Radiall Commercial SMA Series User manual

ISO 9001 APPROVED
SUBMINIATURE COAXIAL CONNECTORS
Commercial SMA series

CONTENTS
commercial
SMA
3
Page
RADIALL company profile 4-5............................................
Finder guide 7.........................................................
Introduction 8-9........................................................
Interface 10...........................................................
Characteristics 11......................................................
Plugs 12-13...........................................................
Jacks 14-16...........................................................
Pigtails and cable assemblies 17.........................................
Receptacles 18-21.....................................................
Accessories 22-23.....................................................
Adapters 24-25........................................................
Coaxial terminals 26-27.................................................
Toolings 28-34.........................................................
Panel drillings / PCB patterns 35.........................................
Mounting instructions 36-45.............................................
Cable dimensions 46...................................................
Index of P/N 47........................................................

RADIALL COMPANY PROFILE
commercial
SMA
4
Head Office -- Rosny sous Bois
RESEARCH & DEVELOPMENT
The ever increasing sophistication of microwave
communication systems is continually requiring
components to meet a higher level of performance.
RADIALL’s research and development groups
understand these needs and are committed to searching
for product solutions that will be needed in the future. They
also are providing continued improvements to our already
extensive lines of high performance products. All our
engineer teams are equipped with state of the art
equipment and facilities, in an effort to provide the best
solutions to our customers.
Screw--machining shop
Since 1952, RADIALL has specialized in the field of
coaxial connectors and cables assemblies. RADIALL’s
experience and high technology focus, combined with our
large worldwide production capability have made the
company a major supplier of RF coaxial connectors in the
world and the number one in Europe.
CAD workstation
MANUFACTURING
RADIALL knows that the quality of the connectors
components is directly related to the mechanical precision
of the machining process, along with good quality
procedures. In an effort to continually meet the highest
quality standards, all our production plants are equipped
with the latest state of the art production equipment.
RADIALL’s manufacturing process maintains strict control
of all procedures and incorporates all tooling, machining,
surface treatment and assembly operations into the
manufacturing process of each production group.

RADIALL COMPANY PROFILE
commercial
SMA
5
Base station of cellular network
HIGH RELIABILITY
Reliability of inter-connection systems is of the utmost
importance in telecommunications applications. This
industry need has led RADIALL to link high performance
design, manufacturinfg and quality control. This has given
the company the capability to produce connectors that will
operate in the most stringent environments. The wide
range of our product offering allows us to propose the best
complete solution for your exact need.
Microwave test device
QUALITY ASSURANCE
RADIALL, as a TQM company, continually searches for
improvements to the quality process. We operate a Quality
Assurance Program that has been developed in accor-
dance with the national and CECC agencies (equivalent to
MIL-I-45208 and MIL-C-45662 standards). This program
has enabled us to achieve QPL approval on several of our
connector series. RADIALL’s Quality Assurance Program
operates at all levels of manufacturing from the initial raw
incoming material to the final testing procedures just prior
to shipping. All test equipment is part of the quality process
and is continually inspected on a regular scheduled basis.
All production plants in Europe are AQA P4-NATO certified.
ISO 9001 ACCREDITATION
This certificate is witness to RADIALL’s achievement and
commitment to the Total Quality Process. RADIALL has
always been, since its inception, a company committed to
being a Total Quality supplier. Quality is our way of life at
RADIALL.

