Rainfresh 30C User manual

C Series Water Softeners
Installation & Operation Manual
(Please save for future reference)
Thank you for purchasing one of our ENVIROGARD / Rainfresh Water Softeners. We are
committed to ensuring that you are totally satisfied.
If you have any problems, don’t go back to the store – please contact us !
Most issues can be resolved over the phone.
Help Line : 1-800-667-8072 (Monday to Friday 8:30 AM to 5:00 PM EST)
www.rainfresh.ca
TABLE OF CONTENTS
A. System Specifications............................................. 2
B. How Your Water Conditioner Works...................... 2
C. Safety Precautions & Cautions ............................... 2
D. Installation............................................................. 3
a. Electrical Requirements ............................... 4
b. Unpacking the unit....................................... 4
c. Plumbing the Softener ................................. 4
E. Start-up and Programming .................................... 6
a. Level 1 Programming .................................. 7
b. Level 2 Programming .................................. 10
c. Manual Regeneration .................................. 12
F. Other Features ...................................................... 12
G. Maintenance.......................................................... 12
H. Troubleshooting..................................................... 13
I. Exploded Diagram & Parts List ............................... 14
J. Warranty................................................................ 16
Certified by IAPMO R&T against CSA B483.1 and NSF/ ANSI 44.

2
A. SYSTEM SPECIFICATIONS & DIMENSIONS
* Note: Install pressure regulator and water hammer arrestor if pressure exceeds rated pressure at any time.
The manufacturer reserves the right to make product improvements which may deviate from the specifications and descriptions stated herein, without
obligation to change previously manufactured products or to note the change.
These softeners conform to NSF/ANSI 44 for the specific performance claims as verified and substantiated by test data. These models are efficiency
rated. The efficiency rating is valid only at the stated salt dose and maximum service flow rate. They have a demand initiated regeneration (D.I.R.)
feature that complies with specific performance specifications in-tended to minimize the amount of regenerant brine and water used in their
operation. These softeners have a rated softener efficiency of not less than 3350 grains of total hardness exchange per pound of salt (based on sodium
chloride) and shall not deliver more salt than their listed ratings. The rated salt efficiency is measured by laboratory tests described in NSF/ANSI
Standard 44. These tests represent the maximum possible efficiency that the systems can achieve. Operational efficiency is the actual efficiency after
the system has been installed. It is typically less than the efficiency due to individual application factors including water hardness, water usage, and
other contaminants that reduce the softener’s capacity.
Feed Water Quality:
Iron < 0.5 PPM; Manganese < 0.05 PPM ; Turbidity < 1 NTU ; Free Chlorine < 0.5 PPM ; Hydrogen Sulphide –Nil ; Organics –Nil.
If feed water quality exceeds above limits, please call Rainfresh for advice on additional treatment that may be necessary.
B. HOW YOUR WATER CONDITIONER WORKS
Your Rainfresh Softener removes hardness using a process called Ion Exchange. In this process, when hard water flows
through the unit, hardness-causing minerals such as Calcium & Magnesium, are trapped by the media (called Resin) and an
equivalent amount of sodium ions are released into the water. When the capacity of the resin to trap hardness minerals is
exhausted, the unit is re-charged by softener salt in an automatic process called Regeneration. During regeneration, the
unit first backwashes to remove any sediment, rust or other particulates, that may have accumulated in the unit. This is
followed by introduction of a saturated salt solution (brine) that bumps off the trapped hardness to drain and recharges the
resin with sodium. It then goes through a final rinse & refills the salt tank with water for the next regeneration.
Once you program the unit at the time of installation, the regeneration process happens automatically. All you need to do is
to ensure that there is always enough salt in the salt tank. The unit automatically calculates when to regenerate based on
your water hardness and use.
C. SAFETY PRECAUTIONS AND CAUTIONS BEFORE INSTALLATION
Follow all applicable province/state and local regulations.
Handle your water softener carefully. Do not lie on side, turn upside down, drop or drag.
This unit requires softener salt (sodium chloride) to regenerate. Softener salt is available at most retailers. Persons
on sodium restricted diets should consider the added sodium as part of their overall intake. Potassium chloride can
be used as an alternate in such situations. Please consult Rainfresh technical support.
Install a pressure regulator and water hammer arrestor if pressure exceeds maximum rating at any time. Note: If
daytime pressure is over 80 psi, night time pressure may exceed maximum pressure rating.
Do not install on water that is microbiologically unsafe without adequate disinfection before or after the unit. For
effective disinfection install a Rainfresh Drinking Water System or Rainfresh UV disinfection system.
For use on cold water only.
MODEL NUMBER
30C
40C
Qty High Capacity resin
0.88 ft³
1.06 ft³
Resin Type
High capacity cation softening resin
Rated Service Flow (GPM)
10.5
11.9
Pressure Drop at Rated Service Flow (psi)
12.0
15.0
Rated Softening Capacity (Grains)
10,263 @ 2.64 lbs
14,456 @ 3.18 lbs
Efficiency (grains/lb salt)
3,887
4,543
Max Flow Rate to Drain (GPM)
2.4
2.4
Working Pressure
Min 20 psi –Max 125 psi*
Operating Temperature
Min 39 –Max 100⁰F
Voltage
110V AC

