Dominion KX III User Station
User Guide
Release 1.2.0
Copyright © 2017 Raritan, Inc.
KX3UST
-0D-v1.2.0-E
March 2017
255-62-0011-00

This document contains proprietary information that is protected by copyright. All rights reserved. No
part of this document may be photocopied, reproduced, or translated into another language without
express prior written consent of Raritan, Inc.
© Copyright 2017 Raritan, Inc. All third-party software and hardware mentioned in this document are
registered trademarks or trademarks of and are the property of their respective holders.
FCC Information
This Equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
VCCI Information (Japan)
Raritan is not responsible for damage to this product resulting from accident, disaster, misuse,
abuse, non-Raritan modification of the product, or other events outside of Raritan's reasonable
control or not arising under normal operating conditions.
If a power cable is included with this product, it must be used exclusively for this product.

iii
Contents
What's New in the Dominion User Station User Guide for Release 1.2.0 viii
Chapter 1 Introduction 1
Overview ...............................................................................................................................................1
Package Contents ................................................................................................................................2
Product Photos and Features .............................................................................................................2
Product Features ......................................................................................................................2
Product Photos..........................................................................................................................3
Introduction to the User Station..........................................................................................................4
Front View..................................................................................................................................4
Rear View ...................................................................................................................................5
Side View....................................................................................................................................5
Introduction to the Software................................................................................................................6
Login Screen..............................................................................................................................6
Main Screen and Main Toolbar.................................................................................................7
Online Help and Hotkeys Help..................................................................................................9
Chapter 2 Getting Started 10
Installation and Configuration...........................................................................................................10
Step 1: Connect the Equipment..............................................................................................10
Step 2: Log in to the Dominion User Station..........................................................................11
Step 3: Add KX III KVM Switches.............................................................................................12
Step 4: Access KVM Switches and KVM Ports .......................................................................14
Step 5: Use the KVM Client .....................................................................................................17
Basic Network Settings .....................................................................................................................20
Logout or Shutdown...........................................................................................................................22
VESA Mount (Optional).......................................................................................................................23
Rackmount Using L-type Brackets (Optional)..................................................................................25
Chapter 3 Managing KVM Switches and Ports 27
User Station Configuration................................................................................................................27
Adding KVM Switches ........................................................................................................................28
Editing KVM Switches ........................................................................................................................30
Deleting KVM Switches......................................................................................................................31
Configuring KVM Ports ......................................................................................................................31
Unavailable Hotkeys for Port Access.....................................................................................33
Port Data Retrieval Status......................................................................................................34

Contents
iv
Chapter 4 Navigation and Access to KVM Ports 36
Port Navigator ....................................................................................................................................37
Identifying States of KVM Switches and Ports..................................................................................39
Identifying External Media.................................................................................................................41
Dual Video Port Status.......................................................................................................................41
Using Search ......................................................................................................................................42
Using Filters .......................................................................................................................................42
Chapter 5 Using the KVM Client 45
Connection Properties .......................................................................................................................46
Default Connection Properties ...............................................................................................48
Text Readability .......................................................................................................................49
Color Accuracy ........................................................................................................................49
Video Mode...............................................................................................................................49
Noise Filter ..............................................................................................................................50
Keyboard Macros ...............................................................................................................................50
Mouse Settings...................................................................................................................................51
Synchronize Mouse .................................................................................................................52
Single Mouse Cursor...............................................................................................................52
Dual Mouse Modes ..................................................................................................................53
Mouse Synchronization Tips ...................................................................................................55
Video Settings.....................................................................................................................................56
Advanced Video Settings.........................................................................................................58
Advanced Color Settings.........................................................................................................60
Peripheral Devices and USB Settings...............................................................................................61
Audio Device ............................................................................................................................63
Virtual Media............................................................................................................................64
SmartCard Reader ..................................................................................................................71
Disconnecting a Virtual Device...............................................................................................75
USB Profiles ............................................................................................................................76
Power Control ....................................................................................................................................79
View Settings ......................................................................................................................................80
Fit window to Target................................................................................................................80
Scale Video...............................................................................................................................80
Show Window Decorations .....................................................................................................81
Full-Screen Mode....................................................................................................................81

