Raymarine
45STV Sa tellite
Te le v ision System
User's Guide
RaymarineSatelliteTVSystemsUser’sGuide

Trademarksandregisteredtrademarks
Autohelm,HSB,RayTechNavigator,SailPilot,SeaT alkandSportpilotareUKregisteredtrademarksofRaymarineUKLimited.Pathnder
andRaymarineareUKregisteredtrademarksofRaymarineHoldingsLimited.45STV,60STV,AST ,Autoadapt,AutoGST ,AutoSeastate,
AutoTrim,Bidata,GSeries,HDFI,LifeT ag,MarineIntelligence,Maxiview,OnBoard,Raychart,Raynav,Raypilot,RayT alk,Raystar,ST40,
ST60+,Seaclutter,SmartRoute,Tridata,UniControlandWaypointNavigationaretrademarksofRaymarineUKLimited.
Allotherproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
Copyright©2009RaymarineUKLtd.Allrightsreserved.
ENGLISH
Documentnumber:81319–4
Date:June2009

Contents
Chapter1Introduction...............................................7
Safetynotices...................................................................7
Importantinformation........................................................7
Chapter2Installation...............................................11
2.1Preparation...............................................................12
2.2Procedures...............................................................18
Chapter3Systemoperation&setup......................25
3.1Introduction...............................................................26
3.2Gettingstarted..........................................................27
3.3SetupusingtheACU.................................................28
3.4Applyingfactorydefaultvalues...................................36
3.5Gettingsysteminformation........................................37
3.6Checkingsystempower.............................................37
3.7Settingtheskewangle..............................................38
3.8UsingtheGraphicalUserInterface.............................39
Chapter4Maintenance&troubleshooting............41
4.1Maintenance.............................................................42
4.2Troubleshooting........................................................42
4.3Raymarinetechnicalsupport......................................44
Chapter5Satelliteinformation...............................45
5.1Introduction...............................................................46
5.2Satellitecoverage.....................................................46
5.3Satelliteproviders.....................................................55
5.4Satellitetrackingdata................................................57
Chapter6TechnicalSpecication..........................61
6.1T echnicalSpecication..............................................62
5

6RaymarineSatelliteTVSystemsUser’sGuide

Chapter1:Introduction
Safetynotices
Warning:Productinstallationand
operation
Thisproductmustbeinstalledandoperatedin
accordancewiththeRaymarineinstructionsprovided.
Failuretodosocouldresultinpersonalinjury,damage
toyourboatand/orpoorproductperformance.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethepower
sourceisadequatelyprotectedbymeansofa
suitably-ratedfuseorautomaticcircuitbreaker.
Caution:Usecorrectliftingpoint
Whenliftingtheantennaunit,alwaysliftfromthe
baseplate.DoNOTusetheantennacoveror
damagetothecovercouldoccur.
Caution:Donotdamageconnectors
Takecaretoavoiddamagetotheconnectors
underneaththeantennabaseplatewhenmoving
theunit.DoNOTusetheseconnectorstoliftthe
unit.
Caution:Removetransitpacking
Beforeinstallingoroperatingtheproduct,open
theantennaunitcoverandremovethefoam
transitpackinginsertsfromtheunitbase.
Caution:Antennacoating
DoNOTpaintorapplyanyothernishtothe
antennaunit.Thiscoulddegradeperformance
beyondacceptablelimits.
Importantinformation
Overview
D1
1563-1
Thishandbookdescribeshowtoinstall,connectandmaintainthe
Mark2Raymarine45SatelliteTelevision(45STV)system.
Your45STVsystemprovidesuninterruptedtelevisionaccessto
hundredsofTVchannelsinalltypesofweatherconditions.
Introduction7