3
Only use thread seal tape (Teflon® tape) for fitting connections into unit. DO NOT USE pipe dope or chemical
sealants.
If water pipes are used to ground electrical system, install jumper wire (#4 gauge solid copper wire) across the unit
to maintain proper grounding of your electrical system
Protect your unit from freezing - drain the unit if freezing temperatures exist.
NOTE: IF SOLDER TYPE FITTINGS ARE USED DO NOT USE torch near inlet/outlet connections. All solder joints
should be made before joining pipe to filter head. Use only lead-free solder and flux.
DO NOT over-tighten metal fittings on to unit connections.
Place the unit on a flat level surface. Do not place shims under the unit to level it. The weight of the unit full of
water and salt can cause the cabinet to crack at the shim.
The unit should only be moved by 2 or more people due to heavy weight. Failure to do so can result in injury.
The unit must be installed in an area where there is reasonable access to the salt tank for regular salt filling.
D. INSTALLATION
Electrical Requirements:
The automatic control valve requires a constant power supply - 110V AC. We recommend a GFI (ground fault
interrupter) outlet within 5 feet of the softener. Extension cords are not recommended.
If water pipes are used to ground electrical system, you will need to install a jumper wire across the filter unit.
Unpacking the unit
The unit includes:
Unpack the unit and discard the plastic air pack inside the unit. Place the unit at the location where you intend to install it.
Stand back and look at the softener to make sure it is standing straight up and not tilted to one side. Make sure your
chosen location will be fairly level, dry, and protected from possible freezing
conditions. The softener can sit directly on the floor and will not corrode. DO
NOT set the softener onto make shift platforms as this can damage the salt tank,
or may cause it to topple.
The system has 3 connections - an inlet, an outlet, and a drain line connection. If
you are looking at the back of the unit (fig 1), the inlet is on the left side.
Warning: Make sure that you have correctly identified the inlet of the system.
REVERSING THE CONNECTIONS WILL RESULT IN RESIN BEADS BEING THROWN
INTO YOUR HOME'S PLUMBING SYSTEM CAUSING DAMAGE TO IT AS WELL AS
THE SOFTENER.
The following pipe can be used for installing your new system - Copper, CPVC, and PEX are the most popular.
1) Softener with
built-in salt
tank and
bypass valve
2) Inlet/outlet elbow fittings (2)
–¾” Male NPT
3) Allen key (for ease of opening
& closing bypass valve)
4) Brine overflow fitting
5) Drain hose (15 ft) with hose
clamp
6) AC power adapter

4
Installation Location
Installation location for city (municipally treated) water
Installation location for well water
Plumbing in your softener
If your hot water tank is electric, turn off the power to it to avoid damage to the element in the tank.
If you have a private well, turn the power off to the pump then shut off the main water shut off valve. If you have
municipal water, simply shut off the main valve. Go to a faucet, (preferably on the lowest floor of the house) turn
on the cold water until all pressure is relieved and the flow of water stops.

