Qutek MagiCure QMN20 User manual

MagiCure Neck Massager
Manual
MagiCure Neck Massager, Model QMN201, White Designed by Qutek
London, Assembled in China
Qutek Technology Limited, 71-75 Shelton Street, Covent Garden,
London, United Kingdom

Product Introduction
The QMN201 MagiCure Neck Massager features a streamlined, ring-
shaped design that matches the human cervical vertebra curve. It
combines four functions of low-frequency electric pulse, magnetic effect,
far infrared heating, and circular traction to ensure the curative effect
reaches the body’s deep tissues and marrow. This multi-functional
massager helps maintain a proper physical position for the prevention
and treatment of cervical vertebra diseases.
It promotes local blood circulation, relaxes local muscles, and relieves
fatigue. It also prevents neck pain, numbness of shoulders and arms,
headaches, and dizziness arising from cervical vertebra diseases.
Product Features
• Ergonomic and aesthetic design
• Easy to operate with wireless remote control and LCD
• Synchronous health care system forms an efficient composite
energy field
• The FIR heat moxibustion offers low, medium, and high grade
options
• The latest 3D intelligent fitting technology ensures perfect fitting
around the nerve curve for comfortable use
• The choice for two automatically-combined electric pulse modes
and four manual modes
• Comes with several built-in magnets and a rechargeable battery
Electrode Sheet
(optional)
USB Cable Power Adapted

Electric pulse
indication
Heat Indication
On/off
Up Button
Strength Indication
Time Indication
Mode Button
Down Button
Heating Button
Conducting / Heating Strip
Power Output
Interface
Working /
Charging
Indicator
On/off
Power Input
Interface
Power Adapted

For Function Buttons:
.1 Rub the cervical part and conducting strips with a wet towel before
fitting the massager closely to your neck. Make sure your neck isn’t
sweaty.
.2 Press the host Power Button so the indicator flashes and beeps. It
will maintain the awaiting signal state for a minute and automatically
shut down if a signal isn’t received. The following settings will be
available:
A. Auto-combination massage
B. Grade 0 intensity
C. Middle temperature
D. Time: 15 minutes
.3 Use of power Button:
When the power is off, press the Power Button to enter the
standby state and turn the massager on. Then, to turn it off, press
the same button.
.4 Use of mode button:
With the pulse mode switch button, you can select the following six
pulse modes. It will be Mode 1by default after the start-up.
How to Operate For Power Supply:
.1For USB power supply, insert the output and input plugs of
Micro USB Cable into the port (DC port) on the lower part of the
massager and the AC power socket respectively.
.2The built-in rechargeable battery can serve as the power supply
when the external power supply is not used.
.3Ensure proper installation of the button cell CR2032 in the remote
control, as shown below. Use a coin or straight screwdriver to
unscrew battery cover at the groove, turn the right (positive) side of
button CR2032 upwards, put it in the battery holder of the remote
control, and insert the positioning pin on the top of the battery
cover. Then press the battery cover tightly.

Installation Diagram
Mode 1: auto-combination mode 1
Mode 2: auto-combination mode 2
Mode 3: Scratch
Mode 4: Shiatsu ( Massage Mode)
Mode 5: Rolling (
Mode 6: Beating ( Scrating)
The first two modes are manual, which will switch on automatically once
every minute between each other. Hence, it is suggested to use the
auto-combination mode.
.5 Use of “+” Button:
When the massager starts up, the intensity will be Grade 0. It will
increase by one grade each time you press this button on the left
handle. There are 16 grades in total. Low intensity is recommended
for first use.
.6 Use of “-” Button:
This button will reduce intensity by one grade with each pressing.
There are 16 grades in total.
.7 Use of heat button:
This button is for choosing between 3different heat modes: low
heat (1), Middle heat or default mode (2), High heat (3). You can stop
the heat by switching to (0) mode.
.8 Use of Electrode Pads (optional):
•Insert one of the two core connector wires into the electrode port
and connect the other end to the electrode pads. Then, use the
massager as specified above. If used with conductive plates, there
will be a little difference in intensity.
•The electrode pads should be clean on their surfaces for optimal
viscosity. If dirty, flush with clean water and dry before using it.
•It can be used 80 times (20 minutes each time). If appropriate
viscosity isn’t recovered after several times of cleaning, consider
purchasing new ones.

