Wi-Fi®BackupCamera
User Manual

FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. This equipment
has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and may cause harmful interference to
radio communications if not installed and used in accordance with the
instructions. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet that is on a different circuit
from the device.
• Consult the dealer or an experienced radio/TV technician for help.
When using the device, ensure that the antenna of the device is at least
20 cm away from all persons.
IC Compliance Statement
This device complies with Part 15 of the FCC Rules and Industry Canada
license-exempt RSS standard(s). Operation is subject to the following two
conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
IC Caution
Intentional or unintentional changes or modifications to the equipment
not expressly approved by Rand McNally could void the user’s authority to
operate the equipment.
IC attestation de conformité
Ce dispositif est conforme à la norme FCC Partie 15 et aux norme(s) RSS
permis-exempte(s) d’Industrie Canada. L’opération est soumise aux deux
conditions suivantes:
1. Ce dispositif ne peut pas provoquer d’interférence nocive et
2. Ce dispositif doit accepter toute interference reçue, y compris les
interférences qui peuvent causer un mauvais fonctionnement du dispositif.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
Attention
Les changements ou modifications à l’équipement, que ce soient
intentionnelles ou non, non expressément approuvés par Rand McNally
pourraient annuler l’autorisation de l’utilisateur à utiliser cet équipement.

2
Important information about your backup camera
About installation: Please note the following installation instructions are intended
to be used as a general guide. Specific requirements will vary by vehicle type, make,
and model. Rand McNally recommends that the backup camera be installed by a
qualified vehicle technician. Rand McNally is not responsible for damage caused by
the installation.
Rand McNally follows a continuous review process and reserves the right to provide
enhancements that may not be reflected in the pictures and specifications in this
document. While the information contained herein is believed to be correct when
compiled, Rand McNally does not guarantee its accuracy.
Professional installation is recommended to get the most out of your Wireless
Backup Camera. Visit randmcnally.com/pro-install to see recommended
service providers.

3
On your OverDryve™device, go to the Rand McNally Market and download the
Wireless Backup Cam app.
Download the Wireless Backup Cam app

4
Box contents
1Camera with license plate bracket
2Wi-Fi transmitter with antenna
33-ft master cable
4Car charger
54 t-tap connectors
64 zip ties
72 rubber grommets
Camera with license plate bracket
Wi-Fi transmitter with antenna
12
3
4
5
6
7

5
Connect the camera
IMPORTANT: Before installing the backup camera in the vehicle, establish a
connection between the camera and the display device.
1. Screw the antenna onto the transmitter.
2. Plug the white connector at the end of the master cable into the transmitter
until it clicks.
3. Plug the black and red connectors on the master cable into the matching wires
on the vehicle charger.
4. Plug the round end of the master cable into the camera cord.
5. Plug the charger into the vehicle’s power source. A red light on the transmitter
indicates power is supplied. When connected, the camera will broadcast a
Wi-Fi signal.
6. Turn on the compatible display device, such as OverDryve™.
7. Open the app. (For download instructions, see page 3.)

6
Using the app
1. The app opens to the Connection page and will search for the camera.
This may take several minutes. Make sure Wi-Fi is enabled on the display device.
2. When the camera appears in the list, tap Connect.
3. The camera image will display on the screen.

7
Using the app
1Close: Closes the app.
2Refresh: This button appears when
Wi-Fi interference is detected. Tap to
switch to a different channel.
3Menu: Return to the
Connection screen.
1 2
3

8
Vehicle installation
Once the camera has established a connection to the display device, it’s ready for
installation in the vehicle. Unplug the pieces of the assembly (camera, master cable,
vehicle charger) before continuing. The master cable should remain connected to
the transmitter.
1. Unscrew the rear license plate.
2. Pass the camera cable through to the interior of the vehicle.
NOTE: It may be necessary to drill a 3/8" hole through the metal behind the
license plate. Insert the rubber grommets around the hole to shield the cable from
the metal.
3. Mount the camera to the top of the license plate, with the metal bracket
either in front of or behind the license plate, and reattach the license plate with
the screws.

9
There are two options for powering the backup camera:
A. Reverse lights—Connecting directly to one of the reverse lights will display
the camera view within the app when the vehicle is shifted into reverse.
(NOTE: Professional installation is recommended.
Visit randmcnally.com/pro-install for a list of service providers.)
B. Rear power source—Plugging the vehicle charger into a rear power source in
an SUV or similar vehicle provides continuous power to the camera. The camera
view will display when the app is opened. This installation does not require any
modifications to the vehicle wiring.
Vehicle installation

10
Vehicle installation A
Installation A instructions (Reverse lights)
Professional installation recommended.
1. Access the vehicle’s rear light wiring system.
2. Connect the reverse (red) and ground (black) wires on the master cable to the
vehicle wires using the T-Tap connectors. If the included master cable contains a
spare blue wire for custom installation, please properly insulate it −this wire will
not be required for standard installations.
3. Plug the round end of the master cable into the camera cord.
4. Shift the vehicle into reverse to display the camera.
5. If necessary, adjust the camera angle downward to achieve the best view.

