Raytech Turbo Sonic 6000 User manual

Raytech®
Turbo®Sonic 6000
Ultrasonic Cleaner
Operating
Instructions
Raytech Industries®
A Division of yman Products
475 Smith Street
Middletown, CT 06457
1-800-243-7163
www.raytech-ind.com
Part # 0000000 Rev. 02/14
SPECIFICATIONS
Description Digital Ultrasonic Cleaner
Model TS-6000
Item No. (115V) 7631725
(230V) 7631726
Tank Size 12.7 x 8.0 x 3.9 in.
32.3 x 20.3 x 9.9 cm
ongest item that can fit in tank 13.4” / 34.0 cm
Rating voltage AC 220~240V ~ 50-60 Hz
& Frequency AC 100~120V ~ 50-60 Hz
Consumption Power AC 220~240V ~ 310W
AC 100~120V ~ 260W
Digital timer 1 to 30 minute full range timer
Temperature Settings 104°F — 140°F / 40°C — 60°C
Drainage Drainage Valve
Ultrasonic Frequency 35,000 Hz
Tank Material Stainless Steel SUS304
Housing Material ABS
Net Weight 11.9 lbs / 5.4 kg
Gross Weight 15.0 lbs / 6.8 kg
Unit Size 17.2 x 11.8 x 9.8 in. / 43.7 x 30.00 x 24.9 cm
Box Size 20.3 x 14.0 x 12.6 in. / 51.5 x 35.5 x 32.0 cm

• 2 •
READ BEFORE OPERATING
Ultrasonic cleaners are very easy to use. To get the best results from
your new purchase we recommend that you read this users guide before
getting started. After reading instructions, if you do not fully understand
the operation of this machine you may contact Raytech customer service
at 1-800-243-7163 for further assistance.
MAIN FEATURES
• arge tank capacity: 1.6 U.S. Gallons / 6000ml
• arger tank size: 12.7” x 8.0” x 3.9” / 32.3 x 20.3 x 9.9 cm
• Two industrial grade ultrasonic transducers with independent control
circuits
• Two ceramic heaters
• 2-color ED display with 5 timed cleaning cycles. From 1-30 minutes
• De-gas feature: removes air bubbles & improves cleaning efficiency
• Cooling fan
• Built in drain: Convenient clean-up
• Multiple circuit protectors
SAFETY INSTRUCTIONS
• Do not use for loaded ammunition cartridges.
• Always unplug this unit when not in use.
• Always keep unit in a safe place to avoid having it fall into water or
other liquids.
• Do not immerse in water or other liquids, do not spray water or other
liquids on unit.
• Always unplug unit immediately if unit has fallen into water or other liq-
uid.
• Always keep unit and power cord away from heated surfaces, never
use unit with damaged power cord.
• Always place unit on dry level surface for use, avoid blocking air vents.
• Do not disassemble unit.
• Always unplug unit before filling tank and never exceed the maximum
fill mark.
• Do not fill tank with abrasive or corrosive materials, use only manufac-
turers recommended cleaning solutions.
• Follow all instructions in this manual.
• 3 •
• Do not run unit for extended time: After 45 minutes of continuous use
let unit stand for 20 minutes to prolong unit's life.
• Never let items being cleaned come in contact with the tank.
• Avoid areas that may have electromagnetic interference.
A. id
B. ED ights
C. Stainless Steel Tank
D. Control Panel
E. Housing
F. Handles
G. Drainage Valve Handle
H. Drainage Pipe
I. Power Switch
J. Power Socket
K. Hose
. Power Cord
M. Plastic Basket
FEATURES AND ACCESSORIES:

• 4 •
CONTROL PANEL AND OPERATION
1. Indic tor Light - Working St tus
Green - Ready (G): Normal working status, ready to use
Red - Overheat (R): Under overheat protection. 15 minutes of waiting
time is needed for the light to change from red to green. Work can re-
sume afterwards.
2. On/Off Button - On/Off Switch
After powering on, the ED displays which is the default time
and the unit is ready with normal working status.
Press On/Off button once and the cleaning starts. The cleaning stops
when the timer counts down to 00:00. If the unit needs to be stopped
before the timer runs out, press On/Off button.
3. Function Button - Functions (De-g s / Norm l)
Press Function Button, illuminates, indicating de-gas function is se-
lected. Press On/Off button to start de-gassing. will flash for two
minutes, then the unit will return to normal cleaning function. Pressing
Function button before it ends will stop de-gassing. If additional de-
gassing is needed after it ends, press Function button again.
De-Gas: When cleaning heavily soiled or greasy items or steel, brass,
silver, or copper items, chemical solutions need to be added to the
water. The solution may form many small droplets and take a long time
to dissolve in the water. Newly added water may generate many air
bubbles on the tank walls. These will reduce the cleaning effect in the
beginning phase of ultrasonic cleaning. Turning on the de-gas function
will dissipate the droplets and the air bubbles, usually in 2 minutes, and
will improve cleaning efficiency.
4. De-G s St tus
Illuminated, the de-gas function is selected.
Flashing, de-gassing is underway.
5. Norm l Cle ning St tus
Illuminated, normal cleaning is underway.
6. He ter St tus
Press TC button, flashes, indicating the heater is turned on. Press
TC button again, dims, indicating the heater is turned off.
7. Actu l - W ter temper ture displ y.
It displays the actual water temperature in the tank.
• 5 •
12 3 8
45 6 7
910 11 12 13
8. Digit l LED displ y of working items.
It counts down after work is started.
9. Set temper ture displ y.
Press Temp button to select one of the 5 set temperatures.
10. Time button - Timer quick set button.
Press the Time button, ED display shows 05:00. Each pressing in-
creases it by 5 minutes.
11. Button - Timer decre sing button.
Each pressing reduces the timer by 1 minute.
12. TC button - He ter button.
Pressing TC button, flashes, indicating the heater is turned on. To
cancel heating, press TC. dims, indicating the heater is turned off.
When the water reaches the set temperature or 140°F (60°C), the
heater will turn off automatically.
13. Temp button - Temper ture Set button.
5 set temperatures can be selected. The default temperature is 104°F
(40°C). Press Temp button to select the temperature in the following se-
quence:
FAHRENHEIT TO CELSIUS CONVERSION CHART
Fahrenheit: 104°F 4 113°F 4 122°F 4 131°F 4 140°F
Celsius: 40°C 4 45°C 4 50°C 4 55°C 4 60°C

• 6 • • 7 •
USER MAINTENANCE
• Unplug and empty unit after each use.
• Do not store water or cleaning solutions in cleaning tank for any long
periods of time.
• Keep unit in cool, dry, ventilated location.
OPERATING INSTRUCTIONS
For step by step instructions please see our instructional videos on the
yman Products website at : www.lymanproducts.com
1. Open the lid and remove basket. Place items into basket, then put bas-
ket into the cleaning tank. Add water to a level between MIN and MAX
to cover the items being cleaned.
If the unit is turned on without water, ultrasonic energy will not be ab-
sorbed. This model is high-powered. If turned on for more than 15 sec-
onds without water, it may damage or severely reduce the life of the
unit.
2. Connect the power cord to an outlet and turn the switch on. ED dis-
play shows 05:00. This is the default setting and most common timer
setting and working state. If the timer needs to be adjusted, press TIME
button and button. The timer can be set between 1 and 30 minutes.
Common cleaning times are 5, 10 or 15 minutes.
Prolonged cleaning time may result in:
a. oosening of screws (if used).
b. Increasing pre-existing cracks.
c. Peeling of coating which was already separated.
3. Press On/Off button to start cleaning. During cleaning, 2 sets of blue
ED lights at the two sides of the unit illuminate, and a buzzing sound
can be heard from the cleaning tank, indicating that cleaning is under-
way. Closing the lid will reduce the noise level. The digital timer will
count down to show the remaining cleaning time. When it displays
00:00, the cleaning is done.
To stop cleaning at any time, press On/Off button. The unit is designed
with overheating protection to avoid extended and continuous operation
for too long. When the red light is on, the unit will not turn on even by
force. The unit will idle for about 20 minutes and can be restarted after the
green light comes on.
a. When the heater is needed, press TEMP button to select one of the 5
preset temperatures. Press TC button, flashes, indicating the heater
is turned on. ED Actual displays actual water temperature. When the
water reaches the set temperature, dims, indicating the heater is
turned off.
To ensure safety, the unit is designed with dual protection. The heater will
be turned off automatically if it has been running for 50 minutes.
b. To speed up the mixing and to use less solution, use De-gas function.
Press TIME button to set the timer for 10 minutes, then press FUNC-
TION button, illuminates. Press On/Off to start de-gassing. It
changes over to normal cleaning after 2 minutes.
c. When debris “smoke” is no longer visible, cleaning is done. If additional
cleaning is needed, reset the timer and repeat the previous steps.
4. When cleaning is completed, unplug the power cord, open the lid and
remove the basket. Connect the supplied drainage hose to the drain
nozzle by pushing straight on. Open the drainage valve to drain the
dirty water. Clean and wipe the tank dry. Close the drainage valve. Re-
move drainage hose and rinse with clean water.
CLEANING SOLUTIONS
It is important to use the proper cleaning solutions for the material being
cleaned. Raytech offers several different ultra-sonic cleaning solutions
for your specific cleaning needs. Always follow the directions on the label
of the cleaning solution for best results.
RAYTECH® CR CONCENTRATED
CORROSION REMOVING SOLUTION
• Can be used to restore surface appearance on metals
• Removes tarnish, oxidation, rust, and scale build up.
• Parts to be cleaned should not have excessive oil – remove bulk oil be-
fore cleaning in this solution.
• For best cleaning action, avoid multiple layers – keep as much space
between parts as possible.
• For best results when cleaning parts with cavities, remove the basket
from the unit and load the parts into the basket. ower the basket into
the solution and shake the basket slightly to help dislodge any bubbles
that might be present inside the parts.

