‐4‐
1.TheweighingHandPalletTruck

1.1.Takingthesystemintooperation

Toactivatetheweighingsystem,turnitonusingtheon/off()keyontheterminal.

After3to5minutestheelectronicsandloadcellshavereachedtheoperational
temperature.Beforethis,inaccuraciesofuptoca.0.3%mayoccur.

Itisrecommendednottoliftloadsbeforethezero‐pointcorrectionhasbeenexecuted.

1.2.Powersupply

Thepowersupplytothesystemtakesplacethroughanexchangeablebatterypack.Note:
Forlegalfortradesystemsthepowersupplytothesystemtakesplacethroughafix
mountedbattery.

Withacompletelychargedbatterythetotalweighingtimeisabout35hours(onasystem
withoutaprinter).

Whenthevoltagelevelofthebatteryisrunninglow,thedisplaywillshow.Whenthe
“LO‐BA”indication  isshownfor1or2minutes,theweighingsystemswitchesoff
automatically.Itisstronglyrecommendedtochargetheemptybatterydirectlywiththe
suppliedcharger.

Inordertomaximizethelifetimeofthebattery,followthecharginginstructionsbelow
precisely:
1. Insertthebatteryintothechargermodule.Note:Forlegalfortradesystemsconnect
thechargercabletothesystem
2. Plug‐inthechargeradaptorplug,intomainsvoltage220‐240VDC.TheredLEDonthe
chargeradaptorislittoindicatethatthechargerischargingthebattery.When
charging,itisnecessarytochargethebatteryforatleast6hours.Thiswillprevent
lossofbatterycapacity.
3. Anemptybatterywillbefullychargedafterapproximately6hours.Whenthered
LEDturnsoff,thebatteryisfullycharged.Itisnotpossibletooverloadthebattery
becausethechargerswitchesoffautomatically.
4. De‐connectthechargeradaptorplugfromthe220‐240VDCmainsvoltage.
5. Aftertakingoutthechargeradaptorplug,directlyremovethebatteryfromthe
chargermodule.Note:Forlegalfortradesystemsdirectlyremovethechargingcable
fromthesystemafterremovingtheadapterfromthecharger.
6. Forcharginganextbattery,startatstep1again.
Ifyouusethesysteminshiftworkorifthesystemhasabuilt‐inprinter,itisrecommended
topurchaseasupplementarybatterypack.

‐5‐
Theweightmustbeliftedfreely:withouttouchingthehousingoftheindicatororother
pallets:




Wrongwayofliftingtheload

Correctwayofliftingtheload

Theaccuracyoftheweighingsystemdiminisheswithcirca0.1%perdegreestartingfroma
tiltedpositionof2°.Thiseffectalsooccurswithpits/pot‐holesinthefloor.Anevenflooris
optimal.Thesystemwillbeproducedwithanelectricallevelswitch.Whentheforksareout
oflevelwithmorethan2degrees,theindicatorwill
display‐‐‐‐‐‐
.


Themostaccurateweighingresultisobtainedwhenthecentreofgravityoftheloadis
placedbetweentheforks.Withannon‐centricloading,theforkswilltordateandbend.This
mayresultinahigherinaccuracy.Withlegalfortradeversions,thelevelcontrolwillswitch
offtheindicatorwithanon‐centricloadingoratiltedpositionthatinfluencestheweighing
accuracy.



Temperaturerange:between‐10and+40°
Cthemaximuminaccuracyis0.1%ofthe
weighedload.Outsidethisrange,
inaccuraciesofupto0.3%mayoccur.

Fasttemperaturechangesmustbeavoidedbecauseitwillcausecondensationintheelectronics.
Duringacclimatisationtheweighingsystemmustbeswitchedoff.




‐6‐
1.3.Maintenance

Themaintenanceguidelinesfornormalpallettrucksapplytothechassisofthemobileweighing
system.Fromexperienceweknowthattheintegratedweighingsystemstillfunctionswhenthe
chassisisdamagedbyoverloading.

