Ranger 1505-FTL User manual

INSTALLATION GUIDE
1505-FTL Cargo Rack
Long Ford Transit 148" and 148" Ext Wheelbase ( Aluminum )

QUICK START GUIDE
REQUIRED ITEMS
2
PERSONS
q1.1 Setup...............................................................................................................................................
q1.2 Cargo Rack Assembly.....................................................................................................................
3 - 4
5 - 6
Phase 1 - Assembly
Phase 2 - Installation
NOTE: Use Sawhorses if possible, or use the box as a at protective surface on the ground or table.
qCordless Impact
qRatchet
qTape Measure
qMarker
qLadder
qCutter
q1/2" Socket
qSawhorse ( Optional )
qBox
qKnife
q1/2" Wrench
qSilicone
q2.1 Mounting Tracks Installation............................................................................................................
q2.2 Cargo Rack Installation...................................................................................................................
7
8 - 11

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 3
PHASE 1 – ASSEMBLY
1.1 SETUP
1.1.1 Unpack components; compare with the bill of materials.
1.1.2 Verify all parts are present.
Item No. Description Qty.
10-702 Mounting Track 2
10-4440 “C” Foot 4
15-0503 Front Crossbar 1
15-0513 Rear Crossbar 1
94-1008 Assembly Fastener Kit 1
96-1004 Install Fastener Kit 1
BILL OF MATERIALS
10-702
15-0513
15-0503
10-4440

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 4
94-1008 Fastener Kit Fastener Assembly
1.1.3 Fastener kits.
8×
#90-491 Carriage Bolt 5/16" × 1"
#98-123 Lock Washer
#94-105 Hex Nut
#98-117 Flat Washer
# 90-491
8×
Carriage Bolt
5/16"-18 × 1"
SS304
# 98-117
Flat Washer
5/16", O.D 3/4"
SS18-8
8×
# 98-123
Lock Washer
Regular 5/16"
SS304
8×
# 94-105
Hex Nut
5/16"-18
SS316wax
8×
96 - 1004 Fastener Kit Fastener Assembly
# 98-117
16×
Flat Washer
5/16", OD 3/4"
SS18-8
# 98-123
16×
Lock Washer
5/16"
SS304
# 90-209
8×
Hex Bolt
5/16"-18 × 1"
SS304
# 94-150 Channel Nut
5/16"
8×
# 98-136
8×
Spacer
0.505" ID × 1" OD × 0.250" L
NYLON
# 98-149
16×
Spacer
0.290" ID × 1.375" OD × 0.125" L
NEOPRENE
# 90-970
8×
Hex Bolt
M8-1.25 × 35 CL 12.9 DIN
933 SS304
8×
#90-209 Hex Bolt 5/16" × 1"
#98-123 Lock Washer
#98-117 Flat Washer
#94-150 Channel Nut
8×
#90-970 Hex Bolt M8 × 35
#98-123 Lock Washer
#98-117 Flat Washer
#98-136 Spacer
#98-149 Neoprene Spacer
#98-149 Neoprene Spacer

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 5
1.2.1 Slide carriage bolts on the bottom face of the crossbars.
NOTE: The track plug must be removed from the underneath of the front crossbar, and reinstalled
after the feet have been installed in the nal position, see 2.2.4.
PHASE 1 – ASSEMBLY
1.2 CARGO RACK ASSEMBLY
Rear crossbar
• Slide 2 pcs. of 1" carriage bolts.
Front crossbar
• Slide 2 pcs. of 1" carriage bolts.
HARDWARE USED
4×
#90-491 Carriage Bolt
5/16" × 1" SS304
PASSENGER SIDE
Rear crossbar
• Slide 2 pcs. of 1" carriage bolts.
Front crossbar
• Slide 2 pcs. of 1" carriage bolts.
DRIVER SIDE
HARDWARE USED
4×
#90-491 Carriage Bolt
5/16" × 1" SS304

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 6
HARDWARE USED
8× hand-tighten the nuts.
Carriage bolts are already on
the crossbars.
#98-123 Lock Washer
#98-117 Flat Washer
#94-105 Hex Nut
1.2.2 Install the feet on the Front, and Rear Crossbars.

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 7
PHASE 2 – INSTALLATION
2.1 MOUNTING TRACKS INSTALLATION
TOOLS
qCordless Impact
q1/2" Socket
FASTENERS USED
8×
#90-970 Hex Bolt M8 × 35
#98-123 Lock Washer
#98-117 Flat Washer
#98-136 Spacer
#98-149 Neoprene Spacer
#98-149 Neoprene Spacer
Mounting Track Orientation
REAR FRONT
use use use use
2.1.1 • Remove existing plugs on the vehicle roof holes.
• Use a tap ( M8 - 1.25 ) to remove the excess dirt/paint in the holes of the van.
• Apply a bead of silicone around each hole, then fasten the tracks to the roof.
TIPS: It’s easier to put the bolts, lock washers, at washers and spacers on the tracks, rst,
then install the tracks to the roof.

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 8
PHASE 2 – INSTALLATION
2.2 CARGO RACK INSTALLATION
2.2.1 Position the front and rear crossbars ( minimum two persons ) on the vehicle
so that the feet are on the mounting tracks.
Cargo Rack

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 9
distance < A >
distance < B >
distance < B >
distance < A >
FASTENERS USED
8×
TOOLS
qRatchet
q1/2" Socket
qTape Measure
#90-209 Hex Bolt 5/16" × 1"
#98-123 Lock Washer
#98-117 Flat Washer
#94-150 Channel Nut
distance < foot to end of track >
2.2.2 • Make sure the crossbars are parallel to each other at the desired distance apart,
then attach all the “C” feet to the mounting tracks.
• Tighten the bolts that attach the foot plate to the ladder rack leg.

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 10
TOOLS
qRatchet
q1/2" Socket
IMPORTANT: Place the cargo rack warning label on a visible area, recommended on a partition.
2.2.3 Center the crossbars on the vehicle, then tighten all the “C” feet to the crossbars.

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 11
TOOLS
qCutter
TRACK PLUG
2.2.4 After installation is complete, cut the track plug underneath the front crossbar to ll all the unused space.
Failure to do so will result in excessive wind noise.

For technical support, contact us at 1-800-565-5321 1505-FTL Installation Guide |REV. B1 | Page 12
“You have successfully installed your
1505-FTL Cargo Rack
Thank you for doing business with us.”
For any feedback or suggestions you may have, please contact: [e-mail]
