Randell 9215-32-7 User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Worktops/Undercounters Side Mount Worktop models 9200-32-7
Description:
Self-contained stainless steel worktop refrigerator or freezer
unit with 3” high backsplash. Randell mullion blower coil,
with thermostatic control, cools pans and/or base, and allows
for use of optional pans in the full depth interiors. R-134a
expansion valve refrigeration system in refrigerators, (R-404a in
freezers) both are CFC free. Units with lift-off louver, condensate
evaporator, “CFC free” foamed in place insulation and 6” high
adjustable legs. Cordset for 115V operation.
model 9215-32-7 9215-32-7F 9205-32-7 9205-32-7F 9235-32-7 9225-32-7
model 9215-32-7
shown
Specifications:
CABINET EXTERIOR: Cabinet body is constructed of all metal. The
top, front, and louver panel are stainless steel. Bottom & back of
unit are corrosion resistant steel. Sides are stainless steel. Worktop
refrigerators and freezers with 1 1/2” square nosing and 3” high
backsplash. Door opening frames are ABS and contain magnetic
strip for positive seal of door gaskets.Work surface to be at 36” work
height with unit on (4) 6” high legs with adjustable bullet feet.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The Interior bottom, back, and top are
anodized aluminum with coved corners for easy clean-up. The
interior ends are ABS. Durable shelf supports molded into sides.
Unit insulated with a minimum of 2.5” of CFC free, foamed in
place polyurethane.
DOORS: Stainless steel front with easy to grasp recessed handles,
mounted on heavy duty concealed hinges. Hinges are all stainless
steel with bronze pivot pin in nylon bushing,. Doors with foamed
in place insulation, press fit magnetic gaskets - (designed for
installation & removal without tools), and deep draw ABS interior
liner for maximum insulation value.
REFRIGERATION:Refrigeratorsutilize aCFCfree,R-134aExpansion
Valve refrigeration system that includes condensing unit, and
thermostatic control for operator adjustability. Compressor
housing to allow maximum airflow and permit mounting of
standard hot gas condensate evaporator. Mullion coil, is coated
to resist corrosion, and offers maximum air flow. Freezers utilizes
R-404a refrigerant with an automatic, self-defrosting system
for blower coil. Freezer models equipped with door frame heater
element to prevent gasket freezing. Units totally prewired and to
be supplied with 8’ cordset (NEMA 5-15P) for 115V operation.
Standard Features:
• Side mounted compressor with mullion “Turbo” coil
provides proper pan cooling, and “full depth” usable
interior space
• R-134a refrigerant in refrigerators and R-404a in
freezers both are “CFC free”
• Exterior stainless steel top & front
• Foamed in place “CFC free” urethane insulation
• Self-closing doors with exclusive press-fit magnetic
gaskets
• Expansion Valve
• Condensate evaporator
• Cord and plug for 115 volt operation
• 6” high adjustable legs
• One piece stainless steel worktop and a 3” high
stainless steel, integral backsplash
Stainless steel back panel
Tray racks for 24” or 27” openings only
Refrigerated drawers
Overshelves
Casters
Export voltages available
Randell Worktops/Undercounters, Page 1
PP SPEC0010 Rev. A
Revised 07/06
Options & Accessories:
33°F to 40°F 18°F to 22°F33°F to 41°F

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Refrigerator
9215-32-7
9205-32-7
9235-32-7
9225-32-7
Freezer
9215F-32-7
9205F-32-7
L
48”
60”
72”
84”
48”
60”
D
33”
33”
33”
33”
33”
33”
H
36”
36”
36”
36”
36”
36”
Doors
(2)18”
(2)24”
(2)27”
(2)24”,(1)18”
(2)18”
(2)24”
Shelves Sq. Ft.
9.5
13.5
20
20
9.5
13.5
HP
1/3
1/3
1/3
1/3
1/3
1/3
Volt
115/60/1
115/60/1
115/60/1
115/60/1
115/60/1
115/60/1
Amps
9
9
9
9
8.7
8.7
NEMA
5-15P
5-15P
5-15P
5-15P
5-15P
5-15P
Ship Wt.
325
370
390
435
325
370
Models 9200-32-7 Worktop
18" 18"
48"
24" 24"
60"
33"
36" 39"
1.57"
*
24"REFRIG. 18"REFRIG. 24"REFRIG.
84"
*
27"REFRIG. 27"REFRIG.
72"
LOUVERED
END PANEL
LOUVERED
END PANEL
LOUVERED
END PANEL
LOUVERED
END PANEL
Storage Cu. Ft.
11.58
16.21
20.07
23.16
11.58
16.21
Drawings are to be viewed in the same order as the chart, one drawing to represent refrigerator and freezer units
NOTE: When ordering casters, 6” casters equal 35” height; 4” casters equal 33” height

