Chapter 1
Introduction
The Raymar-Telenetics RMX is a 2-slot 1U modem rack chassis. It measures 17 inches wide by
1.75 inches high and 8.5 inches deep, and mounts in a standard
19- or 23-inch rack.
The RMX comes in AC and DC configurations with optional redundant power. This guide covers both
versions.
Overview
The Raymar-Telenetics RMX has slots that accept two of the following:
Modems
Digital Data Service (DDS) units
All of these devices are plug-in printed circuit (PC) cards that slide into the front of the RMX. The
cards can be mixed in any way within the RMX. Each card has been independently tested and meets
Part 68, FCC rules and regulations.
Power, Data Terminal Equipment (DTE), and communication-line connections are made at the back
panel of the RMX. This allows PC cards to be installed or replaced, without disturbing the cable
connections at the back of the enclosure.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 2 of 14

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 3 of 14
Back Panel Interface Connectors
All DTE, Telco and power connections are made at the back panel of the RMX.
The DTE connectors are:
Individual 25-pin connectors one for each PC card (standard)
The Telco connectors are:
Individual 8-pin modular jacks one or two for each PC card (standard)
Telephone Line Interfaces
The RMX is FCC certified for connection to the dial-up Public Switched Telephone Network (PSTN).
The following sections describe the standard and optional ways for connecting to the
communications line.
Modular Jack Connectors
The standard RMX back panel has an 8-pin modular jack for each modem. These jacks provide the
interface for connecting individual modems to the telephone line. Each 8-pin jack has contacts that
are used in various combinations depending on the type of service installed. Leased-line modems,
by comparison, have four contacts: a transmit pair and a receive pair.
For a description of the modular jack functions, refer to appendix B.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 4 of 14
Contact Information
For more information about Raymar-Telenetics RMX, or other Raymar-Telenetics solutions, contact
us using any of the following methods.
Voice Calls
We welcome your calls at [phone]
Monday through Friday, from 7:00 am to
5:00 pm Pacific Time.
Fax Number
You can also send your requests for information
to our 24-hour fax number: [phone].
E-mail
If you prefer, you can send information
requests to our 24-hour e-mail address:
[e-mail].
Website
Our website contains valuable information about
our products. We encourage you to visit us
online at www.Raymar-telenetics.com.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 5 of 14
Chapter 2
Installation
This chapter describes how to install the RMX.
Unpacking and Inspecting the Equipment
Unpack the equipment and inspect it for any damage that may have occurred in shipment. If you see
any damage or if items are missing, contact Raymar-Telenetics. Keep the shipping container and
packing material for future shipment.
Site Preparation
When selecting a location to install the RMX, choose a site that:
Is clean, well lit, and free from extremes of temperature, humidity, appreciable shock, and
vibration.
Is within seven feet of a power source that can furnish 90-265VAC/DC or 24-53VDC at 3.5 amps.
Is within 50 feet of the associated data terminal.
Provides at least 36 inches of clearance at the front for operating and maintenance accessibility.
Provides at least 4 inches at the back of the enclosure for interface cable clearance and
unobstructed airflow.
Side and top clearances for rack-mounted equipment are dictated by the rack-cabinet provisions,
but should allow a free flow of cooling air.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 6 of 14
Installation Procedures
Service personnel should be familiar with the complete installation procedure before installing the
RMX.
Required Tools and Equipment
Special tools or test equipment are not required for installation.
CAUTION: To prevent damage to enclosure components from overheating, ensure clearances of 1
¾-inch top and bottom between mounted enclosures. Make adequate provision for cool air circulation
and exhaust of warm air, and an adequate CFM exhaust fan in the top panel of the Data Rack.
Mechanical Assembly
The RMX mounts into a standard 19-inch cabinet and requires 2 inches of vertical panel space.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 7 of 14
Chapter 3
Operation
The RMX accepts leased line, PSTN, and DDS-type modems. Leased-line modems operate on
conditioned or unconditioned leased lines. PSTN-type modems operate on the dial-up network and
have features that allow establishment of dial-up circuits and data transfer. Some modems can
operate on either leased lines or PSTN.
Modems designed for use in the RMX have a standardized interface (EIA-232C) that provides for
orderly calling, answering, and data modes. Many of the modems also have automatic dialing and
answering capabilities.
Test Modes
Each plug-in modem card has a switch or switches that provide for modem testing. Test features are
described in the manual for the modem.
Front Panel Indicators
Two LEDS’s on the front of the chassis represent the power supply status.
Most modems have LED’s mounted on the front edge of the card to indicate the status of various
EIA-232 interface functions. The LED’s are described in the manual for the modem.
Some PC cards have a Liquid Crystal Display (LCD) for observing modem status or selecting options
using pushbuttons on the modem front panel. The LCD functions are explained in the manual for the
modem.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 8 of 14
Chapter 4
Maintenance
This appendix provides maintenance information for PC cards and power modules.
PC Cards
If a PC card becomes inoperative, replace it. Field repair is not recommended. Contact Raymar-
Telenetics for instructions on repairs and replacement (see “Contact Information” on page 12).
When swapping out PC cards, you do not have to turn off system power. This allows PC cards to be
changed while allowing all other PC cards to continue operation.
Power Module
The power modules have no serviceable components. Field repair is not recommended. Contact
Raymar-Telenetics for instructions on replacement.
.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 9 of 14
Appendix A
Specifications
EIA Standard:
Compliant with EIA Standard EIA-310-C
Width:
19 inches (48.3 cm)
Depth:
8.5 inches (21.6 cm)
Height:
1.75 inches (4.4 cm)
Weight:
6 lbs (2.72 Kg) shipped
AC Power
(RMX-2 AC):
Input voltage 90-265 VAC
50/60 Hz
Wattage
150 watts per rack
DC Power
(RMX-2 DC):
Input Voltage 24-53 VDC / 90-265 VDC**
Heat Load
510 BTU/Hr (fully loaded rack).
Environmental
Conditions
Temperature (+40ºF to 185ºF) (-40C to +85C)
** Redundant Power Option Available