FINDER GUIDE
ATTENTION! This guide is intended as an
information and does not include all
COMMERCIAL SMA P/N
commercial
SMA
7
CABLE CONNECTORS
model straight
plug
straight
slide--on
plug
right--angle
plug
straight
jack
straight jack
bulkhead mount
straight jack
square flange
straight jack
narrow
flange
cable crimp/
full crimp solder crimp/or solder crimp solder full crimp solder full crimp solder (panel seal)
crimp/
full crimp solder solder
2/50/S
(RG 178)
R124 069 12x
(page 12)
R124 310 02x
(page 15)
R124 271 12x
(page 16)
2.6/50/S
(RG 316)
R124 071 12x
(page 12)
R124 072 520
(page 12)
R124 172 12x
(page 13)
R124 236 12x
(page 14)
R124 312 12x
(page 15)
R124 272 12x
(page 16)
2.6/50/D
(RD 316)
R124 072 22x
(page 12)
R124 174 12x
(page 13)
R124 233 12x
(page 14)
R124 313 12x
(page 15)
R124 274 12x
(page 16)
5/50/S
(RG 58)
R124 075 32x
(page 12)
R124 175 12x
(page 13)
R124 314 12x
(page 15)
R124 277 12x
(page 16)
5/50/S
(LMR200)
R124 075 200
(page 12)
5/50/D
(RG 142)
R124 076 32x
(page 12)
R124 176 12x
(page 13)
R124 315 12x
(page 15)
R124 278 12x
(page 16)
5.7/50/D
(TZC50019)
R124 176 220
(page 13)
10.3/50/S
(LMR400)
R124 080 030
(page 12)
.085
(RG 405)
R124 052 003
(page 12)
R124 052 520
(page 12)
R124 153 00x
(page 13)
R124 222 xxx
(page 14)
R124 326 00x
(page 15)
R124 256 00x
(page 16)
R124 252 00x
(page 16)
.141
(RG 402)
R124 054 00x
(page 12)
R124 154 00x
(page 13)
R124 225 xxx
(page 14)
R124 325 00x
(page 15)
R124 255 00x
(page 16)
R124 251 00x
(page 16)
RECEPTACLES
model panel female receptacle PCB female
receptacle
straight
flange mount
right--angle
flange
straight bulkhead
mount straight right--angle
back square
(12.7 mm)
square
(25.4 mm)
narrow
(5.65 mm)
square
(12.7 mm)
solder contact
with solder pot
R124 403 12x
(page 18)
R124 454 12x
(page 19)
R124 654 00x
(page 20)
R124 553 12x
R124 581 020
(page 20)
solder contact
slotted
R124 498 0xx
(page 18)
R124 409 50x
(page 18)
solder contact
cylindrical
R124 414 00x
R124 415 27x
(page 18)
R124 464 xxx
(page 19)
solder contact
with custom
back length
R124 413 30x
R124 414 30x
R124 416 30x
(page 18)
R124 463 30x
R124 464 30x
R124 466 30x
(page 19)
solder contact
flat tab
R124 510 00x
(page 18)
removable contact
(universal receptacle)
R124 410 00x
(page 19)
solder pins R124 426 xxx
(page 21)
R124 680 xxx
(page 21)
surface mount
technology
R124 427 xxx
(page 21)
R124 681 xxx
(page 21)
IN--SERIES ADAPTERS
model straight straight
bulkhead
M--M R124 703 00x
(page 24)
F--F R124 705 00x
(page 24)
R124 720 00x
(page 24)
M--F R124 704 00x
(page 24)

The RADIALL commercial SMA connectors have been specially designed for applications where low installed costs are of
the utmost importance. They are easy, fast to assemble and reliable and offer the perfect solution for high volume applica-
tions requiring high level performance like civil telecommunications, datacommunications or test and measurement.
D
Full compatibility :
These commercial SMA connectors are fully compatible
(interchangeable and intermateable) with all existing MIL
standardised SMA connectors. They feature the same per-
formance level except mechanical (life : 100 matings and
coupling nut torque : 60 Ncm).
The coupling nut of the commercial SMA series features a
special design which is different from the standard SMA
coupling nut as the tightening torque is reduced.
D
Wide range :
The commercial SMA range features models which are
adapted to offer a solution for every standard coaxial
flexible or semi--rigid cable as well as PCB models with
traditional through--hole pins or solder pads for SMT
applications.
D
Simple snap--in axial captivation
(for full-crimp models) :
The relative position of the centre contact into the interface
is mechanically guaranteed by the snapping of the insulator
inner shoulder into the groove of the centre contact.
This design facilitates the captivation operation in contrast
to other designs, requiring 2 insulators to provide contact
retention.
It assures constant perfect axial positioning of the center
contact into the interface.
D
Space-saving size :
Due to the captivation technique, these commercial SMA
connectors are shorter than multi--piece body connectors.
D
Convenient 3-piece design :
-- for straight models: body + center contact + outer ferrule
-- for right-angle models : single piece body + back cap +
outer ferrule.
D
Fast and reliable cable attachment :
The cable connectors can be either fully crimped or sol-
dered/crimped, offering full flexibility for high volume indus-
trial production with standard manual or pneumatic tooling :
fast and reliable.
-- the centre contact can be either crimped or soldered.
-- the outer contact is attached to the cable by crimping a
ferrule.
DIndustry adapted packaging :
Standard packaging is 100 pieces bulk--pack. Unit
packaging is available upon request. The PCB models can
also be delivered in tube or tape & reel packaging.
D
Competitive pricing :
The design and materials used in the manufacture of the
commercial SMA range allow us to offer connectors at com-
petitive prices to suit a wide range of applications. The con-
nector body is manufactured in brass and the surface plat-
ing is available in either gold or in BBR finish (RADIALL non-
magnetic bright bronze surface finish).
D
Center contact captivation :
Our connectors have a captive center contact.
INTRODUCTION
commercial
SMA
8

