Radio control model P-51 VooDoo User manual

RADIO CONTROL MODEL / RC FLUGMODELL
SPECIFICATIONS
Wingspan.......57.5 in. / 146cm
Length...............50 in. / 127cm
Engine................46 2T / .70 4T
or Electric equivalent.
Radio..................4~ 6channel
WARNING! This radio control model is not a toy. If modified or flow carelessly it could go out of control and
cause serious bodily injury or property damage.
Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas with no debris or obstacles.
INSTRUCTION MANUAL
Almost ready to fly

1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
The pre-covered film on ARF kit may wrinkle due to variations
of temperature. Smooth out as explained right.
* Use an iron or heat gun. Start as low setting. Increase the
setting if necsessary. If it is too high, you may damage the
film Low setting
SILICON
EPOXY A
EPOXY B
CA
GLUE
Epoxy Glue ( 5 minute type)
Silicon sealer
Cyanoacrylate
Glue
Minimum 5 channel radio
for airplane with 5 servos .60 ~.70 - 4 cycle
10.5x6 for .40 - 2 cycle engine
11x6 for .46 - 2 cycle engine
12x6 for .60 - 4 cycle engine
12x7 for .70 - 4 cycle engine
13x8 for G-46 HP Motor.
Silicone tube
Extension for aileron
servo, retract servo.
.46 ~ .50 - 2 cycle
REQUIRED FOR OPERATION (Purchase separately)
Linkage Stopper x2
(for retract servo)
Epoxy Glue (30 minute type)
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors
Wire Cutters
(Purchase separately)
Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Rubbing alcohol - Drill and Assorted Drill Bits
Read through the manual before you begin, so you will have an overall idea of what to do.
Symbols used throughout this instruction manual, comprise:
(Purchase separately)
Retract landing
gear VQAR03
Retract servo
x1
.Motor control x1
.Elevator x1
.Rudder x1
.Aileron x2
G-46 HP Motor
or equivalent.
Motor Control
Li-Po Battery, 5 cell 4500mAh.
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
16023

2- Joining the wing
AB
Center line
! Make sure to glue securely, If not properly glued, a failure
in flight may occur.
Use epoxy glue to bury the
opening
TOP VIEW
1- Using a pencil, mark the center of the brace.
2- Trial fit the wing joiner into one of the wing panels. It should insert smoothly up to the center line marked above.
3- Slide the other wing half onto the dihedral brace until the wing panel meet. If the fit is over tight, it may be necessary to
lightly sand the dihedral brace.
4- Check for the correct dihedral angle.
5- Mix up some 30 minute epoxy and apply a generous amount of epoxy into the wing joiner cavity of one wing half.
6- Coat one half of the dihedral brace with epoxy up to the center line. Install the epoxy-coated side of the dihedral brace
into the wing joiner cavity up to the center line, marking sure that the “V” of the dihedral brace is positioned correctly
7- Do the same way with the other wing half.
8- Carefully slide the wing halves together, ensuring that they are accurately aligned. Firmly press the two halves
together, allowing the excess epoxy to run out. Clean off the excess epoxy.
Binder clip
Nylon wing bolt
Rubber band
(both the top
and bottom)
IMPORTANT:
Please do not clean off the excess epoxy on the wing with strong solvent or pure alcohol, only use
kerosene to keep the colour of your model not fade.
Cut the opening hole (½”x1/2”)
throughout the balsa wood for
the aileron extension cord exit.
Using the thread (pre-installed at factory) to slide
the aileron extension cord into the wing half.
Thread (pre-installed at factory)
Secure one end of the
aileron extension cord
with adhesive tape
Do the same way with other wing half.
Note: The two wing halves roots must fit together perfectly.
Hold the wing halves together with binder
clip and rubber band (not include)
AB
1- Joining the wing
WING - TOP VIEW
WING ROOT

