Raytech Turbo Sonic 2500 User manual

Raytech Industries®
A Division of Lyman Products
475 Smith Street
Middletown, CT 06457
1-800-243-7163
www.raytech-ind.com
Part # 04347R Rev. 03/14
SPECIFICATIONS
Description Digital Ultrasonic Cleaner
Item No. (115V) 7631700
(230V) 7631702
Rating voltage AC 220~240V ~ 50-60 Hz
& Frequency AC 100~120V ~ 50-60 Hz
Consumption Power 160 Watts
170 Watts
Ultrasonic Frequency 42,000 Hz
Material of tank Stainless Steel SUS304
Plastic Housing ABS 757
Tank Size 9.84 x 5.90 x 3.15 in.
250 x 150 x 80 mm
Tank Capacity 2500ml (MAX-) 2100ml 4.44pt
(5.29 pt) (MIN-) 600ml 1.27pt
5 Recycle digital timer 180s —280s—380s—480s—90s
Net Weight 5lbs, 8.18oz. (2.5 Kg)
Gross Weight 6lbs, 9.82oz. (3.0 Kg)
Raytech®
Turbo®Sonic 2500
Ultrasonic Cleaner
Operating
Instructions

READ BEFORE OPERATING
• Ultrasonic cleaners are very easy to use. To get the best results
from your new purchase we recommend that you read this users
guide before getting started. After reading instructions, if you do not
fully understand the operation of machine you may contact Raytech
customer service at 1-800-243-7163 for further assistance.
MAIN FEATURES
• This machine is the newest generation of ultrasonic cleaners, featur-
ing 5 timed cleaning cycles with a built in heater.
• With a larger fluid capacity of approximately 70 oz (2500 ml) and
larger 160 watt transducer unit, cleaning power and capacity has
been increased.
• 2.5 Liter stainless steel tank: greater holding capacity and durability
• Engineered Plastic Basket: Improves the flow of Ultrasonic waves
and provides greater durability and will not scratch cases or parts.
• Powerful Transducer: More Effective Cleaning
• 5 Cleaning Cycles: For All Your Cleaning Needs
• Circuit Protector: Prevents Damage
• Fan Cooled: Prevents Overheating
• Durable Plastic Housing: Resists Dampness and Shock
SAFETY INSTRUCTIONS
CAUTIONS!
• Do not use for loaded ammunition cartridges.
• Always unplug this unit when not in use.
• Always keep unit in a safe place to avoid having it fall into water or
other liquids.
• Do not immerse in water or other liquids.
• Always unplug unit immediately if unit has fallen into water or other
liquid.
• Always keep unit and power cord away from heated surfaces.
• Never use unit with damaged power cord.
• Always place unit on dry level surface for use.
• Do not disassemble unit.
• Always unplug unit before filling and never exceed the maximum fill
mark.
• Do not fill tank with abrasive or corrosive materials, use only manu-
facturers recommended cleaning solutions.
• Follow all instructions in manual.
• Do not use if there is no water or cleaning solution in cleaning tank.
• 2 •
• Always use basket when cleaning. Never let items being cleaned
make contact with tank.
Raytech offers two different cleaning solutions:
RAYTECH® CR CONCENTRATED
CORROSION REMOVING SOLUTION
• Can be used to restore surface appearance on metals
• Removes tarnish, oxidation, rust, and scale build up.
• Parts to be cleaned should not have excessive oil – remove bulk oil
before cleaning in this solution.
• For best cleaning action, avoid multiple layers – keep as much space
between parts as possible.
• For best results when cleaning parts with cavities, remove the basket
from the unit and load the parts into the basket. Lower the basket into
the solution and shake the basket slightly to help dislodge any bub-
bles that might be present inside the parts.
• Not recommended for cleaning silver, sterling silver or silver plating.
• Will effectively clean gold jewelry, but avoid immersion of gemstones
in the solution as they may be damaged by the solution or sonic
energy or both.
• When starting with a new batch of parts and new cleaning solution
preheat the solution and run the ultrasonic for 5 minutes to “degas”
the solution. Dissolved gas in the solution can diminish the ultrasonic
energy. Once degassed, it is not necessary to degas again until the
solution is changed.