11
Vehicle installation B
Installation B instructions (Rear power source)
1. Connect the reverse (red) and ground (black) wires on the master cable to the
same color wires on the included vehicle charger cord. Leave the brake (blue)
wire unconnected.
2. Plug the vehicle charger into the rear power source.
3. Plug the round end of the master cable into the camera cord.
4. Open the app. The camera displays.
5. If necessary, adjust the camera angle downward to achieve the best view.

12
Warnings, End-User License Agreement, and Warranty
Safe Driving Practices
The backup camera is a valuable safety device. However, the backup camera should always be used in combinaiton with your best judgment and
common sense while operating your vehicle in reverse. Never attempt to adjust or handle the backup camera or any of its accessories while driving. Pull
over and park in a safe and legal manner before making any adjustments to or handling the backup camera or any of its accessories.
End-User License Agreement
Rand McNally hereby grants you (“User”) a single-user non-exclusive, non-transferable license to use the Rand McNally backup camera (hereinafter
referred to as the “product” (including software)) for User’s own business or personal use and not for resale or sublicensing.
This product and the software incorporated in it and related documentation are furnished under license and may be used only in accordance with
this license agreement. Except as permitted by such license, the contents of this product and software may not be disclosed to third parties, copied
or duplicated in any form, in whole or in part, without the prior written permission of Rand McNally. This product and software contain proprietary
and confidential information of Rand McNally and its licensors. Rand McNally grants User a limited license for use of this product and the software
incorporated in the product for its normal operation. By using the product, User acknowledges that the product and software are the property of Rand
McNally and its licensors and are protected by U.S. copyright, trademark and patent laws and international treaties.
THE USER MAY NOT:
Copy, loan or otherwise transfer or sublicense the product, its software or content.
Modify, or adapt the product in any way, or decompile, disassemble, reverse engineer or reduce to human readable form the product and software
incorporated therein.
Alter, remove or obscure any copyright notice, trademark notice, or proprietary legend from the product, its software or content.
This license will terminate automatically if User fails to comply with any of the terms of this license and User agrees to stop using the product. Rand
McNally may revise or update the product and is not obligated to furnish any revisions or updates to User.
WARNING: This product contains chemicals known to the State of California to cause cancer and/or other harm.

13
Warnings, End-User License Agreement, and Warranty
Warranty
RM Acquisition, LLC d/b/a Rand McNally warrants that the product, and the component parts thereof, will be free of defects in workmanship and
materials for a period of one (1) year from the date of purchase.This warranty may be enforced only by the first consumer purchaser (“Customer”),
provided that the product is utilized within the U.S.A. or Canada.
Rand McNally will, without charge, repair or replace (with a new or newly reconditioned unit), at its option, defective products or component parts. For
repair or replacement of defective products, Customer must contact Rand McNally at 877-446-4863 for return authorization and instructions. Customer
will be required to provide proof of date of first Customer purchase, such as a duplicate copy of the original sales receipt, for the warranty to be valid.
The Customer must pay any initial shipping charges required to ship the product for warranty service, but the return charges will be at Rand McNally’s
expense, if the product is repaired or replaced under warranty.
Repairs or replacements have a 90-day warranty. If the product returned is still under its original warranty, then the new warranty is 90 days from the
date of repair or replacement or to the end of the original one (1) year warranty, whichever is longer.
This warranty gives the Customer specific rights. Other rights may be available to Customer which vary from state to state.
Exclusions: This limited warranty does not apply: (1) to any product damaged by accident; (2) in the event of misuse or abuse of the product or as a
result of unauthorized alterations or repairs; (3) if the serial number has been altered, defaced or removed; or (4) if the owner of the product resides
outside of the U.S.A. or Canada.
Caution: Rand McNally disclaims any and all express, implied or statutory warranties, including any implied warranty of merchantability or fitness for a
particular purpose. It is the user’s responsibility to use this product prudently and in accordance with the product documentation.
RAND MCNALLY AND ITS LICENSORS DO NOT MAKE ANY OTHER WARRANTY OR REPRESENTATION, EITHER EXPRESS OR IMPLIED, WITH RESPECT TO
THE PRODUCT, INCLUDING ANY WARRANTY AS TO QUALITY, PERFORMANCE, TITLE OR NON-INFRINGEMENT. IN NO EVENT WILL RAND MCNALLY OR
ITS LICENSORS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE INSTALLATION, USE OR
INABILITY TO USE THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to some consumers.
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
©2016 Rand McNally. All rights reserved. Rand McNally and the Rand McNally globe logo are registered trademarks of RM Acquisition, LLC d/b/a
Rand McNally.

Support
www.randmcnally.com/support
877-446-4863