2mm
3x20mm screw
(not included)
Retract pushrod
BOTTOM-VIEW
Trial fit the push rod into the wing. Join the pushrod to the retract
gear arm and trial fit the retract into the wing.
After checking that the retract works
smoothly, fix the retract on the wing
with 3x20mm self tapping screws.
Do the same way with other half wing.
5- Retract landing gear installation
Put the nylon ring
Retract push rod Retract gear arm
Retract pushrod
VQ-AR03 -160223
Retract (option)
VQ-AR03 -160223
Retract (option)
Plywood buffer
included with
retract set.
FRONT-VIEW WING-TOP
X
Retract landing gear
servo
4- Servo Installation TOP VIEW
3- Retract servo tray TOP VIEW
Cut away only
the covering
Note: The head of servo should be positioned
toward the rear of the wing.
Install the retract servo onto the retract servo mount
and secure it in place with four screw (included with radio set).
BOTTOM
RETRACT SERVO INSTALLATION
1.5mm
1/16”
BC
A
CENTER
WING
SECTION
CA
CA
CA
CA
BOTTOM
A
BC
Retract servo tray installation
CENTER
WING
SECTION
Retract servo
mount
Retract servo
mount
Retract servo tray
1/8(3mm plywood)
Secure one end of the
aileron extension cord
with adhesive tape
RETRACT
SERVO

RETRACTED EXTENDED
Retract servo
Retract gear
Retract gear
6- Retract landing gear Installation
WING TOP-VIEW
Link the servo and retract gear arm with push rod.
Be sure to adjust the stroke so that the landing
gear locks in both up and down position.
With the retract and retract servo in the
retracted position, mark the position where
each of the pushrod will attach to the servo
arm, a small piece of masking tape works
well for this. Cut off the excess length each rod.
Ply gear mount
plate x 2
Gear mount x 2
2mm
Bottom view /Ansicht von unten
ELECTRIC RETRACT
LANDING GEAR
7- Electric retract landing gear / Einziehfahrwerk
RECEIVER
ELECTRIC RETRACT
LANDING GEAR
ON
OFF
GEAR
EXTENDED POSITION
RETRACTED POSITION
2mm
Main landing gear
2mm
3x12mm screw
Gear mount
1
3x20mm
Nylon gear
strap
2mm
23x20mm
Ply gear
mount flat
Square
plastic
2mm
3
3x20mm screw
..........8
3x12mm screw
......16
Nylon gear strap
.......4
3x20mm screw
Wing - bottom view
8- Fixed gear / Starres Fahrwerk
4
Square plastic x 2

2x6mm screw
..........4
....2
...2
CA
5/32” (4mm)
Wing bolt flat
Wing bolt flat 1/8”(3mm)plywood
Wing bolt flat
Center line
Using the wing bolt flat as a
template, trace around the outside
edge of the wing bolt flat and then remove it.
Using a sharp hobby knife, cut away the covering inside the lines. Not
to cut into the wood.
Apply the wing bolt flat in place and secure it with CA glue.
11- Wing bolt flat /
Verstarkung
Bottom view /Ansicht von unten
CA
Cut away only the
covering
4mm collar
10- Fixed gear / Starres Fahrwerk
ABS Wheel well cover
CA
Bottom view /Ansicht von unten
9- Fixed gear / Starres Fahrwerk

13- Aileron servo installation
Plastic control horn
....................2
2x20mm screw
..............4
Connector
......2
Aileron push rod
BOTTOM VIEW
Drill the holes throughout the wing
bolt plat , from the top to the bottom
of the wing.
TOP
Connect the aileron extension cord to the
aileron servo and secure with adhesive tape
before install the aileron servo on to the wing.
Adhesive
tape
Do the same way with second aileron servo.
-Switch on the radio (trims centered)
then mount the ailerons servo horn in
neutral position.
-The servo horn should
be perpendicular to
the servo
YES NO
WING BOTTOM-VIEW
Hinge Line/Control horn Alignment
Depending on the position of the linkage, determine the location
of aileron control horn.
The horn holes must be perfectly aligned with the axis of articulation.
Mark the position of the “foot” of the horn on the aileron. Then, with
the drill, make the 2 holes.
Install the aileron control horn as shown.
......2
..2
AILERON
14- Aileron linkage
2mm screw
BOTTOM
12- Wing bolt flat / Verstarkung
6.5mm
17/64”
RIGHT
WRONG
WING
Aileron pushrod