• Only the electrode pads provided for the massager (40 mm wide,
40 mm high, and 2.0 mm thick) are suitable for use.
• Please dispose of the waste electrode pads according to your local
environmental regulations.
• It is recommended to use the massager once or twice a day; 15
minutes of electric impulse mode and 15 to 30 minutes of thermal
moxibustion.
.9 Use of Button Cell of Remote Control:
The remote control adopts a CR2032 button cell, which can be
used for about 3months (30 min each day).
• The dim LCD backlight brightness and insensitive remote host
button indicate low battery capacity. Replace it with a new one.
• Take out the battery when the product is not in use to prevent
battery leakage and machine fault.
• Use the specified battery only.
• Do not misplace positive and negative electrodes of the battery
with positive up and negative down.
• Using the battery at a temperature above °45 C may influence the
battery›s properties and life.
• The used battery should be disposed of as per urban environment
protection regulations.
Battery Charging:
.1 When the buzzer beeps three times continuously during a
massage, it means the built-in lithium battery is running low and
needs adapter charging.
.2 Shift the toggle switch to the «Charge» position, so the power
indicator turns green and flickers. When it is fully charged after
about 2 hours, the flickering will stop.
.3 A fully charged battery lasts for about 5days with twice a day
usage.
.4 Under normal use, the rechargeable battery supports 500 times of
charging and discharging and lasts about 2to 3years (when used
twice a day for 30 minutes each).
.5 Charge the battery to full once a month for extended service life.

How to Remove the Rechargeable Battery:
• The battery contains substances that may pollute the environment.
Take it out before disposing of the product.
• Turn off the power before disassembling the product.
• Follow the steps as shown below. Disassemble the product in the
order of ①-① and take out the lithium battery.
• The battery should be safely disposed of and discarded in a place
specified by the government or in a recycling unit.
Cleaning and Maintenance:
• Wipe a dirty massager with a dry, soft cloth or dry towel.
• Clean the conducting strips frequently with a wet soft cloth or
towel. If it’s too dirty, use a soft cloth dipped in medical alcohol clean
with a 75% concentration to wipe it clean.
Storage:
• Keep it out of the reach of children.
• Don’t expose it to direct sunshine, high temperature or moisture.
• Store in a dry and well-ventilated place
• Don’t disassemble, repair or refit this product without permission
to prevent accidents
Product Scrapping:
Follow the local environmental protection requirements for disposing of
the aging or useless product to avoid environmental pollution.

1
2
Safety Precautions:
Follow the safety precautions strictly for safe and correct use, and
prevention of injury.
WARNINGS
• This massager should NOT be used by pregnant women and
those on menstrual periods
• People with sensitive skin, abnormal blood pressure, heart
disease, cerebral vascular disease, malignant tumor, or any acute
disease should avoid its use
• People under treatment should NOT use it without a doctor’s
consultation

• Do NOT use it near your mouth, head, heart, private parts, or
disease-infected areas.
• Not suitable for patients with perceptual disability or insensitivity
to heat
• Avoid using while bathing, sleeping, or sweating
• Do NOT use at high temperatures, inflammable areas, or near
electromagnetic radiations
• Do NOT disassemble, repair, or refit this massager without
permission
• Do NOT move it during use. Power it off before switching to
another area
• Not suitable for children
• In case of any discomfort, stop its use and seek medical attention
• Do NOT disassemble, repair, or refit this massager without
permission
• Do NOT move it during use. Power it off before switching to
another area
• Not suitable for children
• In case of any discomfort, stop its use and seek medical attention.
Technical Parameters and Specifications:
1. Product specifications
Name: MagiCure Neck Massager
Type: QMN201
Power supply: 5V DC 1A
Power adaptor (optional): Input 240-100V AC 60/50Hz 0.2A Output 5V
DC 1A
Lithium battery: 3.7V DC 1100mAh
Input power: 5W
Dimension of packaging box: 208x173x50 mm
Weight: about 500 g
2. Normal Working Conditions
Ambient environment: +5°C~+40°C;
Relative humidity: ①80%;
Atmosphere pressure: 86kPa~106kPa;