5
Position the softener in the desired location. The unit comes with
two 90°¾” male NPT elbow fittings (see fig 1). You can rotate them
at any angle to suit your installation. Make sure that the bypass
valve is in bypass mode as shown in fig 2.
Note: To change the connection fitting, simply remove the locking
clips by hand and pull the fitting out. Insert new fitting and reinstall
locking clip (fig 3).
Plumb in the softener using appropriate fittings.
Unscrew the cabinet top using a screwdriver and move the top
aside, making sure that the electronic cable underneath does not
detach from the circuit board.
Attach the drain hose (15 ft included) to the drain fitting and secure
it with a hose clamp (fig 4) (included).
Run the drain line to a nearby laundry tub, standing pipe or floor
drain (fig 5) and cut off excess tubing.
NOTE ABOUT DRAIN LINE : You can run the drain hose from the unit to
the ceiling joists (max 8 ft ceiling) and run it to the nearest laundry tub
or drain pipe. This can be run up overhead or down along the floor. Use
band clamps to hold the drain tubing in place. If running drain line more
than 15 feet from the softener (max 25 ft), increasing the line size to
3/4" will be required. Please follow your local plumbing & other
applicable codes for where to run softener discharge water. NEVER
MAKE A DIRECT CONNECTION INTO A WASTE WATER DRAIN. A
PHYSICAL AIR GAP OF AT LEAST 1.5" SHOULD BE USED TO AVOID
BACTERIA AND WASTEWATER TRAVELING BACK THROUGH THE DRAIN
LINE INTO THE SOFTENER (see fig 5). If you have other water
conditioners, such as an iron filter, carbon filter, tannin filter etc., RUN
THE DRAIN TUBING FOR EACH UNIT SEPARATELY. DO NOT TEE (COMBINE) DRAIN TUBING FROM OTHER UNITS.
You can also use code-approved air-gap attachments available at most plumbing stores.
Attaching the overflow tubing: If the overflow fitting is not pre-attached to the cabinet, then
drill a ¾” hole on the side of the softener about ¾ of the way from the bottom (fig 6). Insert
the over flow fitting from the outside and tighten the nut from the inside to lock it.
Attach the rest of the drain tubing to the overflow fitting and run to the floor drain with an
appropriate air gap, as shown in fig 5. If you do not have any more drain tubing left, you will
need to purchase extra tubing at your local plumbing retailer. WARNING : DO NOT TEE THE
OVERFLOW TUBING TO THE DRAIN TUBING
Re-attach the cabinet top and secure it with the screws.
Fig 5
LAUNDRY TUB
STANDING PIPE
FLOOR DRAIN OR SUMP
Min 1.5”
air gap
Min 1.5”
air gap
Min 1.5”
air gap
Fig 2
Fig 3
Fig 4
Fig 6

6
The salt tank is pre-connected to the control head. Lift the cabinet lid and add about 5 gallons of water in the salt
tank. This is not a critical level but just helps with the process for the first regeneration. Then add 2 bags (20 Kg
bags) of salt to start with. DO NOT ADD MORE THAN 2 BAGS OF SALT to prevent salt bridging.
Turn main house shut-off valve on slightly and watch for leaks. Ensure a faucet is on somewhere and that its aerator
is removed to avoid clogging from loosened scale in the pipes. If you have no leaks, proceed to the next steps.
Turn on the water supply
Using the Allen key (included), turn the bypass inlet slightly (refer to fig 2) to allow water to run into the unit. The
water should initially fill the tank slowly. Once the tank is full of water, you can open valve fully. This prevents resin
from being pushed up into the control head by the initial surge of water going in.
Make sure there are no leaks in your plumbing before proceeding.
At the nearest cold treated water tap remove the faucet screen and open the faucet.
Using the Allen key (included), open the outlet side of the bypass valve and let water
run a few minutes or until the system is free of any air or foreign material resulting
from the plumbing work. Close the water tap when water runs clean, and then proceed
to start up instructions.
Connect the control valve to the power adapter (fig 7) & connect the adapter to the
power supply.
NOTE: Your unit is not yet ready for service until you complete manual
regeneration (see pages 7-11)
E. START UP & PROGRAMMING
The control valve is controlled with simple, user-friendly electronics
displayed on an LCD screen.
When power is first supplied, the valve electronics may take up to two
minutes to initialize. During this time the screen will show “INTIALIZING
WAIT PLEASE”. Do not touch any buttons at this time. When the valve
reaches the service position, it will display the following information in
sequence:
1. Date & Time
2. Capacity (gal of water that can be used between
regenerations)
3. Volume Remaining (gal of water left before regeneration
begins)
4. Regeneration Time (Time of day when regeneration starts)
5. Last Regeneration Date (Last date when system regenerated)
6. Current Flow Rate (GPM) (flow rate of water being currently
used)
7. Peak Flow Rate (GPM) (Max recorded flow rate of the water)
The control valve has a display screen and 4 buttons
MENU BUTTON
The function of this key
is to enter the level one
programming mode
where the valve settings
can be adjusted.
SET / REGEN BUTTON
This button has two functions. The first is to initiate
a manual regeneration by holding the button for 3
or more seconds. The second function is while in
programming mode, pressing this key allows the
user to change the value of each setting.
UP / DOWN
These buttons are used to
increase or decrease the value
of the settings while in the
programming mode.
FOR VIDEO INSTRUCTIONS ON PROGRAMMING
Scan QR code
or visit
http://rainfresh.ca/how_to_videos.php#program
Fig 7

