Quoizel CYP8409WT Mounting instructions

Part Description Quantity
A Crossbar 1pc.
1pc.
2 pcs.
2 pcs.
2 pcs.
2 pcs.
Rippled Glass
B
C
D
E
F
Hex Nut
Lock Washer
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
A
B
C
D
E
Mounting Ball
Mounting Screw
1of6
October2011
ToolsRequired:Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wire
strippers,electricaltape,safetyglasses.
EstimatedAssemblyTime:20-30 minutes
BulbRecommended: (1)MediumBase100WMaximum
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
3pc.
Fixture Body
G
F
Sandblasted Glass 3pc.
H
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
Lock Screw 3pc.
I
3pc.
JTab
G
H
I
J
Assembly Instruction Sheet #IS-CYP8409WT
For Style CYP8409WT

1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
2of6
GND
2.4mm
13Ga
QUOIZEL R
(1)100W A19
Medium Base Bulb
(Not Supplied)
G2997PA PANEL CLEAR THICK /SANDBLASTED 3
G2996PA PANEL RIPPLED GLASS 5.5"W 3
CYP8409WT
FINISH: WESTERN BRONZE
4.5"
9"
9"
12"
10"
6.5"
10.5"

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
3of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
October2011
STEP 1 Remove Cap from Fixture Hood-
A. Remove the Fixture Hood from the Fixture Body by
unscrewing the Screw.
Fixture Body
Fixture
Hood
Screw
Figure 1
Figure 2
Crossbar
Mounting
Screw
Lock Washer
Hex Nut
Fixture
Body
STEP 2 -Attach Mounting Screws, Lock
Washers and Hex Nuts to Crossbar
A. Line up a set of holes on the Crossbar (A) and Holes on
the backplate of the Fixture Body (F).
B. Thread Mounting Screws (B) into the holes on the
Crossbar (A), pass Lock Washers (C) and thread Hex
Nut (D) onto the Mounting Screws (B). Hand tighten
until snug.
STEP 3 -Attach Crossbar to Outlet Box
A. Attach the Crossbar (A) to Outlet Box and secure by
threading Outlet Box Screws (not supplied) into the
Mounting Holes on the Outlet Box. Tighten until snug.
Crossbar
Outlet
Box
Outlet Box
Screw
Mounting
Hole
Figure 3
Assembly Instruction Sheet #IS-CYP8409WT
For Style CYP8409WT

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
4of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
October2011
Figure 4
STEP 4 Make Wire Connections-
A. Use standard wire connectors to make all wire
connections. (Connectors are not included with fixture.)
Strip and prepare wire ends according to instructions
supplied with connectors.
B. Connect White Supply Wire from the Outlet Box to White
Wire from fixture.
C. Connect Black (or Red) Supply Wire from the Outlet Box
to Black Wire from fixture.
D. Connect Ground Wire from the Outlet Box to Ground
Wire from fixture.
E. Twist connectors until wires are tightly joined together.
F. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Outlet Box.
Figure 5
White wire from supply White wire from fixture
Black wire from supply
(or Red)
Black wire from fixture
Ground wire from supply Ground wire from fixture
STEP 5 -Attach Fixture Body to Mounting
Screw
A. Place the backplate of the Fixture Body (F) over the
Mounting Screws (B) and secure with Mounting Balls
(E). Hand tighten until snug.
Mounting Screw
Mounting Ball
Backplate Figure 6
Assembly Instruction Sheet #IS-CYP8409WT
For Style CYP8409WT

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
5of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
October2011
Figure 8
Socket
Bulb
STEP 7 Install Bulb-
A. This fixture uses standard bulb with a standard screw base.
Maximum 100 watts.
B. Insert bulb and screw properly into place.
STEP 6 Attach Shade to Shade Frame-
A. Place the Rippled Glass (G) and the Sandblasted Glass H
into the Shade Frame properly, Place the Tab (J) pinned
thethe Rippled Glass (G) and the Sandblasted Glass H .
By using the Flathead screwdriver, thread the Lock screw (I)
into the lock hole of Tab on the top of Shade Frame to secure
the the Rippled Glass (G) and the Sandblasted Glass H .
Tighten until snug.
()
()
()
Rippled Glass
Sandblasted Glass
Tab
Lock Screw
Shade Frame
Figure 7
Assembly Instruction Sheet #IS-CYP8409WT
For Style CYP8409WT

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2011 QuoizelInc.
6of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
October2011
STEP 9 Apply Silicone Sealer to Mounting
Balls
-
A. To prevent moisture from entering the wire
compartment, apply a small amount of silicone sealer
(not included) to the threaded side of the mounting
balls (E) and then install them onto the mounting
screws (B). Wipe off excess caulk.
Figure 10
Mounting Ball
STEP 10 Apply Silicone Sealer to Backplate-
A. Make sure exterior wall surface and fixture backplate
are free of dirt before applying caulk. Using exterior
grade caulk, start on one side of fixture backplate and
follow contour, where the fixture backplate meets the
exterior wall surface upward. Proceed to caulk over top
of backplate and down other side. Do not caulk bottom
of fixture backplate to ensure proper moisture
drainage.
Your lamp wall fixture is now assembled and ready to
use. Enjoy!
Exterior
Grade Caulk
Outdoor Fixture
Backplate
Exterior
Wall Surface
Figure 11
Fixture
Hood
Screw
STEP 8 -Attach Fixture Hood
A. Secure the Fixture Body to the Shade Holder with Lock
Screws.
Fixture Body
Figure 9
Assembly Instruction Sheet #IS-CYP8409WT
For Style CYP8409WT