17- Installing the wing
BOTTOM-VIEW
Nylon wing bolt
CA
Cut away the covering inside the line
before install the air scoop and wing cover
Plastic air scoop
CA
Wing cover
BOTTOM-VIEW
Wing bolt plat
1/8”(3mm) ply
Wing bolt mount
Plastic air scoop
Plastic cover
6x40 plastic bolt
(Ply wood)
Plastic mount nut
Bottom Wing bolt plat
1-Using the ABS air scoop as a template, trace around the outside edge of the ABS air-scoop,and then remove it.
2-Using a sharp hobby knife, cut away the covering inside the lines. Not to cut into the wood.
3-Apply the ABS air scoop in place and secure with CA glue. Do the same way with the ABS wing cover.
12mm
15/32”
6x40mm nylon bolt
.........2
WING
16- Air Scoop/wing cover
15- Air Scoop/wing cover

AB
A = A’
B = B’
Securely glue together. If coming off during flight, you lose control of
your air plane.
18- Horizontal stabilizer
Cut away only the covering
both the top and bottom side*
AA’
90O90O
Both the top and
bottom side
Cut away only the covering both
the right and left side
BB’
1-Trial fit the horizontal stabilizer in place .
Check the alignment of the horizontal
stabilizer. When you are satisfied with the
alignment, use a pencil to trace around the top and
bottom of the stabilizer where it meets the fuselage.
2-Remove the horizontal stabilizer from the fuselage. Using the
sharp hobby knife, carefully cut away the covering inside the
lines which were marked above.
3-Spread epoxy (30 minute) onto the top and bottom of the horizontal stabilizer
along the area where the covering was removed and to the fuselage where the
horizontal stabilizer mounts.
4-Install the horizontal stabilizer into the fuselage and adust the alignment as described in steep 1
5-Wipe off any excess epoxy using a paper towel and rubbing alcohol.
Allow the epoxy to cure before proceeding to next step.
Vergewissern Sie sich, sauber geklebt zu haben. Andernfalls konnen
Probleme mit der Flugeigenschaft auftreten!
* WARNING: When removing any covering from the airframe, please ensure that you secure the
cut edge with CA or similar cement. This will ensure the covering remain tight.
1-Trial fit the vertical stabilizer in place . Check the
alignment of the vertical stabilizer. When you are
satisfied with the alignment, use a pencil to trace
around the right and left of the stabilizer where it
meets the fuselage.
2-Remove the vertical stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
3-Spread epoxy (30 minute) onto the right and left and
bottom of the vertical stabilizer along the area where
the covering was removed and to the fuselage where
the vertical stabilizer mounts.
4-Install the vertical stabilizer into the fuselage and
adust the alignment as described in steep 1.
Allow the epoxy to cure before proceeding to next step.
AB
Cut away only the covering both
the right and left side*
C = C’
19- Vertical stabilizer
Both the left and
right side
CC’
Securely glue together. If coming off during flight,
you lose control of your air plane.
* WARNING: When removing any covering from the airframe, please ensure that you secure the cut edge with
CA or similar cement. This will ensure the covering remain tight.
IMPORTANT:
Please do not clean off the excess epoxy
with strong solvent or pure alcohol, only use kerosene to
keep the colour of your model not fade.
Control horn
...........1
2x12mm
......2
CA
Thin CA
5-Push the rudder and its hinges into the hinge slots in
the trailing edge of the vertical stabilizer. There
should be a minimal hinge gap.
When satisfied with the and alignment, hinge the
rudder to the vertical stabilizer using thin CA glue.
Make sure to apply a thin CA glue to the left and right
of both hinges and to inside the hinge slots.