7
PROGRAMMING YOUR WATER SOFTENER
The valve has 2 levels of programming –Level 1 and Level 2
You will need to only go through Level 1 programming to start up your unit. Level 2 programming is factory set and
can be changed only if desired.
In level 1 programming you can set current time, date, number of people in your home and the feed water hardness.
Level 1 programming is completed in 5 easy steps.
Level 1 PROGRAMMING
STEP 1 : Set Current Time
1. Press MENU for 3 seconds
5. Press SET/REGEN once
and the highlighted value
flashes
6. Now press UP or DOWN key
to change the hour values to
current time
7. Press SET/REGEN again. Hour
value will be accepted and
minute value will start flashing
2. The display will read “Press
MENU Key for 3 sec to unlock”.
3. After 3 seconds, the display will
beep confirming unlock
4. Press MENU again and the
hour value becomes
highlighted
PRESS MENU KEY
3 SEC TO UNLOCK
CURRENT TIME
05 : 27 PM
CURRENT TIME
05 : 27 PM
CURRENT TIME
07 : 27 PM
CURRENT TIME
07 : 27 PM
CURRENT TIME
07 : 45 PM
8. Now press UP or DOWN key
to change the minute value
to current time
CURRENT TIME
07 : 45 PM
9. Press SET/REGEN again.
Minute value will be
accepted and AM/PM
value will start flashing
10. Now press UP or DOWN key to
change the value to AM or PM
CURRENT TIME
07 : 45 AM
CURRENT TIME
07 : 45 AM
11. Press SET/REGEN again to accept. Flashing stops & hour value
is highlighted again. PROCEED TO STEP 2
JAN/21/2018
05:27 PM

8
STEP 2 : Set Current Date
STEP 3: Set Number of people in the house
13. Press SET/REGEN again and
the MONTH value flashes
15. Press SET/REGEN again.
Month value is accepted and
the DAY starts flashing
CURRENT TIME
07 : 45 AM
12. Press DOWN to advance to
CURRENT DATE. The month
value is highlighted
CURRENT DATE
JAN/21/2018
CURRENT DATE
AUG/21/2018
14. Now press UP or DOWN key
to change the value to current
month
CURRENT DATE
AUG/21/2018
CURRENT DATE
AUG/15/2018
16. Now press UP or DOWN key
to change the value to current
day of the month
CURRENT DATE
AUG/15/2018
17. Press SET/REGEN again. Date
value is accepted and the
YEAR starts flashing
CURRENT DATE
AUG/15/2018
18. Now press UP or DOWN key
to change the value to current
day of the month
NUMBER PEOPLE
4
19. Press SET/REGEN again to accept.
Flashing stops & MONTH value is
highlighted again. PROCEED TO STEP 3
CURRENT DATE
AUG/15/2018
20. Press DOWN to advance
to NUMBER OF PEOPLE
NUMBER PEOPLE
4
NUMBER PEOPLE
3
21. Press SET/REGEN once
and the value flashes
22. Press UP or DOWN to
change the NUMBER OF
PEOPLE in your home

