Ranger Products CRT380R User manual

QUICK ALIGNMENT GUIDE
TO INSURE A STRAIGHT STEERING WHEEL, ALL FOUR HEADS MUST BE USED!
1. Start at the home page. Select your vehicle. Then press “Continue”. (See Fig. 1)
2. Install wheel clamps vertical. Black knob to the top. Attach the ROC Positioning Level to the front left wheel
clamp. Rotate the ROC Positioning Level until the bubble indicates that it is level at the 1st position. Then
press “Continue”. (See Fig. 2)
3. Attach alignment heads to the wheel clamps, DO NOT lock them. Then press “Continue”.
4. Press “Push Mode” on the bottom of the screen.
NOTE: Push Mode should be used unless the vehicle/lift you are using does not allow enough room to
roll the vehicle backwards.
5. Press the ROC button on the front left head and when it instructs to do so, roll the vehicle back until the ROC
Positioning Level indicates that it is level in the 2nd position. Then Press the ROC button on the front left
head again.
6. When instructed to do so, roll the vehicle back until the ROC Position Level indicates that it is level in the 3rd
position. Then press the ROC button on the front left head again.
7. When instructed to do so, roll the vehicle forward until the wheel clamp moves to there original vertical
position. The ROC Positioning Level should indicate that it is level in the 1st position.
8. Level each head using the green LED and lock each head with the black knob. After all four heads are level
and locked, press the ROC button on the front left head a final time.
9. Install the Brake Depressor, remove all pins front the turn/slip plates and jounce the vehicle.
10. Perform the Caster Sweep. (See Fig. 3)
11. Click on “Rear Axle” at the top of the screen and adjust Rear Camber then Toe. (See Fig. 4)
12. Click on “Front Axle” at the top of the screen. Click on “Caster” at the bottom of the screen. (See Fig. 5 & 6)
NOTE: This Caster screen estimates the caster value based on change in camber and toe. To ensure
accurate readings you must perform a caster sweep after any adjustment is made.
13. Adjust the caster, then click on “Caster” at the top of the screen and perform another caster sweep. Repeat
step 10 as necessary until caster is correctly adjusted. (See Fig. 7)
14. Click on” Front Axle” at the top of the screen, and adjust Front Camber. (See Fig. 7)
15. Center the Steering wheel and install Steering Wheel Lock. Adjust Front Toe.
16. Click on “Results” at the top of the screen to record all alignment reading. (See Fig. 8)
For complete operation instructions refer to the CRT 380R manual that came with your aligner.
BendPak , BendPak Incorporated and Ranger Products and their registered logos are registered Trademarks. Copyright 2005 Bendpak Incorporated.
BendPak / Ranger, 1645 Lemonwood Dr., Santa Paula, CA. 93060
Tel: [phone] Fax: [phone]
REFER TO THE COMPLETE SAFETY, INSTALLATION AND OPERATION MANUAL IF YOU ARE
UNSURE OF ANY ALIGNMENT PROCEDURES OR HAVE NOT USED THIS STYLE OF ALIGNER.

BendPak , BendPak Incorporated and Ranger Products and their registered logos are registered Trademarks. Copyright 2005 Bendpak Incorporated.
BendPak / Ranger, 1645 Lemonwood Dr., Santa Paula, CA. 93060
Tel: [phone] Fax: [phone]
REFER TO THE COMPLETE SAFETY, INSTALLATION AND OPERATION MANUAL IF YOU ARE
UNSURE OF ANY ALIGNMENT PROCEDURES OR HAVE NOT USED THIS STYLE OF ALIGNER.
QUICK ALIGNMENT GUIDE
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
REV B 11-12-10
