown in the following
steps:
1. Flush Mount: The AFG can be mounted flush to a rectangular type
louver by fastening through the mounting brackets to the frame of
the louver (as shown in Figure 2.1A).
As stated in the note above, any area of the louver that is not covered
by the AFG should be sealed off to prevent air leakage.
This is the most conventional method of mounting the AFG.
We recommend using the Flush Mount option if possible for all
applications.
2. Wide Mount: The AFG can be mounted on a wide louver, but
additional mounting steps must be taken in order for the fan to
work properly. As shown in Figure 2.1B, two additional boards must
be fastened to the boards framing the gable vent so the AFG can be
mounted securely.
As stated in the note above, any area of the louver that is not
covered by the AFG should be sealed off to prevent air leakage.
Figure 2.1A
Figure 2.1B

4QUIETCOOLSYSTEMS.COM
3. Odd Mount: The AFG can also be mounted off center for an
odd shaped louver (as shown in Figure 2.1C).
As stated in the note above, any area of the louver that is
not covered by the AFG should be sealed off to prevent air
leakage.
While this is not the most ideal way to mount the gable fan, it
is possible. However, since the fan is not completely covering
the vent, maximum airflow will not be achieved.
NOTE: The AFG can be mounted on many other types of louvers, including triangle
vents, round vents, half-round vents, etc. If the vent is smaller than the area of the
fan, we recommend constructing a chamber that surrounds the vent, and then mount
the AFG to the chamber to ensure maximum airflow and performance.
2.2 Installing GA Model Fans
VERY IMPORTANT: MINIMUM OF 26” CLEARANCE REQUIRED ABOVE CEILING FOR
INSTALLATION OF GA MODEL FANS.
1. Determine which ceiling area you would like to install your QuietCool Garage Attic Fan. Now it’s time to
find the exact location using a stud finder. Locate the ceiling studs and mark the location for the fan
to be installed (see Figure 2.2A). One side of the cut out should be directly next to a wood member
for proper fan mounting and support.
2. When you find the location, mark a 14 1/4” square using a framing square or template. Make sure you
have 2” of clearance all the way around it. The grille that will be installed later is a 16” square (see
Figure 2.2B).
3. Starting at one corner of the square using a drywall saw, cut out the opening. Remove the drywall
cutout and clear away insulation (if applicable) (see Figure 2.2C).
4. Take the GA fan model into the attic and place it over the ceiling cut out. Attach the fan using screws
into the ceiling joists (see Figure 2.2D). Install the ceiling grille.
VERY IMPORTANT: CHECK TO MAKE SURE FAN BLADE SPINS FREELY AND THE FIRE DAMPER
CLOSES EASILY. MAKE SURE TO SECURE THE LATCH IN THE OPEN POSITION.
AVOID BACKDRAFTS: MAKE SURE THE GARAGE FAN HAS ENOUGH CONTINUOUS INLET
VENTING (AS SHOWN IN SECTION 1.4) TO AVOID BACKDRAFTING COMBUSTION APPLIANCES
IN THE GARAGE.
Figure 2.1C

5
1-888-QUIETCOOL
2.3 Installing GX Model Fans
1. Determine which area you would like to install your QuietCool Garage Exterior Mount Fan. Now it’s time
to find the exact location using a stud finder. Locate the wall studs and mark the location for the fan
to be installed on the wall (similar to Figure 2.2A). One side of the cut out should be directly next to
a wood member for proper fan mounting and support.
2. When you find the location, mark a 14 1/4” square using a framing square or template. Make sure you
have 2” of clearance all the way around it. The grille that will be installed later is a 16” square (similar
to Figure 2.2B).
3. Starting at one corner of the square using a drywall saw, cut out the opening. Remove the drywall
cutout and clear away insulation (if applicable) (similar to Figure 2.2C).
4. From the interior, drill a hole through the exterior at the four corners of the cut out (see Figure
2.3A).
5. Go to the exterior and place the square wall mounting bracket aligned to the 4 drilled holes. Using a
level, mark the inside of the bracket with a pencil (see Figure 2.3B).
6. Using a saw or angle grinder, cut out the marked area of stucco or siding (see Figure 2.3C).
7. Remove cut out of exterior stucco or siding. Then cut out any applicable sheathing.
8. Now install the exterior cover frame. Make sure the frame is level and then attach the four corners
with long enough screws to penetrate the wood studs. Note: Predrilling may be required (see Figure
2.3D).
Figure 2.2A Figure 2.2B Figure 2.2C Figure 2.2D
Figure 2.3A Figure 2.3B Figure 2.3C Figure 2.3D

