Rainbow Zodiac CX20 User manual

WARNING
H0446500 Rev A
FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this
manual, this product must be serviced by a pool technician who is licensed and qualified in pool equipment
by the jurisdiction in which the product will be installed where such state or local requirements exist.
In the event no such state or local requirement exists, the pool technician must be a professional with
sufficient experience in pool equipment installation and maintenance so that all of the instructions in this
manual can be followed exactly. Improper installation and/or operation will void the warranty.
CyclonX Robotic Pool Cleaner
Owner's Manual
®Rainbow Pool Products
PO Box 2388, Mansfield Qld 4122
Telephone STD 61-7-3849 5385
Facsimile STD 61-7-3849 5384
Email: [email protected]
Web: www.rainbowpoolproducts.com.au

THANK YOU FOR PURCHASING THIS ROBOTIC POOL CLEANER BY ZODIAC®.
YOUR CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY INSTALLED AND TO
PROVIDE LOW MAINTENANCE OPERATION. A WARRANTY CARD IS SUPPLIED IN THE BOX. PLEASE GO
TO ZODIAC.COM.AU TO REGISTER FOR WARRANTY.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required, please
contact your original dealer. If the original dealer does not perform warranty service, please visit
www.zodiac.com.au to locate an independent service company near you. If you are unable to locate a service
company, please call our After Sales Support Team at 1300 763 021.
Section 1. Important Safety Instructions........ 3
Section 2. Getting Started................................ 4
*HQHUDO6SHFL¿FDWLRQV ...................................... 4
2.2 Unpacking .......................................................... 4
2.3 Cleaner Control box ........................................... 4
2.4 Connecting the Floating Cable to
the Control Box................................................... 5
Section 3. Operation......................................... 6
3.1 Submerging the Cleaner .................................... 6
3.2 Starting the Cleaner ........................................... 7
3.3 Wall Climbing
(Surface Control System) ................................... 7
3.4 Stopping the Cleaner
and Removing from the Pool.............................. 7
3.5 Rinsing the Cleaner............................................ 8
3.6 Cleaning the Filter Canister................................ 8
3.7 Storing the Cleaner ........................................... 9
Table of Contents
Section 4. Maintenance.................................. 10
4.1 Cord Tangling ................................................... 10
4.2 Replacing the Brushes ..................................... 10
4.3 Replacing the Track...........................................11
Section 5. Troubleshooting ........................... 12
5.1 Using the Information LED ............................... 12
5.2 General Troubleshooting .................................. 13
Section 6. Conformity .................................... 14
2 H0446500_REV A

Section 1. Important Safety Instructions
Congratulations on purchasing the Zodiac®Robotic Cleaner. Please read through the entire manual before installing
your new robotic pool cleaner. Your cleaner must be installed and operated as specified.
READ AND FOLLOW ALL INSTRUCTIONS
CAUTION
USE OF THE ZODIAC ROBOTIC CLEANER IN A VINYL LINER POOL
Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused by objects coming into contact
with the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine dispensers, and automatic pool cleaners. Some
vinyl liner patterns can be seriously scratched or abraded simply by rubbing the surface with a pool brush. Ink from the pattern can
also rub off during the installation process or when it comes into contact with objects in the pool. Zodiac Group Australia Pty Ltd is not
responsible for, and the Limited Warranty does not cover, pattern removal, abrasion or markings on vinyl liners.
SAVE THESE INSTRUCTIONS
WARNING
Failure to comply with the following warnings can result in permanent injury, electrocution or death.
PREVENT ELECTRICAL SHOCK
To reduce risk of electrical shock:
•The cleaner is to be installed in accordance with the relevant requirements of the Australian wiring rules AS/NZS 3000. Also refer to
the installation instructions relating to the swimming pool equipment for which the cleaner will be an integral part. The cleaner is to be
supplied through a Residual Current Device (RCD) with a rated residual operating current of 30mA.
•Do not enter pool while the robotic cleaner is in water.
•Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and other equipment.
•To reduce the risk of electrical shock, do not use the robotic cleaner or control box if the cord is worn or damaged. Contact Zodiac
Customer Care Service 1300 763 021 immediately for proper servicing and replacement of the damaged cord.
•Double insulation—For continued protection against possible electric shock, use only identical replacement parts when servicing. Do
not attempt repair of the robotic cleaner, control box, power cord, or floating cable.
•Use only the power supply provided with the product.
•NEVER OPEN Control box.
•DO NOT USE AN EXTENSION CORD TO CONNECT THE UNIT TO ELECTRIC SUPPLY; PROVIDE A PROPERLY LOCATED RCD
PROTECTED POWER OUTLET. THE CONTROL BOX SHOULD BE PLACED NEAR THE RCD PROTECTED GFCI POWER OUTLET
POINT.
PREVENT CHILD INJURY AND DROWNING
•To reduce the risk of injury, do not permit children or persons with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge to operate this product.
•Do not let anyone, especially small children, sit, step, lean, or climb on any equipment installed as part of your pool’s operational
system.
CAUTION
Failure to comply with the following warnings could cause damage to pool equipment or personal injury.
•The robotic cleaner must be installed and operated as specified.
•This product is intended for use with permanently-installed pools. Do not use with storable pools. A permanently-installed pool is
constructed in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool is constructed so
that it is capable of being readily disassembled for storage and reassembled to its original integrity.
•Clean the filter canister after each use.
•'RQRWXVHWKHSURGXFWLQ\RXUSRROLIWKHZDWHUWHPSHUDWXUHLVDERYHÛ& (Û))RUEHORZÛ& (Û)).
3
H0446500_REV A