50 8DC - 18 GHz
INTRODUCTION
commercial
SMA
9
GENERAL
DSubminiature coaxial connectors
DScrew-on coupling
DHigh RF performance
D2 plating options : -- BBR
-- Gold
APPLICABLE STANDARDS
DMIL- C - 39012
DIEC 169-1
DCECC 22110
DCECC 22111 - 801 to 808
DBS 9210 N006
APPLICATIONS
DTelecommunication / Datacommunication
- cellular networks (GMS, DCS, PCN, ....)
- cordless systems (DECT, CT2, ...)
- wireless equipment (WLL, ...)
- positioning systems (GPS, ...)
- Internet equipment
-...
DAeronautics
DMeasurement and test systems
DGeneral electronics

INTERFACE
PLUG JACK
* statistics quotation : .0539 ¦ .0055 (.0594 max)/(1.37 ¦ 0.14)(1.51 max)
1) Coupling nut against on datum 1
2) Coupling nut against on datum 2 All dimensions are given in mm.
commercial
SMA
10

CHARACTERISTICS
commercial
SMA
11
MIL--C--39012
paragraph VALUES / REMARKS
GENERAL
Impedance 50 8
Frequency range Semi--rigid cables
DC -- 18 GHz
Standard models
DC -- 12.4 GHz
Temperature range -- 6 5 _C + 105_C-- 6 5 _C + 165_C
ELECTRICAL
Insulation resistance 3-11 5000M8mini.
Contact resistance
Outer conductor
Inner conductor
3-16
Initial
3m8
2m8
After test
4m8
3m8
V.S.W.R. max up to : 18 GHz for
semi-rigid cable - 12.4 GHz for
r
i
g
h
t
a
n
g
l
e
c
o
n
n
e
c
t
o
r
(
S
R
)
.085” .141” 2.6 / 50 / S 5/50/D
right angle connector (SR
)
-
12.4 GHz for flexible cable
Straight Connector
Right angle connector
3-14
1.07 + .01F
1.10 + .01F
1.05 + .01F
1.10 + .01F
1.15 + .02F
1.15 + .03F
1.15 + .01F
1.15 + .02F
Dielectric withstanding
voltage in VRMS 3-17 750 1000 750 1000
Working voltage in VRMS (sea level) 335 500 250 335
Working voltage in VRMS (70 000 ft) 85 125 65 85
RF testing voltage at 5MHz in VRMS 3-23 500 670 500 670
MECHANICAL
C
a
b
l
e
r
e
t
e
n
t
i
o
n
f
o
r
c
e
3
2
4
.085” .141” 2.6 / 50 / S 5/50/D
Cable retention
f
orce 3-24 130 N 270 N 90 N 204 N
Life 3-15 100 matings
Force to engage and disengage 3-5-1 23 Ncm -- 2 inch pounds
Coupling nut torque recommended 60 Ncm -- 5.2 inch pounds
Coupling nut retention force 3-25 272 N min
ENVIRONMENTAL
Vibration 3-18 MIL STD 202, method 204, condition D,20g
Shock 3-19 MIL STD 202, method 213, condition I,100g
Thermal shock 3-20 MIL STD 202, method 107, condition B,
Corrosion (salt spray) 3-13 MIL STD 202, method 101, condition B,
Moisture resistance 3-21 MIL STD 202, method 106
Barometric pressure 3-22 MIL STD 202, method 105, condition C
Hermetic test down to 10-- 6 mmHg (Torr) leakage rate < 10-- 8 atm/cm3/sec
Life (at high temperature) MIL STD 202, method 108
MATERIALS
Body Brass
Center contacts
f
emale Ber
y
llium co
p
p
er
C
e
n
t
e
r
c
o
n
t
a
c
t
s
f
e
m
a
l
e
male
B
e
r
y
l
l
i
u
m
c
o
p
p
e
r
Brass
Insulators PTFE teflon
Gaskets Silicone rubber
FINISH
Bodies BBR or Gold plated
Center contacts Gold plated
STANDARD PACKAGING : 100 pieces - UNIT : add W after the P/N.

