Rayrun T110 User manual

MODE
+
SPEED
-
SPEED
+
MODE
-
25%
Single Color LED Controller
Introduction
1. Power supply input
The controller supply voltage range is from DC 5V to 24V.
Please refer to the print on the controller for cable polarity.
The output voltage is at the same level as the power voltage,
please make sure the power supply voltage is correct and the
power wattage is capable for the load wattage. Please be
noted the positive power cable is directly connected to the
output  cable inside the controller.
Model: T110 (-H)
1
32
Wireless Remote
Overheat Protection
Wide Voltage Range
Memory Function
Ultra Compact
T110 LED controller is designed to drive constant voltage
single color LED products such as LED strip or LED module in
voltage range of DC5-24V. The receiver works with the RF
wireless remote controller, user can setup LED brightness
and dynamic effects from the remote controller.
Receiver & wiring
12
50mm
15mm
38mm
Connect to LED loads. Please refer to the print on the
controller for cable polarity and connect LED load with
2. LED output
according polarity. Please make sure the LED rated voltage is
same as the power supply and the maximum load current is
below the controller rated current.
CAUTION! The controller might be permanently
damaged if output cables short circuit. Please ensure the
cables are well insulated to each other.
To 110/230
AC power
5-24V DC output
Power supply
T110 LED
Controller
5-24V DC
LED Loads
LED Controller
5-24V Driving
3. Wiring diagram
Please connect the controller output to LED loads and
power supply to the controller power input. The output
voltage of power supply must be same as the LED load's
rated voltage. Check all cables to be well connected and
insulated before power on.
Remote
Controller
Remote controller function
4
5
7
6
4. Turn ON / OFF
Press ‘I’ key to turn on controller or press ‘O’ key to turn
off. The controller will memorize the on/off status and will
restore to the previous status on the next power on. Please
use remote controller to turn on the unit if it was switched to
off status before power cut.
5. Brightness adjust
Press ‘+’ and '-' key to adjust brightness sequently or
press the 100%, 50%, 25% and 10% key to jump to specified
brightness level.
* H version picture
Advanced RF Remote

54
6. Dynamic effects
Press and keys to adjust the dynamic effect mode
and press and keys to adjust the effect playing speed.
7. Remote indicator
This indicator blinks when remote controller is working.
If the indicator flashes slowly when pressing keys, it means
the remote battery is used up and please change the battery
in this case. The battery type is CR2032.
Remote controller operation
8. Using the remote controller
Please pull out the battery insulate tape before using.
The RF wireless remote signal can pass through some
nonmetal barrier. For proper receiving remote signal, please
do not install the controller in closed metal parts.
9. Pair a new remote controller
The remote controller and receiver is 1 to 1 paired as
factory default. It’s possible to pair maximum 5 remote
controllers to one receiver and each remote controller could
be paired to any receivers.
To pair a new remote controller, please follow two steps:
1). Plug off the power of receiver and plug in again after
more than 5 seconds.
2). Press and key simultaneously for about 3
seconds, within 10 seconds after the receiver powered on.
After this operation, the LED fixture will flash quickly to
acknowledge that remote pairing is accomplished.
10. Keep one remote and forget others
In some cases, one receiver might be paired with several
remote controllers but extra remote controllers are no
longer needed except current using one. User can simply
pair the current using remote to receiver again, then the
receiver will dis-pair all other remote controllers and
recognize current one only.
Output mode
PWM constant voltage
Working voltage
DC 5-24V
Rated output current
5A
White brightness grade
10 levels
Dynamic effect
8 modes
Dynamic speed grade
10 levels
PWM frequency
1KHz
PWM physical grade
256 steps
Overheat protection
Yes
Remote frequency
433.92MHz
Remote control distance
>15m at open area
Power off memorizing
Yes, restore to previous mode before off.
Housing
Tubed for standard, ABS+Slicon for -H version
Controller dimension
50x15x7mm
Specification
Overheat Protection
The controller has overheat protection feature and it can
protect itself from damage caused by some abnormal usage
such as overloading which generates excess heat. At
overheat situation, the controller will shutdown the output for
a short while and recover when temperature drops to a safe
range.
Please check the output current and make sure it’s under
rated level at this situation.
MODE
MODE