Section 2. Getting Started
*HQHUDO6SHFL¿FDWLRQV
7KHJHQHUDOVSHFL¿FDWLRQVIRUWKHFOHDQHUDUHDVIROORZV
Control box
supply
voltage
220-240 VAC, 50 Hz; short circuit-proof
safety isolating type
Supply voltage 30 V DC
Installed load 150 W max
Cable length 15m (50 ft)
Cleaner size
(WxDxH)
41 x 42 x 25 cm
Weight of Cleaner 9 kg
Filtration
$OOSXUSRVH¿OWHUFDQLVWHU
Cycle lengths Variable programming
This cleaner is a double-insulated product. A double-
insulated electrical appliance is one which has been
designed in such a way that it does not require a safety
connection to ground. The basic requirement for
double-insulation is that no single failure will result in
dangerous voltage becoming exposed so that it might
cause an electric shock and that this is achieved by
having two (2) layers of insulating material surrounding
live parts or by using reinforced insulation. Therefore,
devices having double-insulated construction, such as
this cleaner, do not require a grounded (three-prong)
plug.
2.2 Unpacking
7KHSDFNDJLQJVKRXOGFRQWDLQWKHIROORZLQJLWHPV
•Zodiac®Robotic Cleaner
•Floating Cable
•Control box
:KHQXQSDFNLQJWKHFOHDQHUDQGLWVFRPSRQHQWV
•Check to make sure each component is in the box.
•Check cleaner and components for damage during
transport.
•If there are missing parts or damage, contact
=RGLDF7HFKQLFDO6XSSRUW
2.3 Cleaner Control box
SURFACE CONTROL SYSTEM
12 34ROUGH SMOOTH
Select Cleaning Surface
• Floor
• Floor and Walls
Start/Stop
Cleaner
Cleaner Error
Indicator
Surface Control
System (SCS)
for wall cleaning
(rough to smooth
surfaces)
LEDs indicating
pump strength for
SCS
4 H0446500_REV A

"CLICK"
"CLICK"
2
1
"CLICK"
"CLICK"
Figure 1. Connect the Power Cord
To Disconnect:
*ULSWKHSRZHUFRUG¿UPO\RQHDFKVLGHDQG
press two tabs to release (see Figure 2.)
Figure 2. Disconnect the Power Cord
2.4 Connecting the Floating Cable to
the Control Box
WARNING
Failure to comply with the following warnings can
result in permanent injury, electrocution or drowning.
PREVENT ELECTRICAL SHOCK
•Keep the Control box at least 3.5 m from the edge
of the pool.
•The cleaner is to be installed in accordance with
the relevant requirements of the Australian wiring
rules AS/NZS 3000. Also refer to the installation
instructions relating to the swimming pool equipment
for which the cleaner will be an integral part. The
cleaner is to be supplied through a Residual Current
Device (RCD) with a rated residual operating current
of 30mA.
•Do not use an extension cord to connect the
Control box.
•Do not allow anyone to swim while the cleaner is in
the pool.
•The Control box is water-resistant, not waterproof.
In order to prevent electrocution, never submerge
the Control box or leave exposed to inclement
weather.
To Connect:
•Rotate the power cord so that TOP is shown on
WKHWRSVLGH3UHVVWKHSRZHUFRUG¿UPO\LQWR
the control unit until you hear a "click" (see
)LJXUH7KHFOLFNLQJLQGLFDWHVWKHSRZHUFRUG
is connected correctly creating a watertight seal.
5
H0446500_REV A

