Raisecom ISCOM5504-GP Guide

ISCOM5504-GP (A)
Hardware Description
(Rel_01)
www.raisecom.com

Raisecom Technology Co., Ltd. provides customers with comprehensive technical support and services. For any
assistance, please contact our local office or company headquarters.
Website: http://www.raisecom.com
Tel: [phone]
Fax: [phone]-8886
Email: [e-mail]
Address: No. 11, EastArea, No. 10 Block, East Xibeiwang Rd, Haidian District, Beijing, P.R.China
Postal code: 100094
-----------------------------------------------------------------------------------------------------------------------------------------
Notice
Copyright © 2017
Raisecom
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in Writing from Raisecom
Technology Co., Ltd.
is the trademark of Raisecom Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

Raisecom
ISCOM5504-GP (A) Hardware Description
Preface
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
1
Preface
Objectives
This document describes the chassis, hardware components, and cables of the ISCOM5504-
GP, including hardware features, components, functions supported by each component, and
appearance and technical specifications of cables.
Versions
The following table lists the product versions related to this document.
Product name
Hardware version
Software version
ISCOM5504-GP
A.00 or later
V2.6 or later
Related manuals
The following table lists manuals and their contents related to the ISCOM5504-GP.
Name
Description
ISCOM5504-GP (A)
Hardware Description
This document introduces the hardware structure and
cards, including product overview, components, fiber
and cables, pluggable optical module, lookup table of
LEDs, lookup table of weight and power consumption.
ISCOM5504-GP (A)
Configuration Guide
This document introduces supported services of the
ISCOM5504-GP from aspects of service introduction,
default configurations, configuration methods, and
configuration examples, including basic configuration,
GPON service configuration, multicast service
configuration, MAC address table configuration, VLAN
configuration, Spanning Tree configuration, routing
configuration, DHCP configuration, QoS configuration,
system security configuration, link security
configuration, and system management configuration.

Raisecom
ISCOM5504-GP (A) Hardware Description
Preface
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
2
Name
Description
ISCOM5504-GP (A)
Installation Guide
This document describes the precautions before
installation, installation methods, and post-installation
check, including safety instruction, installation
instruction, chassis installation, installation of fan and air
exhaust plenum, cards installation, cabling, hardware
installation check, power-on test, device initialization,
and installation reference.
ISCOM5504-GP (A) Quick
Installation Guide
This document describes the installation process after
unpacking the device, including installation tools,
precautions, installation scenarios, installation
conditions, and installation steps.
Conventions
Symbol conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicate a hazard with a medium or low level of risk which, if
not avoided, could result in minor or moderate injury.
Indicate a potentially hazardous situation that, if not avoided,
could cause equipment damage, data loss, and performance
degradation, or unexpected results.
Provide additional information to emphasize or supplement
important points of the main text.
Indicate a tip that may help you solve a problem or save time.
General conventions
Convention
Description
Times New Roman
Normal paragraphs are in Times New Roman.
Arial
Paragraphs in Warning, Caution, Notes, and Tip are in Arial.
Boldface
Buttons and navigation path are in Boldface.
Italic
Book titles are in italics.
Lucida Console
Terminal display is in Lucida Console.

Raisecom
ISCOM5504-GP (A) Hardware Description
Preface
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
3
Convention
Description
Book Antiqua
Heading 1, Heading 2, Heading 3, and Block are in Book
Antiqua.
Change history
Updates between document versions are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Issue 01 (2017-10-12)
Initial commercial release

