Quoizel INF8407EK User manual

Mounting Screw
x 2
DD
SAFETY INFORMATION
Fixture Body
x 1
INSTALLATION GUIDE FOR INF8407EK, INF8409EK
Released Date: 2020-12-29
CARE AND MAINTENANCE
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am – 5:00pm EST), or visit us on-line at www.quoizel.com.
PACKAGE CONTENTS
MOUNTING HARDWARE
A
Shade
x 1
BSocket Collar
x 1
C
Inner Backplate
x 1
AA Outlet Box Screw
x 2
CC
Wire Connector
x 3
BB
- 1 -

1
INSTALLATION
Green ground screw
Rectangle/Square Backplate Round Backplate
Black (or red) wire from supply
Ground wire from supply
White from fixture
Black from fixture
Ground wire
from fixture
White wire from supply
5
Install one correct bulb referring to fixture markings and/or
labels for maximum wattage.
Recommended Bulb type (not included):
Your installation is now complete! Restore electricity and save this sheet for future reference.
Apply Caulking (Backplate shape is varies depends on items
purchased)
*Note: Do NOT caulk the bottom of the backplate to allow
moisture to escape.
Install Inner Backplate
3
6
Install Bulb
2
Wiring
Exterior Caulk Exterior Caulk
Exterior Caulk
Exterior Caulk
Exterior Caulk
Exterior Caulk
- 2 -
BULB BASE TYPE
Medium (E26)
BULB SHAPE
TYPE A
100W
MAX
Install Fixture Body Install Shade
4