Section 3. Operation
CAUTION
To prevent damage to the cleaner, be sure to adhere
to the following guidelines:
•Remove the cleaner from the pool after the
cleaning cycle is completed and store out of direct
sunlight or inclement weather.
•Take additional care when lifting the cleaner out of
the pool. It becomes heavier when filled with water.
•Always remove the cleaner from pool before adding
chemicals.
•Do not handle cleaner while it is in operation.
IMPORTANT
•Always make sure the cleaner head is fully
submerged before you begin operation.
•Clean the filter canister after each cleaning cycle.
•Do not leave your cleaner in the pool on a permanent
basis.
•At the end of each cycle, remove the cleaner from
the pool. Start at the cleaner head and untangle any
coils in the cable before storing the cleaner.
The Zodiac®robotic cleaner includes a safety feature
that automatically stops the cleaner if it is powered on
but not submerged in water. For pools equipped with a
beach area, this safety feature is programmed to drive
the cleaner in reverse and back into the pool when the
impeller is out of the water.
3.1 Submerging the Cleaner
6XEPHUJHFOHDQHUYHUWLFDOO\DQGKROGLW
under the surface, moving gently from side to
side (2) until the bubbles stop to remove any air
WUDSSHGLQVLGH)LJXUH
2. When the bubbles stop, allow the cleaner to
sink to the bottom of the pool.
9HULI\WKHFOHDQHULVVLWWLQJRQWKHERWWRP
of the pool. Remove additional air if the cleaner
LVVWLOOÀRDWLQJ
NOTE: The cable side of the cleaner remains up as long as
the cleaner fan motor is OFF. As soon as you turn the
cleaner ON, the handle lowers.
1
Figure 3. Submerge and Remove Trapped Air
2
6SUHDGWKHÀRDWLQJFDEOHRYHUWKHSRROPDNLQJ
sure there are no kinks or coils in the cable.
$OORZHQRXJKÀRDWLQJFDEOHIRUWKHFOHDQHUWR
reach the farthest point of the pool (Figure 4).
Figure 4. Spread Floating Cable Over the Pool
6 H0446500_REV A

•Adjust the wall climbing setting as necessary
XVLQJWKHIROORZLQJJXLGHOLQHV
Increase: if cleaner is climbing the wall
slowly and stays below the waterline.
Decrease: if cleaner is climbing the wall too
quickly and sucking air at the waterline.
Adjust SCS Wall Climbing Setting:
You can change the wall climbing setting at any
time during cleaner operation with the SCS button.
The new setting will be active when the cleaner
climbs the next wall.
•Press to adjust the wall climbing setting
one level higher.
•One additional LED lights each time you press
the button to indicate stronger grip on the wall.
•To decrease setting, press button to cycle
through back to one LED (lowest setting).
+
_
+
_
4
2
1
3
4
2
1
3
3.4 Stopping the Cleaner
and Removing from the Pool
3UHVV to interrupt operation.
2. When the cleaner is within arm's reach, use the
handle to lift it from the water (Figure 5).
Never lift the cleaner out of the pool by the
ÀRDWLQJFDEOH
1
2
Figure 5. Lift Cleaner From Pool with Handle
3.2 Starting the Cleaner
7KH¿UVWWLPH\RXXVHWKHFOHDQHUWKHFOHDQLQJVXUIDFH
setting is Floor and Wall
$IWHUWKH¿UVWWLPHWKHGHIDXOWLVWKHODVWVHWWLQJXVHG
Select Cleaning Surface:
• Use to change cleaning surface setting.
Begin Cleaning:
•After selecting the cleaning surface,
press to begin operation.
•At the beginning of the cycle, the cleaner
remains in place for a few seconds to initialize
the microcontroller after the fan motor starts.
3.3 Wall Climbing
(Surface Control System)
The cleaner has the ability to clean the pool walls up to
the waterline. How much the cleaner needs to grip to the
wall depends upon the pool surface.
Grip Intensity Indicator:
Surface Control System (SCS) settings are as follows
IRUGLIIHUHQWSRROVXUIDFHW\SHV
1 Pebble Surface (ROUGH)
2 Concrete
3 Vinyl / Fiberglass
4 Tile (SMOOTH)
Check Wall Climbing Setting:
• Start the cleaner and watch as the cleaner
climbs each wall. If grip setting is correct, the
cleaner will easily climb the wall and clean up
to the waterline. The default setting is
NOTE: Wall climbing is programmed in a randomized
(SMOOTH) pattern. Cleaner may climb wall and not
reach waterline until third or fourth attempt in order
to thoroughly clean wall surface below the waterline
first.
7
H0446500_REV A

+ROGWKHFOHDQHUYHUWLFDOO\RYHUWKHSRROVXUIDFH
WRGUDLQZDWHUEHIRUHUHPRYLQJ)LJXUH
3
Figure 6. Lift Cleaner From Pool with Handle
CAUTION
Use care and correct lifting technique when lifting
heavy objects. Incorrect removal of the cleaner from
the pool can cause muscle strain or back injury.
3.5 Rinsing the Cleaner
Rinse the cleaner after every cleaning cycle. Use
slightly soapy clean water, then rinse generously with
clean water. Do not use solvents such as acetone or its
equivalent. Do not let your cleaner dry in direct sunlight
near the pool.
3.6 Cleaning the Filter Canister
WARNING
To avoid electric shock and other hazards which
could result in permanent injury or death, disconnect
(unplug) the control box from the power source
before performing any cleaning and maintenance.
8QSOXJWKHÀRDWLQJFDEOHDWWKH&RQWUROER[
Unplug the Control box from the power source.
3UHVVWKH3XVKQ*REXWWRQWRUHOHDVHWKH
¿OWHUFDQLVWHUKDQGOH)LJXUH
Figure 7. Release Filter Canister Handle
1
2
8 H0446500_REV A

*UDVSWKHKDQGOHDQGOLIWXSWRUHPRYHWKH¿OWHU
canister (Figure 8).
Figure 8. Remove the Filter Canister
3UHVVWZRODWFKHVDQGUHPRYHWKH¿OWHU
canister lid (2). See Figure 9.
Figure 9. Remove Filter Canister Lid
1
2
1
8VLQJDKRVHZLWKFOHDQZDWHUULQVHWKH¿OWHU
FDQLVWHUDQGOLGWRUHPRYHDOOGHEULV)LJXUH
Figure 10. Rinse the Filter Canister
/HWWKHOLGDQG¿OWHUFDQLVWHUGU\
5HSODFHOLGRQWKHFDQLVWHUDQGWKHQUHSODFH
canister back into the cleaner body.
3OXJWKHÀRDWLQJFDEOHEDFNLQWRWKH&RQWURO
box and store the cleaner out of direct sunlight
for next use.
3.7 Storing the Cleaner
Do not let your cleaner dry in direct sunlight near the
pool.
6WDUWLQJDWWKHFOHDQHUKHDG5HPRYHDOOFRLOV
DQGWDQJOHVIURPWKHFDEOH)LJXUH
2. Store the cleaner out of direct sunlight.
Figure 11. Untangle the Floating Cable
9
H0446500_REV A

Section 4. Maintenance
WARNING
To avoid electric shock and other hazards which
could result in permanent injury or death, disconnect
(unplug) the cleaner from the power source before
performing any cleaning and maintenance.
4.1 Cord Tangling
Figure 12. Correct Floating Cable
IMPORTANT
The floating cable may become tangled if correct
procedure is not followed after each cleaning cycle.
After every cleaning cycle:
8QSOXJWKHÀRDWLQJFDEOHIURPWKH&RQWUROER[
2. Remove the cleaner from the pool and untangle
DOONLQNVDQGFRLOVLQWKHÀRDWLQJFDEOHVWDUWLQJ
DWWKHFOHDQHUKHDG)LJXUH
3OXJWKHÀRDWLQJFDEOHEDFNLQWR&RQWUROER[
and store cleaner out of direct sunlight for next
use.
Figure 13. Untangle the Floating Cable
4.2 Replacing the Brushes
7KHFOHDQHULV¿WWHGZLWK39&EUXVKHVLQIURQWDQGUHDU
7KHUHDUHZHDULQGLFDWRUV)LJXUHRQWKHEUXVKHV
To maintain cleaner performance at its best you need
to replace the brush matt as soon as one of the wear
indicators has been reached (even if the bristle wear is
not even). Zodiac Group Australia Pty Ltd recommends
that you replace the brushes every two (2) years.
Figure 14. Wear Indicators
Stand the cleaner on its end in a vertical
SRVLWLRQ)LJXUH
Figure 15. Stand Cleaner Upright
2. Separate the edges of the brush, undo the tabs,
and remove the worn matt.
10 H0446500_REV A

3RVLWLRQWKHQHZEUXVKPDWWXQGHUQHDWKWKH
roller with the bristles facing downwards. Refer
WR)LJXUH
Figure 16. Position the New Brush on Roller
4. Thread each tab into the slot provided and
gently feed it through until the heel comes out
DWWKHRWKHUVLGHRIWKHVORW5HIHUWR)LJXUH
4
Figure 17. Pull Tabs Through Each Slot
5. Use scissors to cut the tabs at the guides, as
VKRZQLQ)LJXUH
Figure 18. Cut Tabs
5HSHDWWKLVSURFHGXUHWRUHSODFHWKHVHFRQG
brush matt.
4.3 Replacing the Track
6WDQGWKHFOHDQHURQLWVVLGH)LJXUH
Figure 19. Stand Cleaner on its Side
2. Starting at one of the wheels, pull on the inside
of the track to separate the tire lip from the
ZKHHO6HH)LJXUH5HPRYHWKHWUDFNIURP
the cleaner.
Figure 20. Pull the Track Over Wheels to Remove
7RLQVWDOODQHZWUDFNSODFHWKHLQVLGHULERI
WKHWUDFNLQWRWKHJURRYHLQWKH¿UVWZKHHO6HH
)LJXUH
Figure 21. Position Track into Wheel Grooves
1
4. Stretch the track around the second wheel, then
pull over the last wheel (see Figure 22). Push
and position the rib of the track so that the track
is seated properly in the groove of the wheel.
11
H0446500_REV A

1
3
2
Figure 22. Stretch Track Around Wheels
9HULI\WKHULERIWKHWUDFNLVSRVLWLRQHGSURSHUO\
within the groove of each of the three wheels
and under the track guide. If necessary, turn the
wheels gently to seat the track.
Section 5. Troubleshooting
5.1 Using the Information LED
The information LED RQWKH&RQWUROER[ÀDVKHV
LQDVSHFL¿FVHTXHQFHWRLQGLFDWHRQHRIWKUHHSRVVLEOH
cleaner malfunctions.
LED Flashing Cause Solution
1 Flash
/('ÀDVKHVRQFH
Floating cable may not be plugged
into the Control box correctly.
8QSOXJWKHÀRDWLQJFDEOHIURPWKH
Control box and reconnect.
If the problem persists, contact
Zodiac After Sales Support at
1300 763 021
2 Flashes
/('ÀDVKHVWZLFH
Cleaner wheels may be jammed
or brushes may be blocked with
debris.
Turn cleaner wheels to ensure
they are not jammed.
Check brushes for debris.
Start a new cleaning cycle.
If the problem persists, contact
Zodiac After Sales Support at
1300 763 021.
3 Flashes
/('ÀDVKHVWKUHH
Pump axis or propeller may be
jammed with debris.
'LUW\¿OWHU
Check the pump axis for debris.
Check propeller for debris.
&OHDQWKH¿OWHU
Start a new cleaning cycle.
If the problem persists, contact
Zodiac After Sales Support at
1300 763 021.
12 H0446500_REV A