D Upon request. Standard packaging : 100 pieces
STRAIGHT PLUG, FULL CRIMP TYPE, FOR FLEXIBLE CABLE
STRAIGHT PLUG, SOLDER TYPE, FOR SEMI-RIGID CABLE
Fig. 1 Fig. 2 Fig. 3
Fig. 1 Fig. 2
Fig. 4
Fig. 3
PLUGS
commercial
SMA
12
cable group part number fig. A B C D mounting finish note
2/50/S R124 069 120 125 12,55 7,7 M08 BBR
B
a
c
k
n
u
t
/
s
o
l
d
e
r
c
o
n
t
a
c
t
2/50/S R124 069 123 125 12,55 7,7 M08 Gold Back nut
/
solder contact
2.6/ 50 / S R124 071 120 223,4 1,61 3,25 7,7 M01 BBR
2.6/ 50 / S R124 071 123 223,4 1,61 3,25 7,7 M01 Gold
3
p
i
e
c
e
S
M
A
2.6/ 50 / D R124 072 220 223,4 1,61 3,5 7,7 M01 BBR 3pieceSM
A
2.6/ 50 / D R124 072 223 223,4 1,61 3,5 7,7 M01 Gold
2.6/ 50 / S R124 072 520D327,14 1,7 3,25 8,9 M01 BBR Slide-on interface - Non
captivated center contact
5/50/S R124 075 320 226,4 3,11 5,41 7,7 M01 BBR
3
p
i
e
c
e
S
M
A
5/50/S R124 075 323 226,4 3,11 5,41 7,7 M01 Gold 3pieceSM
A
5/50/S R124 075 200D424,15 3,11 5,55 M01 Gold Cable LMR200 Non
captivated center contact
5/50/D R124 076 320 226,4 3,11 5,8 7,7 M01 BBR
3
p
i
e
c
e
S
M
A
5/50/D R124 076 323 226,4 3,11 5,8 7,7 M01 Gold 3pieceSM
A
10.3 /50 / S R124 080 030D229,65 7,44 11,05 12,7 M01 BBR Cable LMR400 Non capti-
vated center contact
cable group part number fig. A B mounting finish note
.085 R124 052 003 111,1 2,25 M04 Gold Non captivated center contact
.085 R124 052 520D221,14 2,25 M07 Gold Slide-on interface
.141 R124 054 001 38,5 3,65 M06 BBR
W
i
t
h
o
u
t
c
e
n
t
e
r
c
o
n
t
a
c
t
.141 R124 054 003 38,5 3,65 M06 Gold Without center contact

RIGHT ANGLE PLUG, CRIMP TYPE, FOR FLEXIBLE CABLE
RIGHT ANGLE PLUG, SOLDER TYPE, FOR SEMI-RIGID CABLE
D Upon request. Standard packaging : 100 pieces
PLUGS
commercial
SMA
13
cable group part number A B C D mounting finish note
2.6/ 50 / S R124 172 120 18 16,35 1,61 3,25 M02 BBR
2.6/ 50 / S R124 172 123 18 16,35 1,61 3,25 M02 Gold
3
p
i
e
c
e
S
M
A
2.6/ 50 / D R124 174 120 18 16,35 1,61 3,5 M02 BBR 3pieceSM
A
2.6/ 50 / D R124 174 123 18 16,35 1,61 3,5 M02 Gold
5/50/S R124 175 120 21 16,35 3,1 5,41 M02 BBR
5/50/S R124 175 123 21 16,35 3,1 5,41 M02 Gold
3
p
i
e
c
e
S
M
A
5/50/D R124 176 120 21 16,35 3,1 5,8 M02 BBR 3pieceSM
A
5/50/D R124 176 123 21 16,35 3,1 5,8 M02 Gold
5.7/ 50 / D R124 176 220D21 16,8 3,87 6,6 M02 BBR 3pieceSMA
Cable TZC 50019
cable group part number Amounting finish
.085 R124 153 001 2,25 M05 BBR
.085 R124 153 003 2,25 M05 Gold
.141 R124 154 001 3,65 M05 BBR
.141 R124 154 003 3,65 M05 Gold

