Hardware Contents
Package Contents
Pleasegoto forproductcleaningtips.Gotothe selection.www.quoizel.com Care+Maintenance
ToolsRequired:Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
BulbRecommended: (2)B10CandelabraBaseBulbs60WMaximum
EstimatedAssemblyTime:
Preparation:
Fixturecanonlybemountedinthedirectionindicatedonpage2.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
Warnings and Cautions
1of2
Assembly Instruction Sheet #IS-TML8407K_R1
For Style TML8407K
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
AA Inner Backplate
x1
A
Fixture
Body
x1
C
Narrow
Glass
x2
BB Mounting Screw
x2
B
Wide
Glass
x2
Figure 3
STEP 1 Install Bulbs-
A. Insert bulbs onto sockets and screw
snugly into place.
Figure 2
Bulb (not
supplied)
Socket
Figure 1
STEP 2 Attach Glass to Fixture
Body
-
A. Insert the Wider Glass (B) Panel
to the Cage close to the
backplate first. Then insert the
two Narrow Glasses C to the
cage next to the installed wider
glass. Insert the other Wider
Glass to the cage at last.
()
(B) B
C
C
B
A
STEP 3 - Wire Connections
A. Wrap bare or green ground wire around green ground screw on the
crossbar, no less than 2 inches from the end of the wire. Tighten the
green ground screw.
B. Use standard wire connectors (not included) to make all wire
connections. Twist connectors until wires are tightly joined together.
Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
Green Ground Screw
on the Crossbar
White wire
from outlet box White wire
from fixture
Black wire from
outlet box (or Red)
Black wire
from fixture
Bare, or Green
Ground wire
from outlet box
Ground wire
from Fixture
A
STEP 4 - Attach fixture to Inner
Backplate
A. Place the backplate of the
Fixture Body (A) onto the Inner
Backplate (AA). Line up holes
on both of them. Thread
Mounting Screws (BB) into the
mounting holes on the Inner
Backplate (AA) and hand
tighten until snug to secure
them.
BB
Backplate
Mounting
Hole
Figure 5
STEP 5 -Apply Silicone Sealer
A. Make sure exterior wall surface
and fixture backplate are free of
dirt before applying caulk. Using
exterior grade caulk, caulk over
top of backplate and down other
side. Do not caulk bottom of fixture
backplate to ensure proper
moisture drainage.
Your fixture is now assembled and
ready to use. Enjoy! Backplate
Exterior
Grade
Caulk
AA
Figure 4
2017 QuoizelInc.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
RevisedDate:2017-11-09
2of2
TML8407K
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
FINISH: MYSTIC BLACK
Fixture can only be
mounted in the
direction indicated
18.5”
7” 75”.
6”
5” Sq.
2017 QuoizelInc.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
RevisedDate:2017-11-09