Ontheopenseaoratthedock,theRaymarineSatelliteTVsystem
automaticallyidenties,acquiresandtrackscompatiblesignalsfrom
alldigitalvideobroadcast(DVB)satellites.
Pleasecarefullyreadandfollowtheinstallation,operatingand
maintenanceprocedures,toensureoptimumperformance.
IntendedUse
YourSTVsystemisintendedforuseaboardleisuremarineboats
andworkboatsnotcoveredbyInternationalMaritimeOrganization
(IMO)carriageregulations.ItisNOTintendedforinstallationor
useinanyothersituation.
Geographiclocation
TheSTVSystemwillreceivesignalsfromselectedsatellitesinthe
followingareas:
•NorthAmerica
•SouthAmerica
•Europe
•Australia
•NewZealand
•China
•MiddleEast
Ifyouchangeyourareaofoperation,youmayneedtochangesome
settingsonyourSTVsystem:
•SatelliteTVistransmittedwithsignalsthatareeitherlinearlyor
circularlypolarized.Youcannotreceivesignalsthathavelinear
polarizationonasystemthatissetupforcircularpolarization,
orcircularpolarizedsignalsonasystemthatissetupforlinear
polarizedsignals.
•Ifyourgeographiclocationchanges,youmayneedto:
–Adjusttheantennalownoiseblock(LNB)asappropriateforthe
areainwhichyouareoperating.
–Changeyourcontrolboard,ACUsoftwareandsatellite
receivers(IRDs).
Forfulldetailsofchangingyourgeographicareaofoperation,
contactRaymarineProductSupport.
Televisionreception
ForfullfunctionalityofyourSTVSystem,youmustsubscribetothe
relevantservice(s)fromtheappropriateserviceprovider(s).Full
detailsofserviceprovidersaregiven.
EMCconformance
Raymarineequipmentandaccessoriesconformtotheappropriate
ElectromagneticCompatibility(EMC)regulationsforuseinthe
recreationalmarineenvironment.
CorrectinstallationisrequiredtoensurethatEMCperformanceis
notcompromised.
Declarationofconformity
ThisproductconformswithEUDirective2004/108/ECandis
labelledwiththeCEconformitymark.
Productdisposal
DisposeofthisproductinaccordancewiththeWEEEDirective.
TheWasteElectricalandElectronicEquipment(WEEE)
Directiverequirestherecyclingofwasteelectricalandelectronic
8RaymarineSatelliteTVSystemsUser’sGuide

equipment.WhilsttheWEEEDirectivedoesnotapplytosome
Raymarineproducts,wesupportitspolicyandaskyoutobeaware
ofhowtodisposeofthisproduct.
Warrantyregistration
ToregisteryourRaymarineproductownership,pleasetakeafew
minutestolloutthewarrantyregistrationcardfoundinthebox,or
visitwww.raymarine.comandregisteron-line.
Itisimportantthatyouregisteryourproducttoreceivefullwarranty
benets.Yourunitpackageincludesabarcodelabelindicatingthe
serialnumberoftheunit.Youshouldstickthislabeltothewarranty
registrationcard.
Technicalaccuracy
Tothebestofourknowledge,theinformationinthisdocumentwas
correctatthetimeitwasproduced.However,Raymarinecannot
acceptliabilityforanyinaccuraciesoromissionsitmaycontain.In
addition,ourpolicyofcontinuousproductimprovementmaychange
specicationswithoutnotice.Asaresult,Raymarinecannotaccept
liabilityforanydifferencesbetweentheproductandthisdocument.
Introduction9

10RaymarineSatelliteTVSystemsUser’sGuide

Chapter2:Installation
Chaptercontents
•2.1Preparationonpage12
•2.2Proceduresonpage18
Installation11

2.1Preparation
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformtotheappropriate
ElectromagneticCompatibility(EMC)regulations,tominimize
electromagneticinterferencebetweenequipmentandminimizethe
effectsuchinterferencecouldhaveontheperformanceofyour
system
CorrectinstallationisrequiredtoensurethatEMCperformanceis
notcompromised.
ForoptimumEMCperformancewerecommendthatwherever
possible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingorcables
carryingradiosignalse.g.VHFradios,cablesandantennas.
InthecaseofSSBradios,thedistanceshouldbeincreased
to7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.Aradar
beamcannormallybeassumedtospread20degreesabove
andbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatused
forenginestart.Thisisimportanttopreventerraticbehavior
anddatalosswhichcanoccuriftheenginestartdoesnothave
aseparatebattery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedin
theinstallationmanual.
Note:Whereconstraintsontheinstallationpreventanyof
theaboverecommendations,alwaysensurethemaximum
possibleseparationbetweendifferentitemsofelectrical
equipment,toprovidethebestconditionsforEMCperformance
throughouttheinstallation
Suppressionferrites
Raymarinecablesmaybettedwithsuppressionferrites.These
areimportantforcorrectEMCperformance.Ifaferritehastobe
removedforanypurpose(e.g.installationormaintenance),itmust
bereplacedintheoriginalpositionbeforetheproductisused.
Useonlyferritesofthecorrecttype,suppliedbyRaymarine
authorizeddealers.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables
IfyourRaymarineequipmentistobeconnectedtootherequipment
usingacablenotsuppliedbyRaymarine,asuppressionferrite
MUSTalwaysbeattachedtothecableneartheRaymarineunit.
Partssupplied
Thefollowingpartsareprovidedfora45STVsystem:
•AntennaUnit
•AntennaControlUnit(ACU)
•InstallationKitcomprising:
–Bolts
–Flatwashers
–Springwashers
–Selftappingscrews
•Cablesasfollows:
12RaymarineSatelliteTVSystemsUser’sGuide