• Discard the solution when it becomes highly discolored or murky.
Rinse the unit with clean water before recharging.
• Do not mix with other cleaners or chemicals.
(Caution- removes bluing from steel, coated surfaces can be damaged
by excessive ultrasonic action)
RAYTECH® GP CONCENTRATED
GENERAL PURPOSE CLEANING SOLUTION
• Can be used as a general purpose cleaner for most metals
• When cleaning aluminum, keep the use of the sonics to the minimum
time needed. The part(s) can be allowed to soak (no sonics) to help
in decreasing the time required for sonic cleaning. Aluminum can be
damaged by excessive sonic energy.
• 3 •

OPERATING INSTRUCTIONS
• Open lid by pulling straight up.
• Follow instructions on cleaning solutions for proper mixing ratios.
• Add water or water and cleaning solution but do not exceed “MAX” fill
line, taking into account that when items and basket are placed in
tank fluid level will rise.
• Fluid should cover surface of items being cleaned.
• Do not overlap items that may scratch.
• Never let items come in contact with tank.
• Plug the power cord into side of unit and then plug unit into wall.
• When unit is first powered up the 180 second (3minute) cleaning
cycle will appear. Pressing the “Set” button will display the next high-
est cleaning cycle, all the way up to 480 seconds (8 minutes).
• A short 90 second (1 minute 30 seconds) cleaning cycle at the end of
the menu will appear, this option may be used as a rinsing cycle with
plain water and the heat setting to remove any leftover cleaning solu-
tion or if the desired cleaning result has not been achieved and a full
180 second(3 minutes) is not needed.
• Using the “Heater” function; Pressing the TC button on the unit turns
on built in heating unit. The red LED will illuminate on the left side of
the display. The water will heat to 65 degrees Celsius (approximately
150 degrees Fahrenheit) in approximately 20 to 30 minutes.
Hint: By using warm water the heating time will be decreased and your
cleaning cycle can start sooner.
• Once the unit has been filled with desired fluids place items to be
cleaned in basket. Then slowly insert basket into tank and shake it
slightly to dislodge air bubbles. Replace cover. You may press the
“SET” button to choose your desired cleaning cycle.
• Press the “ON” button to start your cleaning. You will hear a “BUZZ”
sound from the machine. This means it is working. The timer will
count backwards showing you how much cleaning time is left for the
chosen cycle.
• Pressing the “OFF” button will pause the cleaning cycle. It does not
turn off the power to the unit. You must unplug the unit from the wall
to power off!!!
• When cleaning cycle is finished, unplug and open lid.
• Remove basket carefully remembering that if you used the “HEATER”
function water will be HOT. Tip the basket side to side over the tank
as it is removed from the solution. This will help to pour out any
trapped water or solution in the parts. Place basket on some sort of
moisture absorbing material (paper towel, shop rag).
• Parts should be rinsed in clean water before continuing. A bucket
with clean water may be used to dunk basket and rinse parts. Shake
basket over bucket to help in removing excess water and cleaning
• Designed to clean oil, grease, and grime buildup on parts.
• Not recommended for cleaning silver, sterling silver or silver plating.
• Avoid cleaning jewelry, particularly gemstones in this cleaning solu-
tion.
• Will provide limited corrosion protection – after cleaning, do not rinse
the part(s). The part(s) should be properly drained and allowed to air
dry. Not meant as a long term inhibitor – part(s) should be oiled for
long term corrosion protection.
• When starting with a new batch of parts and new cleaning solution,
preheat the solution and run the ultrasonic for 5 minutes to “degas”
the solution. Dissolved gas in the solution can diminish the ultrasonic
energy. Once degassed, it is not necessary to degas again until the
solution is changed.
(Caution: can cause discoloration on aluminum and pitting when used
for extended periods of time)
FEATURES AND ACCESSORIES:
• 4 • • 5 •

solution. You may speed up the drying process by utilizing a hair
dryer or compressed air. Caution do not use any heat source that
will overheat the parts.
