Radio Shack 60-4360 User manual

Corvette C5-R
60-4360
What’s Included
Step Three
Installing Batteries
To power and operate your vehicle, you will need:
•SixAAalkalineorone9.6Vrechargeablebatterypack(AAbatteries,battery
pack and charger not supplied, available at your local RadioShack store).
•One 9V battery (not supplied).
In the Adapter Pack
If you are using alkaline batteries to poweryour vehicle, you will first need to
insert them into the supplied adapter pack.
1. Loosen the two screws, and then remove the adapter pack’s cover.
2. Place the batteries in the adapter pack according to the polarity
symbols (+/–) marked inside.
3. Replace the cover, and secure the two screws.
In the Vehicle
1. Turnthevehicleoff.
2. Remove the battery compartment’s cover.
3. Place the rechargeable battery pack oradapter pack in the
compartment. Situate the pack’s wires in the slot on the side of the
compartment, so the wiring does not rest on the battery pack.
4. Attach the pack’s white plastic connector to the vehicle’s matching
connector. Do not force the connection. It fits only one way.
5. Replace the cover and secure the latches.
Before you can use the rechargeable battery pack, it will need to be
charged.
Rechargethebatterypack orreplace theAA batteriesif thevehicledoes
not run, runs slowly, or does not respond to the transmitter.
In the Transmitter
1. Turn the transmitter off.
2. Remove the battery compartment’s cover.
3. Insert the9V battery according to the polaritysymbols (+/–)marked
inside.
4. Replace the cover and snap itshut.
Replace the battery when the transmitter’srange decreases.
Screws Cover
Adapter Pack
Wheel Alignment R/L
ON / OFF
Battery
Compartment
Latches
Compartment Cover
Battery Pack or
Adapter Pack
9V Battery
Cover
Compartment
Driving the Corvette
1. Turn the vehicle and transmitter on.
The transmitter’s LED lights
2. Use the transmitter’s levers to control the vehicle.
3. When you finish driving the Corvette, turn the vehicle
and transmitter off.
Wheel Alignment
If the vehicle does not drive in a straight line
when you release the right lever, adjust the
wheel alignment control on the bottom of the
car. Turn the control toward Lif the car is
pulling to the right, or toward Rif the car is
pulling to the left.
Step One
Step Two
6Corvette C5-R 1/12 scale model (RX)
6Transmitter (TX)
6AA battery adapter pack
6User’s Guide
• If your vehicle gets stuck under an object, immediately release the
transmitter levers and retrieve the car.
• Running your vehicle continuously for long periods of time generates
high heat levels. Heat causes wear and tear on the motor. To help
keep heat levels down, when your vehicle’s battery pack runs down,
letthevehiclecoolat least 10minutes beforeinstalling anewor newly
charged battery pack.
• If someone uses a CB radio nearby, it might interfere with control of
the vehicle. If this happens, move the car away from the area where
the CB is being operated.
• You cannot operate your vehicle near devices with transmitters that
use the same frequency as your’s (27 MHz or 49 MHz). Check this
product’s box to see which frequency your vehicle uses.
• Ifthe vehicle movesslowly, andyou justinstalled afreshbattery pack,
check the wheel mechanisms for lint, threads, hair, or dust.
Helpful Hints
Important
The EPA certified RBRC®Battery Recycling Seal on the
nickel-cadmium (Ni-Cd) battery indicates RadioShack is
voluntarily participating in an industry program to collect and
recycle these batteries at the end of their useful life, when
taken out of service in the United States or Canada. The RBRC program
provides a convenient alternative to placing used Ni-Cd batteries into the
trash or the municipal waste stream, which may be illegal in your area.
Please call 1-800-THE-SHACK (1-800-843-7422) for information on Ni-Cd
batteryrecycling and disposal bans/restrictionsin yourarea. RadioShack’s
involvement in this program is part of the company’s commitment to
preserving our environment and conserving our natural resources.
Thank you for purchasing the RadioShack
Corvette C5-R. It’s spring suspension lets it
handle the road in style. Built to 1/12 scale, it will
dazzle your friends as it reaches speeds up to
1,000 feet per minute. Your vehicle is available
in two frequencies (27 and 49MHz) so you can
race other radio-controlled vehicles.
Right Lever —
6Push left to turn
left.
6Push right to turn
right.
6Releasetogo
straight.
Left Lever —
6Push forward to
drive forward.
6Pull back to drive in
reverse.
6Release to stop.
• Using alkaline batteries slightly decreases
the vehicle’s speed.
• Dispose of old batteries promptly and
properly.
• Do not burn or burybatteries.
• Use only fresh batteries ofthe required
size and recommended type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or
rechargeable),orrechargeablebatteriesof
different capacities.
• If you do not plan to use the vehicle for
several weeks, remove the batteries.
Batteries can leak chemicals that can
damage electronic parts.
• Donotchargeorrechargethebatterypack
while it is in the vehicle.
Battery Notes
oWARNINGS o
•If you use alkaline batteries to power the vehicle, they will
get very hot. To avoid getting burned, wait a few minutes
before attempting to remove the batteries.
• Do not charge alkaline batteries. They will overheat, and
explode.

©2003. RadioShack Corporation. 60-4360
All Rights Reserved. Printed in China
RadioShack and RadioShack.com are trademarks 05A03
used by RadioShack Corporation.