6QUIETCOOLSYSTEMS.COM
9. Place fan into the cut out area. Fasten the fan in each 4 corners to the vertical wood studs (see
Figure 2.3E).
10. Caulk exterior around frame (see Figure 2.3F).
11. Attach the exterior cover to mounting frame using 4 sheet metal screws (see Figure 2.3G).
12. Mount inside wall grille (see Figure 2.3H).
2.4 Installing RM Model Fans
1. Determine which roof area you would like to install your QuietCool Roof Mount Fan. (see Figure 2.4D)
IMPORTANT: If you are installing the RM fan as a ducted whole house fan, move on to step 2a. If
you are installing the RM fan as a whole house fan without a duct, move on to step 2b. If you are
installing the RM fan as an attic fan, for homes with an attic space, move on to step 3.
2a. When installing your RM fan as a ducted whole house fan, find the exact ceiling location for your
ceiling box using a stud finder. Be sure that the ceiling box will fit between the ceiling box location
and fan location with a minimum of 20” clearance. Now, using a drywall saw, cut out the drywall (using
the rough opening measurements shown in Figure 2.4A).
2b. When installing your RM fan as a whole house fan without a duct, find the exact ceiling location for
your ceiling damper grille using a stud finder. Now, using a drywall saw, cut out the drywall (using the
rough opening measurements shown in Figure 2.4A). Install your ceiling damper grille.
3. Mark the location for the roof mount fan. (using the rough opening measurements shown in
Figure 2.4A)
4. Move to the roof and, using a circular saw, cut out the square. (see Figure 2.4B)
5. With the square cut out, place the roof mount fan over the cutout. (see Figure 2.4C)
6. Fasten the fan to the roof using appropriate connectors for your roof material.
7. Fasten and flash in fan curb using appropriate weatherproofing and materials based on roof material.
8. If installing the RM fan as a ducted whole house fan, install the duct to the fan. Place the ceiling
box in the cutout and attach the duct. Install the ceiling box by fastening it to the ceiling joists.
(similar to Figure 2.2D). Install the ceiling grille. (similar to Figure 2.3H)
Figure 2.3E Figure 2.3F Figure 2.3G Figure 2.3H

7
1-888-QUIETCOOL
Fan Model Roof Rough
Opening
Ceiling Rough
Opening
RM ES-1100 14 1/4” x 14 1/4” 14 1/4” x 14 1/4”
RM ES-2200 16 1/4” x 16 1/4” 14 1/4” x 18 1/4”
EXTREMELY IMPORTANT: It is very important that you install the RM fans correctly, as shown
in the following diagram, as it will dramatically affect the sound level of the fan. NEVER install the
ceiling grille directly underneath the fan. We recommend a grille offset of 3 to 4 feet.
Figure 2.4A Figure 2.4B Figure 2.4C
Figure 2.4D: Roof Mount Application Diagrams
Flat Roof - No Duct: Works with CRB and FLT Models
Sloped Roof - No Duct: Works with SLP Models
Flat Roof - With Duct: Works with CRB and FLT Models
Sloped Roof - With Duct: Works with SLP Models

8QUIETCOOLSYSTEMS.COM
3. WIRING
NOTE: Wiring Diagrams are for examples ONLY. Wiring should be done by an experienced
electrician.
3.1. Specialty Fan Wiring - Thermostat (see Figure 3.1A)
For wiring of a Specialty Series Fan with a thermostat. This wiring method works with all of our Specialty
Series fans, but we do NOT recommend using it with a Roof Mount fan that is being used as a whole house
fan. All fans wired on a thermostat must have enough continuous inlet venting (as stated in section 1.4).
1. For this installation, you will need a 2 wire Romex, and a thermostat.
2. Open up the junction box that is connected to the fan. Bring your 2 wire romex from the power source
into the junction box.
3. With a wire nut, tie the white common wires together. Using the green ground screw, ground the green
wire from the fan to the handy box.
NOTE: If you are NOT installing the thermostat in the junction box on the fan, continue to
step 7 to wire the thermostat.
4. With the thermostat, tie the black wire from the fan to the red wire on the thermostat.
5. Tie the two remaining black wires together.
6. Using the ground screw on the thermostat, ground your power source. Mount thermostat to junction
box.
Wiring the Thermostat Remotely (see Figure 3.1B)
7. Mount an electrical box for your thermostat in the best location for thermostat readings. Begin wiring
the thermostat.
8. With a 2 wire Romex, tie the black wire to the black wire from the thermostat.
9. Tape the white common wire on both sides of the 2 wire Romex because we will be using this as our
switch leg.
10. Tie the red wire and the taped white wire together.