–R08133-10mPowercable-usedforconnectingtheACUto
theDCpowersupply.(45STVmodelsonly).
–R08257-3mRFcable-usedforconnectingtheACUand
IntegratedReceiverDecoder(IRD)
–R08135-15mRFcable-usedforconnectingtheAntenna
andACU.
–R08138-1.8mPCcable-usedforconnectingtheACUtoa
personalcomputerforsystemsetupanddiagnostics.
•CDROM-contains:
–SoftwareforrunningtheSTVGraphicalUserInterface(GUI)
onapersonalcomputer(PC).
–Productusermanual,asPDF.
Toolsrequired
Toolsnecessaryforinstallation.
Power drill
13 mm (1/2 in)
socket
10 mm (3/8 in)
drill
13 mm (1/2in)
spanner 11 mm (7/16in)
spanner
Socket wrench
80 mm (3 in)
hole saw
Pencil
Adhesive tape
Cross-head
screwdriver
5 mm
Allen key
Suitable waterproof
sealant
D11453-1
Installation13

Planningtheinstallation
AntennaUnit
RF 2RF 1
RF 2
RF 1
RF 4RF 3
Base plate
connector detail
North America &Asia Rest of the world
Antenna Unit
TheAntennaUnitcomprisestheantennadish,positioning
mechanism,lownoiseblock(LNB),powersupplyandcontrol
elementsinamoldedradome.
Connectorsontheundersideofthebaseplateconnectthepower,
signalandcontrolcablingfromthebelowdecksunits.
Forconnectiondetails,refertotheinstallationprocedures.
AntennaControlUnit(ACU)
TheAntennaControlUnit(ACU)providesallcontroland
power-switchingfunctionsfortheantenna.Threesoftkeysenable
satelliteprogrammingandantennadiagnosticstobecarriedout.
D11531-1
Twobuttonsattheright-handsideofthefrontpanelareusedwith
somesetupprocedurestoprovideBACKandENTERfunctions.
TheACUrearconnectorsare:
•DC9to30Vforpowerinput.
•ANTRF1-connectspowerandsignaltotheantenna.
•NMEA-connectstoGPS(optional).
•PCINTERFACE-connectstoPCserialportforremoteoperation
fromacomputer(optional).
•RECEIVER-connectstothesatellitereceiver(notsupplied).
ANTRF1
FUSEDC 9 to 30V NMEA PC INTERFACE
RECEIVER
-
+
-+
MADE IN KOREA
D11542-2
Forconnectiondetails,refertotheinstallationprocedures.
14RaymarineSatelliteTVSystemsUser’sGuide

Antennaposition
Clear view of sky
D11449-1
Theantenna,mustbeinstalledwhere:
•Thereisanallroundclearviewofthehorizon.
•Itisnottoohighabovethewater-themaximumrecommended
heightisonenotexceedinghalfthelengthoftheboat.
•Itisasnearaspossibletothecenterlineoftheboat.
•Onarigidmountingplatformthatisnotsubjecttoexcessive
vibration.
•Awayfromtheedgeoftheboat.Thiswillminimizeexcessive
motion,whichcanadverselyaffectreception.
•Clearofanyradarbeam.Thiscouldadverselyaffectantenna
operation.
Above the beam
Below the beam
In the
beam
Min 1.2 m (4 ft)
Min 1.2 m (4 ft)
D7950_1
•Clearofanyobjectwhichcouldblockthesatellitesignal.Ensure
thereisa+15°to+90°lookangleattheintendedinstallation
position.
+15
90 0
0
Mast
Blocked!
D7951_1
ACUinstallation
TheACUmustbettedbelowdecksinapositionthatis:
•Dry.
•Wellventilated.
•Easilyaccessible.
•NeartothemainTVviewingarea.
Installation15

