Quoizel WWD8409IB User manual

Package Contents
Warnings and Cautions
1of2
For Style WWD8409IB
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
A
Crossbar
Assembly
x1
Pleasegoto forproductcleaningtips.Gotothe selection.
(1)A21MediumBasebulb150WMaximum,bulbnotincluded.
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.
www.quoizel.com Care + Maintenance
LightSource:
EstimatedAssembly Time:
Preparation:
Fixturecanonlybemountedinthedirectionindicatedonpage2.
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
MissingParts?Contactyouroriginalplaceof
purchase.
Fixture Body
x1 BMounting Ball
A
Backplate
Hex Nut and
Lock Washer
Mounting Screw
B
STEP 1 Remove Styrofoam inside
of the Cage
-
Figure 1
STEP 2 Installing the Crossbar Assembly-
A. Pass the supply wires through the Crossbar Assembly (A). Attach
the Crossbar Assembly (A) to the Outlet Box with the head of the
Green Ground Screw facing you. Secure the Crossbar Assembly (A)
with Outlet Box Screws (not included). Tighten until snug.
Supply Wires
with Ground Wire
Outlet Box Screws
(not included)
Outlet Box
A
Figure 2
STEP 4 - Wire Connections
A. Wrap bare or green ground wire around green ground screw on the
crossbar, no less than 2 inches from the end of the wire. Tighten the
green ground screw.
B. Use standard wire connectors (not included) to make all wire
connections. Twist connectors until wires are tightly joined together.
Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
Figure 4
Green Ground Screw
on the Crossbar
White wire
from outlet box White wire
from fixture
Black wire from
outlet box (or Red)
Black wire
from fixture
Bare, or Green
Ground wire
from outlet box
Ground wire
from Fixture
STEP 3 Test Fit the Backplate to the Crossbar Assembly-
A. Remove the mounting balls from the Crossbar Assembly (A). Place
the backplate and Fixture Body (B) onto the Crossbar Assembly
(A) and secure with mounting balls. Note: The backplate and
Fixture Body (B) should be snug against the wall and held tight
with the mounting balls. If it is not, adjust the length of the
mounting screws on the Crossbar Assembly (A) by unscrewing the
preassembled hex nut and lock washer and then screwing the
Figure 3
mounting screws in or
out of the crossbar until
the correct length is
achieved. Once the
backplate and Fixture
Body (B) is secure,
remove the mounting
ball and Fixture Body (B)
and proceed to Step 4.
Cage
2018 QuoizelInc. ReleasedDate:2018-04-04
visit us on-line at www.quoizel.com
Styrofoam
(Remove)
Installation Guide #IS-WWD8409IB

2of2
Socket
Bulb (not
included)
Exterior
Grade Caulk
Backplate
Exterior
Grade
Caulk
WWD8409IB
FINISH: IMPERIAL BRONZE
NOTE: ALL DIMENSIONS ARE ROUNDED
UP TO THE NEAREST 1/4"
Fixture can
only be
mounted in
the direction
indicated
Screw
Glass Panel Holder
Glass Panel
Cage
8"
2.5"
4.75"
18"
9.5” 9.25” SQ.
STEP 6 -Install the Bulb and
Apply Silicone Sealer
A. Insert the bulb onto socket
and screw snugly into place.
B. Make sure the exterior wall
surface and fixture backplate
are free of dirt before applying
caulk. Using exterior grade
caulk, caulk over top of
backplate and down both
sides. Do not caulk the bottom
of the fixture backplate to
ensure proper moisture
drainage.
Your fixture is now assembled
and ready to use. Enjoy!
Figure 6
HOW TO REPLACE GLASS PANEL
A. Unscrew screws on the bottom edge of the cage and remove the
glass panel holder from the cage.
B. Replace glass panel carefully and secure with previously removed
glass panel holder and screws. Tighten screws until snug with
screwdrivers.
STEP 5 -Install the Fixture
Body
A. Position the backplate and
Fixture Body (B) onto the
Crossbar Assembly (A).
Place the holes in the
backplate over the
mounting screws. Secure
the Fixture Body by using
the mounting balls and
hand tighten the mounting
balls until snug.
Figure 5
Mounting Ball
A
Backplate
Mounting Screw
B
2018 QuoizelInc. ReleasedDate:2018-04-04
visit us on-line at www.quoizel.com
