Radijator EK 06 Smart EU Installation instructions

TECHNICAL INSTRUCTIONS FOR ASSEMBLY,
OPERATION AND MAINTANCE OF ELECTRIC
BOILER
Živojina Lazića Solunca 6, 36000 Kraljevo, Serbia,
tel: [phone], 390-150, e-mail: [e-mail]
EK SMART EU
06-09-12-16-18-21-24-27 kW
ENG

2
Table of content
1. Explanation of the symbols and safe work instructions ...................................................................................... 3
1.1 Introduction ................................................................................................................................................... 3
1.2 List of symbols with explanations ................................................................................................................ 3
1.3 General boiler safe work instructions ........................................................................................................... 3
2. Information about the boiler ............................................................................................................................... 5
2.1 Description of the product ............................................................................................................................ 5
2.2 Electro-boiler models .................................................................................................................................... 8
2.3 Declaration of conformity ............................................................................................................................. 8
2.4 Minimum separation distance and flammability of building materials............................................................. 9
2.5 Tools, materials and auxiliary aids ................................................................................................................ 9
2.6 Antifreeze protection .................................................................................................................................... 9
2.7 Waste disposal .............................................................................................................................................. 9
2.8 Scope of delivery .......................................................................................................................................... 9
2.9 Name plate .................................................................................................................................................. 10
2.10 Dimensions and technical data .................................................................................................................. 10
4.1 Caution when assembling the boiler ........................................................................................................... 12
4.2 Clearance around the boiler to floor, wall and ceiling ................................................................................. 13
4.3 Removal of the boiler front casing ............................................................................................................. 13
4.4 Assembly of the boiler ................................................................................................................................. 14
5. Boiler hydraulic scheme ................................................................................................................................... 15
6.1 Position of electrical cable grommets in the boiler ...................................................................................... 18
6.2 Connecting the electric boiler to permanent electrical installation .............................................................. 18
7. Operating the boiler ......................................................................................................................................... 23
7.1 Safety instructions ...................................................................................................................................... 23
7.2 Overview of elements for operating the boiler ........................................................................................... 23
7.3 Alarm .......................................................................................................................................................... 24
7.4 Blockade ..................................................................................................................................................... 24
7.8 Turning the boiler on/off ............................................................................................................................ 25
7.9 Automation deblocade of pump .................................................................................................................. 25
7.9 Communications port.................................................................................................................................. 25
7.11 Master application .................................................................................................................................... 25
7.13 Room thermostat ....................................................................................................................................... 25
8. Hidden menu ................................................................................................................................................ 25
9. Boiler commissioning ...................................................................................................................................... 28
10. Cleaning and maintenance of boiler ............................................................................................................... 28
11. Operating problems and solutions .............................................................................................................. 29
12. Product disposal after use ............................................................................................................................ 29
13. Designing manual .......................................................................................................................................... 30
13.1 Systems to which the boiler may be connected ............................................................................... 30
14. Warranty ......................................................................................................................................................... 31

3
1. Explanation of the symbols and safe work instructions
1.1 Introduction
These technical instructions contain important information about adequate assembly,
commissioning, handling and maintains of the device.
It is intended for authorized installers, authorized service technician’s and end – users of the
electro-boiler.
Please read and retain the instructions for future reference in case of need.
1.2 List of symbols with explanations
Warning symbols
RISK OF ELECTRIC SHOCK
Risk of electric shock symbol is presented by a lightning bolt arrow in a triangle
warning symbol
WARNING
Warning symbol in the text is presented by the warning sign in a triangle
IMPORTANT INFORMATION
Important information for which there is no risk of injury or material damage
SETTINGS
Settings intended for service technicians or experts and end user should not
perform them by themselves.
Key words at the beginning of the safety notice denote the type of hazard and potential
consequences if one does not comply with the measures for preventing hazard.
- NOTE indicates that there might be some material damage.
- CAUTION indicates that there might be minor or moderate bodily injuries.
- WARNING indicates that there might be severe or life-threatening bodily injures.
- DANGER indicates that might be life – threating bodily injuries.
1.3 General boiler safe work instructions
General safety instructions
This device is not intended for use by persons with limited mental or psychophysical
capabilities, as well as by inexperienced persons including children. Children above 8
may handle this device only if an adult is present or if they are instructed for date
handling and are aware of all hazards.
Non-compliance with the safe work instructions may result in severe injuries, death,
material damage, and may jeopardize environment.
Before assembling the boiler professional inspection and control testing of the
electrical installation is required.
All works on the electrical installation should be performed by a competent and
authorized person in accordance with relevant regulations.
Commissioning, maintenance and repair may only be performed by an authorized
service technician.

