teko Astra-8 User manual

Astra-8
Dual Channel (infra-red + acoustic)
Detector
User Guide
Manufacturer:
TEKO-TD
M.Gafuri. 71
420108 Kazan, Russia
[phone]
[email protected]
Made in Russia
Rev. 8-v1_1_instr_EN
1 FUNCTION
The detector is intended for detection of
unauthorized access into an enclosed area,
detection of glass breaking of glazed
constructions of an enclosed area and
generation of alarm notification by opening
contacts of dedicated alarm relay.
2 DETECTION ZONE
3 SPECIFICATION
Range of detectable
moving speed, m/s.................from 0,3 up to 3,0
Power supply voltage, V.............from 8 up to 15
Current consumption, mA, max..................... 21
Overall dimensions, mm..................diameter 91
height 31
Operating Conditions
Temperature range, °С........ from - 20 up to +50
Relative air humidity, % .......... up to 95 at +35 °С
Withoutmoisture condensation
4 DELIVERY SET
Delivery set includes: dowel –2 pcs., screw –2
pcs., user guide –1 pcs.
5 MODES OF OPERATION
Plug
Jumper
position
Indication ON
Indication OFF
Ind
High sensitivity
of AC-channel
Normal sensitivi-
ty of AC-channel
GB
High
detectability of
IR channel
Normal
detectability of
IR channel
PIR
AC-

Plug
Jumper
position
“Alarm memory”
ON
“Alarm memory”
OFF
Mem
AC-channel
TEST
Tst
See sec. 9
6 INSTALLATION PLACE
1) Recommended installation height is 2.4-3.6
mand at a distance not more than 6m from the
most distant spot of protected glass.
2) Detector should be installed on the ceiling
(or any other horizontal surface) strictly
horizontally.
3) The detector cannot be used in premises
with high level of acoustic interference.
4) Alarm loop and power supply wires should
be located far from power cables.
To eliminate false alarm hazards
1) It is recommended to close all doors, air-
vents, switch off possible sourses of intense air
flows (fans, air-conditioners) and acoustic inter-
ferences (loudspeakers, etc.) in the room during
protection period.
2) The detector's location should provide di-
rect visibility of all secured glass parts; masking
the detector with decorative curtains is not al-
lowed, as sensitivity may be lost.
Not recommended installation places
7 INSTALLATION PROCEDURE
1) Remove cover
2) Remove PCB
3) Install on the ceiling
4) Install PCB and perform wiring (see sec.8)
5) Perform AC-channel and IR-channel testing
(see sec.9)
8 WIRING
Perform wiring to detector`s terminals in
accordance with control panel operating manual.
TMP –detector tampering control terminals;
RELAY-PIR, RELAY-GB –terminals for detector
connection to alarm loop;
+12V, GND –power supply terminals.
9 TESTING
AC-channel:
1) Remove jumpers from Mem and GB plugs,
install jumper on Ind plug.
2) Power detector ON. LED starts flash during
60 sec.
3) During this time close shortly Тst plug using
screwdriver. AC-channel TEST mode switches
for 8 min.
4) Close detector.
5) Apply non-destructive
strike to the most distant
part of the protected
glass.
6) At the detection
moment LED should light
up for 4s and relay
shouldopen (check with
control panel) or LED should double-flash one
time.
IR-channel:
Perform TEST-pass.
To detect sensitive zones
pass through detection
zone with the speed of
0.3-3 m/s. Make sure the
"Alarm - IR" notification
is issued with each pass.
10 WARRANTY
The operation warranty period is 5 years from the date
of operation start-up but no longer than 5 years 6
months from the date of manufacturing subject to the
requirements of Operating Manual.
Glass
35 cm
Hook