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 10 of 14
NOTES

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 11 of 14
Appendix B
Telephone/Power Line Cables
Figure D-1 lists the functions of the modular jacks on the back panel of the RMX.
Figure D-2 lists the function of the modular jacks on the back panel of RMX-R redundant power supply model.
NOTE: This figure is for illustrative purposes only. Actual units will have either the DSP9612/MOT202T Rear Panel OR the
V.3600 Rear Panel. Power connectors vary depending on the model. See Figure D-2.
Figure D-1.
Figure D-2.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 12 of 14
RS-232 (DTE) Interface
DB25 Pin
Signal Name
Modem Input / Output
Description
1
GND
—
Earth Ground
2
TD
Input
Transmit Data
3
RD
Output
Receive Data
4
RTS
Input
Request to Send
5
CTS
Output
Clear to Send
6
DSR
Output
Data Set Ready
(Modem Ready)
7
SG
—
Signal Ground
8
DCD
Output
Data Carrier Detected
15
TXCLK
Output
Transmit Clock (DCE)
17
RXCLK
Output
Receive clock
20
DTR
Input
Data Terminal Ready

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 13 of 14
FCC Requirements
This equipment complies with FCC Rules, Part 68. Located on the equipment are the FCC Registration Number and Ringer
Equivalence Number (REN). You must provide this information to the telephone company if requested.
The Registration number and REN will be inscribed on the printed circuit board on insert cards or on a label attached to either
the chassis bottom or metal end plate on standalone or rack models. In any case, the FCC requires these numbers to be
prominently displayed on an outside surface of the equipment.
The REN is used to determine the number of devices you may legally connect to your telephone line. In most areas, the sum
of the REN of all devices connected to one line must not exceed five (5.0). You should contact your telephone company to
determine the maximum REN for your calling area.
The telephone company may change technical operations or procedures affecting your equipment. You will be notified of
changes in advance to give you ample time to maintain uninterrupted telephone service.
If you experience trouble with this telephone equipment, please contact:
Raymar-Telenetics
7325 Roseville Road
Sacramento, California 95842
Tel: [phone]
Fax: [phone]
[email protected]
The telephone company may ask that you disconnect this equipment from the network until the problem has been resolved. If
your equipment continues to disrupt the network, the telephone company may temporarily disconnect service. If this occurs,
you will be informed of your right to file a complaint with the FCC.
This equipment may not be used on coin services provided by the telephone company. Connection to party lines is subject to
state tariffs.
WARNING: This equipment uses, generates, and can radiate radio-frequency energy, interfering with radio communications,
if not installed and used according to the instruction manual. It has been tested and complies with the limits for a Class A
computer device, according to FCC Rules, Part 15. Operation of this equipment in a residential area may cause interference.
If it does, you must correct the cause of the interference.
Changes or modifications to this unit are not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 14 of 14
Raymar Information Technology, Inc.
Limited Warranty
One Year Limited Hardware Warranty
Raymar Information Technology, Inc., dba Raymar-Telenetics, warrants their products against defects in hardware, material and workmanship under normal
use for one (1) year from the date of purchase. Raymar will, at no charge, either repair the product (with new or reconditioned parts), or replace it (with a
new or reconditioned product). Repaired replacement products are warranted for either 90 days or the remainder of the original warranty period, whichever
is longer. This warranty extends to the original end-user only.
What This Warranty Does Not Cover
This warranty does not cover: (a) software; (b) installation or service of the product; (c) conditions resulting from consumer damage such as improper
maintenance or misuse, abuse, accident or alteration; (d) all plastic surfaces (including display screens) and all other exposed parts that are scratched or
damaged due to normal use; (e) operation of our products with equipment not supplied by Raymar (f) products which have had the serial number removed
or made illegible; or (g) products rented to others. This warranty applies only to hardware products manufactured by or for Raymar Information Technology,