Raisecom
ISCOM5504-GP (A) Hardware Description
Contents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
4
Contents
1 Overview.........................................................................................................................................1
1.1 Introduction......................................................................................................................................................1
1.2 Appearance and slots........................................................................................................................................2
1.2.1 Appearance of chassis.............................................................................................................................2
1.2.2 Distribution of slots.................................................................................................................................2
1.3 Physical parameters..........................................................................................................................................2
2 Components ...................................................................................................................................4
2.1 Overview..........................................................................................................................................................4
2.1.1 Classification of components..................................................................................................................4
2.1.2 Appearances of components....................................................................................................................5
2.1.3 Hardware information label ....................................................................................................................6
2.2 Main control switching card (GPSC)...............................................................................................................7
2.2.1 Introduction.............................................................................................................................................7
2.2.2 Panel and slots.........................................................................................................................................7
2.2.3 Interfaces.................................................................................................................................................7
2.2.4 LEDs.......................................................................................................................................................9
2.2.5 Technical specifications ........................................................................................................................10
2.3 AC power module (RPA1101-SI-220S12) .....................................................................................................10
2.3.1 Introduction...........................................................................................................................................10
2.3.2 Panel and slots.......................................................................................................................................10
2.3.3 Interfaces............................................................................................................................................... 11
2.3.4 LEDs..................................................................................................................................................... 11
2.3.5 Technical specifications ........................................................................................................................ 11
2.4 DC power module (RPD1101-48S12)............................................................................................................12
2.4.1 Introduction...........................................................................................................................................12
2.4.2 Panel and slots.......................................................................................................................................12
2.4.3 Interfaces...............................................................................................................................................13
2.4.4 LEDs.....................................................................................................................................................13
2.4.5 Technical specifications ........................................................................................................................13
2.5 Fan module (FANS306) .................................................................................................................................14
2.5.1 Introduction...........................................................................................................................................14
2.5.2 Panel and slots.......................................................................................................................................14

Raisecom
ISCOM5504-GP (A) Hardware Description
Contents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
5
2.5.3 LEDs.....................................................................................................................................................14
2.5.4 Technical specifications ........................................................................................................................15
3 Fiber and cables...........................................................................................................................16
3.1 Fiber...............................................................................................................................................................16
3.1.1 Introduction...........................................................................................................................................16
3.1.2 Connector..............................................................................................................................................17
3.1.3 Wiring ...................................................................................................................................................19
3.2 Ethernet cable.................................................................................................................................................19
3.2.1 Introduction...........................................................................................................................................19
3.2.2 Appearance............................................................................................................................................20
3.2.3 Technical specifications ........................................................................................................................20
3.3 Configuration cable........................................................................................................................................22
3.3.1 Appearance............................................................................................................................................23
3.3.2 Wiring ...................................................................................................................................................23
3.4 DC power cable..............................................................................................................................................24
3.4.1 Introduction...........................................................................................................................................24
3.4.2 Appearance............................................................................................................................................24
3.4.3 Technical specifications ........................................................................................................................24
3.5 AC power cable..............................................................................................................................................25
3.5.1 Introduction...........................................................................................................................................25
3.5.2 Appearance............................................................................................................................................25
3.5.3 Technical specifications ........................................................................................................................26
3.6 Ground cable..................................................................................................................................................27
3.6.1 Introduction...........................................................................................................................................27
3.6.2 Appearance............................................................................................................................................27
3.6.3 Technical specifications ........................................................................................................................28
4 Pluggable optical modules........................................................................................................30
4.1 1000 Mbit/s SFP optical module....................................................................................................................30
4.1.1 Functions and appearance.....................................................................................................................30
4.1.2 Label .....................................................................................................................................................30
4.1.3 Technical specifications ........................................................................................................................31
4.2 10 Gbit/s SFP+ optical module ......................................................................................................................32
4.2.1 Functions and appearance.....................................................................................................................32
4.2.2 Technical specifications ........................................................................................................................32
4.3 PON SFP optical module ...............................................................................................................................33
4.3.1 Functions and appearance.....................................................................................................................33
4.3.2 Standard ................................................................................................................................................33
4.3.3 Technical specifications ........................................................................................................................34
5 Lookup table of LEDs.................................................................................................................35
6 Lookup table of weight and power consumption ................................................................37

Raisecom
ISCOM5504-GP (A) Hardware Description
Contents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
6
7 Appendix ......................................................................................................................................38
7.1 Terms..............................................................................................................................................................38
7.2 Acronyms and abbreviations ..........................................................................................................................39

