Rampage ACD-12 User manual

128-6196A
1 of 16
ACD-12ACD-12
ACD-12ACD-12
ACD-12
AM/FM/MPXRADIO
WITH COMPACT DISC PLAYER
ANDQUARTZ CLOCK
OWNER'S MANUAL
POWER 
ACD-12 EJECT
MUTE
BANDT/F
MONO/INT
LOUD/RND
VOL VOL
SEL 
LOC/RPT
RADIO
IN
AUX

128-6196A
2 of 16
22
22
2
THISPAGEINTENTIONALLYLEFTBLANK

128-6196A
3 of 16
33
33
3
INSTINST
INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases,
a special installation kit will be required to mount the radio to the dashboard. These kits are available at
electronics supply stores and car stereo specialist shops. Always check the kit application before purchasing to
make sure the kit works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line at
1-800-645-4994.
UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE
1. Slidethemountingsleeveoffofthechassis. Ifitislockedintoposition,usetheremovaltools(supplied)todisengage
it.
2. Checkthedashboardopeningsizebyslidingthemountingsleeveintoit. Iftheopeningisnotlargeenough,carefully
cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening
or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve
fully inserted into the dashboard opening, bend as many of the tabs outward as necessary so that the
sleeve is firmly secured to the dashboard.
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting
sleeve. Follow the wiring diagram carefully and make certain all connections of the wiring harness are
secureandinsulatedwithwire nutsorelectricaltapetoinsureproperoperationoftheunit. Aftercompleting
the wiring connections, turn the unit on to confirm operation (ignition switch must be “on”). If unit does not
operate, re-check all wiring until problem is corrected.
5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and
the spring clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using
the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either
above or below the radio using the screw provided. Bend the strap to position it as necessary.
CAUTION:The rear of the radio must be supported with the strap to prevent damage to the dashboard
from the weight of the radio or improper operation due to vibration.
7. Test radio operation by referring to the Operating Instructions.
INSTALLATION USING KITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with
the installation kit to attach the radio to the mounting plate supplied with the kit.
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
ISO INSTALLATION PROCEDURE
This unit has threaded holes in the chassis side panels which may be used with the original factory mounting
brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the
dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and
brackets as they will be used to mount the new radio.
2. Carefully un-snap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION:DO NOT EXCEED M5 X 6 MM MAXIMUM SCREW SIZE.
LONGER SCREWS MAY TOUCH AND DAMAGE COMPONENTS INSIDE THE CHASSIS.
4. Wire the new radio to the vehicle as per step 4 above.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

128-6196A
4 of 16
33
33
3
44
44
4
INSTINST
INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
DAY
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATION
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
8:30AM - 7PM
9AM - 5PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON.-FRI.
SATURDAY
TT
TT
TOLL-FREE INSTOLL-FREE INST
OLL-FREE INSTOLL-FREE INST
OLL-FREE INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION ASSISTION ASSIST
ION ASSISTION ASSIST
ION ASSISTAA
AA
ANCENCE
NCENCE
NCE
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you
do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days
and hours shown (U.S.A. and Canada only).
7:30AM - 6PM
8AM - 4PM
NUT (5MM) EXISTINGDASH OPENING
FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE
NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF
MOUNTINGSLEEVE AS ATEMPLATE &CUT OPENING
REMOVETHEPLASTICFRAMEFROMTHEFRONTOFTHECHAS-
SISBYCAREFULLYUN-SNAPPINGIT.
TYPICAL INSTALLATION
20° MAX.
FRONT PANEL
CAUTION:
FORPROPEROPERATIONOFTHE CDPLAYER,THECHASSIS MUST BE
MOUNTED WITHIN 20° OF HORIZONTAL. MAKESURETHEUNITIS
MOUNTED WITHIN THIS LIMITATION.
SIDEVIEW
OF
CHASSIS
UN-SNAP ON LEFT AND
RIGHT SIDES
MAXIMUM
SCREWSIZE
M5 x 6
MAXIMUM
SCREWSIZE
M5 x 6
PERFORATED STRAP
MOUNTINGSLEEVE
PLASTICFRAME FACTORY MOUNTING
BRACKETS
BEND BOTTOM
TABS DOWNWARD
BEND TOP
TABS UPWARD
RADIO
SCREW STUD
NOTE: PLASTIC FRAME MUST BE REMOVED (UN-SNAP ON LEFT
AND RIGHT SIDES) TO USE REMOVAL TOOLS.
REMOVALTOOLS
FASTEN THIS END TO SECURE
PART OF DASHBOARD.
DRILL HOLE IF NECESSARY.
FASTEN THIS END TO SCREW
STUD ON REAR OF CHASSIS
SCREW
(5MM)
TIME ZONE

128-6196A
5 of 16
55
55
5
RADIO WIRING
RR
RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
REFER TO PAGE 5 FOR SPEAKER WIRING

128-6196A
6 of 16
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
66
66
6
1-800-645-49941-800-645-4994
1-800-645-49941-800-645-4994
1-800-645-4994
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
REFER TO PAGE 4
FOR RADIOWIRING
WARNING!
lNEVERCOMBINE(BRIDGE)OUTPUTSFORUSEWITH1SPEAKER.
lNEVERGROUNDNEGATIVESPEAKERLEADSTOCHASSISGROUND.
lFAILURETOWIREEXACTLYASSHOWNBELOWMAYCAUSEELECTRICALDAMAGETO
THERADIO.
8:30am-7:00pmEastern
9:00am-5:00pmEastern
Monday-Friday
Saturday
HELP!

128-6196A
7 of 16
77
77
7
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
1POWERON-OFFBUTTON
Press this button to turn the unit on and off
when the ignition switch is on. When the unit is
off, the time of day is automatically displayed
on the Liquid Crystal Display (LCD) panel
unless the ignition switch is off. If the radio is
off when the ignition switch is turned off, the
POWER button must be pressed to turn on the
radioaftertheignitionswitch isturned on.Ifthe
ignition switch is turned off while the radio is
on, the radio will come on automatically when
the ignition switch is again turned on.
2VOLUMECONTROLBUTTONS
To increase the volume level, press the
VOL+ button.Thevolumewillincreaseandthe
level will be shown on the display panel from
a minimum of V 0 toamaximumof V 63. To
decrease the volume level, press the VOL -
button. The display will automatically return to
the normal indication 5 seconds after the last
volume adjustment or when another function
is activated. These buttons are also used
in conjunction with the SEL button to adjust
the bass, treble, balance and fader levels as
described in ",#,$,and %.
3SELECT(SEL)BUTTON
This button is used to select the audio func-
tion (volume, bass, treble, balance or fade) to
be adjusted using the VOL + and - buttons.
Pressing the Select button once will set the
unit for volume adjustment (VOL will momen-
tarily appear on the display panel, followed a
few seconds later by VOL and the setting num-
ber). Pressing the button additional times will
select bass adjustment (bAS on display
panel),treble adjustment(TRE), balance (bAL),
fader (FAd), and volume (VOL) again. The dis-
play will return to the normal indication 5
seconds after the last adjustment or when
another function is activated.
4BASSCONTROL
To adjust the bass level, first select the Bass
modebypressing theSEL button untilthebAS
indicationappearsonthedisplaypanel.. Within
5 seconds of choosing the Bass mode, press
the VOL + or - buttons to adjust the bass
POWER 
ACD-12 EJECT
MUTE
BANDT/F
MONO/INT
LOUD/RND
VOL VOL
SEL 
LOC/RPT
RADIO
IN
AUX
1
10
8
21
11,2012,1992417
18
16
23, 4, 5, 6, 7
23
13
15 14 25 22