3. Electrical Performance
Pulse frequency: 1Hz – 1000Hz;
Pulse width: 20µs ~ 400µs;
Pulse shape: square;
Rated load impedance: 500①, with a tolerance of ±10%;
Heating temperature: +38°C ~ +48°C (under a temperature of 25°C);
Surface magnetic field intensity: not less than 0.01T;
Timing time: 5-30 minutes, with a tolerance of ±10%;
4. Transport and Storage Conditions
Ambient temperature: -2°C~+55°C;
Relative humidity: ①93%;
Atmosphere pressure: 50 kPa~106 kPa
Trouble Shooting and Solutions:
Problem Inspection Item Solution
Boot Failure Internal rechargeable
battery If the battery is low, charge it.
Charging
Check if the USB charging cable is
plugged in. The charging indicator should
flash.
The host
Press the power button of the host to
enter a standby state before pressing
the power button on the remote control.
Low battery of remote
control’s button cell Replace the button cell CR 2032
The massager
isn’t working
properly despite
the normal display
The contact between
massager electrodes
and the neck
The electrodes should be in direct
contact with the skin of the neck.
Remove any accessories, clothes, or hair
in between.
Intensity adjustment
The default massager state is 0-gear
strength. Increase the intensity until you
feel the right pressure.

The feeling of
sharp pain
The contact between
massager electrodes
and the neck
Rub a wet towel on the neck before
bringing the electrodes in contact with
the skin. Adjust the intensity accordingly.
Massage duration Appropriate massage time is 15-20
minutes
High intensity Lower the pressure if the intensity is
too high.
Skin’s sensitivity to the
electrodes
Check for skin allergies and shorten
the massage time. in case of a serious
allergy, stop the treatment immediately
and get desensitization treatment.
Cold weather and
dry skin
Rub the skin and electrodes’ surface
with a wet towel.
Use after staying up
late
Don’t use it until the next day due to
electrolyte drop.
Weak stimulation
The contact between
massager electrodes
and the neck
Ensure proper contact between
the electrodes and the neck before
adjusting the intensity and massage
mode.
Dirty or oily electrodes Make sure the surface of the electrodes
is clean.
Low battery If the battery is low, connect to an
external power supply.
Red spots on the
skin after use
Strong tingling
sensation on the
treated skin
Stop use immediately. The spots will
disappear in 3-5 days.

Frequently Asked Questions
Q: Why do I feel tingling in the neck after using the electric pulse function?
A: You may feel tingling sensation if your skin is dry or the massager is
not in close contact with the skin. Consider using a wet towel on your
neck before use. Make sure the device is in close contact with your skin.
You should begin with weak electric pulse intensity before moving on to
strong for gradual adaption. Electric pulse massage uses the traditional
Chinese medicine acupuncture method to massage the neck meridian,
not the cervical massage apparatus leakage. If you don’t feel suitable,
you can choose other massage functions.
Q: Why does my skin have a red rash?
A: After using the electric pulse function, you may see rashes on your
skin if it is dry or the massage device was not close to the skin. Use a wet
towel on the neck and ensure close contact between the massager and
the skin. The rash usually disappears on its own after 2days.
Q: Why does my skin feels hot after using the hot moxibustion function?
A: When using the hot moxibustion function, you should go from low
to a high temperature to prevent skin discomfort caused by high-
temperature moxibustion.
Q: How long does it take the cervical massager battery to charge fully?
A: The cervical vertebra massager is equipped with an environmental-
friendly lithium polymer battery. Its charging time is about 3-2 hours.
Once fully charged, it lasts for about 5days (30 minutes of usage per
day).
Q: Does the cervical vertebra massager clip the neck?
A: The ergonomic cervical vertebra massager fits different neck sizes
perfectly. It is made of high-grade rubber paint to protect the neck.
Maintain an appropriate posture after wearing it. It is recommended to
use it twice a day for 15 minutes to relax the cervical vertebrae.

ً
•
•
•
•
•
ً
•
•
•
•
•
•
•

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
