Rapidline SS-SPCNR PS User manual

SS-SPCNR PS
Assembly instructions

Assembly instruction
|
2
TABLE OF CONTENT
1. SAFETY AND WARNINGS
2. USAGE
3. SET UP AND INSTALLATION
4. OPERATION
5. MAINTENANCE AND DEFECTS
6. TECHNICAL DATA
7. PARTS
8. ASSEMBLY DIRECTIONS
9. DECLARATION OF CONFORMITY
2. USAGE
– The electromotive, height-adjustable tables are designed for workstations in dry work environments only (0-40°C; 20-90% relative
humidity). The table height is innitely adjustable, so that it can be set to the most ergonomically suitable working level.
– They have not been designed for other purposes than those included in this manual, e.g. they are not to be used in areas of
high humidity or dampness, nor for lifting people. Any other use is at one’s own risk!
– Do not crawl, lie or move around under the table frame, and do not sit or stand on the table frame.
– CHILDREN should only use the table when supervised by adults.
– Liability: The manufacturer accepts under no circumstances warranty claims or liability claims for damages arising from improper use
or handling of the table frame other than that described in this operation manual.
3. SET UP AND INSTALLATION
When the table has been assembled (see assembly directions in CHAPTER 8) the adjustable feet are installed so that the table is level
and does not shift. Then the table is connected to the 100-240 VAC outlet and the table is ready for use.
– Make sure that no cables can get jammed.
– Place the table in a safe distance from window frames, radiators, furniture etc. so that people do not get stuck.
– Do not place any objects above 550 mm underneath the table.
– When moving the table after it has been assembled, the tabletop needs to be removed. The table CANNOT be lifted by the tabletop.
The desk need to be lowered to minimum height before moving.
1. SAFETY AND WARNINGS
This table complies with the prescribed safety regulations. Inappropriate use may cause damage to persons and table.
Please read the operation manual prior to using the table. It provides you with important information about safety, use,
installation and maintenance of the table, and thus protecting you and your children and avoiding damage on the table.
Please guard this operation manual and pass it on to any future owner!
IMPORTANT NOTES !
Prior to installation, use and
maintenance of the table frame, any
installer and any user of the table
must study this assembly and operation
manual carefully, so as to gain a complete
understanding of its contents.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS
AND WARNINGS REGARDING THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.

Assembly instruction
|
3
4. OPERATION
UP/DOWN operation:
Push the buttons for operation up or down
5. MAINTENANCE AND DEFECTS
– The table does not require any maintenance by usage as described in chapter 2 in the directions for use.
– The table is only to be maintained with a damp cloth.
– In the event of the occurrence of jarring sounds during operation, STOP using the table and please contact the dealer.
6. TECHNICAL DATA
Frame, materials: Steel, powder lacquered
Weights (frame): 27 kg | 29 kg | 31 kg
Width: 1200 x 1200 mm |1500 x 1500 mm |1800 x 1800 mm
Depth: 700 mm
Height (frame): 660-1180 mm
V(speed): ~ 25 mm/sec., depends on load.
FMAX = Max. load: 100 kg (evenly distributed on frame)
Duty cycle: 10% by 50% of max. load on frame or max. 2 min. continuously
Operation: Micro switches
Voltage: 100-240 VAC | 50/60 Hz
Consumption: 80 Watt
Standby Consumption: <0,4 Watt
Above specications may vary depending on local temperature, humidity and input voltage.
7. PARTS See page 4.
8. ASSEMBLY DIRECTIONS See pages 5-7.
9. DECLARATION OF CONFORMITY
We hereby declare, under our sole responsibility that the following products:
– Sit and stand table product type SSSPLEG PS combined with SSSPCNR PS
is in accordance with:
– Directive 2006/42/EF of The European Parliament and of the Council of 17 May 2006 on machinery
and on changes of directive 95/16/EF
With reference to the above please be aware that:
– the sit and stand table is considered a machine and
– the sit and stand table may not be used until it has been assembled and installed according to the instructions.
Manufacturer:
FurnX Pty Ltd
PO Box 357
Zillmere, QLD 4034
Australia
Phone: [phone] / Fax: [phone]
www.rapidline.com.au

Assembly instruction
|
4
Driveshaft
x1
7. Parts
A1
Legs
A2
x1
A3
3rd leg
x1
x1 x2
B1
B2
x1
Transformer
D
x8
M6*16H screws
I
x4
Adjustable glide
H
x13
5*16H screws
J
x2
Cable clips
K
Transformer bracket
M
x2
4*16H screws
L
Cable tie
N
Power cable
E
x1
Modesty panel
C
Supplied in a separate package. x2
Controller
F
x1
Stiening rail incl.
20 pcs. 5*20H screws
NB: Stiening rail is not required
for 1200 W desks.
G
Supplied in a separate package. x2
packed with and
packed with
A2A1B1
B2 A3

Assembly instruction
|
5
8. Assembly directions
2.
C
C
Pre-tted A3
A2
A1
H
I
1.
Screws
pre-tted A3
A3

Assembly instruction
|
6
3.
– Fit tabletop, rst centre top and ensure that
the correct length screw is used.
– Desk frame and top have to be parallel
before xing the top
– Do NOT start the desk before top is xed to A1 and A2
– See component positions on page 8
4.
– Fit telescopic driveshafts – extend both ends
onto driveshaft spigots.
– Do not over-tighten grup screws.
Only very light pressure required.
B2
B1
J
X
1= X2
X
1
X
2
F
K
L
M
N
E
DJ

Assembly instruction
|
7
5.
6.
– Stiening rail Gis not required for
tabletops width 1200W
– See component positions on page 8
– Raise desk and t remaining screws to
stiening rail Gand screws to A3
– See component positions on page 8
G
G
5*20H - 5 pcs.
J
5*20H - 5 pcs.
5*20H - 5 pcs.
5*20H - 5 pcs.

Assembly instruction
|
8
Components position and wiring
How to create space for wiring
To ensure correct up and down operation of the desk frame
it has to be tted with a tabletop or applied a similar weight.
Without a tabletop tted, the desk frame may not operate in
the downward direction.
Red/Red
Important:
Only plug leads red to red
and black to black.
Black/Black
343230.0
1Remove screw
2Tilt out cover
Cover need to be tted again after wiring.