4
Ensure technical approval of the installation in accordance with the relevant
regulations.
Danger due to compromising one’s own safety in case of need, e.g. in case of fire
Never put yourself in a life-threatening situation. Your safety should always come
first.
Damage due to errors in operating the boiler
Error in operating the device may cause bodily injuries or material damage.
Ensure that only persons who are able to use this boiler adequately have access to it.
Errors in operating the boiler may cause injuries and/or damage to the installations.
Assembly and commissioning of the boiler
Assembly of the boiler should be carried out only by authorized service technician.
The commissioning of the boiler should always be performed only if there is
appropriate pressure in the installation, while the working pressure must be in
accordance with the data of manufacturer. Do not close safety valves in any case, as
the material damage that may be caused by high pressure will thus be avoided.
The boiler should be installed only in a room in which water cannot freeze.
Do not use or store flammable materials (paper, thinner, paint, etc.) near the boiler.
Maintain safe separation distance from the boiler, in accordance with the regulations
in effect.
Life-threatening risk of electric shock
Electrical connection works should be done by authorized service technicians. Please
comply with the connection scheme.
Prior to works on electrical installations disconnect the power supply and ensure that
it may not be accidentally connected again.
The device must not be assembled in damp premises.
Maintained/check-up
We recommend that you sign a contract on inspection/maintenance with an expert
company, so that the inspection and necessary maintenance of the device may be
carried out once a year.
End-user of the boiler is responsible for ensuring that the hearing installation is safe
and environmentally friendly.
Adhere to the safe work instructions in the section
Spree parts
No liability shall be accepted for damage caused by use of spare parts which have not
been delivered by the manufacturer.
Use only original spare parts.
Damage to the system as a result of freezing temperatures
In case of freezing temperatures, protect the heating system from freezing. Heating
water should be drained at the lowest point of the heating system.
Instructions for service technicians
Inform the end-users about the manner of work and the maintenance of the boiler.
Warn the end-users that they must not make any change or repairs on their own.
Ensure that the children do not use this boiler without supervision and not play with it.

5
Hand over boiler technical documentation to the end-user.
Environmental protection/Disposal of waste
Dispose of packaging in an environmentally friendly manner.
Dispose of the boiler in an environmentally friendly manner at the recycling spot.
Cleaning of the boiler
Clean the boiler on the outside with a damp cloth.
2. Information about the boiler
2.1 Description of the product
EK-SMART EU is produced with the following powers:
6kW, 9kW, 12kW, 16kW, 18kW, 21kW, 24kW, 27kW.
Advantages of electric boilers: reliable heating, quiet work, not requiring, a separate room for
installation, small dimensions, low price, high level of operational safety, absence of
chimney, no harmful emissions during operation (environmental protection). Smaller power
boilers of up to 9kW may require Single Phase or Three Phase power supply, while boilers of
greater power exclusively require Three Phase power supply.
In addition to standard elements of an electric boiler, the EK Smart EU electric boiler contains:
expansion vessel, circulation pump, safety valve, filling and drainage tap, automatic air vent,
etc.
The device is equipped with a protective assembly unit which guarantees complete safety.
Heating elements and pump valve are turned on through controller in charge of maximum work
optimisation.
Specially designed logarithm measures the time of work of each heating element and
periodically turns off the heating elements which worked the most and turns on those that
worked the least. In this way, equal exploitation of the heating elements is ensured, which
significantly extends the working life of the product.
Algorithm is designed upon the principle of modulation, so, as the boiler approaches the set
temperature, it reduces its power output and thus achieves maximum comfort with minimum
consumption.
Additional equipment: room thermostat is recommended since they significantly increase the
efficient energy use of the product and retain the same comfort with reduced consumption.
Electric boiler may be used:
1) As a principal source of heating (through radiators: in houses, holiday cottages,
apartments...)
2) As an auxiliary/additional source of heating (systems with a heat pump, solar systems,
pyrolytic boiler...)
3) For heating through heat accumulator (accumulation)
In addition to already mentioned inputs and outputs, EK-Smart EU boiler controller also
contains additional equipment and functions which provide maximum comfort and safety to
the end-user with minimum consumption.