9
STEP 4: Setting Water Hardness
This value is the hardness value of your water in grains per gallon (GPG). If you have the reading in PPM or mg/L,
simply divide that by 17.1 to get the reading in GPG. You must also add (5 x iron level in PPM) to the hardness value.
HARDNESS VALUE = YOUR WATER HARDNESS + (5 x Iron concentration in PPM)
For example, if your water hardness is 20 GPG and the iron level is 0.3 PPM, the hardness value you enter must be
20 + 5 x (0.3) = 20 + 1.5 = 21.5 GPG
Note: If you do not know your water hardness, please call customer service for details on how to send us a water
sample and receive a free water analysis. In the meantime, you can leave the hardness value at default
setting. You can also visit www.rainfresh.ca for details.
STEP 5: Setting Vacation Mode
This function may be activated during a prolonged absence, such as a vacation for more than 2 weeks. The system
will perform a brief backwash and rinse based on advanced setting. The purpose is to keep the water fresh in the
softener tank and plumbing system.
When you return from vacation, return the holiday mode to "NO".
YOUR UNIT IS NOW READY FOR SERVICE
23. Press SET/REGEN again to accept the
value. Highlight stops flashing
26. Now press UP or DOWN keys to
set feed water hardness & press
SET/REGEN again to accept
NUMBER PEOPLE
3
WATER HARDNESS
20 GPG
25. Press SET/REGEN again.
HARDNESS value starts
flashing
WATER HARDNESS
15 GPG
VACATION MODE
YES NO
27. Now press DOWN key to advance
to VACATION MODE. Press DOWN
again to exit or press SET/REGEN
to set vacation mode
24. Press DOWN to advance to WATER HARDNESS. The
value is highlighted. PROCEED TO STEP 4
WATER HARDNESS
20 GPG
Press the DOWN
button to enter the
holiday mode setting.
Press SET / REGEN
to flash the
display.
Press the UP or
DOWN buttons to
select YES or NO.
Press SET / REGEN again
to confirm the setting.
The display stops
blinking. Press MENU to
exit level 1
programming.

10
Level 2 PROGRAMMING (OPTIONAL SETTINGS)
NOTE : Under normal use there is no need to change the settings under level 2 programming. You can, however,
change the default settings if required. CAUTION: DO NOT CHANGE LEVEL 2 SETTINGS WITHOUT CONSULTING
RAINFRESH TECHNICIAN (1-800-667 8072). Wrongly changing the settings can result in malfunction of the unit.
When the Level 2 Master Programming Mode is entered, all available option setting displays may be viewed and set
as needed. Depending on current option settings, some parameters cannot be viewed or set.
To change any setting under level 2 programming
-press the SET/REGEN key and the value flashes
-press the UP or DOWN keys to change the value
-press the SET/REGEN key again to accept value
-press the DOWN key to advance to the next value
The following chart indicates choices and default settings. Note: Default settings are indicated in bold letters
Use same programming method as you used in level 1 to advance and/or change values.
Bold letters indicate default settings
Parameter
Option 1
Option 2
Option 3
Option 4
Comments
1
System Language
English
Spanish
French
Set to French if desired.
Spanish not enabled
2
Valve Operation
Softener
Filter
Iron
Filter
Leave at default setting
3
Regeneration
Mode
Meter
Delayed
Meter
Override
Calendar
Clock
Meter
Immediate
Leave at default setting
4
Regeneration Time
2:00 AM
The unit is factory set to regenerate at 2:00
AM on the day of regeneration. You can
change to another time if desired.
5
Capacity
Calculation
Automatic
Manual
Automatic (recommended). Change to
manual settings if desired.
6
Resin Volume
For model 30C, set resin volume at 0.88 cu ft
For model 40C set resin volume at 1.06 cu ft
7
Salt Setting
Leave at default setting for maximum efficiency. (Defaults –6 lbs/ft³)
Note: Capacity = Amount of water that can be softened between regenerations. Capacity reduces
when salt setting is reduced, but salt consumption efficiency increases.
1. Press MENU for 3 seconds
to unlock screen.
JAN/21/2015
05:27 PM
2. The display will read “Press
MENU Key for 3 sec to unlock”.
3. After 3 seconds, the display will
beep confirming unlock
PRESS MENU KEY
3 SEC TO UNLOCK
SYSTEM LANGUAGE
ENGLISH
4. Press and hold UP & DOWN keys
together for three seconds to
enter Level Two Master
Programming.