ACUdimensions
228 mm (9.0 in)55 mm
(2.2 in)
185 mm (7.3 in)
D11550-1
217 mm (8.5 in)
178 mm (7.0 in)
Routingcables
Cablesmustberoutedcorrectly,tomaximizeperformanceand
prolongcablelife.
•DoNOTbendcablesexcessively.Whereverpossible,ensurea
minimumbendradiusof100mm.
Minimum bend of cable
100 mm (4 in) radius
Minimum bend
200 mm (8 in)
diameter
•Protectallcablesfromphysicaldamageandexposuretoheat.
Usetrunkingorconduitwherepossible.DoNOTruncables
throughbilgesordoorways,orclosetomovingorhotobjects.
•Securecablesinplaceusingtie-wrapsorlacingtwine.Coilany
extracableandtieitoutoftheway.
•Whereacablepassesthroughanexposedbulkheadordeckhead,
useasuitablewatertightfeed-through.
•DoNOTruncablesneartoenginesoruorescentlights.
Alwaysroutedatacablesasfarawayaspossiblefrom:
•otherequipmentandcables,
•highcurrentcarryingacanddcpowerlines,
•antennae.
PowerRequirements
ARaymarine45STVsystemneedseithera12Vdcor24Vdc
powersupply.
IftheIRD(s)andtelevision(s)requirea220/240Vacpowersupply,
asuitabledc-to-actoconvertermustbetted,toprovidethe
necessarypowerfromtheboat’sdcpowersupply.
Grounding
TheserequirementsapplywhengroundingRaymarineequipment.
16RaymarineSatelliteTVSystemsUser’sGuide

Requirement
Theproductpowercabledrainconductor(screen)mustbe
connectedtoacommongroundpoint.
Commongroundpoint
Itisrecommendedthatthecommongroundpointisabonded
ground,i.e.withthegroundpointconnectedtobatterynegative,
andsituatedascloseaspossibletothebatterynegativeterminal.If
abondedgroundsystemisnotpossible,anon-bondedRFground
maybeused.
Drain
(screen)
Power cable
to product Battery
Bonded ground system
(preferred)
Bonded
ground
point
Drain
(screen)
Power cable
to product Battery
RF ground system
(alternative)
Non-bonded
ground
point
D11703-1
Implementation
Ifseveralitemsrequiregrounding,theymayrstbeconnected
toasinglelocalpoint(e.g.withinaswitchpanel),withthispoint
connectedviaasingle,appropriately-ratedconductor,totheboat’s
commonground.Thepreferredminimumrequirementforthepath
toground(bondedornon-bonded)isviaaattinnedcopperbraid,
witha30Arating(1/4inch)orgreater.Ifthisisnotpossible,an
equivalentstrandedwireconductormaybeused,ratedasfollows:
•forrunsof<ftuse#10AWG(6mm2)orgreater.
•forrunsof>ftuse#8AWG(8mm2)orgreater
Inanygroundingsystem,alwayskeepthelengthofconnecting
braidorwiresasshortaspossible.
Important:DoNOTconnectthisproducttoapositively-grounded
powersystem.
References
ISO10133/13297
BMEAcodeofpractice
NMEA0400
Extendingcableruns
IftheRFcablesuppliedasstandardisnotlongenough,a
98ft(30m)cable,isavailablefromyourRaymarinedealer,
asPartNumberE96008.Youcanconnectthelongercabletothe
suppliedRFcabletoobtainatotalcablelengthof147ft(45m).
Note:Donotattempttouseatotalcablelengthgreaterthan
147ft(45m),asthiscouldcausereducedperformance.
Installation17

