RADtec TORRID Series User manual

OPERATING MANUAL
INFRARED RADIANT HEATER: TORRID SERIES
T6000/12r & T6000/18r

2
Table of contents
Description of heaters __________________________________3
Advantages of heaters__________________________________4
Characteristics of T6000 ________________________________4
Package_____________________________________________ 5
Heater device (fig. 1)____________________________________5
Heater fixing procedure__________________________________5
Heater fastening mechanism_____________________________6
Heater Connection Requirements__________________________7
Safety warnings ________________________________________7
Heater maintenance ____________________________________7
Limited Warranty ______________________________________8

3
T6000/12R T6000/18R
A (Min-Max) 10-13 13-16
B(Min-Max) 7-13 13-20
C(Min-Max) 12-13 14-15
D(Min-Max) 7-11 11-15
S(Min-Max) 161-230 230-300
Thank you for choosing RADtec heating products.
This product operates in compliance with the information laid out in this manual.
***Attention! Before using this product, please read the manual carefully***
You have purchased the following model: RADtec Torrid Series - Infrared Radiant Heater
RADtec T6000/12r
RADtec T6000/18r
This model heater operates by projecting a “Radiant Footprint” over your living space. Radiant energy is transferred to people
and objects within this projected footprint via radiant energy – similar to how the sun warms you up when you stand in sunlight.
This method of heating is very popular today because infrared heat energy transfer is hyper efficient. Remember, warm or hot
air is less dense than surrounding colder air and rises due to thermal convection. Infrared heat is not lost to air currents because
infrared heaters do not heat the air. Infrared energy does not “excite” air molecules, instead bypassing them and warming
whatever surface this energy hits thereafter.
Please reference the graphic below to better understand how this footprint projects from the heater you have purchased.
Description of RADtec Torrid Series Heaters:
RADtec infrared heaters are designed for various applications, both outdoors and indoors.
Example: terraces, patios, verandas, gazebos, hangars, workshops, etc.
RADtec Torrid series heaters have a stylish compact design. Applications can include both vertical(wall) and horizontal(ceiling)
installations. It is also possible to place this heater on a mobile stand (not included, purchased separately).
RADtec state-of-the-art infrared heaters use high efficiency heating elements. 95% or more of the electrical power consumed is
converted into a heat flux. Infrared heating achieves this efficiency by heating objects in the area without having to heat the
surrounding air.
What Does Heat Flux Mean?
Heat flux is thermal energy transferred from one substance to another per unit time and area denoted by temperature change
measured in watts per feet/meter squared units. In simple terms, it is the heat transferred per unit area. To obtain this value, one
must obtain the change in temperature, the thermal conductivity of the medium of conduction and the direction of the heat
transfer. Accurate figures are obtained when the system is in a steady state condition.

4
T6000/12r T6000/18r
Controller Yes Yes
IRWavelength 1,2 µm 1,2 µm
IRQuantity 3 3
IRFilament Length (mm) 3x355 3x550
OperatingVoltage (Volt) 220V 220V
Total Power (Watts) 6000 6000
Dimensions (in) 52x6x5 75x6x5
IPClass IP67 IP67
Heating Area (ft2) 160-255 175-300
Infrared Life (hours) 7000 7000
Warranty Period 2 Years 2 Years
BODYFEATURES
Material used Aluminum Aluminum
Color Black Black
Power Cord 48in 48in
MOUNTING FEATURES
Application surface Wall/Ceiling Wall/Ceiling
Advantages of RADtec heaters
• Wide range of applications
• Eco-friendly, safe for humans and animals
• Remote controlled
• Instant heat
• High efciency
• 2-yr warranty
• First heater with IP67 certication
Characteristics of Torrid Series Models
Product ID

5
Equipment
• Packaging containers - 1 pc.
• Heater with power cable and plug - 1 pc.
• Remote control (with power supply - 2 pcs., Type AAA battery) - 1 pc. *
* (for r series models)
• Fasteners - set.
• Operation manual - 1 pc.
• Warranty card - 1 pc.
Heater device (g. 1)
1. Heater body 2. Side control module covers *
3. Heater casing lateral covers 4. Protective grill
5. Side walls of the reector 6. Control module housing *
7. Control module panel * 8. Infrared element
9. Power cable with plug 10. Heat Reector
Heater xing procedure
1. Inspect the heater for external damage.
2. Determine mounting location for the heater, taking into account the requirements indicated
in the diagram.
6feet
(min)
24in
(min)
39in
(min)
2in
(min)
2in
(min)
24in
(min)
6feet
(min)

6
3.Fix the mounting bracket to the surface (wall or ceiling).
4. Assemble the heater mounting mechanism as shown in the Heater Mounting section.
5. Install the heater on the bracket using the guides on the back of the housing . When
mounting the heater on a vertical surface, ensure that the Control Module is in the correct
position (page 8)
6. Connect the heater to a power supply in accordance with local electrical and re safety
requirements.
Heater mounting:
Correct position of the heater
on a vertical surface (wall)
for Torrid series models
vertical placement horizontal placement
MountingBracket
Screw
WingNut
Screw
Channel Bracket
Channel Tightening Screws
Finishedmounting hardware Wall installationof the infrared
heater