Mainguidelines:
‐ Becausethesteeringwheelsaremountedinthefront,pullingofthepallettruckispreferred
abovepushingit.
‐ Whentheliftingmechanismisnotused,thehandleshouldbekeptintheneutral,middle,
position.Thisprolongsthelifespanofthesealings.
‐ TheweighingsystemmeetsuptotheprotectionclassIP65.Thismeansthatdustormoisture
(rainorwaterbeamfromallsides),willnotinfluencetheoperationoftheelectronics.
However,high‐pressurecleansingincombinationwithwarmwaterorchemicalcleanserswill
leadtotheentryofmoistureandthereforenegativelyinfluencetheoperationofthesystem.
Incaseofastainlesssteelchassisyoushouldneveruseadetergentthatcontainschloride,
otherwiseyouwillgetbrownspotsonthechassis.
‐ Onlyspecialistsmayundertakeanywelding.Thisistoavoiddamagetoelectronicsandload
cells.
‐ Thebearingsofthewheels(non‐polyurethane)andthepivotingpointsofthelevellingbarof
theloadingwheelsmustbecleansedandgreasedregularly.


1.4.MobileWeighingsystem

Amobileweighingsystemisamobilescale.Thismeansthattheownershouldconsiderthesame
maintenanceasapplicablewithstandardstationaryscales.

Ayearlyinspection,byanauthorizedserviceprovider,isrecommended.Andincasethescaleis
stamped‘legalfortrade’thentheweighingsystemshouldbere‐stampedinaccordancewiththe
metrologicalregulationsinthecountryofuse.

WhenyourcompanyisISOcertificated,itisverylikelythatallmeasuringdevicesshouldbe
checkedmoreregularlythanonceayear(i.e.½yearor¼year).Foraneasyoverviewyoucanfill
outthefollowingmaintenancesheet.

DATEOFINSPECTIONCOMPANYTECHNICIANSIGNATURE










Basedontheserecommendationsweareconvincedthatyourmobileweighingsystemwillwork
accuratelyandreliablyforaverylongtime.

‐7‐
2.Touchpanelindicator



Frontindicator


Thedisplay
Bymeansofthreepointerbarsthedisplayshows:

◄theweighingsystem(includingload)isstable

▬theweightshownisnegative

NET◄thedisplayshowsthenetweight



Thedisplayindications
Theminussignlightsinthedisplay.Thefollowingindicationscanbeshowninthedisplay:

HELP1Theweighingsystemhasbeenoverloaded.
HELP2Taringofnegativeweight.
HELP3NegativesignalfromtheloadcellonADconverter/tiltedposition.
HELP4Thetarevalueentered(manually)istoohigh.PresskeyPTagaintodelete
thishelpmessageandkeyinalowertarevalue.
HELP5Totallingmemoryfull.
HELP6NoBluetoothconnection(onlyRF‐systems).
HELP7SignalfromtheloadcellonADconverteristoohigh.
HELP8Tiltedposition(onlyRF‐systems).
HELP9Lowbatontransmitter(onlyRF‐systems).
LO‐BAor

Thebatteryvoltagelevel(indicator)isrunninglow.Thebatteryhastobe
charged.

‐8‐
Thetouchpanel 
Eachkeyhasanoperationalandanentryfunction.


Operational
function
Entryfunction
 


zerosettingand
automatictare

confirmand
digittotheleft


tareentry

decreasingflashingdigit


totalising

increasingflashingdigit


on/off

clear


Important
Operationofakeyisnotacceptedunlesstheweighingsystemisstable(andthesign“loadstable”
lightsup).Thismeansthattheindicatoronlyexecutescommandswithastableload.


Warning
Whentheweighedloadsurpassesthepre‐setmaximum,thedisplayshows:“HELP1”.Inorderto
preventdamagetotheindicatororloadcells,theweighingsystemmustbeunloaded
immediately.


Tiltedposition 
Withtheapprovedversionoftheweighingsystem,thehelpdisplayshowssmallbarswhenthis
systemisinatiltedpositionlargerthan2°.Inthiscase,theweighingsystemmustbeplacedina
horizontalposition.Afterthis,thesystemcontinuesexecutinganycommands.