2.2Procedures
Installingtheantenna
Theproceduresforinstallingtheantennaassemblycomprise:
•Preparation-removetransitpacking.
•Procedure-preparemountandtantenna.
Preparation
1.Removeandretaintheboltsandwasherssecuringtheantenna
dome.
2.Removetheantennadomeandretaininasafeplace.
Packing
restraint
Packing
restraint
D11564_1
3.Locateandremovethepackingrestraintsfromtheantenna
assembly.
4.Replacetheantennadomeandsecurewiththeboltsretained
atstep1.
Procedure
Preparethemountingsurfacethenttheantenna.
1.Usingadhesivetape,attachthetemplatetothemounting
surface,ensuringthatitisparalleltoyourboat’scenterlineas
markedonthetemplate.
2.Usingasuitableholesaw,removetheshadedcenterportion.
Drillhole
,
10mm(
4
/
10
inch
)
diameterin
4positions
Cuth
ole
,
80mm(3
3
/
20
inch
es)
diameter
228.6mm(9 in
ches)
228.6mm(9 in
ches)
114.3mm(4
1
/
2
inches)
114.3mm
(4
1
/
2
inch
es)
Antenna Base Unit
Templat e
D11451-1
3.Drillfour10mmholesinthepositionsindicated.
Drillhole
,
10mm(
4
/
10
inch
)
diameterin
4positions
Cuth
ole
,
80mm(3
3
/
20
inch
es)
diameter
228.6mm(9 in
ches)
228.6mm(9 in
ches)
114.3mm(4
1
/
2
inches)
114.3mm(4
1
/
2
inch
es)
Antenna Base Unit
T
emplat e
D11452-1
4.Countersinkthemountingholes,thensmooththeedgesofthe
centerholewithasuitablele,toavoiddamagetothemounting
surface.
5.Securetheantennatothebaseusingbolts,springwashersand
atwashers.
D7956_1
6.Tightentheboltstoatorqueof22.1ft.lb(30Nm)toensurethat
thefoamsealingringiscompressedtopreventwateringress.
18RaymarineSatelliteTVSystemsUser’sGuide

InstallingtheACU
UsethetwoxingbracketssuppliedtoinstalltheACU.These
bracketscanbettedtothesidesoftheunittoprovideatopor
bottomx.
Antenna Cont
rol Unit
Antenna Cont
rol Unit
Under shelf mounting
Desk top mounting D11551-1
1.Selecttheinstallationsite,ensuringthattheproposedsitemeets
thecriteriadescribedunderPlanningtheACUinstallation.
2.UsethescrewsfromtheACUtoxthemountingbracketsto
theACU.
3.PlacetheACUinthepositionwhereitisgoingtobeinstalled.
4.Markthe2xingholepositionsforeachmountingbracket,on
themountingsurface.
5.Usingasuitabledrillbit,drillthe4holesinthemarkedpositions.
6.Wherenecessary(forexample,ongel-coatedsurfaces),
countersinkthemountingholestoavoiddamagetothemounting
surface.
7.Usingsuitablescrews,securetheACUintoposition.
Systemoptions
YourRaymarineSatelliteTVsystemcanbeconnectedtooneor
multipleIRDs,toofferthemaximumchoiceofchannelstodifferent
cabins.Thissectiondescribesthedifferentcombinationsavailable
andthemethodofconnectingeachvariant.
EnsurethepowersupplyfortheACUisprotectedbyeithera
5Aquick-blowfuseoranequivalentautomaticcircuitbreaker,
connectedin-lineonthepositive(whitewithredtag)wireof
thepowercable.
Notethatforallvariants,theRF1connectorontheACUmustbe
connectedtotheRF1connectorontheantennabaseplate.
Installation19

Connectingabasicsystem
connects to
Television Monitor
(not supplied)
IRD (not supplied)
ANTRF1
FUSE NMEA PC INTERFACE
RECEIVER
-
+
-+
MADE IN KOREA
RF 2
RF 1
RF 4RF 3
RF cable
Antenna base plate
ACU
DC 9 to30V
12 V or 24 V dc
power supply
D11546-2
Brown with
red sleeve
Blue with
blue sleeve
Green/yellow with
white sleeve
Ground
Drain (screen)
1.ConnectanRFcablefromtheANTRF1connectorontheACU
totheRF1connectorontheantennabaseplate.
2.ConnectanRFcablefromtheRECEIVERconnectoronthe
ACUtoeithertheLNB,ANT,orSatelliteInconnectoronthe
rearoftheIRD.
3.Connecta12Vora24VdcsupplytotheDC9to30Vconnector
ontherearoftheACU.
4.RefertotherelevantManufacturer’shandbookfordetailson
conguringyourIRD.
ConnectingtwoIRDs
to TV monitor (not supplied)
to TV monitor (not supplied)
IRD1 (not supplied)
ANTRF1
FUSE
DC 9 to 30V NMEA PC INTERFACE
RECEIVER
-
+
-+
MADE IN KOREA
RF 2
RF 1
RF 4RF 3
IRD2 (not supplied)
RF cable
Antenna base plate
ACU
Power in
D11547-2
YoucanconnecttwoIRDstoyourantennaasshowninthefollowing
diagram.Inthissystem,oneIRDcanbesetasatwosatellite
receiver.TheotherIRDmustbesetasaonesatellitereceiver.
20RaymarineSatelliteTVSystemsUser’sGuide
