R2TECK NEXG1 T User manual

ZeroDelay Full-HD digital video
transmission system
NEXG1 T
USER MANUAL
Wuxi R2TECKCo.,Ltd.

无锡人人行拍网络科技有限公司
Content
1. Easy way to start the device...................................................................................................................1
1.1 Operating steps and instructions........................................................................................................1
2. Specification.............................................................................................................................................. 2
3. Introduction ...............................................................................................................................................3
3.1 Disclaimer .........................................................................................................................................3
3.2 Profile................................................................................................................................................3
3.3 Intended usage...................................................................................................................................3
3.4 Caution..............................................................................................................................................3
4. Module Port definition.............................................................................................................................. 5
4.1 port ....................................................................................................................................................5
5. Contact info...............................................................................................................................................7

无锡人人行拍网络科技有限公司
1
1. Easy way to start the device
1.1 Operating steps and instructions
1.1.1Transmitter
 Install the antennas.
 Install the camera.
 Connect transmitter to the power.
There should be below instructions if the transmitter works well.
After 15 seconds of power on, the WORK light will display the breathing effect, and the WORK light will
loop from on to off on display.
CAM light turn-on.
LINK light turn-on if the transmitterconnect to receiver.
The Transmitter is Module,is use for outdoor,not a portable device.

无锡人人行拍网络科技有限公司
2
2. Specification
Here list the detailed specification about NEXG1 T , as shown in Table 2.1.1.
Table 2.1.1 List of specification
Function specification
Communication distance
(outdoor, no obstruction)
≥400m
Effective Radiated Power（EIRP
）
>10mw
Receiving sensitivity -95dbm±2dbm
Operating frequency 5200MHz
Physics specification
Operating Temperature -10~60
℃
Storage Temperature -20~50
℃
Size (Include shell, no antenna)
L.70mm×W. 36 mm×H.10 mm
Weight ( Include s hell, no
antenna) 16g
Hardware function support
Transmitter working voltage
DC-12V

无锡人人行拍网络科技有限公司
3
3. Introduction
3.1 Disclaimer
Thanks for purchasing the NEXG1 T from Wuxi R2TECK. Everyone need to read and understand this
disclaimer before using the NEXG1 T. You are supposed to be accepted the disclaimer once the product
is started to use. Please comply with the installation and using process indicated in this use manual. Wuxi
R2TECK w ill not be r esponsible f or t he c onsequence of t he i mproper us e, i mproper i nstall, i mproper
modify.
The product name, brand mentioned here are belong to R2TECK.
3.2 Profile
This use manual as the instruction of Zero DelayFull-HD digital video transmission systemNEXG1 T,
the components and functions mentioned here may not be the standard spec. please check the enclosed
list with the product, please contact with the dealer if you have any question.
The r ight o f t he manual lay out , m odify and r elease on ly bel ong t o Wuxi R2TECK, Without t he
authorization of Wuxi R2TECK, this use manual could not be copied or modified or released.
The i nformation i n this m anual i s only for NEXG1 T Zero DelayFull-HD digital v ideo t ransmission
system.
This manual is subject to change without prior notice.
Version
Profile code & Version
Release Date
RR.H.0007. 0017. V01
November 2018
3.3 Intended usage
NEXG1 T use for Zero Delay wireless Full-HD digital video transmission.
3.4 Caution
The ef fectiveness o f t he use pr oduct i s s ubject t o i f c omply w ith oper ate and m aintain
direction in this manual.
Before starting the product, the staff must make sure the operate process and condition is
correct. Specially to check the product cables are good or not, if the cable is damaged,
please change it before starting the product.
NEXG1 T is i ntended t o us e on t he f ilm a nd ot her F ull-HD d igital v ideo t ransmission.
NEXG1 T may not be reached the defined function if it works in the improper temperature,
improper humidity and improver air pressure.

无锡人人行拍网络科技有限公司
4
NEXG1 T should not work when it is wet. Have to make sure it is dry when you use it.
NEXG1 T is the high precise product, it is forbidden to beat and clash.
Product life time is 2 years, quality warranty is 1 year.
Manufacture and dea ler ar e r esponsible f or t he pr oduct m aintenance, w ithout t he
authorization, please don't fix the product and don't modify the product.

无锡人人行拍网络科技有限公司
5
4. Module Port definition
4.1 port
4.1.1 Back side port
Figure 4.1.1.1 schematic diagram of back side port
[1]: Camera port: For connect the camera.
4.1.2 Side 1 port
Figure 4.1.2.1 schematic diagram of side 1 port
[1]: Work light, For monitoring the g transmitter operating status.
Light status
Description
Operation
Flash regularly Transmitter works well NA
Other status Transmitter does not work
Connect t he system t o t he
power agai n, or c ontact with
the customer service.
[2]: Link light, for monitoring the status of connect with the receiver.
Light status Description Operation
Turn-on Connect with receiver well NA
Turn-off
Does not c onnect w ith
receiver
1. Please wait for connecting
2. M ake s ure t he r eceiver i s
connected the power.
3. B ind t he Transmitter and
receiver again
4. Connect the power again
[3]: CAM light：For monitoring the status of connect with the camera.
Light status
Description
Operation
Turn-on
Connect with camera well
NA

无锡人人行拍网络科技有限公司
6
Turn-off Does not connect with camera Check whether the camera is
well connected.
4.1.3 Side 2 port
Figure 4.1.3.1 schematic diagram of side 2 port
[1]: Bind button, For bind the transmitter and receiver. (Both the transmitter and receiver are
required to operate simultaneously).
Press the button more than 5 seconds, 3 lights (WORL, LINK, CAM) are all turn-off, then 3 lights
flash one by one, when the LED light works well that means they are well binded. This may take
2 minutes. If the connection has not been resumed after 2 minutes, repower on both ends, and
do not need to rebind.
4.1.4 Bottom side port
Figure 4.1.4.1 schematic diagram of bottom side port
[1]: DC-12V port, For power supply, connect with 12V DC power supply.

无锡人人行拍网络科技有限公司
7
5. Contact info
Thanks for p urchasing o ur dev ice again. I f y ou have any s uggestion or n eed t echnical s upport,
please visit our website or send us the email, also welcome to call us.
Wuxi R2TECK Co., Ltd
Address：Room307,Building of Cetus,Wuxi software park,111th Linghuavenue,new district ,Wuxi
city,Jiangsu Province
P. C .：214000
Tel：[phone]
Fax：[phone]
Web：http://www.gor2teck.com
Email：[e-mail]

无锡人人行拍网络科技有限公司
8
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could void the user's
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction
with any other antenna or transmitter.
15.105 Information to the user.
(b) For a Class B digital device or peripheral, the instructions furnished the
user shall include the following or similar statement, placed in a prominent
location in the text of the manual:
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled en
vironment. This equipment should be installed and operated with minimum distance 20cm b
etween the radiator and your body.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands
are country dependent and are firmware programmed at the factory to match
the intended destination.
The firmware setting is not accessible by the end user.
The final end product must be labelled in a visible area with the following:
“Contains Transmitter Module 2AR2B-NEXG1T”