Raisecom
ISCOM5504-GP (A) Hardware Description
Figures
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
7
Figures
Figure 1-1 Appearance of the ISCOM5504-GP chassis.........................................................................................2
Figure 1-2 Distribution of slots on the ISCOM5504-GP .......................................................................................2
Figure 2-1 Appearance of the main control switching card (GPSC) ......................................................................5
Figure 2-2 Appearance of the power module .........................................................................................................5
Figure 2-3 Appearance of the fan module..............................................................................................................6
Figure 2-4 Hardware information label on the ISCOM5504-GP...........................................................................6
Figure 2-5 Panel of the GPSC card........................................................................................................................7
Figure 2-6 Panel of the RPA1101 power module................................................................................................. 11
Figure 2-7 Panel of the RPD1101 power module.................................................................................................12
Figure 2-8 Panel of the FANS306 module ...........................................................................................................14
Figure 3-1 LC/PC fiber connector........................................................................................................................18
Figure 3-2 SC/PC fiber connector........................................................................................................................18
Figure 3-3 FC/PC fiber connector........................................................................................................................19
Figure 3-4 Ethernet cable.....................................................................................................................................20
Figure 3-5 Wiring of the straight-through cable...................................................................................................21
Figure 3-6 Crossover cable wiring.......................................................................................................................22
Figure 3-7 Configuration cable ............................................................................................................................23
Figure 3-8 PINs and wiring..................................................................................................................................23
Figure 3-9 DC power cable..................................................................................................................................24
Figure 3-10 European AC power cable................................................................................................................25
Figure 3-11 American AC power cable................................................................................................................25
Figure 3-12 Ground cable ....................................................................................................................................27
Figure 3-13 OT terminal ......................................................................................................................................27
Figure 4-1 1000 Mbit/s SFP optical module ........................................................................................................30
Figure 4-2 Label of the 1000 Mbit/s SFP optical module ....................................................................................31
Figure 4-3 SFP+ optical module ..........................................................................................................................32

Raisecom
ISCOM5504-GP (A) Hardware Description
Figures
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
8
Figure 4-4 PON SFP optical module....................................................................................................................33

Raisecom
ISCOM5504-GP (A) Hardware Description
Tables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
9
Tables
Table 1-1 Physical parameters of the ISCOM5504-GP..........................................................................................3
Table 2-1 Components of the ISCOM5504-GP .....................................................................................................4
Table 2-2 Items on the hardware information label................................................................................................7
Table 2-3 Interfaces on the GPSC card ..................................................................................................................7
Table 2-4 Parameters of the Console interface.......................................................................................................8
Table 2-5 Parameters of the SNMP interface .........................................................................................................8
Table 2-6 Parameters of the GE interface based on 10/100/1000BASE-T standard ..............................................9
Table 2-7 LEDs on the GPSC card.........................................................................................................................9
Table 2-8 Technical specifications of the GPSC card...........................................................................................10
Table 2-9 Interface on the RPA1101 power module............................................................................................. 11
Table 2-10 LEDs on the RPA1101 power module................................................................................................ 11
Table 2-11 Technical specifications of the RPA1101 power module ...................................................................12
Table 2-12 Interface on the RPD1101 power module ..........................................................................................13
Table 2-13 LEDs on the RPD1101 power module ...............................................................................................13
Table 2-14 Technical specifications of the RPD1101 power module...................................................................13
Table 2-15 LEDs on the FANS306 module..........................................................................................................14
Table 2-16 Technical specifications of the FANS306 module..............................................................................15
Table 3-1 Type and usage of the fiber ..................................................................................................................16
Table 3-2 Fiber connectors...................................................................................................................................17
Table 3-3 Wiring of the fiber................................................................................................................................19
Table 3-4 PIN definitions of the straight-through cable .......................................................................................20
Table 3-5 PIN definitions of the crossover cable .................................................................................................21
Table 3-6 Technical specifications of the Ethernet cable .....................................................................................22
Table 3-7 PINs of the RS-232 interface ...............................................................................................................23
Table 3-8 PINs of the RJ45 Ethernet interface.....................................................................................................24
Table 3-9 Technical specifications of the DC power cable ..................................................................................24