9
1-888-QUIETCOOL
Figure 3.1A: Thermostat Wiring at the Junction Box
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box Thermostat
Power
Source
Ground the Power to the Green
Ground Screw on the Thermostat
14-2 Wire
OFF
55
65
75
85
50 60 70 80 90
14-2 Wire
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box Thermostat
Power
Source
Ground the Power to the Green
Ground Screw on the Thermostat
14-2 Wire
OFF
55
65
75
85
50 60 70 80 90
14-2 Wire
Figure 3.1B: Thermostat Wiring in a Remote Location
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box
Power
Source
14-2 Wire
OFF
55
65
75
85
50 60 70 80 90
14-2 Wire
14-2 Wire
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box
Power
Source
14-2 Wire
OFF
55
65
75
85
50 60 70 80 90
14-2 Wire
14-2 Wire
11. Attach the ground wire to the ground screw on the timer.
12. In the fan’s junction box, tie the black wire from the fan to the taped white wire.
13. Tie the two remaining black wires together. Then, tie the remaining copper wires together.

10 QUIETCOOLSYSTEMS.COM
3.2. Specialty Fan Wiring - Timer (see Figure 3.2A)
For wiring of a Specialty Series Fan with a timer. This wiring method works with all of our Specialty Series fans.
We recommend using this method if installing a Roof Mount fan as a whole house fan. This also works well
with a Garage fan.
1. For this installation, you will need a 2 & 3 wire Romex, and an 8 Hour Timer.
2. Begin wiring the timer. From your 3 wire Romex, using a wire nut, tie the two red wires together, the
two white wires together, the two black wires together, and the two ground wires together (copper
and green).
3. Open up the junction box that is connected to the fan. Bring your 2 wire and 3 wire into the junction
box.
3. Tie the white common wires from the fan, the power source, and the timer together. Then, using the
green ground screw, ground a copper jumper wire and the green wire from the fan to the handy box.
4. With a wire nut, tie the black wire from the fan to the red wire from the timer.
5. Then, tie the black wire from the power source to the black wire from the timer.
6. Lastly, tie the copper ground wire from the power source and the copper jumper wire from the fan to
the copper ground wire coming from the 14-3 wire from the timer.
Figure 3.2A
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box
Power
Source
14-2 Wire
14-2 Wire
8 HOUR
4 HOUR
2 HOUR
1 HOUR
HOLD
Bare Copper Wires Tied
Together
Match Wire
Colors Together
14-3 Wire
Ground the fan to the junction box
using the green ground screw
Specialty Series Fan
Junction
Box
Power
Source
14-2 Wire
14-2 Wire
8 HOUR
4 HOUR
2 HOUR
1 HOUR
HOLD
Bare Copper Wires Tied
Together
Match Wire
Colors Together
14-3 Wire

11
1-888-QUIETCOOL
4. SYSTEM OPERATING INSTRUCTIONS
4.1 QuietCool Attic Fans
QuietCool Attic Fans work almost everywhere, almost anytime. During the summer, an attic can be 40-50
degrees hotter than the outside temperature, which in turn heats up the house much faster. With an attic
fan, you can cool the attic to almost the same temperature as it is outside, greatly reducing the house from
heating up as quickly. Set your thermostat to the recommended 85-90°F and forget about your QuietCool
Attic Fan. You will probably not even realize it was running when you look at your electric bill, either.
4.2 QuietCool Garage Fans
QuietCool Garage Fans work great to cool your garage, man cave, or workshop. Our two models work for
different applications. Our GA ES-1500 works to cool and ventilate your garage and the attic above your
garage. This greatly reduces the heat transfer between the attic and garage on really hot days. Our GX ES-
1100 works well to cool and ventilate your garage. Run both of these fans when it is cooler outside than it is in
your garage.
Don’t let your garage get hot and worry about damage to your vehicles, motorcycles, boat, etc.; just flip on
your QuietCool Garage Fan!
4.3 QuietCool Roof Mount Fans
The QuietCool Roof Mount Fans are the most versatile fans that we offer. They can be used as an attic fan, a
whole house fan with a duct, or a whole house fan with multiple inlet vents. QuietCool Roof Mount Fans also
work where a conventional QuietCool Whole House Fan will not. Roof Mount fans work with homes that have a
sealed attic, manufactured homes with no attic, homes with cathedral ceilings, and even industrial buildings
such as warehouses.
If you installed your Roof Mount as a whole house fan, run the fan when it is cooler outside than it is inside
your home. Be sure to crack open a few select windows in your home and let the Roof Mount fan do the rest.
If you installed your Roof Mount as an attic fan, set your thermostat and let it run! When installed as an attic
fan, it is effective almost everywhere, almost anytime.
If you have any trouble installing or operating your new QuietCool Specialty Series Fan, please visit our
website at www.QuietCoolSystems.com or call us at 951-325-6340 for support.
Quiet Cool is proudly designed and built in California.