11
Salt Setting (lbs/cu ft)*
Model
2.0
2.5
3.0
4.5
6.0
8.0
10.0
12.0
15.0
30C
0.9
1.0
1.3
1.9
2.5
3.4
4.2
5.0
6.3
40C
1.0
1.3
1.5
2.3
3.0
4.0
5.0
6.0
7.5
Table 1 : Refill time (in minutes) for various salt settings using Sodium Chloride
* Salt settings not validated by IAPMO
Disinfecting the Softener
It is possible that during shipping, storage & installing, bacteria can go into the unit.
Therefore, as a good installation practice, it is recommended that the softener be disinfected
prior to use. To disinfect, open the lid of the brine well in the salt tank and add approx. 3
tablespoons of fresh common household bleach. Replace lid & proceed to next step.
Manual Regeneration
If screen is locked, press MENU key for 3 seconds to unlock. To initiate an immediate regeneration, press the
SET/REGEN button for 3 seconds, an option for “Delayed” or “Immediate” regeneration will appear. Press the
SET/REGEN button again and “Delayed” will begin flashing. Now press the down arrow button and “Immediate” will
flash. Press the SET/REGEN button once and then press the menu button once. Valve will immediately start manual
regeneration.
YOUR UNIT IS NOW READY FOR SERVICE
F. OTHER FEATURES
Control Operation During a Power Failure
In the event of a power failure, the valve will keep track of the time and day for 48 hours. The programmed settings
are stored in a non-volatile memory and will not be lost during a power failure. If power fails while the unit is in
regeneration, the valve will finish regeneration after power is restored. If the valve misses a scheduled regeneration
due to a power failure, it will queue regeneration at the next regeneration time once power is restored.
Safety Float
The brine tank is equipped with a safety float which prevents your brine tank from overfilling as a result of a
malfunction such as a power failure.
New Sounds
You may notice new sounds as your water softener operates. The regeneration cycle lasts approximately 2 hours.
During this time, you may hear water running intermittently to the drain.
8
Refill Flow Rate
0.7 GPM
Leave at default setting
9
Unit Capacity
For 30C unit, set at 33,000 grains if you chose 15 lbs salt/ft³ otherwise leave at default
For 40C unit, set at 40,000 grains if you chose 15 lbs salt/ft³ otherwise leave at default
10
Reserve Capacity
75
gal/person
Increase or decrease value as desired
11
Capacity
This will be the calculated unit capacity in US Gal. The unit will regenerate only when this much
water has been used.
12
Backwash
05
Increase to 10 if water has lot of dirt or rust
13
Brine / Rinse
50
Increase to 60 if water is more than 15
grains hard
14
Rapid Rinse
5
Increase to 10 if you want a longer rinse
time after regeneration
15
Refill
For REFILL settings based on your chosen salt settings, please refer to Table 1 below
16
Restore Default
NO
Leave at default. Change only if you would like
to re-start programming from the beginning
Open this lid &
pour bleach inside