• 8 •
• Not recommended for cleaning silver, sterling silver or silver plating.
• Will effectively clean gold jewelry, but avoid immersion of gemstones in
the solution as they may be damaged by the solution or sonic energy
or both.
• When starting with a new batch of parts and new cleaning solution pre-
heat the solution and run the ultrasonic for 5 minutes to “degas” the so-
lution. Dissolved gas in the solution can diminish the ultrasonic energy.
Once degassed, it is not necessary to degas again until the solution is
changed.
• Discard the solution when it becomes highly discolored or murky. Rinse
the unit with clean water before recharging.
• Do not mix with other cleaners or chemicals.
(Caution- removes bluing from steel, coated surfaces can be damaged by
excessive ultra sonic action)
RAYTECH® GP CONCENTRATED
GENERAL PURPOSE CLEANING SOLUTION
• Can be used as a general purpose cleaner for most metals
• 9 •
• When cleaning aluminum, keep the use of the sonics to the minimum
time needed. The part(s) can be allowed to soak (no sonics) to help in
decreasing the time required for sonic cleaning. Aluminum can be
damaged by excessive sonic energy.
• Designed to clean oil, grease, and grime buildup on parts.
• Not recommended for cleaning silver, sterling silver or silver plating.
• Avoid cleaning jewelry, particularly gemstones in this cleaning solution.
• Will provide limited corrosion protection – after cleaning, do not rinse
the part(s). The part(s) should be properly drained and allowed to air
dry. Not meant as a long term inhibitor – part(s) should be oiled for
long term corrosion protection.
• When starting with a new batch of parts and new cleaning solution
preheat the solution and run the ultrasonic for 5 minutes to “degas” the
solution. Dissolved gas in the solution can diminish the ultrasonic en-
ergy. Once degassed, it is not necessary to degas again until the solu-
tion is changed.
(Caution: can cause discoloration on aluminum and pitting when used for
extended periods of time)

• 10 •
ULTRASONIC APPLICATIONS
Your Raytech Turbo® Sonic Ultrasonic Cleaner offers a new and innova-
tive approach to cleaning small intricate parts. Ultrasonic cleaning is
widely used in the industrial, medical, jewelry, automotive, and firearms
industries. Ultrasonic cleaners may also be used for a variety of general
purpose applications for the hobbyist and professional alike. It is ex-
tremely important when using the Turbo Sonic for uses other than steel
parts that you use the correct cleaning solution or you risk damage to the
item you are cleaning. Raytech offers a special jewelry cleaning solution.
For items questionable about their suitability for ultrasonic cleaning we
suggest contacting the manufacturer of the item to determine if ultrasonic
cleaning is appropriate for that item.
For step-by-step instructional videos on using the
Raytech Turbo®Sonic Ultrasonic Cleaner
Visit our website at:
www.lymanproducts.com
• 11 •
WARRANTY/REPAIR POLICY
Your Raytech Product has been produced under rigid standards of manu-
facture and inspection. However, if your Raytech product is found to be
defective in material or workmanship within one year of delivery to the
first retail purchaser, we will repair or replace it without charge.
If you require service under this warranty, please contact Raytech for a
return authorization. Return the complete item along with a letter of expla-
nation, including your complete name and address, freight prepaid to the
factory at the address listed below, be sure to write the RMA number on
the outside of the package. Your Raytech product will be repaired or re-
placed and returned to you within 30 days of our receipt. In making any
return of a Raytech product to the factory, please be sure it is packaged
with proper care to protect it from damage in transit.
We are sorry, but our warranty cannot apply to a defect which results
from misuse, abuse, neglect, accident or improper care, or if your
Raytech product has been altered or repaired by anyone other than fac-
tory personnel.
If the item is out of warranty and is in need of repairs, the Raytech prod-
uct should also be returned to the same address listed below. Appropriate
charges will apply for parts and labor. Estimates are available only when
the item has been thoroughly inspected by our repair personnel.
Raytech IND, Div. of yman Products Corporation
475 Smith Street, Middletown, CT 06457
Attn: Service Department