Inc. and identified by the Raymar-Telenetics trademark, trade name or product identification logo affixed to them. Refer to the Service and Support section
of the User’s Guide for service after the warranty expires. No warranty is made as to coverage availability or grade of service provided by the carrier.
General Provisions
This warranty sets forth Raymar’s entire hardware responsibilities regarding this product. Repair, replacement or refund of the purchase price is at Raymar’s
discretion. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES, IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL RAYMAR BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE
PRICE OF THE PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS, LOST PROFITS OR SAVINGS,
OR OTHER INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THIS RAYMAR
PRODUCT, TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW. WITHOUT LIMITING THE FOREGOING, RAYMAR SHALL HAVE
NO LIABILITY FOR ANY DATA STORED IN OR USED WITH THE PRODUCT, INCLUDING THE RECOVERY COSTS OF SUCH DATA OR
PROGRAMS.
State Law Rights
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS. THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. This warranty
gives you specific legal rights, and you may also have other rights which vary from State to State.
Provincial Law Rights
SOME PROVINCIAL LAWS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES, THE
EXCLUSION OR LIMITATION OF WARRANTY COVERAGE IN CERTAIN SITUATIONS. SOME OF THE ABOVE
LIMITATIONS OR EXCLUSIONS CONTAINED IN THIS LIMITED WARRANTY MAY NOT APPLY TO YOU. This warranty gives you specific rights,
and you may have other rights which vary from province to province.
How To Use Raymar’s Limited Warranty Service
To take advantage of this warranty, you must do the following:
• If you are having trouble with your product, contact Raymar service using the appropriate number from the Service and Support
section of the User’s Guide. If it is determined that your product requires service, you will be issued a Return Materials
Authorization (RMA) form.
• Pack the defective product securely for shipping. Include only the units pre-approved by service on your RMA form.
• This warranty is void if the product is damaged in transit, you must insure your shipment.
• Ship the defective product, proof of date of purchase, and the RMA form to the address specified.
• Display your RMA number prominently on the outside of the shipping box. Customer is responsible for freight in, door to door. Raymar is responsible for
return shipping costs.
• To ensure prompt service, please write on the RMA form a brief description of the problem you are experiencing with the
product.
Raymar Information Technology, Inc.
7325 Roseville Road
Sacramento, CA 95842
Service Hotline [phone]
http://www.raymar.telenetics.com or e-mail to [email protected]

0049-1650-001 RMX –USER GUIDE 1/02/2014
Rev. E Page 15 of 14
Raymar Information Technology, Inc.
Return Merchandise Authorization (RMA) Procedure
Before returning any Raymar-Telenetics product, an RMA number must be obtained.
The most convenient way to obtain an RMA number for a product purchased from Raymar-Telenetics is
to call 1-800-747-1522 ([phone]). When doing so, please have the following information
ready:
- Company name
- Full billing address, as well as the address for the location where the product should be returned
once repaired or replaced
- Telephone & Fax numbers
- Email address
- Product model number and serial number
For each item being returned, please include the product model number, the serial number, a description
of the problem being encountered, and the cause of the problem (if known).
Please note that prior to authorizing a return, a product support specialist may call to verify that the
product is properly installed or may ask you to perform tests to insure that the product has actually
failed.
The product must be properly packed and returned to:
Raymar-Telenetics
7325 Roseville Road
Sacramento, CA 95842
The RMA number must be legibly displayed on the shipping carton. Raymar-Telenetics will not be
responsible for any product returned without an RMA number.
If the product is out of warranty, estimates for repair rates and any applicable shipping costs will be
communicated by a customer service representative. Currently, Raymar-Telenetics accepts purchase
orders or credit cards as payment methods.
Repairs currently require 5 –10 business days and are returned via UPS Ground.