128-6196A
8 of 16
77
77
7
88
88
8
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TI0NSI0NS
I0NSI0NS
I0NS
response as desired. The bass level will be
shown on the display panel from a mini-
mum of B -7 to a maximum of B +7 (bAS 0
represents flat response).The display will
automatically return to the normal indication 5
seconds after the last adjustment or when
another function is activated.
5TREBLECONTROL
Toadjust thetreble level,first selectthe Treble
mode by pressing the SEL button until the
TRE indication appears on the display
panel. Within 5 seconds of choosing the
Treble mode, press the VOL + or - buttons
to adjust the treble response as desired. The
treble level will be shown on the display panel
from a minimum of TRE -7 to a maximum of
TRE +7(TRE 0 representsflat response). The
display will automatically return to the
normal indication 5 seconds after the last
adjustment or when another function is
activated.
6LEFT/RIGHTBALANCECONTROL
To adjust the left-right speaker balance, first
select the Balance mode by pressing the SEL
button until the bAL indication appears on the
display panel. Within 5 seconds of choosing
theBalance mode,presstheVOL +or -buttons
to adjust the audio balance between the right
channel or left channel speakers, respectively.
The balance position will be shown on the
display panel from bA.l 10 (full left) to bA.r 10
(fullright). When thevolume levelbetween the
left and right speakers is equal, bAL 0willbe
shown on the display panel. The display will
automatically return to the normal indica-
tion5secondsafter thelast adjustment or when
another function is activated.
7FRONT/REARFADERCONTROL
To adjust the front-rear speaker balance,
first select the Fader mode by pressing the
SEL button until the FAd indication appears
on the display panel. Within 5 seconds of
choosing the Fader mode, press the VOL + or
-buttons toadjust thefront-rearspeakerlevels
asdesired. Thefader positionwill beshown on
the display panel from FA.F 10 (full front) to
FA.r 10 (full rear). When the volume level
betweenthefrontandrearspeakersisequal,
FAd 0 will appear on the display panel. The
display will automatically return to the normal
indication 5 seconds after the last adjust-
ment or when another function is activated.
8LOUDNESSCONTOUR(LOUD)
When listening to music at low volume levels,
thisfeaturewillboostthebassandtrebleranges
to compensate for the characteristics of
human hearing. Momentarily press the
LOUD/RND button to activate this feature as
indicated by LOUD on the display panel.
Pressing the button again will de-activate
the function and LOUD will disappear from
the display.
9AM/FMBANDSELECTOR
During radio play, each time the BAND button
is pressed, the radio band changes. The
indications AM or FM will appear on the
display panel according to your selection.
During CD play, pressing this button will
change to radio operation without ejecting the
disc.
bl MANUALTUNINGCONTROL
Turn this knob clockwise to tune upward in
frequency on the band in use, counter-clock-
wise to tune downward in frequency. The fre-
quency to which you are tuned will be shown in
digitalform onthe displaypanel. When tuning
in a station, always adjust thecontrol so that
the correct broadcast frequency is shown on
the display and adjust the control so that you
arereceivingaclearsignal. Iftheradioistuned
off-frequency, you could experience distorted
audio, noise and other reception problems.
bm FMMONO/INTRO(INT)SELECTBUTTON
DuringFMradio operation,pressthisbutton to
select mono or stereo reception of the
broadcast signal. Under normal reception

128-6196A
9 of 16
99
99
9
conditions, the unit should be left in the stereo
mode as indicated by the ST icon on the
display panel when tuned to an FM stereo
signal. If the stereo signal is too noisy for
comfortable listening, press the MONO/INT
select button to switch to monaural reception
(theST iconwilldisappearfromthe display
panel). To return to stereo reception mode,
press the button again so that the ST
indication reappears.
bn LOCAL(LOC)/REPEAT(RPT)BUTTON
During radio operation, received signals are
usually in stereo mode as indicated by the
ST icon;however,whenthesignalsareweak
or intermittent, it may be worthwhile activating
the Local (LOC) mode by pressing the LOC/
RPTbutton(LOCappearsonthedisplay).This
mode favors access to local stations whose
signals are much stronger; thereby improving
radio reception. Press this button again to
terminatelocalreceivemode;LOC disappears
from the display panel.
bo AUDIO MUTE (MUTE)
This button is used to mute the volume from
the system. By pressing the button, a MUTE
indication will appear on the display panel and
the volume will be muted. Pressing the MUTE
button again, or pressing the Volume Control
buttons, Select (SEL) button, or LOUD button
will return the volume level to the setting in
use before the Mute function was activated.
bp LIQUIDCRYSTALDISPLAYPANEL
FUNCTIONS
The Liquid Crystal Display (LCD) panel dis-
playsthe frequency,time,andall activated func-
tions, including five bar graphs which provide a
visual representation of the audio signal power
level.
NOTE: It is a characteristic of LCD
panels that, if subjected to cold
temperatures for an extended
period of time, they may take longer
to illuminate than under normal
conditions. In addition, the visibility of
the numbers on the LCD may slightly
decrease. The LCD read-out will
return to normal when the
temperature increases to a normal
range.
bq DISC SLOT
With the label surface facing up, fully insert a
compactdisc intothe slotuntil themechanism
engages; the EJECT button will pop out,
making it possible to mechanically eject the
disc when desired. The disc symbol ( )
will appear on the display and play will begin
from the first track (01) on the disc,
accompanied by the elapsed time of track
play.
NOTE: This unit is designed for play of
standard 5" (12cm) Compact Discs
ONLY. Do not attempt to use 3"
(8cm) CD-Singles in this unit, either
with or without an adapter, as
damage to the player and/or disc
can occur. Such damage will not
be covered by the Warranty on this
product.
br CD PLAY/PAUSE ( ) SELECTOR
Press this button to resume play of a disc.
Playback willbeginfromthetrack beingplayed
previously, and continue until all tracks on the
disc have been played, after which playback
willautomaticallystop(unlesstherepeatmode
had been selected).
During disc play, pressing this button will
/
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