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Worktops/Undercounters Back Mount Worktop models 9000-7
Description:
Self-contained, refrigerator or freezer unit with stainless steel flat
worktop and a 3” high backsplash. Back-mounted removable,
replaceable, R-134a refrigeration. “Front Breathing” system,
requires no side or back clearance. Integrated rubber bumpers
provide 1” rear clearance on models 9802F-7 and 9302F-7. Self-
closing door(s), 6” high adjustable legs, and cordset for 115V
operation. Models range from 27” to 72”, and are 30” deep and
36” high.
model 9604-7
shown
Specifications:
CABINET EXTERIOR: The top, sides, and front are stainless steel.
Bottom and back of unit are corrosion resistant steel. Door
opening frames are ABS and contain magnetic strip for positive
seal of door gaskets. Freezer models with door frame heater to
prevent gasket freezing. Units ship standard on (4) 6” high legs
with adjustable bullet feet.
CABINET INTERIOR: Interior of cabinet is fully coved to meet N.S.F.
standard #7. The Interior bottom, back, and top are anodized
aluminum with coved corners for easy clean-up. The interior ends
are ABS. Two adjustable powder coat finished shelves behind each
door, adjustable on 1” increments. Unit insulated with a minimum
of 2.5” of CFC free, foamed in place polyurethane.
DOORS: Stainless steel front with easy to grasp recessed
handle, mounted on heavy duty concealed hinges. Hinges are
all stainless steel with bronze pivot pin in nylon bushing, spring
loaded to be self-closing. Doors with foamed in place insulation,
press fit magnetic gaskets - (designed for installation & removal
without tools), and deep draw ABS interior liner for maximum
insulation value.
REFRIGERATION: CFC free, R-134a back-mounted refrigeration
system to be self-contained with evaporator blower coil,
compressor, thermostatic control, forced-air condensing coil and
capillary tube contained in removable assembly. Condensate
evaporator provided. Freezer utilizes CFC free, R-404a refrigerant,
and automatic, self-defrosting system for blower coil. Units totally
prewired and to be supplied with 8’ cordset (NEMA 5-15P) for
115V operation. “Front Breathing” refrigeration system, requires
no side or back clearance. Integrated rubber bumpers provide 1”
rear clearance on models 9802F-7 and 9302F-7.
Standard Features:
• Self-contained, removable, replaceable refrigeration
package that utilizes R-134a refrigerant, (R-404a in
freezer models) both are “CFC free”
• “Front Breathing” (on legs/casters) refrigeration system, no side or
back clearance required. Integrated rubber bumpers provide 1” rear
clearance on models 9802F-7 and 9302F-7.
• Stainless steel top, sides, and front
• Fully adjustable shelves behind self-closing door
Stainless steel back panel
Refrigerated drawers
Overshelves (double or single tier)
Casters
Export voltages
Randell Worktops/Undercounters, Page 2
PP SPEC0011 Rev. A
Revised 07/06
Options & Accessories:
model 9402-7 9402F-7 9802-7 9802F-7 9302-7 9302F-7
9602-7 9604-7
33°F to 40°F 18°F to 22°F33°F to 41°F

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 9000-7 Worktop
Model L D H Doors Storage
Cu. Ft.
Top HP Volt Amps NEMA Ship Wt.
9402-7 27” 30” 36” (1) 27” 5.66 backsplash 1/4 115/60/1 5.5 5-15P 190
9402F-7 27” 30” 36” (1) 27” 5.66 backsplash 1/3 115/60/1 6.8 5-15P 190
9802-7 36” 30” 36” (2) 18” 7.87 backsplash 1/4 115/60/1 5.5 5-15P 220
9802F-7 36” 30” 36” (2) 18” 7.87 backsplash 1/2 115/60/1 8.2 5-15P 220
9302-7 48” 30” 36” (2) 24” 10.82 backsplash 1/4 115/60/1 5.5 5-15P 265
9302F-7 48” 30” 36” (2) 24” 10.82 backsplash 1/2 115/60/1 8.2 5-15P 265
9602-7 60” 30” 36” (2) 27” 13.77 backsplash 1/4 115/60/1 5.5 5-15P 300
9604-7 72” 30” 36” (3) 24” 16.72 backsplash 1/4 115/60/1 5.5 5-15P 330
27"REFRIG
18"18"
*
36"
27"REFRIG
60"
24"24"
39"
*
S/S
END
48"
36"
30"
27"
27"
24"REFRIG 24"REFRIG 24"REFRIG
72"
(4) 1" RUBBER
BUMPER @ REAR
MUST HAVE 1" OF
CLEARENCE
IN THE REAR FOR
PROPER AIR FLOW
9302F-7 & 9802F-7 Only
Drawings are to be viewed in the same order as the chart, one drawing to represent refrigerator and freezer units
NOTE: When ordering casters, 6” casters equal 35” height; 4” casters equal 33” height