7
Heater Connection Requirements
1. The heater is 220-240 volts.
2. The heater (s) are connected to a separate line with a dedicated circuit breaker with a current
cut-off rating corresponding to the power of the heater (s).
3. Consult a licensed electrician for installation.
WARNING: Do not use extension cords as they are not designed to power outdoor heaters.
Safety warnings
1. Use the heater only for its intended purpose.
2. Observe the required distances to the suspension height when installing and using the heater.
- Heater distance to ground or floor - not less than 6feet.
- Heater distance to heated surfaces - not less than 24 inches.
3. Do not place or store flammable objects and materials in the place where the heater is used.
4. Do not touch the heater during operation, and do not allow children and pets to come into contact
with the heater.
Heater remote control
There are 3 buttons on the remote control.
Button 1 (bottom right) - power on / off.
Buttons 2 and 3 - selection of 4 heating power modes.
The selected mode is displayed on the display of the heater control module. It is
possible to control several heaters using one remote control.
Heater maintenance
• To ensure stable operation of the product, regularly inspect the heater and the supply cable for
external damage
• As the heater and reflector become dirty, clean in the following order:
1. Make sure that the heater has not been used and that the casing of the heater is at ambient
temperature.
2. Disconnect the heater from the power source, remove it from the attachment point and place it
on a horizontal surface.
3. Clean the external elements of the heater with a dry clean, soft cloth.
4. Remove the left side cover of the heater housing. There are two screws on the end of the heater
and two screws on the rear wall of the housing
5. Carefully slide the protective grill out of the left side.
6. Clean the internal elements of the compartment with a dry clean, soft cloth.
WARNING: Use cotton or latex gloves to clean. This will prevent contact with the IR element. Direct
contact with the element will leave fingerprints, which will negatively affect its operation and damage
the heating element.
7. After cleaning the heater, reassemble in the reverse order and reinstall the heater.

8
Limited Warranty
RADtec provides a 30-Day Return Window (see refund and return policy page) and the following limited warranty.
This limited warranty extends only to the original purchaser.
Please note that any warranty services or questions must be accompanied by order number from the transaction through which
the warranted product was purchased, and the ID number located on the unit. The order number and ID# serve as your warranty
numbers and must be retained. RADtec will offer no warranty service without these numbers. RADtec warrants this product and
its parts against defects in materials or workmanship for (2) years' parts and labor (residential use) and (1) year parts and labor
(commercial use) from the original ship date. During this period, RADtec will repair or replace defective parts with new or
reconditioned parts at RADtec's option, without charge to you.
Shipping fees incurred from returns for under-warranty service in the first 30-days will be paid by RADtec. All shipping fees
both to and from RADtec following this 30-day period must be paid by the customer. All returns, both during and following the
30-day period, must be affected via the Procedures for Obtaining Warranty Service described below. All original parts (parts
installed by RADtec at the original build) replaced by RADtec or its authorized service center, become the property of
RADtec. Any after-market additions or modifications will not be warranted. The heater owner is responsible for the payment,
at current rates, for any service or repair outside the scope of this limited warranty.
RADtec makes no other warranty, either express of implied, including but not limited to implied warranties or
merchantability, fitness for a particularpurpose, or conformity to any representation or description, with respect to this heater
other than as set forth below. RADtec makes no warranty or representation, either express or implied, with respect to any other
manufacturer’s product or documentation, its quality, performance, merchantability, fitness for a particular purpose, or
conformity to any representation or description.
Except as provided below, RADtec is not liable for any loss, cost, expense, inconvenience or damage that may result from use
or inability to use the heater. Under no circumstances shall RADtec be liable forany loss, cost, expense, inconvenience or
damage exceeding the purchase price of the heater.
The warranty and remedies set forth below are exclusive and in lieu of all others, oral or written, expressed or implied. No
reseller, agent or employee is authorized to make any modification, extension or addition to this warranty.
Warranty Conditions
The above Limited Warranty is subject to the following conditions:
1. This warranty extends only to products distributed and/or sold by RADtec. It is effective only if the products are
purchased and operated in the USA. (Within the USA including US 48 States, Alaska, and Hawaii.)
2. This warranty covers only normal use of the heater. RADtec shall not be liable under this warranty if any damage or
defect results from (i) misuse, abuse, neglect, improper shipping or installation; (ii) disasters such as fire, flood,
lightning or improper electric current; or (iii) service or alteration by anyone other than an authorized RADtec
representative; (iv) damages incurred through irresponsible use, including those resulting from mounting the heater
above a body of water, mounting the heater vertically and or other non-recommended practices.
3. You must retain your bill of sale or other proof of purchase to receive warranty service.
4. No warranty extension will be granted for any replacement part(s) furnished to the purchaser in fulfillment of this
warranty.
5. RADtec makes no warranty either expressed or implied regarding third-party (non-RADtec) parts.
6. You must have filled out and filed your Warranty Card with RADtec to activate this warranty.
Return of Non-Defective Products
A non-defective product may be returned to RADtec within thirty (30) days of the invoice date for a refund of the original
purchase price with the following amendments/fees:
1. RADtec will refund neither the original shipping cost nor the shipping and handling fees incurred from
the products return. If the original purchase was made under a “Free Shipping” promotion, then a
standard $50 fee will be deducted from any return in counter to that offer.
2. No refund will be granted for the heater which has been used or tampered with in any way which
jeopardized RADtec’s ability to remarket or resell the product. RADtec maintains full discretion in
decisions regarding a product’s fitness for return.
3. No refund will be granted if the product has been installed OR more than 30 days has elapsed since
the product was purchased.
4. Any non-defective returns are subjectto a 15% restocking fee; which percentage is taken from the final
purchase price less any shipping or handling charges.
5. Quantity purchases of five heaters or more are not eligible for return.