CA
1- Insert the tail wheel pushrod into the hole on the tail gear control
horn (as show).
2- Install the tail wheel control horn in place.
4- Secure the tail wheel control horn in place using a 5/64”(2mm) screw set,
Ensure smooth non-binding movement.
5- Installing the tail wheel hatch (H) in place using a four 5/64x25/64”(2x10mm) self tapping screws.
6- Attach the tail wheel doors (D) in place using CA glue.
21- Tail gear
1
3
4
5
2
5/64 in.(2mm) I.D collar
2x10mm
screw
...............1
Tail landing gear
..........1
............1
2x3mm screw
............4
2x10mm screw
.................1
Tail wheel control-
horn
2mm I.D collar
6
3- Instal the tail wheel gear in place.
BOTTOM-VIEW
H
D
Securely glue together. If coming
off during flight, you lose control
of your air plane.
5 5
Bottom view
3/8 in. (9.5mm)
push the elevator and its hinges into the hinge slots in
the trailing edge of the horizontal stabilizer. There
should be a minimal hinge gap.
When satisfied with the and alignment, hinge the elevator
to the horizontal stabilizer using thin CA glue. Make
sure to apply a thin CA glue to the top and bottom of both
hinges and to inside the hinge slots. Repeat the previous
procedures to hinge the second elevator to the other side
of the horizontal stabilizer.
Control horn
................2
2x12mm screw
..........4
20- Elevator installation
Vergewissern Sie sich, sauber geklebt zu haben.
Andernfalls konnen Probleme mit der Flugeigenschaft
auftreten!
CA

! Align the mark on both mounts
with the mark on the fuselage
22- Engine mount - engine
A
B
B’
B=B’
FRONT-VIEW
- Remove the engine mount and drill a 13/64”(5mm) hole through
the fire-wall at each of the four marks marked.
- Using a pencil or felt tipped pen, mark the fire wall where the four
holes are to be drilled
- Reposition the engine mounts on to the fire-wall.
Attach the four blind-nut to the fire-wall as show.
Secure them with four 4x25mm screw.
- Position the engine on to the engine mounts so the distance
from the prop hub to the fire wall is 5-1/8”(127mm)
125~127mm
! Engine thrust on balk
head is already adjust
at factory
1.5
TOP-VIEW
- Mark the engine mounting plate where the four holes are to be
drilled.
Note: Mark the mounting plate through the engine mounting flanges.
- Remove the engine and drill a 1/8”(3mm) holes through the beam
at each of the four marks made above.
- Reposition the engine on the engine mount beams, aligning it with
the holes. Secure the engine to the engine mount using four
1/8x51/64”(3x25mm) screws.
3mm
1/8”
Note: Apply Silicon sealer to
each of the 1/8x51/64” screw.
...4
.................4
4x25mm screw
Blind-nut
3x20mm screw
1/8”(3mm) nut
.................4
...4
1/8x5-1/64”
5/32x1”
(5-1/8”)
A
5mm
13/64”
5-1/8”
A