Problem Cause Solution
The Information LED
ÀDVKHVMXVWDIWHU
Start.
Floating cable may not be plugged
into the Control box correctly.
5HPRYHFOHDQHUIURPWKHSRRO8QSOXJÀRDWLQJFDEOH
from the Control box and reconnect.
Cleaner may not be fully submerged. Remove cleaner from the pool and re-submerge,
see Submerging the Cleaner.
Cleaner may need to be reset and
begin a new cycle.
Remove cleaner from the pool. Press power button
OFF, then begin a new cycle.
Propeller may be jammed and not
turning correctly.
Remove cleaner from the pool. Contact Zodiac After
Sales Support at 1300 763 021.
Wheels may be jammed and not turn-
ing correctly.
Remove cleaner from the pool. Contact Zodiac After
Sales Support at 1300 763 021.
The Information LED
ÀDVKHVGXULQJWKH
cleaning cycle.
Cleaner may be sucking air (lights will
appear after 60 seconds air intake)
Remove cleaner from the pool and re-submerge, see
Submerging the Cleaner.
The cleaner does
QRWVWD\¿UPO\RQWKH
pool bottom.
There is air in the appliance casing. Remove cleaner from the pool and re-submerge, see
Submerging the Cleaner.
7KH¿OWHUFDQLVWHULVIXOORUGLUW\ 5HPRYHFOHDQHUIURPWKHSRRO&OHDQWKH¿OWHUFDQLVWHU
see Cleaning the Filter Canister.
The cleaner does
not or no longer
climbs the pool
walls.
7KH¿OWHUFDQLVWHULVIXOORUGLUW\ 5HPRYHFOHDQHUIURPWKHSRRO&OHDQWKH¿OWHUFDQLVWHU
see Cleaning the Filter Canister.
Walls of pool are slippery or slimy.
Although the water seems clear,
microscopic algae, invisible to the
human eye, are present in the pool.
As a result the pool sides become
slippery and prevent the cleaner from
climbing. Check tires for wear and
replace as necessary.
Remove cleaner from the pool. Do a shock chlorination
treatment to eliminate algae. DO NOT leave the
cleaner in the pool during this treatment.
On startup the
cleaner does not
move.
No power supply to the cleaner. Remove cleaner from the pool. Check that the
power outlet to which the Control box is connected is
operating correctly by plugging another device into the
power outlet..
Unit is turned OFF. Remove cleaner from the pool. Turn the wheels
then disconnect the Control box and wait at least 20
seconds before reconnecting.
If the problem persists, contact Zodiac After Sales
Support at 1300 763 021.
Cable is tangling in
the pool
Too little cable length in the water. Remove cleaner from the pool. Do not unravel the
entire cable. Use only maximum cable length to cover
the pool area. Place the remaining unused cable on
the side of the pool. Adjust the entry location in the pool
to correct cord tangling.Follow the procedure in Cord
Tangling to avoid and correct tangled cord.
The cleaner is not
cleaning effectively.
The brushes have become smooth or
the "wear" indicator shows.
Remove cleaner from the pool. Replace the brushes
following the procedure in
Replacing the Brushes.
Filter canister is full or dirty. 5HPRYHFOHDQHUIURPWKHSRRO&OHDQWKH¿OWHUFDQLVWHU
following the procedure in Cleaning the Filter Canister.
Floating cable is excessively coiled or
kinked.
5HPRYHFOHDQHUIURPWKHSRRO0DNHVXUHWKHÀRDWLQJ
cable is spread out over the pool. Ensure the cable is
not too tightly wrapped or coiled when storing. If the
problem persists, lay the cable straight in the sun to
relax it and remove kinks. Follow the procedure in Cord
Tangling to avoid and correct tangled cord.
5.2 General Troubleshooting
The following table lists some of the common symptoms, causes, and solutions for correcting cleaner operation
problems.
13
H0446500_REV A

Section 6. Conformity
IEC 60335-2-41
Australian Cert. No. SAA100894EA
SAA100540
3145455L100001-01A
87002641965
The manufacturer reserves the right to modify these
VSHFL¿FDWLRQVZLWKRXWQRWLFH$OWKRXJKWKHURERWLF
pool cleaners have been tested in a large variety of
swimming pools, Zodiac cannot guarantee that this
robotic pool cleaner will be compatible with all pools.
Some pool features may affect performance. For further
advice, please contact your Zodiac dealer.
14 H0446500_REV A
®Rainbow Pool Products
PO Box 2388, Mansfield Qld 4122
Telephone STD 61-7-3849 5385
Facsimile STD 61-7-3849 5384
Email: [email protected]
Web: www.rainbowpoolproducts.com.au
This manual suits for next models
1
Table of contents