temporarily stop play of the disc (the disc
symbol( ) willflashonthedisplaypanel).
Press the button again to resume play of the
disc from the point at which it was stopped.
bs FORWARDTRACKSELECTOR ( )
During disc play, this button is used to quickly
select the beginning of a particular track in the
forwarddirection.Witheachpressofthebutton,
the next higher track number will be selected
as shown on the display panel.
bt BACKWARD TRACKSELECTOR ( )
During disc play, this button is used to quickly
select the beginning of a particular track in the
backward direction. With each press of the
button, the next lower track number will be
selected as shown on the display panel.
bu REPEATPLAYSELECTOR
Duringdiscplay,pressingtheLOC/RPTbutton
once will select the track repeat play mode;
pressing the button twice will select the disc
play repeat mode.
Torepeattheplaybackofadesiredtrack,press
the button once; RPT appears on the display
panel. Play of the selected track will continue
to repeat until the Track Repeat function is
canceled by pressing the button twice or by
activating the Intro-Scan function so that the
RPT indication disappears.
Torepeat playbackof theentiredisc,pressthe
buttontwice; theDISC RPT indicationappears
on the display panel. Play of the disc will
continuetorepeatuntiltheDiscRepeat function
iscanceledby pressing thebutton once again,
or by activating the Intro-Scan function; the
DISC RPT indication disappears.
cl INTRODUCTION (INT)SCANSELECT
During disc play, press the MONO/INT button
to sample or scan the introduction, or first 10
seconds,ofeachtrackonthedisc. INTappears
on the display, and each track is played in
1010
1010
10
128-6196
10 of 16
order. By using this option, you can quickly
choose the track(s) on the disc that you prefer.
When the desired track is recognized, press
the MONO/INT button again to exit the INT
mode or press the LOUD/RND button for 2
seconds; INT disappears from the display.
cm RANDOM(RND)SELECT
During disc play, press and hold the LOUD/
RND button for 2 seconds to play the tracks
on the disc in a random or shuffled order (RDM
will appear on the display panel). In Random
Play mode, pressing the Forward Track Se-
lect button ( ) will also select tracks in a
random order instead of the normal progres-
sion. Pressing the Backward Track Select but-
ton ( ) will also select tracks inrandom order.
The Random Play mode can be cancelled
by pressing the button again for 2 seconds
(RDM indication will disappear from the dis-
play panel) or by activating the Track Intro-
Scan function.
cn DISC EJECT ( ) BUTTON
When the button is pressed in, disc play is
stopped and the disc is mechanically ejected;
will disappear from the display panel and
the unit will revert to radio operation. Remove
the disc and insert another disc into the unit
(disc play will begin automatically). Discs may
be ejected with the ignition switch on or off.
NOTE: To prevent an ejected disc from
accidentally being damaged, always
remove the disc from the unit. Do
not leave the disc extending from
the disc slot.
co AUXILIARY(AUX)INJACK
An audio input jack (AUX IN) for use with a
portable audio device is located on the lower
left front corner of the control panel. Using an
audio patch cable with standard 1/8” phono
plugs (available at most radio supply stores),
attachtheaudiooutputfromtheexternalplayer
to the AUX input jack on the unit. By selecting
OPEROPER OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS

128-6196A
11 of 16
1111
1111
11
the auxiliary input mode, the portable audio
device will now operate through the audio
system of the radio using the volume, tone
and balance controls of the radio for
adjustment of the sound.
cp TIME/FREQUENCYSELECTOR(T/F)
This unit can display either the clock time or
radio frequency/CD player functions. Ordinarily,
the radio frequency or CD player track in-
dication is displayed, but the display can
also show the time when this button is
pressed. The time will then be displayed
for approximately 5 seconds after which it
will return to the radio or CD player function
display.
The correct time-of-day can also be set into
the unit by pressing the Time/Frequency
Selector button. This procedure is outlined
later in these operating instructions.
cq RESETBUTTON
A Reset button is located on the front panel of the
unit to the right of the LED display. The Reset
function is provided to protect the microproces-
sor circuitry and should onlybe activated under the
following circumstances as it will erase the time
and pre-set memories:
1.Upon initial installation after all wiring is
completed.
2.If there is a malfunction of any of the switches
on the unit, pressing the Reset button may
clear the system and return to normal opera-
tion.
If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3, etc.)
may appear on the display panel. This can indicate a number of problems with the unit, includ-
ing a mechanical error or an error in the microprocessor control of the player. If an error code
should appear, try ejecting and re-loading the disc into the player. While the disc is out of the unit,
make sure it is clean, undamaged, and loaded correctly (label surface up). You may also try
activating the RESET button ?G on the unit, but this will also erase the time memory.
If the suggested measures do not solve the problem, contact an approved warranty station near
you for further assistance.
CD PLCD PL
CD PLCD PL
CD PLAA
AA
AYER ERRYER ERR
YER ERRYER ERR
YER ERROR CODESOR CODES
OR CODESOR CODES
OR CODES
SETSET
SETSET
SETTT
TT
TING THE CLOCKING THE CLOCK
ING THE CLOCKING THE CLOCK
ING THE CLOCK
1. Turn the vehicle ignition and radio on.
2. Press and hold the Time/Frequency button cp for approximately 2 seconds; the time
display will begin to flash.
3. Within 5 seconds of selecting the flashing display, press the VOL + button to adjust the
hours and the AM/PM indication to the desired setting.
4. Press the VOL - button to adjust the minutes to the desired time.
4. Five seconds after the last hour or minute adjustment is made, the time will be set in the
unit and normal operation will resume.
OPEROPER
OPEROPER
OPERAA
AA
ATT
TT
TING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCTT
TT
TI0NSI0NS
I0NSI0NS
I0NS
ERROR CODE /ERROR CODE /
ERROR CODE /ERROR CODE /
ERROR CODE /

128-6196A
12 of 16
1212
1212
12
SPECIFICASPECIFICA
SPECIFICASPECIFICA
SPECIFICATT
TT
TIONSIONS
IONSIONS
IONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
Size: 7" W x 2" H x 6-1/8"D
178mm x 50 mm x 155mm
OperatingVoltage: 12voltsDC,negativeground
FuseRatings: Constant (yellow) lead: 8 AMP.
Switched (red) lead: 0.5 AMP.
OutputPower: 28 watts maximum (7 watts x 4 channels)
OutputWiring: Floating-groundtypedesignedfor4speakeruse.
OutputImpedance: Compatiblewith4-8ohmspeakers.
TuningRange: AM: 530 – 1,720 kHz.
FM: 87.5 – 107.9 MHz.
Sensitivity: AM: 20uv.
FM: 1.5uv.
FMStereoSeparation: >25 dB
CDFrequencyResponse: 20 – 20,000 Hz. ±1 dB
CDSignal/NoiseRatio: >60 dB
CDChannelSeparation: >60 dB
CDDistortion: 0.2%
*Specifications are subject to change without notice.
CD-R AND CD-RW PLAYBACK CAPABILITY
This model can play most CD-R and CD-RW media that contains audio programs.
Playback of both CD-R and CD-RW depends on the conditions of the recording
equipment and the CD-R or CD-RW disc quality. In some cases, a CD-R or CD-RW
disc cannot be played on this unit.