Contents
v
Window Management ........................................................................................................................82
Dual Video Port Connections.............................................................................................................84
Chapter 6 Setting User Preferences 85
Managing Keyboard Macros..............................................................................................................85
Executing Macros....................................................................................................................87
Editing or Deleting Macros .....................................................................................................88
Keyboard Macro Example.......................................................................................................88
Audio Settings ....................................................................................................................................89
KVM Client Settings ...........................................................................................................................90
Desktop Settings ................................................................................................................................92
Password Change ..............................................................................................................................93
Chapter 7 Administration Features 95
Users...................................................................................................................................................95
Editing or Deleting Users........................................................................................................98
User Groups .......................................................................................................................................99
Privileges ...............................................................................................................................101
Editing or Deleting User Groups ..........................................................................................101
LDAP .................................................................................................................................................103
Adding LDAP Servers............................................................................................................104
Enabling or Disabling the LDAP Authentication..................................................................112
Searching for LDAP Users and Groups................................................................................113
Setting the Maximum Search Results..................................................................................117
Certificates .......................................................................................................................................117
Removing an Installed Certificate ........................................................................................119
Certificate Failure Message .................................................................................................119
Security Settings ..............................................................................................................................120
Display Settings................................................................................................................................122
Chapter 8 Maintenance Features 124
Event Log ..........................................................................................................................................125
Event Type and Description ..................................................................................................127
Event Log Archives................................................................................................................128
Backup and Restore.........................................................................................................................132
Exporting and Importing Backup Files ................................................................................134
Deleting Backup Files ...........................................................................................................135
Factory Reset ...................................................................................................................................136
Software Update...............................................................................................................................138
Support .............................................................................................................................................140
Support Login ........................................................................................................................140

Contents
vi
Log Level for Diagnostic Log Files .......................................................................................141
Diagnostic Log File................................................................................................................141
About this Device..............................................................................................................................143
Chapter 9 System Settings 144
Date/Time .........................................................................................................................................144
Date and Time........................................................................................................................145
Time Zone ..............................................................................................................................146
Keyboard...........................................................................................................................................147
Layouts...................................................................................................................................148
Mouse Keys............................................................................................................................149
Monitor .............................................................................................................................................150
Network Connections ......................................................................................................................151
IPv4 Settings ..........................................................................................................................154
IPv6 Settings ..........................................................................................................................157
Default Shortcut Icons in the Main Toolbar....................................................................................160
Keyboard Layout Icon............................................................................................................160
Volume Icon ...........................................................................................................................160
Network Icon .........................................................................................................................161
Clock Icon ..............................................................................................................................162
Location and Clock Time Format .........................................................................................164

Contents
vii
Login Screen Settings......................................................................................................................167
Chapter 10 Additional Features 168
Device Resume or Screen Unlocking..............................................................................................168
Factory Reset at Startup..................................................................................................................169
Appendix A Specification 171
Appendix B Authentication of User Stations and KVM Switches 172
Appendix C Available Key Sets 174
Appendix D Pre-programmed User Station Hotkeys 177
Hotkeys for Controlling the User Station .......................................................................................177
Hotkeys for Controlling User Station Windows..............................................................................177
Appendix E Card Reader Restriction Caused by KX III KVM Switch Settings 180
Appendix F Certificate Requirements 181
Index 185

viii
The following sections have changed or information has been added to
the Dominion User Station User Guide based on enhancements and
changes to the equipment and/or user documentation.
• Window Management (on page 82): A new tool for managing KVM
session windows.
• Dual Video Port Connections (on page 84): Support for dual video
port groups on KX3 devices.
• Event Log (on page 125)
• Display Settings (on page 122): A new setting for monitor turn off
and screen locking after idle timeout.
• KVM Client Settings (on page 90): A new setting for saving KVM
session window position and size.
• Maintenance Features (on page 124): A new menu containing the
Event Log function, as well as all maintenance functions that were
previously under Administration.
What's New in the Dominion User
Station User Guide for Release 1.2.0

