RanServe Fiberglass Electric Heated Well models HTD-B
model RANFG HTD-4S shown
Standard Features:
• Easy access to drain and controls
• Unique integral toe-kick provides neater finish
• Easy access to service electrical components
• Concealed locking mechanism with easy to use
spring-activated catch
Additional Available Configurations:
•RANFG HTD Series
Standard enclosed base series. Available in the 2, 3, 4, 5 & 6
well models to offer most efficient space capacity.
•RANFG HTD “S” Series
Same basic construction of standard enclosed base
series with an optional open shelf storage compartment.
Available in the 3, 4, 5 & 6 well models to offer most
efficient space capacity.
Description:
Randell’s RANFG HTD Series Electric Heated Well Units designed
for virtually any hot food serving application, the RANFG HTD
series is enclosed in a brilliant one-piece fiberglass body and 14
gauge stainless steel top.
Specifications:
CABINET CONSTRUCTION: One-piece molded fiberglass body for
smooth exterior finish. All corners and areas where accessories are
mounted are reinforced internally with metal backers. Unit to be
provided with integral toe-kick. Heated storage compartment.
TOP CONSTRUCTION: Exterior top is standard in reinforced 14
gauge 300 series stainless steel with #4 finish.
HOT WELL CONSTRUCTION: The hot wells are constructed of die
stamped and annealed stainless steel and are provided with indi-
vidual drains manifolded to a common gate valve. The gate valve
is accessed through an enclosed housing with louvered access
door. Two types of fittings are provided to offer flexibility in type
of drain hose the operator wishes to attach (hose not included).
Only available in single phase.
Heated Base RANFG HTD-3B RANFG HTD-4B RANFG HTD-5B RANFG HTD-6B
Randell RanServe, Page 25b
Revised 2/07
Available Fiberglass Colors:
Pitch Black
Dark-Bark Brown
Cabernet Wine
British Racing Green
Tin Man Gray
True Blue
Light Sky Blue
Candy Apple Red
Tiger Lilly Orange
Canary Yellow
White
Options & Accessories:
Corian top
Granite top
No kick-plate
Graphics
Sneeze Guards
Elementary School Height
Electrical Distribution System
Canopy
Overshelves
Trayslides

Randell, Unified Brands 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models HTD-B
DRAIN LINE EXTENDS
TO LOUVER
1/2" DIA COPPER
LEGEND FOR
RANFG HTD
ABOVE FIXED FLOOR
AFF =
J-BOX = 14" AFF
30"
35"
86"
72"
60.25"
48"
BOTTOM OF UNIT
EXTENDIND FROM
9' CORD & PLUG
J
Drawings are to be viewed in the same order as the chart
Model L D H No. of Wells (12x20)
and/or Pans
120 Volt Operation 208 Volt Operation 240 Volt Operation Ship
Wt.
KW Amps* NEMA* KW Amps* NEMA* KW Amps* NEMA*
“B” Heated Storage Base
RANFG HTD-3B 48” 30” 35” Top; (3) Wells,
Base; (4) 12x20 or (3) 18x26 NA 4.125 19.8 6-30P 4.4 18.3 6-30P 350
RANFG HTD-4B 60.25” 30” 35” Top; (4) Wells,
Base; (4) 12x20 or (3) 18x26 NA 5.225 25.1 6-50P 5.5 22.9 6-50P 400
RANFG HTD-5B 72” 30” 35” Top; (5) Wells,
Base; (8) 12x20 or (6) 18x26 NA 6.325 30.4 6-50P 6.6 27.5 6-50P 450
RANFG HTD-6B 86” 30” 35” Top; (6) Wells,
Base; (8) 12x20 or (6) 18x26 NA 7.425 35.7 6-50P 7.7 32.1 6-50P 500
*Amp loads for base unit with light option-adding any Heat lamps or incandescent light options will change total load and/or number of electrical cords/
connections (consult factory for clarification).