12
Manual Bypass
In the case of emergency, such as an overflowing brine tank, you can isolate your water softener from the water
supply using the bypass valve located at the back of the control. To resume soft water service, open bypass valve by
rotating the knobs counterclockwise.
G. MAINTENANCE
Adding Salt
Fill the salt tank only with nugget or pellet salt that is specifically for water softeners only. DO
NOT USE rock salt, road salt or other types of impure salts. Use only high grade water softener
salt (Sodium Chloride). You can use Potassium Chloride but you will need to increase salt settings
(see page 11). Check the salt level monthly. It is important to ALWAYS maintain the salt level
above the water level. To add salt, simply slide the cabinet lid and add the salt directly into the
brine tank. Be sure the brine well cover is on and fill only to the height of the brine well. The salt
tank should never be empty.
DO NOT OVERFILL THE SALT TANK TO THE TOP. Once you can see the water level in the tank, do
not fill more than 2-3 bags of salt.
Preventing and breaking a Salt Bridge
Humidity or wrong type of salt may create a cavity between the water and the salt. This action,
known as “bridging”, prevents the brine solution from being made, leading to your water supply
being hard. If you suspect salt bridging, pour some warm water over the salt to break up the
bridge. Allow at least four hours to produce a brine solution, and then manually regenerate the
softener. This should always be followed up by allowing the unit to use up any remaining salt and then thoroughly
cleaning out the brine tank.
If you are unable to break the bridge this way, take a strong rod and carefully push down the salt, working it up and
down (see fig on the right). Do not pound on the walls of the tank.
If the wrong kind of salt has been used, take it out and fill with nugget or pellet salt.
Care of Your Softener
To retain the attractive appearance of your new water softener, clean occasionally with mild soap solution. Do not
use abrasive cleaners, ammonia or solvents.
Cleaning the Injector Assembly
Sediment, salt and silt will restrict or clog the injector. A clean water supply and pure salt will prevent this from
happening. The injector assembly is located on the right side of the control valve. This assembly is easy to clean.
Shut off the water supply to your softener and reduce the pressure by opening a cold soft water faucet. Using a
screwdriver, remove the two screws holding the injector cover to the control valve body. Carefully remove the
assembly and disassemble as shown in Figure 6. The injector orifice is removed from the valve body by carefully
turning it out with a large screwdriver. Remove the injector throat the same way. Carefully flush all parts including
the screen. Use a mild acid such as vinegar to clean the small holes in the orifice and throat.
Reassemble using the reverse procedure.
Injector
Screen

13
H. TROUBLESHOOTING
Please consult the following troubleshooting guide before calling customer service.
• If you are unable to resolve the problem using the guide below, please call Customer Service at
18006678072 (Monday to Friday 8:30 am to 5:00 pm Eastern Time)
• Please have your receipt and model number ready before calling. Customer service can
request digital photos of your installation to help resolve the unit.
ISSUE
POSSIBLE CAUSE
POSSIBLE SOLUTION
A. Unit fails to start
a regeneration
cycle
1. No power supply
2. Defective circuit board
1. Check electrical service & re-set time of day
2. Replace faulty parts
B. Water is hard
1. Bypass valve is closed
2. No salt in salt tank
3. Plugged injector/screen
4. Brine refill settings wrong
5. Leak between valve and riser tube
6. Internal valve leak
1. Open bypass valve
2. Add salt to salt tank
3. Clean parts (see page 9)
4. Correct brine refill settings (Table 1)
5. Check if riser is cracked or O-ring is
damaged. Replace faulty parts
6. Replace valve seals, spacer and piston assly
C. Salt use is high
1. Refill time is too high
1. Correct brine refill settings (Table 1)
D. Low water
pressure
1. Iron or scale buildup in line feeding
softener
2. Iron buildup inside valve or tank
3. Inlet of control valve plugged due
to dirt
1. Clean/replace supply line
2. Clean control valve & add resin cleaner to
clean bed. Increase regeneration frequency
3. Clean control valve inlet
E. Resin in drain line
1. Air in water system
2. Incorrect or missing drain line flow
control (DLFC)
1. Check well system for proper air elimination
2. Check and replace DLFC
F. Too much water
in brine tank
1. Plugged injector or screen
2. Plugged brine valve
3. DLFC plugged
1. Clean parts (page 12-13)
2. Clean parts
3. Clean DLFC
G. Unit fails to draw
brine
1. DLFC plugged
2. Injector or screen is plugged
3. Inlet pressure too low
4. Internal valve leak
1. Clean DLFC
2. Clean parts
3. Increase min pressure to at least 25 psi
4. Replace seals, spacer & piston assembly
H. Unit cycles
continuously
1. Defective circuit board
1. Replace faulty parts
I. Water flows to
drain
continuously
1. Valve settings incorrect
2. Internal leak
1. Check valve settings
2. Replace seals, spacer & piston assembly
Need help troubleshooting? Call Toll Free 1-800-667-8072 Monday to Friday 8:30 AM to 5 PM EST.