MODE
+
SPEED
-
SPEED
+
MODE
-
25%
简介
RF⽆线遥控
1.电源输⼊
控制器可接受电压为5V到24V的直流电源供电。请按
照控制器上标明的电源极性进⾏连接。控制器的输出电
平与电源输⼊电压相同，请确保LED灯具额定电压与电
源相同，且电源的功率满⾜控制器和灯具的需求。
型号:T110（ -H）
1
32
无线遥控
过热保护
宽压范围
记忆功能
小尺寸
T110单⾊LED控制器⽤来驱动电压范围为5V到
24V的LED灯带或LED模块等恒压LED灯具。⽤⼾可以通
过卡⽚式射频控制器来调节LED灯具的亮度和动态模
式。控制器需要直流电源供电，并根据接收到的遥控器
指令驱动LED灯具，实现亮度和动态模式调节功能。
主机和接线
12
50mm
15mm
38mm
2.LED输出
连接LED灯具。LED灯具必须为恒压型且适⽤于
PWM驱动。请参考控制器上标明的电缆极性，并连接
LED灯具的同极性电缆。请确保LED的额定电压与电源
相同，并且最⼤负载电流低于控制器额定电流。
请注意！如果控制器输出电缆被意外短路，可能将导
致控制器严重损坏，请确保电缆可靠连接并良好绝缘。

接交流电
5-24V
直流电源 T110控制器
5-24V直流
LED恒压灯具
3.接线图解
请将控制器输出与恒压LED灯具相连接，并将控制
器输⼊与电源相连接。电源电压需与LED恒压灯具的额
定电压相同。请在通电前检查所有电缆连接是否正确。
RF遥控器
功能
4
5
7
6
4.开/关
按“I”键开启灯光，按“O”键关闭。控制器会记忆断电
前的开关状态，如果在断电前为关机状态，下次通电后
请使⽤遥控器开灯。
5.亮度调节
调节灯光亮度。按“+”增加亮度，按“-”降低亮度。亮度快
捷键分别有全亮度的100%、50%、25%和10%。
* -H版本图⽚
单⾊LED控制器

54
6.动态模式调节
7.遥控器指⽰灯
按下遥控器按键时，该指⽰灯会快速闪烁。如果指⽰
灯慢闪，则说明遥控器电池电量已耗尽，请更换遥控器
电池（CR2032型纽扣电池）。
操作⽅法
8.使⽤遥控器
使⽤前请拔出遥控器电池绝缘⽚。RF⽆线遥控信号可以
穿过⼀定的⾮⾦属屏障，为了保证控制器的接收效果，请勿
将控制器安装在有⼤⾯积⾦属遮挡的位置。
9.与新遥控器配对
遥控器和控制器出⼚默认为1对1的配对状态。1个控
制器最多可配对5个遥控器，⽽遥控器可配对到任意的
控制器。
如需配对新遥控器，请按以下两个步骤操作：
1）断开控制器电源，并在超过5秒后重新通电。
2）在控制器通电后的10秒内，同时按下新遥控器的
和键约3秒钟
配对成功后，LED灯具将快速闪烁提⽰配对成功。
10.保留当前遥控器并清除其他遥控器
在控制器已与多个遥控器配对，⽽仅想保留当前遥
控器的情况下，可以将正在使⽤的遥控器与控制器再进
⾏⼀次配对操作，此后控制器将清除其他已配对的遥控
器⽽仅保留当前使⽤的遥控器。
输出⽅式
PWM恒压
⼯作电压
DC5-24V
额定输出电流
5A
⽩光亮度可调级数
10级
动态模式
8种
动态速度可调级数
10级
PWM分辨率
4000级
过热保护
有
遥控器⼯作频率
433.92MHz
遥控器⼯作距离
空旷地带>15m
断电记忆功能
有，含开关状态
外壳类型
热缩套管/ABS+硅胶(-H版本)
控制器尺⼨
50x15x7mm
规格
过热保护
按和调节动态模式，按和键调节动态模
式的运⾏速度。
MODE
MODE
本机具有过热保护功能，可防⽌控制器因负载过重
引起异常发热⽽导致损坏。过热保护时控制器将关断输
出，当温度下降到安全范围时，将尝试恢复正常⼯作。过
热保护功能仅能在⼀定程度上防⽌控制器损坏，为确保
安全，请勿将控制器输出过载或短路。