12
AFG CON-3.0
The AFG CON-3.0 is the most powerful residential attic fan. At a great
12.1 CFM/Watt, this fan won’t break the bank either.
Watts Airflow CFM/Watt
250 3013 CFM 12.1
AFG ES-1500
The AFG ES-1500 is the most energy efficient attic fan.
Watts Airflow CFM/Watt
52 1560 CFM 52
GA ES-1500
The GA ES-1500 is the perfect fan to cool your garage
and attic for pennies an hour.
Watts Airflow CFM/Watt
47 1452 CFM 30.8
GX ES-1100
The GX ES-1100 is the perfect fan to cool and ventilate
your garage, man cave, or workshop through the wall.
Watts Airflow CFM/Watt
69 1103 CFM 15.9
RM ES-1100
The RM ES-1100 is the perfect fan to cool and ventilate
your attic, home, or warehouse building. The RM line is extremely
versatile offering almost any application imaginable.
Watts Airflow CFM/Watt
66 1130 CFM 17.1
RM ES-2200
The RM ES-2200 is the perfect fan to cool and ventilate
your attic, home, or warehouse building. The RM line is extremely
versatile offering almost any application imaginable.
Watts Airflow CFM/Watt
197 2245 CFM 11.4
Ultra Energy Efficient ECM Motor =
SPECIALTY SERIES OVERVIEW

13
1-888-QUIETCOOL
SPECIALTY SERIES FANS LIMITED WARRANTY
10 YEAR LIMITED WARRANTY
QUIETCOOL SPECIALTY SERIES FANS
PRODUCT INFORMATION
QC Serial # QC Serial #
QC Serial # QC Serial #
QC Manufacturing Inc. extends this warranty to the original purchaser of the following QuietCool
Specialty Series Fans ---- AFG CON-3.0, AFG ES-1500, GA ES-1500, GX ES-1100, RM ES-1100, RM ES-2200
---- installed and used in a residence under normal conditions within the United States:
A. Ten year coverage applies to the QuietCool motor fan assembly. At our option we will repair or
replace any part of the assembly should it fail to operate during the rst ten years from the date
of original purchase.
B. One year coverage for all other components including grills, housings, controls and accessories
furnished by QC Manufacturing Inc. At our option we will repair or replace any part which fails as a
result of defective material or workmanship during the rst year from the original date of purchase.
C. This warranty does not cover any of the following:
1. Incidental or consequential damage resulting from the operation of our equipment or any
malfunction thereof.
2. Cost of service calls to diagnose the cause of problems or the labor charge to un-install or install
any components.
3. Product failure or damage due to faulty installation including motor issues caused by incorrect
wiring, abuse, misuse, unauthorized alteration to factory specs, lack of maintenance, or
transportation damage.
4. Shipping or postage for warranty claims.
D. To obtain service under this warranty, contact the dealer where you purchased the equipment.
If you are unable to nd or reach your dealer, contact Customer Service at QCManufacturing, Inc.,
at the address below.
E. Please register your product(s) for warranty on line at www.QuietCoolSystems.com
This warranty is the only warranty extended by QC Manufacturing, Inc. to purchasers or suppliers of our equipment. QC Manufacturing Inc. disclaims all
other warranties, express or implied. Any additional warranties offered by third party contractors installing or distributing QuietCool are made without the
express consent of QC Manufacturing, Inc.
Product Registration: Please register your product online at www.QuietCoolSystems.com/support/registration Be sure to keep a copy of this warranty form for future
reference and submit proof of purchase with any warranty claim. QC Manufacturing, Inc. will not process any warranty claim without proof of purchase from an
authorized QuietCool dealer. Where consumer may have additional warranty rights in accordance with federal and state law, such rights shall supersede those stated
herein."
Rev. 8.05.14

14
1-888-QUIETCOOL
QuietCool is Proudly Designed and Built in California
43352 Business Park Drive, Temecula, CA 92590 // PH 951.325.6340 // QUIETCOOLSYSTEMS.COM