STRAIGHT JACK, FULL CRIMP TYPE, FOR FLEXIBLE CABLE
STRAIGHT JACK, SOLDER TYPE, FOR SEMI-RIGID CABLE
Standard packaging : 100 pieces
JACKS
commercial
SMA
14
cable group part number Amounting finish note
2.6/ 50 / S R124 236 120 3,25 M01 BBR
2.6/ 50 / S R124 236 123 3,25 M01 Gold
3
p
i
e
c
e
S
M
A
2.6/ 50 / D R124 233 120 3,5 M01 BBR 3pieceSM
A
2.6/ 50 / D R124 233 123 3,5 M01 Gold
cable group part number Amounting finish note
.085 R124 222 000 2,25 M04 BBR
.085 R124 222 003 2,25 M04 Gold
N
o
n
c
a
p
t
i
v
a
t
e
d
c
e
n
t
e
r
c
o
n
t
a
c
t
.141 R124 225 000 3,65 M04 BBR Non captivated center contact
.141 R124 225 003 3,65 M04 Gold

BULKHEAD FEEDTHROUGH STRAIGHT JACK, FULL CRIMP TYPE, FOR FLEXIBLE CABLE
Fig. 1 Fig. 2
BULKHEAD FEEDTHROUGH STRAIGHT JACK, SOLDER TYPE, FOR SEMI-RIGID CABLE
(PANEL SEAL)
Standard packaging : 100 pieces
Gasket
JACKS
commercial
SMA
15
cable group part number fig. A B C mounting panel drilling finish note
2/50/S R124 310 020 1M03 P08 BBR Reverse crim
p
in
g
2/50/S R124 310 023 1M03 P08 Gold
R
e
v
e
r
s
e
c
r
i
m
p
i
n
g
/ Solder contact
2.6/ 50 / S R124 312 120 222,4 1,61 3,25 M01 P01 BBR
2.6/ 50 / S R124 312 123 222,4 1,61 3,25 M01 P01 Gold
3
p
i
e
c
e
S
M
A
2.6/ 50 / D R124 313 120 222,4 1,61 3,5 M01 P01 BBR 3pieceSM
A
2.6/ 50 / D R124 313 123 222,4 1,61 3,5 M01 P01 Gold
5/50/S R124 314 120 225,4 3,11 5,41 M01 P01 BBR
5/50/S R124 314 123 225,4 3,11 5,41 M01 P01 Gold
3
p
i
e
c
e
S
M
A
5/50/D R124 315 120 225,4 3,11 5,8 M01 P01 BBR 3pieceSM
A
5/50/D R124 315 123 225,4 3,11 5,8 M01 P01 Gold
cable group part number Amounting panel drilling finish note
.085 R124 326 000 2,25 M04 P01 BBR
.085 R124 326 003 2,25 M04 P01 Gold
N
o
n
c
a
p
t
i
v
a
t
e
d
c
e
n
t
e
r
c
o
n
t
a
c
t
.141 R124 325 000 3,65 M04 P01 BBR Non captivated center contact
.141 R124 325 003 3,65 M04 P01 Gold

