RAMTONS RM/475 User manual

READ AND SAVE THESE INSTRUCTIONS
Version 1.0 2015
Attention: Pictures in the IM are for reference only.
FAN HEATER
MODEL: RM/475
GD Midea Environment Appliances MFG. Co.Ltd.
No.28,Dong Fu Road,HeSui East Industrial Area,Dong Feng Town,
ZhongShan,GuangDong,China.
OWNER’S MANUAL

1
IMPORTANT SAFEGUARDS
When using any electrical appliance, basic safety
precautions should always be followed, including the
following:
1. To ensure Familiarity with the controls, safety features,
and operation of your heater -Read all instructions before
using.
2. Do not insert foreign objects through the intake or
discharge grilles.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
4. Disconnect the cord from the outlet before cleaning. A
heater should never be used under conditions where it
may be immersed, or come in contact with water.
Similarly do not plug in your heater if its surfaces are
damp.
5. Do not use the appliance on the same socket or electric
circuit with other electrical appliances so as to prevent
the circuit from being overloaded, which will cause fire.
Please do not prolong the power cords by yourself or use
movable socket.
6. Unplug heater by grasping plug and pulling it from the
outlet. NEVER YANK ON CORD.
7. If the supply cord is damaged, it must be replaced by its
service agent or a similar qualify person in order to avoid
hazard.

2
8. Do not use in locations when the heater will be left
unattended for long periods of time. (for example -
several weeks in an unoccupied summer cottage)
9. Do not use attachments not recommended and sold by
MIDEA distributor.
10. Loose connections between the heater plug and the
electrical outlet may cause the plug to overheat.
11. Ensure no other appliances are plugged into the same
circuit as your heater. A circuit overload could occur
resulting in dimmed lights, blown fuses, tripped circuit
breakers, or fire hazard.
12. The heater is intended for household indoor use only.
13. The heater must not be located immediately below a
socket-outlet.
14. Warning: In order to avoid overheating, do not cover
the heater.
15. Do not use this heater in the immediate surroundings of
a bath, a shower or a swimming pool.
16.
17. Children of less than 3 years should be kept away unless
continuously supervised. Children aged from 3 years and
less than 8 years shall only switch on/off the appliance
provided that it has been placed or installed in its intended
normal operating position and they have been given
supervision or instruction concerning use of the appliance
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.

3
PART FIGURE
in a safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or perform
user maintenance.
18. CAUTION — Some parts of this product can become
very hot and cause burns. Particular attention has to be
given where children and vulnerable people are present.
19. WARNING: This heater is not equipped with a device
to control the room temperature. Do not use this heater
in small rooms when they are occupied by persons not
capable of leaving the room on their own, unless
constant supervision is provided.
CAUTION — Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
WARNING: IN ORDER TO AVOID OVERHEATING,
DO NOT COVER THE HEATER.
Thermostat Control
Power and Setting Control
Handle (behind unit)
Pilot lamp
Outer Grill
Front Housing

4
This heater is pre-assembled in factory.
ASSEMBLY
OPERATING INSTRUCTION
• Place the heater on a firm level surface free from obstructions, and at least 3 ft.
away from any wall and any other objects such as furniture, curtains, plants or
combustible material.
• With the Power and Setting Control “ Power and Setting Control” in the ”OFF”
position, plug the heater into a grounded 220-240V outlet.
• Turn the heater ”ON” by turning the Power and Setting Control “Power and Setting
Control” clockwise to your desired power setting (FAN, LOW, MED, or HIGH). The
Power Indicator Light “ Power Indicator A C Light ” will illuminate. The power
settings operate as follows:
FAN: The Fan Circulates room air only. The heating elements are “OFF”.
LOW: The Fan and heating elements operate at 800 Watts.
MED: The Fan and heating elements operate at 1200 Watts.
HIGH: The Fan and heating elements operate at 2000 Watts.
• Turn the Thermostat Control “ Thermostat Control ” to your desired setting from
“MIN” to “MAX”.
CAUTION: This heater includes a Thermal Cut-Off Overheat Protection System
that shuts the heater off if it overheats due to abnormal conditions. If this occurs,
turn the heater ”OFF”, unplug it, and inspect and remove any objects on or
adjacent to the heater. Allow it to cool fora few minutes, plug it back in, and
resume normal operation.
SAFETY FEATURES
This heater is equipped with an automatic Safety Shutoff Switch for overheat
protection, which is activated when the internal temperature exceeds normal
operating temperatures.
If this occurs, turn the heater to “OFF”. Unplug the heater and allow it to cool.
Inspect and carefully remove any objects on or adjacent to the heater.
Plug the heater back in and resume normal operation.
Tip Over Switch: This heater includes a Safety Tip-Over Protection Feature which
will shut the heater off in case it is tipped over. If, at any time, the heater does tip
over, put the heater back in the upright position. The heater will resume its normal
operation.

5
1. Light accumulated dust may be removed from the heater with a soft cloth. Wipe
the exterior surfaces of the heater occasionally with a cloth moistened (not
dripping wet) with a solution of mild detergent and water. Dry the case
thoroughly with a soft dry cloth before operating the heater.
2. The fan motor is lubricated by the factory, and will require no further lubrication.
3. No other user maintenance is required or recommended. If service is required,
send your heater to the nearest authorized service depot.
4. Store heater in a clean and dry place when not in use.
REMEMBER - portable electric heaters are designed for spot heating, or as a
supplementary heat source. They are not intended to be main sources of heat
during the normal heating season.
Note: There may be trace of smoke or odour when unit is first operated. Do not
be alarmed. This indicates that a drop of oil fell on the heating coil during the
manufacturing process. It will quickly evaporate, and should not re-occur.
READ AND SAVE THESE INSTRUCTIONS
CLEANING AND MAINTENANCE
This fan heater is equipped with a pilot lamp that glows whenever the heater is
plugged in and turned on. It will continue to glow even if the thermostat has cycled
the heating elements off. This feature is to prevent you from being unaware that
the heater is operating and maintaining the temperature of the room.
When you do not wish the heater to control the room temperature, turn the control
switch to O (off) and remove the plug from the electrical outlet.
PILOT LAMP
Your heater is fitted with a safety device "Double Protector" that (1) switches off the
heater by thermal cut-off in the event of overheating or malfunction, It will reset
while the temperature reduce to a normal level. (2) Shuts off the heater by thermal
fuse in the event of overheating or malfunction and not operates by some other
accidental reason.
If overheating or malfunctions continue, return the heater to an Approved Service
Agent for examination.
The most common cause of overheating is deposits of dust or fluff entering the
heater, Ensure these deposits are removed regularly by unplugging the unit and
vacuum cleaning air vents and front grille.
SAFETY CONTROL