1
This chapter introduces the Dominion KX III User Station (Dominion User
Station).
In This Chapter
Overview ........................................................................................................ 1
Package Contents ......................................................................................... 2
Product Photos and Features....................................................................... 2
Introduction to the User Station................................................................... 4
Introduction to the Software......................................................................... 6
Overview
The Dominion User Station (DKX3-UST) is designed to access servers
and computer devices connected to Dominion KX III KVM switches from
customer LAN/WAN networks. ALL KX III KVM switches are supported.
Note: For information on KX III KVM switches, access its user
documentation from its application or the Dominion KX III section of the
Raritan website's
Support page ( http://www.raritan.com/support/ ).
You can store the IP addresses of multiple KX III KVM switches on the
Dominion User Station so that you can remotely access any IT device
connected to these KVM switches with only one click.
Illustration diagram:
Chapter 1
Introduction

Chapter 1: Introduction
2
A
A USB Keyboard, USB mouse, and one or two HDMI- or
DisplayPort-interfaced monitors
B
Analog or digital audio appliances
C
Optional smart card reader for remote IT device authentication
D
External drives as virtual media, such as CD-ROM
E
USB drives for virtual media or User Station software update
Package Contents
The Dominion User Station ships with the following contents.
•Dominion User Station
•Power adapter
•VESA mount kit
•Quick Setup Guide
•Warranty card
•L-type rackmount kit (optional)
Product Photos and Features
Product Features
•Support KVM-over-IP connections to target servers
Note: The User Station CANNOT access a KVM port that is connected
to a tiered KVM switch or a blade chassis server.
•Support a HDMI- or DisplayPort-interfaced monitor
•Support for dual video ports
•Support dual monitors
•Support dual LAN connections
•Support virtual media, including external DVD or USB drives
Note: Virtual media is supported only when the accessed KX III KVM
switch supports it and you have permissions to use virtual media.
See
Virtual Media (on page 64).

Chapter 1: Introduction
3
•Support USB audio
•Support power control for target servers (with Raritan PX PDUs)
•Support authentication to target servers via an optional smart card
•Support authentication and authorization via LDAP
•Support the optional FIPS 140-2 mode
Product Photos
Dominion User Station
Power adapter and cord

Chapter 1: Introduction
4
VESA mount kit
Introduction to the User Station
Front View
1. Microphone input 5. Power button
2. Audio output 6. SD card reader
3. Power LED 7. USB 2.0 ports
4. Hard disk LED

Chapter 1: Introduction
5
Rear View
1. RS232/RS422/RS485 7. USB 3.0 ports
2. RS232 8. USB 2.0 ports
3. Ventilation 9. DisplayPort (DP) video 1
4. DC power input 10. DisplayPort (DP) video 2
5. Gigabit LAN port 1 11. HDMI video
6. Gigabit LAN port 2 12. Connector for external
power button
Note: Both RS232 ports are reserved and cannot be used by the user.
The connector for external power button is reserved for future use.
Side View
1. Kensington Lock holes

Chapter 1: Introduction
6
Introduction to the Software
After powering on the User Station, the Login Screen is shown.
After successfully logging in to the User Station, the Main Screen
displays.
Login Screen
The following diagram illustrates the Login Screen.
1. Text box for entering user credentials:
For initial login, see Step 2: Log in to the Dominion User Station (on
page 11).
2. System date and time.
3. Icons to configure system settings in the Login Screen:
Click the desired icon to configure its settings. These settings apply
to the Login Screen only. They do NOT impact the Main Screen, which
is shown after login. The only setting that applies to both the Login
Screen and Main Screen is the keyboard layout setting.

Chapter 1: Introduction
7
Icons
Description
Determine the keyboard layout. The default is
English (US).
Turn on or off the following functions:

Large Font

High Contrast
By default, these settings are turned OFF. For
details, see
Login Screen Settings
(on page 167).
Perform one of power control operations:

Suspend: Enters the power-saving mode.

Restart: Restarts the User Station.

Shut Down : Powers off the User Station.
Main Screen and Main Toolbar
The screen displayed after login is the Main Screen.
The Main Toolbar is located at the bottom of this screen. This toolbar
shows the Main Menu, shortcut icons and lists any open User Station and
KVM Client windows.
1. Main Menu:
This menu contains the primary User Station commands and system
settings.
2. Open window(s):
If any window is launched, its name is shown in the Main Toolbar. In
the above diagram, only the Port Navigator window is launched.