SQUARE FLANGE JACK, FULL CRIMP TYPE, FOR FLEXIBLE CABLE
Fig. 1 Fig. 2
FLANGE JACK, SOLDER TYPE, FOR SEMI-RIGID CABLE
Fig. 1 Fig. 2
Standard packaging : 100 pieces
JACKS
commercial
SMA
16
cable group part number fig. A B C mounting panel drilling finish note
2/50/S R124 271 120 126,6 12,55 M08 P02 BBR
B
a
c
k
n
u
t
/
S
o
l
d
e
r
c
o
n
t
a
c
t
2/50/S R124 271 123 126,6 12,55 M08 P02 Gold Back nut
/
Solder contact
2.6/ 50 / S R124 272 120 222,4 1,61 3,25 M01 P02 BBR
2.6/ 50 / S R124 272 123 222,4 1,61 3,25 M01 P02 Gold
3
p
i
e
c
e
S
M
A
2.6/ 50 / D R124 274 120 222,4 1,61 3,5 M01 P02 BBR 3pieceSM
A
2.6/ 50 / D R124 274 123 222,4 1,61 3,5 M01 P02 Gold
5/50/S R124 277 120 225,4 3,11 5,41 M01 P02 BBR
5/50/S R124 277 123 225,4 3,11 5,41 M01 P02 Gold
3
p
i
e
c
e
S
M
A
5/50/D R124 278 120 225,4 3,11 5,8 M01 P02 BBR 3pieceSM
A
5/50/D R124 278 123 225,4 3,11 5,8 M01 P02 Gold
cable group part number fig. Amounting panel drilling finsh note
.141 R124 251 000 13,65 M04 P05 BBR
.141 R124 251 003 13,65 M04 P05 Gold
N
o
n
c
a
p
t
i
v
a
t
e
d
c
e
n
t
e
r
c
o
n
t
a
c
t
.085 R124 252 000 12,25 M04 P05 BBR Non captivated center contact
.085 R124 252 003 12,25 M04 P05 Gold
.141 R124 255 000 23,65 M04 P02 BBR
.141 R124 255 003 23,65 M04 P02 Gold
N
o
n
c
a
p
t
i
v
a
t
e
d
c
e
n
t
e
r
c
o
n
t
a
c
t
.085 R124 256 000 22,25 M04 P02 BBR Non captivated center contact
.085 R124 256 003 22,25 M04 P02 Gold

commercial
SMA
17
RADIALL CABLE PART NUMBER
cable type part number
S
e
m
i
r
i
g
i
d
.085 RG 405 C291 850 001
Semi-rigid
.141 RG 402 C291 860 001
2/50/S RG 178 C291 145 007
2.6 / 50 / S RG 174
RG 316
C291 150 000
C291 170 007
Flexible 2.6 / 50 / D RD 316 C291 185 067
5/50/S RG 58 C291 305 000
5/50/D RG 223 C291 330 000
R 124 071 123 /C 291 150 000 /L=15 cm
A=10 mm B =5mm C=5mm
PIGTAILS AND CABLE ASSEMBLIES
R 124 153 003 /C 291 850 001 /L=15 cm
L
HOW TO ORDER : Examples of composition (minimum length = 4 cm ±2%)
Pigtail featuring one right angle plug soldered on RG 405(.085)
L
Pigtail featuring one straight plug crimped on RG 174 with
stripping option*
AB C
..
* Stripping according to customers requirements with
possibility of tin central conductor.
R 124 075 320 /C 291 305 000 /R 124 277 120 /L=15 cm.
L
Cable assembly featuring one straight plug and one square flange jack crimped on RG 58

SQUARE FLANGE FEMALE RECEPTACLE
Fig. 1 Fig. 3
Fig. 4 Fig. 5
Fig. 2
Fig.1 to 4
D Upon request. Standard packaging : 100 pieces
RECEPTACLES
* : For more details, see Application guide for SMA extended dielectric receptacles D 1 125 DE.
commercial
SMA
18
part number fig. A B panel drilling finish note
R124 403 120 1P04 BBR
R124 403 123 1P04 Gold
R124 498 030D21,3 0,7 P04 Gold
R124 498 047D2 2 0,51 P04 BBR
R124 510 000 4P04 BBR
R124 510 003 4P04 Gold
R124 409 503D5P07 Gold
2
5
4
f
l
a
n
g
e
R124 409 507D5P07 BBR 25,4 flange
R124 414 000 3* 15,9 12,7 P04 BBR
R124 414 003 3* 15,9 12,7 P04 Gold
4
I
n
d
e
n
t
s
R124 415 270 3* 17,9 15 P04 BBR 4 Indents
R124 415 273 3* 17,9 15 P04 Gold
R124 414 004 3* 15,9 12,7 P04 Gold
R124 414 005 3* 15,9 12,7 P04 BBR
E
p
o
x
y
R124 415 274 3* 17,9 15 P04 Gold Epo
x
y
R124 415 275 3* 17,9 15 P04 BBR