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Worktops/Undercounters Undercounter models 9000-7 & 9404-32-7
Description:
Self-contained refrigerated work top unit with back-mounted
removable, replaceable, R-134a (refrigerator), R-404a (freezer)
refrigeration system. “Front Breathing” refrigeration system,
requires no side or back clearance. Integrated rubber bumpers
provide 1” rear clearance on model 9301F-7. Model 9404-
32D-7 with two refrigerated drawers in lieu of door and shelves.
Stainless steel worktop, self-closing door, locking casters and
cordset for 115V operation. Range from 27” to 48” long, and are
36” high. Models 9404-32-7 and 9404-32D-7 are 32.75” deep,
while the others are 30” deep.
model 9404-32D-7
shown
Specifications:
CABINET EXTERIOR: The top, sides, and front are stainless steel.
Cabinet top to be one piece die-formed 20 gauge stainless steel
with 1 1/2” high square nosing. Exterior sides, and die-stamped
front louver panel extend to 1/4” AFF. Bottom and back of unit are
corrosion resistant steel. Door openings to be ABS and contain
magnetic strip for positive sealing of gaskets. Model 9404-32-7
& 9404-32D-7 with drawer opening frames to be stainless steel
with ABS breaker strips. Drawer fronts to be 24 gauge stainless
steel with 16 gauge stainless handle, magnetic gasket, ABS
interior liner and foamed in place insulation. Work surface to
be at 36” work height with unit on standard 2 1/2” high casters
(front two with locks). 9404-7 & 9301-7 with legs.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The Interior bottom, back, and top are
anodized aluminum with coved corners for easy clean-up. The
interior ends are ABS. Unit insulated with a minimum of 2.5” of
CFC free, foamed in place polyurethane. Model 9404-32D-7 with
two refrigerated drawers below top. Each drawer contains two
12” x 20” x 6” deep polycarbonate pans- pans are removable
without removing drawer tracks. Drawer tracks are 14 gauge
stainless steel with 1 5/16” stainless steel ball bearings, self-
closing and removable.
DOORS: Stainless steel front with easy to grasp recessed
handles, mounted on heavy duty concealed hinges. Hinges are
all stainless steel with bronze pivot pin in nylon bushing, spring
loaded to be self-closing. Door with foamed in place insulation,
press fit magnetic gaskets - (designed for installation & removal
without tools), and deep draw ABS interior liner for maximum
insulation value. Model 9404-32D-7, with refrigerated drawers
in lieu of door.
Standard Features:
• Self-contained, removable, replaceable refrigeration
package that utilizes “CFC free” R-134a refrigerant
• “Front Breathing” (on legs/casters) refrigeration system, no side or
back clearance required. Integrated rubber bumpers provide 1” rear
clearance on model 9301F-7.
• Fully adjustable shelves, behind self-closing stainless steel door
(Model 9404-32D-7 has (2) drawers in leiu of doors)
Stainless steel back panel
Overshelves (double or single tier)
Export voltages
Backsplash
Casters (9404-7 & 9301-7)
Randell Worktops/Undercounters, Page 3
PP SPEC0012 Rev. A
Revised 07/06
REFRIGERATION: CFC free, R-134a (refrigerators), R-404a (freezer)
back-mounted refrigeration system to be self-contained with evaporator
blower coil, compressor, thermostatic control, forced-air condensing
coil and capillary tube contained in removable assembly. Condensate
evaporator provided. Units totally prewired and to be supplied with 8’
cordset (NEMA 5-15P) for 115V operation. “Front Breathing” refrigeration
system, requires no side or back clearance. Integrated rubber bumpers
provide 1” rear clearance on model 9301F-7.
Options:
model 9404-7 9404F-7 9404-32-7 9404-32F-7 9404-32D-7
9404-32DF-7 9301-7 9301F-7
33°F to 40°F 18°F to 22°F33°F to 41°F

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
*
END
S/S
27"
27"
30"
36"
*
36"
32"REFRIG
32"
32"
S/S
END
32.5"
32" REFRIG
32" REFRIG
22"
32"
24"REFRIG
*
24"REFRIG
48"
(4) 1" RUBBER
BUMPER @ REAR
MUST HAVE 1" OF
CLEARENCE
IN THE REAR FOR
PROPER AIR FLOW
9301F-7 Only
Models 9000-7 & 9404-32-7 Undercounter
markings exclude model 9404-32F-7
Model L D H Doors Storage
Cu. Ft.
Pan Capacity HP Volt Amps NEMA Ship Wt.
9404-7 27” 30” 36” (1) 27” 5.66 - 1/4 115/60/1 5.5 5-15P 190
9404F-7 27” 30” 36” (1) 27” 5.66 - 1/3 115/60/1 6.8 5-15P 190
9404-32-7 32” 32.75” 36” (1) 32” 8.62 - 1/4 115/60/1 5.5 5-15P 252
9404-32F-7 32” 32.75” 36” (1) 32” 8.62 - 1/2 115/60/1 8.2 5-15P 252
9404-32D-7 32” 32.75” 36” (2) 32”
drawers
- (2) 12”x20”x6” per
drawer
1/4 115/60/1 5.5 5-15P 300
9404-32DF-7 32” 32.75” 36” (2) 32”
drawers
- - 1/4 115/60/1 5.5 5-15P 300
9301-7 48” 30” 36” (2) 24” 10.82 - 1/4 115/60/1 5.5 5-15P 265
9301F-7 48” 30” 36” (2) 24” 10.82 - 1/2 115/60/1 8.2 5-15P 265
Drawings are to be viewed in the same order as the chart, one drawing to represent refrigerator and freezer units