Raisecom
ISCOM5504-GP (A) Hardware Description
Tables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
10
Table 3-10 AC power cable..................................................................................................................................25
Table 3-11 Technical specifications of the European AC power cable.................................................................26
Table 3-12 Technical specifications of the American AC power cable ................................................................26
Table 3-13 Technical specifications of the ground cable......................................................................................28
Table 3-14 Technical specifications of the OT terminal.......................................................................................28
Table 4-1 Model of the 1000 Mbit/s SFP optical module.....................................................................................31
Table 4-2 Technical specifications of the 1000BASE-X SFP optical interface....................................................31
Table 4-3 Technical specifications of the 1000BASE-X SFP optical module......................................................32
Table 4-4 Technical specifications of the SFP+ optical interface.........................................................................33
Table 4-5 Technical specifications of the SFP+ optical module...........................................................................33
Table 4-6 Technical specifications of the Class B+ optical module .....................................................................34
Table 4-7 Technical specifications of the Class C+ optical module .....................................................................34
Table 5-1 LEDs of the ISCOM5504-GP..............................................................................................................35
Table 6-1 Weight and power consumption of the ISCOM5504-GP.....................................................................37

Raisecom
ISCOM5504-GP (A) Hardware Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
1
1 Overview
This chapter describes orientation, appearance, and physical parameters of the ISCOM5504-
GP, including the following sections:
Introduction
Appearance and slots
Physical parameters
1.1 Introduction
The ISCOM5504-GP is a next-generation, small-capacity, 1U, and plug-in Gigabit Passive
Optical Network (GPON) Optical Line Terminal (OLT). It is oriented to industrial customers,
providing rich features and flexible networking schemes to meet low-density and long-
distance requirements for optical fiber access.
Act as an OLT in GPON and work with the Optical Network Unit (ONU).
Meet Fiber to The Home (FTTH) and Fiber to The Building (FTTB) networking
requirements.
Support automatically collecting information about the power grid, and meet
requirements on building the intelligent community.
Support providing Triple Play services using the single-fiber.
Meet networking requirements on bidirectional reconstruction of the Hybrid Fiber
Coaxial (HFC) network (EPON+EoC).
Provide high-bandwidth and long-distance access to solve small and medium-scale
network fiber access problem.
The ISCOM5504-GP can be installed in the following scenarios:
ETSI 600-mm cabinet
19-inch 450-mm cabinet
19-inch 600-mm cabinet
Open rack
Workbench

Raisecom
ISCOM5504-GP (A) Hardware Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
2
When installing the chassis to the 19-inch 600-mm cabinet, you need to purchase
brackets applicable to the cabinet.
1.2 Appearance and slots
1.2.1 Appearance of chassis
The ISCOM5504-GP is a cartridge device, which is flexible to be deployed. Dimensions of
the chassis are: 440 mm (Width) ×266 mm (Depth) ×44 mm (Height) (without brackets).
Figure 1-1 shows the appearance of the ISCOM5504-GP chassis.
Figure 1-1 Appearance of the ISCOM5504-GP chassis
1.2.2 Distribution of slots
The ISCOM5504-GP provides the following 4 slots:
1 main control switching card slot
1 fan module slot
2 power module slots
Figure 1-2 shows distribution of slots on the ISCOM5504-GP.
Figure 1-2 Distribution of slots on the ISCOM5504-GP
1.3 Physical parameters
Table 1-1 lists physical parameters of the ISCOM5504-GP.

Raisecom
ISCOM5504-GP (A) Hardware Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
3
Table 1-1 Physical parameters of the ISCOM5504-GP
Parameter
Description
Dimensions
440 mm (Width) ×266 mm (Depth) ×44 mm
(Height) (without brackets)
Weight
DC: 5.0 kg
AC: 5.3 kg
Maximum power consumption
DC: 41 W
AC: 44 W
DC power
Rated voltage
-48 VDC
Voltage range
-38 to -72 VDC
AC power
Rated voltage
110/220 VAC
Voltage range
100–240 VAC
Frequency
50/60 Hz