• The unit is also equipped with overheating protection. If “ON” button
is pressed and the red LED illuminates and no “BUZZ” is heard over-
heating has occurred, let unit stand for 15 minutes before using
again.
• Do not turn unit on without any fluid in cleaning tank!!!
• Pour water out following the solution manufacturer’s disposal instruc-
tions and wipe tank clean.
USER MAINTENANCE
• Unplug and empty unit after using. Do not store water or cleaning
solutions in cleaning tank for any long periods of time.
• Keep unit in cool dry location.
WARRANTY/REPAIR POLICY
Your Raytech Product has been produced under rigid standards of
manufacture and inspection. However, if your Raytech product is found
to be defective in material or workmanship within one year of delivery
to the first retail purchaser, we will repair or replace it without charge.
If you require service under this warranty, please contact Raytech for a
return authorization. Return the complete item along with a letter of
explanation, including your complete name and address, freight prepaid
to the factory at the address listed below, be sure to write the RMA
number on the outside of the package. Your Raytech product will be
repaired or replaced and returned to you within 30 days of our receipt.
In making any return of a Raytech product to the factory, please be
sure it is packaged with proper care to protect it from damage in transit.
We are sorry, but our warranty cannot apply to a defect which results
from misuse, abuse, neglect, accident or improper care, or if your
Raytech product has been altered or repaired by anyone other than
factory personnel.
If the item is out of warranty and is in need of repairs, the Raytech
product should also be returned to the same address listed below.
Appropriate charges will apply for parts and labor. Estimates are avail-
able only when the item has been thoroughly inspected by our repair
personnel.
Raytech IND, Div. of Lyman Products Corporation
475 Smith Street, Middletown, CT 06457
Attn: Service Department
• 6 • • 7 •
Jewelry
Recommended for: Gold, silver, platinum, diamonds, sapphires.
Not recommended for: Porous stones such as pearls, opals, rubies, turquoise.
Do not wash oil treated stones in chemicals.
Suggested Directions: 3-5 minutes using Lyman Jewelry Cleaning Solution.
Caution: Silver tarnish must be removed using a silver tarnish remover.
It cannot be removed by an ultrasonic using only tap water.
Eye Glasses/Camera Lenses
Recommended for: Eye glasses, sunglasses, camera lenses.
Caution: If cracks exist in coating or glasses, they may become more
noticeable after ultrasonic cleaning. Screws may loosen during
ultrasonic cleaning.
Suggested Directions: 2 minutes using tap water.
Contact Lenses
Recommended for: Hard contact lenses.
Not recommended for: Soft contact lenses.
Caution: Use saline water.
Watches
Recommended for: Waterproof watches may be submerged in water.
Caution: Use watch stand (supplied with TS-700 Model) to keep watch
body above water if not waterproof.
Suggested Directions: 3-8 minutes using Lyman Jewelry Cleaning Solution.
Dentures/Retainers/Mouth Guards
Caution: Use tap water for daily cleaning.
Suggested Directions: 5 minutes using tap water.
Shavers/Razors
Recommended for: Shaver/razor heads can be submerged in water for cleaning.
Caution: Do not submerge electronic parts or motors.
Suggested Directions: 3-8 minutes using tap water.
CD/DVDs
Caution: Use CD stand (supplied with TS-700 Model).
Suggested Directions: 3-5 minutes using tap water.
Firearms and Ammunition Case Cleaning
ULTRASONIC APPLICATIONS
Your Raytech Turbo® Sonic Ultrasonic Cleaner offers a new and innovative
approach to cleaning small intricate parts. Ultrasonic cleaning is widely used in
the industrial, medical, automotive, and firearms industries. Ultrasonic cleaners
may also be used for a variety of general purpose applications for the hobbyist
and professional alike. It is extremely important when using the Turbo Sonic for
uses other than ferrous metals that you use the correct cleaning solution or you
risk damage to the item you are cleaning. Raytech offers a special jewelry clean-
ing solution. Other recommended uses for your Turbo Sonic are listed below. For
items questionable about their suitability for ultrasonic cleaning we suggest con-
tacting the manufacturer of the item to determine if ultrasonic cleaning is appro-
priate for that item.