6
Picture 1. Boiler overview: isometric view, front side, left and right side, top side, bottom side

7
3. Connection for hot and cold water
8 - Cold water
9 - Hot water
4. Cross-section of the exchanger
Picture 2. Boiler components
1 - LCD display
2 – Expansion vessel
3 – Automatic air vent
4 – Pressure safety valve
5 – Safety thermostat
6 – Exchanger
7
-
Pump

8
2.2 Electro-boiler models
It is important to emphasise that the boilers of 6kW and 9kW are produced in
two versions, with Single Phase and Three Phase connector. The boilers with Single Phase
connectors are EK 06 Smart MONO EU and EK 09 Smart MONO EU, boilers with Three
Phase connectors are EK 06 Smart EU and EK 09 Smart EU. When purchasing the product,
you should emphasise which connector you want. Subsequent “reconnections” are not
approved by the manufacturer.
2.3 Declaration of conformity
We declare that these boilers have been examined in accordance with the Directives 2006/95/EC
(Low Voltage Directive - LVD) and 2014/30/EU (Electromagnetic Compatibility Directive -
EMC).
Electro-boiler models Power
EK 06 Smart EU 6 kW
EK 06 Smart MONO EU 6 kW
EK 09 Smart EU 9 kW
EK 09 Smart MONO EU 9 kW
EK 12 Smart EU 12 kW
EK 16 Smart EU 16 kW
EK 18 Smart EU 18 kW
EK 21 Smart EU 21 kW
EK 24 Smart EU 24 kW
EK 27 Smart EU 27 kW
Table 1. Electro-boiler models

9
Delivery Item
No of units
Boiler
1
Assembly set
1
Instruction for use
1
2.4 Minimum separation distance and flammability of building
materials
Minimum separation distance from inflammable materials may differ from country to country.
Please adhere to the regulations on electrical installations and prescribed minimum distances
in your country. The following table shows the classification of flammability of building
materials as per DIN 4102.
Flammability of building materials
A
A1
A2
Non-combustible
Non-combustible Asbestos, stone, ceramic wall tiles, terracotta,
plaster (without organic additives).
Containing minor
quantities of
flammable additives
(organic ingredients)
Gypsum-cardboard plates, base felt plates, glass
fibre, plates of AKUMINE, lycopene
RAYOLITE, LIGNOS, VELOX and
HERACLITE
B Flammable
B1 Not easily flammable Beech and oak wood, composite wood, felt, plates
of HOBREX, VERSALITE and UMAKART
B2 Flammable
Pine wood, larch and spruce wood,
veneered wood
B3 Easily flammable
Asphalt, cardboard, cellulosic material, tar paper,
particle board, cork, polyurethane, polystyrene,
polyethylene, floor fibres
Table 2. Flammability of building materials per DIN 4102
2.5 Tools, materials and auxiliary aids
For assembly and maintenance of the boiler, standard tools for doing thermo-technical,
plumbing and electrical installations are required.
2.6 Antifreeze protection
If the use of antifreeze additives cannot be avoided, use those additives which are permitted
for heating installations.
2.7 Waste disposal
- Dispose of the packaging in an environmentally friendly manner.
- Dispose of the components which should be replaced in an environmentally friendly
manner.
2.8 Scope of delivery
During delivery of the boiler, adhere to the following:
- Check whether the packaging is undamaged
During delivery.
- Check whether the delivery is complete.

10
2.9 Name plate
Standard plate of the boiler is located on the outside of the boiler and contains the following
technical data: model, voltage, power, serial number, year of production.
2.10 Dimensions and technical data
Picture 5. Dimensions
A=640mm; B=400mm; C=290mm