Raisecom
ISCOM5504-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
4
2 Components
This chapter describes the appearances, dimensions, and technical specifications of
components of the ISCOM5504-GP, including the following sections:
Overview
Main control switching card (GPSC)
AC power module (RPA1101-SI-220S12)
DC power module (RPD1101-48S12)
Fan module (FANS306)
2.1 Overview
2.1.1 Classification of components
The ISCOM5504-GP is composed of the following four types of components:
Main control switching card
Power module
Fan module
Table 2-1 lists components of the ISCOM5504-GP.
Table 2-1 Components of the ISCOM5504-GP
Component
Name
Description
Main control
switching card
GPSC
Control, management, aggregation, and
switching card
Power module
RPA1101-SI-220S12
110/220 VAC power module
RPD1101-48S12
-48 VDC power module
Fan module
FANS306
Fan module

Raisecom
ISCOM5504-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
5
2.1.2 Appearances of components
Appearance of main control switching card
Figure 2-1 shows the appearance of the main control switching card (GPSC).
Figure 2-1 Appearance of the main control switching card (GPSC)
Appearance of power module
Figure 2-2 shows the appearance of the power module.
Figure 2-2 Appearance of the power module
Appearance of fan module
Figure 2-3 shows the appearance of the fan module.

Raisecom
ISCOM5504-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
6
Figure 2-3 Appearance of the fan module
2.1.3 Hardware information label
Hardware information of ISCOM5504-GP components will be described by a label pasted on
the Printed Circuit Board (PCB) to facilitate you to view it, as shown in Figure 2-4.
Figure 2-4 Hardware information label on the ISCOM5504-GP

Raisecom
ISCOM5504-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
7
The position of hardware information labels may be different because the layout of
components is different, so search for it carefully.
Table 2-2 lists items on the hardware information label.
Table 2-2 Items on the hardware information label
Parameter
Description
P/N
Name and type of the component
REV
Hardware version of the component, where "A" means a release
version and "00" means a build
Bar code
Bar code of the component
2.2 Main control switching card (GPSC)
2.2.1 Introduction
The GPSC card is the main unit for accessing, processing, and switching services. It provides
4 GPON optical interfaces, 2 GE electrical interfaces (RJ45), 2 GE optical interfaces (SFP),
and two 10GE optical interfaces (SFP+). Moreover, it supports managing and maintaining the
ISCOM5504-GP through the SNMP interface and Console interface.
2.2.2 Panel and slots
The GPSC card can be inserted into slot 1 only.
Figure 2-5 shows the panel of the GPSC card.
Figure 2-5 Panel of the GPSC card
2.2.3 Interfaces
There are 10 interfaces on the GPSC card.
Table 2-3 lists interfaces on the GPSC card.
Table 2-3 Interfaces on the GPSC card
Interface
Type
Usage
Description
CONSOLE
RJ45
Local management
interface
RS-232 serial interface

Raisecom
ISCOM5504-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
8
Interface
Type
Usage
Description
SNMP
RJ45
Remote network
management
interface
10/100BASE-T adaptive electrical
interface
GE 1/2
RJ45
Ethernet service
interface
10/100/1000BASE-T adaptive
electrical interface
GE 3/4
SFP
1000 Mbit/s
Ethernet service
interface
Supported optical module type:
1000BASE-X
10GE 5/6
SFP+
10 Gbit/s Ethernet
service interface
Supported optical module type:
10GBASE-LX/SX
PON 1/2/3/4
PON
SFP
GPON service
interface
Supported optical module type: Class
B+ or Class C+
Table 2-4 lists parameters of the Console interface.
Table 2-4 Parameters of the Console interface
Parameter
Description
Connector
RJ45
Working mode
Duplex UART
Electrical features
RS-232
Baud rate
9600 baud
Cable specifications
4-core shielded cable
Table 2-5 lists parameters of the SNMP interface.
Table 2-5 Parameters of the SNMPinterface
Parameter
Description
Connector
RJ45
Interface rate
10/100BASE-T auto-negotiation
Wiring
Support adaption to straight-through and crossover cable in host
mode
Compliant standard
IEEE 802.3
Table 2-6 lists parameters of the GE interface.