14
I. PARTS LIST
Item No.
Part No.
Description
Quantity
A01
05056087
Screw - M5x12 (Hexagon)
3
A02
05056088
Screw - M5x16 (Hexagon with washer)
2
A03
05056047
End plug retainer
1
A04
05030002
Piston rod
1
A05
05056097
Piston pin
1
A06
05056023
End plug
1
A07
05056070
Quad ring
2
A08
05056024
End plug washer
1
A09
05056022
Piston retainer
1
A10
05056181
Piston (electrical)
1
A11
05056104
Muffler
1
A12
05056021
Spacer
4
A13
05056073
Seal
5
A14
05030001
Valve body
1
A15
05056129
O-ring φ 23x3
4
A16
05056025
Adaper coupling
2
A17
05056044
Adaptor clip
2
A18
05056090
Screw-ST4. 2x13 (Hexagon with washer)
2

15
A19
21709003
Secure clip
2
A20
05056140
Valve connector
1
A21
05056065
O-ring φ 23.6x2.65
2
A22
21319006
Screw adaptor
2
A23
05056508
Screw M5x12 (Hexagon with washer)
5
A24
05030004
End cover
1
A25
05030013
O-ring φ 30x2.65
1
A26
13000426
Screw-ST2. 9x13 (Large)
2
A27
07060007
Valve bottom connector
1
A28
26010103
O-ring φ 25x3.55
1
A29
05056063
O-ring φ 78.74x5.33
1
A30
05056086
Screw - M5x30 (Hexagon with washer)
2
A31
05056029
Injector cover
1
A32
05056072
O-ring φ 24x2
1
A33
05056027
Injector nozzle
1
A34
05056103
Injector screen
1
A35
05056028
Injector throat
1
A36
05056035
BLFC button retainer
1
A37
05056191
BLFC - 2#
1
A38
05056138
O-ring φ 14x1.8
1
A39
05056100B
BLFC fitting
1
A40
05056106
Brine line screen
1
A41
05056107
BLFC tube insert
1
A56
Drain line flow control (DLFC)
1
12
To order replacement parts:
Call 1800 667 8072
Monday to Friday
8:00 AM to 5 PM EST.
DESCRIPTION
1
Control Valve Display Module
2
Top distributor
3
Riser
4
Media Tank for model 30C –9”x 35
Media Tank for model 40C –10”x 35
5
Softener resin
6
Cabinet
7
Cabinet top cover
8
Brine safety float
9
Brine Well
10
Salt (not included)
11
Bottom Distributor
12
Power adapter (110V)

16
J. Limited Warranty
This “C” Series Softener System is warranted to the original Consumer purchaser for a period of one (1) year, from the date
of purchase, against defects in materials or workmanship. The electronic controls and mineral tank are warranted for 5 and
10 years respectively against defects in materials or workmanship. The company's obligation under this warranty shall
consist of repair or replacement, at its option, of any part found by company inspection to be defective, provided that the
product has not been misused, abuse, altered or damaged by Consumer with respect to the original installation, as
determined by the company. This warranty will not apply if water passing through the System has a) Turbidity / Suspended
Solids > 5 ppm (mg/l). b) Hydrogen Sulphide concentrations greater than 0.05 ppm (0.05 mg/l). c) Iron concentration greater
than 0.5 ppm (0.5 mg/l) or Manganese greater than 0.05 ppm (0.05 mg/l), f) Tannins or colour. This limited Warranty applies
only to a unit when returned to the Warrantor at the owner’s expense and in accordance with shipping instructions received
from the Warrantor. This warranty does NOT cover, and is intended to exclude, any liability on the part of Envirogard for any
incidental damages, consequential damages, labour charges or any other costs incurred in connection with the purchase,
installation, use, maintenance or repair of the system whether under this warranty or any other warranty implied by law.
Some provinces/states do not allow the exclusion of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary
from province/state to province/state. This warranty applies only to softeners purchased in Canada or the U.S.A.
Envirogard Products Limited
446 Major Mackenzie Drive East,
Richmond Hill, ON L4C 1J2, Canada
Tel : [phone] Helpline: 1800 667 8072
Web: www.rainfresh.ca
April 2018