UNIVERSAL SQUARE FLANGE FEMALE RECEPTACLE
To be used with removable contacts and insulators pages : 22 and 23
NARROW FLANGE FEMALE RECEPTACLE
Fig. 1 Fig. 2
Standard packaging : 100 pieces
RECEPTACLES
* : For more details, see Application guide for SMA extended dielectric receptacles D 1 125 DE.
commercial
SMA
19
part number panel drilling finish
R124 410 000 P04 BBR
R124 410 003 P04 Gold
part number fig. A B panel drilling finish note
R124 454 120 1P05 BBR
R124 454 123 1P05 Gold
R124 464 000 2* 15,9 12,7 P05 BBR
R124 464 003 2* 15,9 12,7 P05 Gold
4
I
n
d
e
n
t
s
R124 464 270 2* 17,9 15 P05 BBR 4 Indents
R124 464 273 2* 17,9 15 P05 Gold
R124 464 004 2* 15,9 12,7 P05 Gold
R124 464 005 2* 15,9 12,7 P05 BBR
E
p
o
x
y
R124 464 274 2* 17,9 15 P05 Gold Epo
x
y
R124 464 275 2* 17,9 15 P05 BBR

RIGHT ANGLE SQUARE FLANGE FEMALE RECEPTACLE
BULKHEAD FEEDTHROUGH STRAIGHT FEMALE RECEPTACLE
Fig. 1 Fig. 2
D Upon request Standard packaging : 100 pieces
RECEPTACLES
commercial
SMA
20
part number panel drilling finish
R124 654 000 P02 BBR
R124 654 003 P02 Gold
part number fig. panel drilling finish note
R124 553 120 1P01 BBR Rear mount
R124 553 123 1P01 Gold Rear mount
R124 581 020D2P10 BBR Panel seal / Front mount

RIGHT ANGLE FEMALE PCB RECEPTACLE
Fig. 1 Fig. 2
STRAIGHT FEMALE PCB RECEPTACLE
Fig. 1 Fig. 2
D Upon request. Standard packaging : 100 pieces
RECEPTACLES
commercial
SMA
21
part number fig. PCB pattern finish note
R124 426 120 1P03 BBR
R124 426 121D1P03 BBR + Tin-lead 60/40
R124 426 123 1P03 Gold
R124 426 850 1P03 BBR Tube of 78 pieces
R124 426 853 1P03 Gold Tube of 78 pieces
R124 427 000 2M09 Gold Surface mount / Unit packaging
R124 427 800 2M09 Gold Surface mount / Tape and reel of 100 pieces
R124 427 850 2M09 Gold Surfacemount/tubeof78pieces
part number fig. PCB pattern finish note
R124 680 120 1P03 BBR
R124 680 123 1P03 Gold
R124 680 130D1P03 BBR+Tinlead60/40
R124 680 850 1P03 BBR Tube of 40 pieces
R124 680 853 1P03 Gold Tube of 40 pieces
R124 681 000 2M09 Gold Surface mount / Unit packaging
R124 681 800 2M09 Gold Surface mount / Tape and reel of 100 pieces
R124 681 850 2M09 Gold Surface mount / tube of 40 pieces

REMOVABLE CONTACTS (to be used with universal receptacles, R124 410 000 and R124 410 003 page : 19)
Fig. 1 Fig. 2
Fig. 4 Fig. 5Fig. 3
DEMONSTRATION BOARD
part number
R124 900 520
This demonstration board includes straight and R/A
solder pins receptacles and straight and R/A SMT
receptacles.
ACCESSORIES
commercial
SMA
22
part number fig. standard
packaging
R280 458 030 1
R280 464 000 2
1
0
R280 465 000 310
R280 465 020 4
part number fig. Astandard
packaging
R280 466 020 0,71
R280 466 030 50,46 10
R280 466 040 0,33