X
25- Radio and battery
Elevator push rod
Throttle push rod
Rudder push rod
Tail wheel push rod
4-49/64”
(120mm)
2-61/64”
(75mm)
Carefully cut a 2-9/32”(58mm) wide area which is 2-61/64”
(75mm) in length through both the covering and the balsa
wood. Remove the excess balsa.
Put the battery pack into the box (pre-build at factory) and
fasten down with rubber bands or similar, ensuring it will not
come loose or rattle during flights.
Link the battery wire with the battery extension cord.
Reposition the hatch in place and secure it with CA glue.
Battery area
(in case of 4T engine)
BOTTOM VIEW
Battery area
(in case of 2T engine)
800-1000mah, flat pack
BOTTOM VIEW
Hatch
Hatch
2-9/32”
(58mm) 2”(51mm)
2-61/64”(75mm)
FUSELAGE
BOTTOM
X
To muffler
Filler tube
To engine
3x25mm
screw
Rubber stopper
1
After confirming the direction . Insert this assembly, clunk end first, into the fuel
tank and tighten and screw the fuel tank cap on firmly.
3x35 mm screw 4mm
2
23- Fuel tank
24- Electric motor
Firewall
125~127mm
(5-1/8”)
B’
B
B=B’
A
A=A’
A’
TOP-VIEW
SIDE-VIEW
! Engine thrust on balk head
is already adjust at factory
Using a aluminum motor mounting
plate as a template, mark the
plywood motor mounting plate
where the four holes are to be
drilled (2).
Remove the aluminum
motor mounting plate and
drill a 1/8”(3mm) hole
through the plywood at
each of the four marks
marked .
CA
1
3mm
2
Note: The aluminum motor mounting
included with electric motor set.
Checking for leaks - block the vents and blow into the feed - if in doubt submersing the tank in a blow of water will
show up any problems
34

26- Linkages
Elevator push rod
Elevator push rod
Tail wheel push rod
Rudder push rod
Throttle push rod
................2
....................3
2mm
Connector
Elev. servo
Rudder servo
Thrott. servo
BOTTOM VIEW
X
Elevator pushrod
or rudder pusshrod
D=5/64”(2mm)
Tail wheel pushrod
D=.050”(1.2mm)
3mm set Screw
2 mm
Elevator pushrod
ELEVATOR / RUDDER SERVO
X
3mm set Screw
2 mm
THROTTLE SERVO
throttle pushrod
D=.050”(1.2mm)
2.5x10mm
27- Cowling installation
1~2mm
Board or
transparent
plastic
Adhesive
tape 1-Attach the board or transparent plastic on the side of
the fuselage with the adhesive tape as show.
2-Using a pencil or felt tipped pen trace around the engine
head where it meet the cowl. Cut the opening the board
or transparent plastic for the engine head as marked before.
3-Remove the engine and insert the cowl on to the fuselage
so the distance from the fire wall to the front of the cowl is
4-59/64”(125mm). Trace around inside the hole on the board
or transparent plastic with a pencil.
4-Remove the cowl from the fuselage and carefully cut the
opening for the engine head as marked above. Do the same
way with the hole for needle-valve.
5-Again. Insert the cowl on to the fuselage and secure it in
place with five 2.5x10mm self tapping screws.
125mm
Ruler
Cut the opening
Cut the opening
1.5mm
1/16”
1.5mm
1/16”
2.5x10mm self
tapping screw
3/32x25/64” self tapping screw
.................4
1/16”

Wing center section
DO NOT try to fly an out-of-balance model !
29- Balance
5-13/64” (132mm)
Note: If necessary, move the battery pack or add weight to either the tail
or nose until the correct balance is achieved.
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors.
Arrange sticker on model and when satisfied adhere the corner without backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model
surface with the tip of the knife or sharp pin and squeeze out the air.
At curves stretch sticker and apply a little heat so that no ceases occur.
Cut off the excess that is produced.
28- Decor
All details are subject to change
without notice !
Technische Anderungen und Irrtumer
vorbehalten !
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
FUELS FUELS
CHAMPION
A E R O S P A C E

1-23/64”(35 mm)
15/64”(6mm)
13/32”(10mm)
RUDDER STROKE ELEVATOR STROKE
AILERON STROKE
Adjust the travel of the control surfaces to achieve the values stated in the diagrams.
These value will be suitable for average flight requirements. Adjust the values to suit your particular needs.
15/64”(6mm)
13/32”(10mm)
1-23/64”(35 mm)
30 Control Surface
