Ranger 3320-TC User manual

INSTALLATION GUIDE
3320-TC CONTOURED PARTITION
Transit Connect Partition ( Clear Plastic )

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 2
QUICK START GUIDE
REQUIRED ITEMS
2
PERSONS
qCordless Impact
qCordless Drill
qTorque Gun
q1/2" Socket
q7/16" Socket
q10mm Socket
qT50 Torque Bit
q1.1 Setup....................................................................................................................................................
q1.1.1 Unpack components; compare with the bill of materials................................................................
q1.1.2 Verify all parts are present...............................................................................................................
q1.1.3 Identify the assembly and installation fastener bags......................................................................
q1.2 Partition Assembly................................................................................................................................
q1.2.1 Attach the lower panel and mounting track to the upper panel......................................................
q1.2.2 Attach the sides of the upper panel and lower panel together on both sides................................
3
3
3
4
5
5
6
Phase 1 - Assembly
q2.1 Vehicle preparation...............................................................................................................................
q2.1.1 Floor preparation.............................................................................................................................
q2.2 Contoured Partition Installation............................................................................................................
q2.2.1 Attach the oor bracket to the van..................................................................................................
q2.2.2 Put the assembled partition in place, then bolt both sides to the van............................................
q2.2.3 Attach the lower panel to the oor bracket.....................................................................................
q2.2.4 Put the warning label on the indicated location..............................................................................
6
6
7
7
8
9
9
Phase 2 - Installation

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 3
PHASE 1 – ASSEMBLY
1.1 SETUP
1.1.2 Verify all parts are present.
Item No. Description Qty.
30-226 Lower Panel 1
30-402 Floor Bracket 1
70-636 Mounting Track 51" 1
79-932 Warning Label ( Bilingual ) 1
33-2000 Upper Panel w/ Label 1
94-3006 Assembly Fastener Bag 1
96-3003 Installation Fastener Bag 1
1.1.1 Unpack components; compare with the bill of materials.
30-402
33-2000
70-636
30-226

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 4
1.1.3 Identify the Assembly and Installation fastener bags.
Assembly Fastener Bag Hardware Assembly
Hardware AssemblyInstallation Fastener Bag
#90-971 Hex Bolt M6-1.0 × 20mm
10×
7×
2×
4×
#90-208 Hex Bolt 5/16" × 1"
#98-116 Flat Washer
#94-116 Serrated Nut
Hex Bolt
1/4"-20 × 7/8"
GR-5 ZINC
# 90-112
2×
# 90-114
Hex Bolt
1/4"-20 × 1"
GR-5 ZINC
7×
Hex Bolt
5/16"-18 × 1"
GR-5 ZINC
# 90-208
4×
Serrated Nut
1/4"-20
ZINC
# 94-112
9×
Serrated Nut
5/16"-18
ZINC
# 94-116
4×
# 98-112
Flat Washer
1/4", 3/4" OD
ZINC
9×
Flat Washer
5/16", 7/8" OD
ZINC
# 98-116
4×
# 90-971
Hex Bolt
M6-1.0 × 20mm
1022 BO
10×
#90-114 Hex Bolt 1/4" × 1"
#98-112 Flat Washer
#94-112 Serrated Nut
#90-112 Hex Bolt 1/4" × 7/8"
#98-112 Flat Washer
#94-112 Serrated Nut

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 5
PHASE 1 – ASSEMBLY
1.2 PARTITION ASSEMBLY
1.2.1 Attach the lower panel and mounting track to the upper panel.
#90-114 Hex Bolt 1/4" × 1"
#98-112 Flat Washer
#94-112 Serrated Nut
HARDWARE USED
7×
TOOLS
qCordless Impact
q7/16" Socket

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 6
1.2.2 Attach the sides of the upper panel and lower panel together on both sides.
#90-112 Hex Bolt 1/4" × 7/8"
#98-112 Flat Washer
#94-112 Serrated Nut
HARDWARE USED
2×
TOOLS
qCordless Impact
q7/16" Socket
PHASE 2 – INSTALLATION
2.1 VEHICLE PREPARATION
2.1.1 Floor preparation.
TOOLS
qTorque Gun
qT50 Torque Bit
Remove the 2 D-rings, for re-use.

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 7
PHASE 2 – INSTALLATION
2.2 CONTOURED PARTITION INSTALLATION
HARDWARE USED
2×
Use the D-ring Bolts
TOOLS
qCordless Impact
qT50 Torque Bit
2.2.1 Attach the oor bracket to the van using the 2 D-rings.

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 8
#90-971 Hex Bolt M6-1.0 × 20mm
HARDWARE USED
10×
TOOLS
qCordless Drill
q10mm Socket
2.2.2 Put the assembled partition in place, then bolt both sides to the van.
NOTE: Do not tighten the bolt too much to prevent breakage.

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 9
2.2.3 Attach lower panel to the oor bracket.
2.2.4 Put the warning label on the indicated location.
NOTE: The english warning label is already attached to the upper panel.
WARNING LABEL
#90-208 Hex Bolt 5/16" × 1"
#98-116 Flat Washer
#94-116 Serrated Nut
HARDWARE USED
4×
TOOLS
qCordless Impact
q1/2" Socket

For technical support, contact us at 1-800-565-5321 3320-TC Installation Guide |REV. C2 | Page 10
“Congratulations, you have successfully installed your
Contoured Partition!
Thank you for doing business with us.”
For any feedback or suggestions you may have, please contact: [e-mail]