128-6196A
13 of 16
CACA
CACA
CARE ARE A
RE ARE A
RE AND MAND MA
ND MAND MA
ND MAINTENAINTENA
INTENAINTENA
INTENANCENCE
NCENCE
NCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We
recommend that you keep this manual for reference on the many features found in this unit as
well as how to set the clock.
The compact disc player section also requires no routine maintenance, but proper
understanding of its use and handling will help you obtain maximum enjoyment of its
capabilities. The following points should be observed:
lWhen cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit.
lThe CD player is a precision instrument and will not operate properly in extreme heat or
cold. In case of such conditions, wait until the interior temperature of the vehicle reaches a
normal temperature before using the player.
lIf the temperature inside the player gets too hot, a protective circuit will automatically stop
play of the disc. In this case, allow the unit to cool off before operating the player again.
lNever insert anything other than a 5" (12 cm) compact disc into the player as the
mechanism can be damaged by foreign objects.
lDo not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an
adaptor, as damage to the player and/or disc may occur. Such damage will not be covered
by the Warranty on this product.
lWhen not using the disc player, always remove the compact disc. Do not leave an ejected
disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.
lDo not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside.
lWhen the vehicle warms up during cold weather or under damp conditions, moisture may
condense on the lens of the disc player. Should this occur, the player will not operate
properly until the moisture has evaporated.
lThe unit is designed with a vibration dampening CD mechanism to minimize interruption
of disc play due to normal vibration in a moving vehicle. When driving on very rough roads,
however, occasional sound skips may occur. This will not scratch or damage the disc and
normal play will resume when the rough conditions cease.
HANDLINGCOMPACTDISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound
quality. Please follow these guidelines to take care of your compact discs:
lUse only compact discs with the mark .
lFingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.
lNever use chemicals such as record sprays, household cleaners or thinner to clean
compact discs. Such chemicals can irreparably damage the disc’s surface.
lDiscs should be kept in their storage cases when not in use.
lDo not expose discs to direct sunlight, high temperatures or high humidity for extended periods.
lDo not stick paper, tape, or labels on the disc surfaces nor write on them withany typeof marker.
1313
1313
13

128-6196A
14 of 16
1414
1414
14
FormNo.128-4270E
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser
of this product that should this product or any part thereof, under normal use and
conditions, be proven defective in material or workmanship within 12 months from the
date of original purchase, such defect(s) will be repaired or replaced with new or
reconditioned product (at the Company's option) without charge for parts and repair
labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be
deliveredwithproofofwarrantycoverage(e.g.dated billofsale),specificationofdefect(s),
transportation prepaid, to the warranty center at the address shown below.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrection
of antenna problems, to costs incurred for installation, removal, or reinstallation of the
product,ordamagetotapes,compactdiscs,speakers,accessories,orvehicleelectrical
systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the
Company,hassufferedorbeendamagedthroughalteration,improperinstallation,mishan-
dling, misuse, neglect, accident, or by removal or defacement of the factory serial
number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY
ACTIONFORBREACHOFANY WARRANTYHEREUNDERINCLUDINGANYIMPLIED
WARRANTYOF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30
MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANYBELIABLEFORANYCONSEQUENTIALORINCIDENTALDAMAGESFOR
BREACHOFTHISORANYOTHERWARRANTY,EXPRESSORIMPLIED,WHATSO-
EVER. NopersonorrepresentativeisauthorizedtoassumefortheCompanyanyliability
other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusionorlimitationofincidentalorconsequentialdamagesotheabovelimitationsor
exclusions may not apply to you. This Warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
U.S.A.: AUDIOVOX CORPORATION,150 MARCUS BLVD.,HAUPPAUGE, NEWYORK 11788 • 1-800-645-4994
CANADA:CALL 1-800-645-4994 FORLOCATIONOFWARRANTYSTATIONSERVINGYOURAREA
12 MONTH LIMI12 MONTH LIMI
12 MONTH LIMI12 MONTH LIMI
12 MONTH LIMITED WTED W
TED WTED W
TED WAA
AA
ARRRR
RRRR
RRAA
AA
ANTNT
NTNT
NTYY
YY
Y
WW WW
WAA
AA
ARRRR
RRRR
RRAA
AA
ANTNT
NTNT
NTYY
YY
Y

128-6196A
15 of 16
THISPAGEINTENTIONALLYLEFTBLANK
1515
1515
15

128-6196A
16 of 16
© 2001 Audiovox Electronics Corp., Hauppauge, NY 11788
128-6196A
Printed in China
1 61 6
1 61 6
1 6