Chapter 1: Introduction
8
You can right-click any open window in the Main Toolbar to perform
one of the following commands:
Command
Description
Minimize Minimize the window.
After a window is minimized, the Minimize command will be replaced by the
Unminimize command. Select Unminimize to restore the window.
Maximize Maximize the window.
After a window is maximized, the Maximize command will be replaced by the
Unmaximize command. Select Unmaximize to restore the window.
Move After selecting this command, move your mouse to move the window.
Resize After selecting this command, move your mouse to resize the window.
Always On Top When selected, the window is always on top of any open windows.
Close Close the window.
3. Shortcut icons for viewing/configuring system settings:
Hover your mouse pointer over an icon to view information, or click
or right-click it to configure settings.
Note: The above diagram shows factory default icons. More icons
may be available if you change any system settings. For example,
Displays (see " Monitor " on page 150).
Default icons
Description
The Keyboard Layout icon indicates the current keyboard layout. The
default is
en (American English).
See
Keyboard Layout Icon
(on page 160).
This icon controls the volume. See
Volume Icon
(on page 160).
This icon shows or configures the network information. See
Network
Icon
(on page 161).
The
Clock icon indicates the day of the week, date and current time. See
Clock Icon
(on page 162).

Chapter 1: Introduction
9
Online Help and Hotkeys Help
Both online help for using the Dominion User Station and information on
pre-programmed hotkeys are available in the Main Menu.
Online help:
•Choose Main Menu > Help > User Manual.
As long as the User Station is connected to the Internet, the User
Manual link directs you to the Dominion User Station's online help.
Information on pre-programmed hot keys:
•Choose Main Menu > Help > Help on Hotkeys.
A list of pre-programmed as well as user-configurable hot keys for
the User Station displays onscreen.
Note: Information of most hot keys is also available in this User
Guide. See Configuring KVM Ports (on page 31) and Hotkeys for
Controlling User Station Windows (on page 177).

10
This chapter introduces the basic installation and configuration.
In This Chapter
Installation and Configuration.................................................................... 10
Basic Network Settings .............................................................................. 20
Logout or Shutdown.................................................................................... 22
VESA Mount (Optional)................................................................................ 23
Rackmount Using L-type Brackets (Optional)........................................... 25
Installation and Configuration
Step 1: Connect the Equipment
Only the basic hardware installation is described. For additional
connection information, see
Overview (on page 1).
To make a basic connection:
1. Disconnect all devices from power.
2. Connect a USB keyboard and mouse to the front or rear USB 2.0
ports.
3. Optional. Connect a microphone and speakers to the front panel.
4. Connect the User Station to the network using either or both LAN
ports on the rear panel.
5. Connect one or two monitors using either or both DisplayPort ports,
or the HDMI port.
Chapter 2
Getting Started

Chapter 2: Getting Started
11
Note 1: DisplayPort and HDMI transmit both video and audio signals.
Your monitors must support the audio transmission if audio is
intended.
Note 2: Only one or two monitors can be connected to the User
Station.
6. Power ON all devices.
Step 2: Log in to the Dominion User Station
Use the factory default user credentials for initial login. User credentials
are case sensitive.
To log in to the User Station:
1. Type the user name: admin
2. Type the password: raritan
3. Click Login or press Enter.

Chapter 2: Getting Started
12
Note: It is strongly recommended to change the factory default password.
If not yet, a reminder message appears in the User Station Configuration
and Navigator windows. See
Password Change (on page 93).
Step 3: Add KX III KVM Switches
If the User Station is connected to a non-DHCP network, you must
manually configure the network settings prior to adding KX III KVM
switches. See Basic Network Settings (on page 20).
KX III KVM switches are added in the User Station Configuration window.
To add KX III KVM switches:
1. Launch the User Station Configuration window using either method
below.
Press
Ctrl+Alt+C .
Choose Main Menu > User Station Configuration. For the Main
Menu's location, see
Main Screen and Main Toolbar (on page
7).
2. Click .
3. Enter the data for the KX III KVM switch.