‐9‐
3.Functionsindicator


3.1.Graduation

Thegraduationoftheindicatordependsontheweighedload:
from40to2000kgtheweightisshownin2kgsteps,or
from20to2000kgtheweightisshownin1kgsteps


3.2.Beforeweighing:checkzeropoint

Beforeeachweighingitisnecessarytocheckwhetherthesystemisunloadedandfree.The
indicatorisfittedwithanautomaticzerocorrection.Thismeansthatsmalldeviationsofthezero
pointwillbecorrectedautomatically.Iftheindicatordoesnotdeterminethezeropoint
automatically,itmustbedonemanuallyusingthe  0/T  key.


3.3.Grossweighing

Afterliftingaload,thedisplayshowsthegrossvalueoftheweighedload.


3.4.Netweighing:automatictare

Theindicatoroffersthepossibilitytoresettareweightstozeroautomatically.Thiswayaddedor
subtractedweightscanbedetermined.Aftertaring,thedisplaycontinuesinthesmalleststep.

 Liftload.
 Presskey  0/T  .

 Theindicatorissettozero.
  The"NET"pointershowsthatatareweightisactivated.
 Placeorremovethenetload.
  Thedisplayshowsthenetvalueoftheweighedload.
  Whenremovingload,thisisanegativevalue.
 Byexecutingazerosettinginunloadedposition,thesystemwillreturntothestandard
weighingmode.





3.5.Netweighing:manualtareentry

‐10‐

Atareweightcanbeenteredatanymoment,meaningineitheraloadedorunloadedsituation.
Forahigheraccuracy,atareweightcanbeenteredwithasmallergraduationstep,independent
oftheappliedloadandtheactivegraduationoftheindicator.

Atareweightlargerthantheso‐calledMAX1oftheweighingsystemwillnotbeacceptedbythe
indicator.TheMAX1isthevalueoftheweightofthefirstrange;inthestandardversion200kg
(see3.1.).Ifalargerweightiskeyedin,thedisplayshows:“HELP4”.UponpressingkeyPT,this
HELPindicationdisappears.

 PressthePTkey.
 Thedisplayshowsthecurrenttarevalue.
 Thedigitontherightflashes.
 PressENTER(  )forthreesecondsifthecurrenttarevalueisrequired.
Or
 PressthePTkey.
 Pressthekeytogoupavalueorpressthekeytogodownavalueuntiltherequiredvalue
isreached.
 PressENTER(  )tochangethenextvalue.
 Repeatthisprocedureuntiltherequiredtarevalueisdisplayed.

 Toactivatethetareweight,butwithoutstorageinthememory:pressENTER(  )forthree
seconds.
 Thetareweightisactivated.
 The“NET”pointerlightsup.
 Whenthesystemisloadedatthismoment,thenetvalueappearsinthedisplay.
 Whenthesystemisunloaded,theread‐outdisplaysthegiventarevaluenegatively.
 Thekeyedinvalueremainsactiveuntilthesystemisturnedoff,anewtareweightis
entered,anewloadistared(see3.4.)orbyresettingthetarevaluetozero:
 Theweighingsystemisloaded:pressthePTkeyfortwoseconds.Thetarevalueisset
tozeroandthesystemreturnstothestandardweighingmode.
Or
 Theweighingsystemisunloaded:pressthe  0/T  key.Thetarevalueissettozeroand
thesystemreturnstothestandardweighingmode.

 Toactivatethetareweightandstoreitinmemory:gothroughallthedigitsbypressing
ENTER(  ).
 Thetareweightisactivatedandstoredinthememory.
 The“NET”pointerlightsup.
 Whenthesystemisloadedatthismoment,thenetvalueappearsinthedisplay.
 Whenthesystemisnotloaded,thetarevalueinputisdisplayednegatively.
 Thekeyedinvalueremainsactive,evenifthesystemisturnedoff,untilanewtareweight
isentered,anewloadistared(see3.4.)orbyresettingthetarevaluetozero:
