Razer ABYSSUS 1800 Use and care manual

The Razer Abyssus is created for gamers looking for quality, reliability and performance in a no-
nonsense, straightforward gaming-grade mouse. Designed to focus on the fundamentals of competitive
gaming, the Razer Abyssus is armed with ultra-responsive buttons tuned for maximum tactile feedback.
With an uncompromising 1800dpi Razer Precision infrared sensor at its core, take full control of your
every aim with perfect tracking so you outgun your competition.
MASTER GUIDE
CONTENTS
1. Package Contents/ System Requirements / Registration
2. Connecting Your Razer Abyssus 1800
3. Key Features
4. Configuring Your Razer Abyssus 1800
5. Using Your Razer Abyssus 1800
6. Advanced Settings Guide
7. Safety and Maintenance
8. Legalese

1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS / REGISTRATION
PACKAGE CONTENTS
Razer Abyssus 1800 Gaming Mouse
Quick Start Guide
SYSTEM REQUIREMENTS
PC with USB ports
Windows® 7 / Windows Vista® / Windows® XP
Internet connection (for driver installation)
35MB of free hard disk space
REGISTRATION
Please visit www.razerzone.com/registration/ for online product registration.
What you’ll get:
• 2 years limited manufacturer’s warranty for the Razer Abyssus 1800
•Access to manual and free online technical support at www.razersupport.com

2. CONNECTING YOUR RAZER ABYSSUS 1800
WINDOWS® 7 / WINDOWS VISTA® / WINDOWS® XP INSTALLATION INSTRUCTIONS
Step 1: Plug your Razer Abyssus 1800 into the USB port of your computer.
Step 2: Download the Driver Installer from http://www.razersupport.com/
Step 3: Run the installer.
Step 4: Choose setup language. Click OK to proceed.
Step 5: The Razer Abyssus 1800 setup screen appears. Click NEXT to proceed.
Step 6: Read the license agreement. If you agree to all the terms, select “I accept the terms in the license
agreement”. Click NEXT to proceed.
Step 7: Enter your User Name and Organization. Click NEXT to proceed.
Step 8: Choose your installation setup. Click NEXT to proceed.
Step 9: If everything is correct. Click INSTALL to begin installation.
Step 10: At the end of the installation, click FINISH to complete the installation.
Step 11: Follow the instructions onscreen to restart your computer. Click YES.

3. RAZER ABYSSUS 1800 KEY FEATURES
A Mouse button 1 –Click
B Mouse button 2 –Menu
C Mouse button 3 –Scroll Wheel and Universal Scrolling
D Razer Precision 3G Infrared Sensor
E Ultraslick Mouse Feet
F 1000Hz (1ms) Response Time
G 16-Bit Ultra-Wide Data Path

4. CONFIGURING YOUR RAZER ABYSSUS 1800
The features listed here require the Razer Abyssus 1800 software driver to be installed and the Razer
Abyssus 1800 Tray Icon to be active. Each setting will be saved to the current Profile on the current
machine only.
ASSIGN BUTTONS TAB
In the Assign Buttons tab, you can assign various functions to each of the buttons based on your own
preferences. The following functions are possible:
Click –Perform a left mouse click.
Menu –Open a context-sensitive menu.
Universal Scrolling –Click once on the assigned button to activate universal scrolling. Drag your
Razer Abyssus 1800to scroll in the direction of the mouse movement.
Double Click –Perform a double click with the assigned button.

Macro –If the button function or key is not listed, or if you would like to assign a macro to a
button, select “Macro”from the dropdown menu. In addition, all saved macros will be shown
on a sub dropdown menu for quick selection when you mouse over the “Macro” option.
Forward –Assign a “Forward” command in Windows Explorer / Internet Explorer.
Backward –Assign a “Back” command in Windows Explorer / Internet Explorer.
On-The-Fly Sensitivity –Enable change of sensitivity settings on the fly without the need to
enter the configuration menu.
Single Key –Activate a key on your keyboard.
Scroll Up –Scroll up the page you are currently viewing.
Scroll Down –Scroll down the page you are currently viewing.
Button Off: –Disable any function on the assigned button.
TWEAK PERFORMANCE TAB
1. Current DPI
You can switch between 800 and 1800 DPI.
2. Sensitivity
The current sensitivity of your Razer Abyssus 1800 can be easily adjusted by moving the arrow along the
slider.

To set a different sensitivity level in the X and Y axis, you can select the “Enable independent X-Y
sensitivity” option and move the individual X and Y arrows along the slider.
To display the On-The-Fly Sensitivity indicator onscreen whenever you make changes on the fly, select
the “Enable On-The-Fly sensitivity on-screen display” option.
3. Acceleration
You can activate acceleration by checking the “Enable Acceleration” box and moving the arrow along
the slider.
4. Polling Rate
You can switch between 125Hz (8ms), 500Hz (2ms) and 1000Hz (1ms) by clicking on the individual
polling rate buttons.
MANAGE PROFILES TAB
In the Manage Profiles tab, you can create and activate customized profiles based on the application you
have launched.

a. Current: Indicates the current active profile.
b. Profile: Indicates the profile number
c. Profile Name: Right-click on this row and select “Rename” to enter a profile name of your choice.
d. Application: Right-click on this row and select “Assign Application” to open up the directory browsing.
Select the executable file of the program you want the profile to be linked to.
e. Auto Switch: Check the box to enable automatic profile switching when the chosen application is
launched.
Right-clicking on any profile allows you to quickly access a list of extra commands.
MANAGE MACROS TAB
In the Manage Macros tab, you can record unlimited keystrokes (dependent on your storage resources).
These macros can also be imported and exported onto your hard disk for future usage.
a. Macro Entry: Enter your macro in the Macro Entry box. You can even choose to insert a delay time
and/or a mouse-button press.
b. Delay (ms): Choose the amount of delay to be inserted between keystrokes of your macro.

c. Basic Commands: A list of basic commands in Windows OS that can be inserted between keystrokes
of your macro.
d. Additional Commands: Another list of basic commands in Windows OS that can be inserted between
keystrokes of your macro.
You can ignore delays between events of a macro by clicking on the respective checkbox before
recording.
You can specify a fixed default delay timing to be used in between events of a macro by clicking on the
respective checkbox before recording.
LIGHTING TAB
Lighting
Turn on/off the Razer logo light on the Razer Abyssus 1800.

5. USING YOUR RAZER ABYSSUS 1800
Creating Macros
a. Load the Razer Abyssus 1800 Configurator.
b. Click on the Manage Macros tab.
c. Click “New” to start a new macro
d. Click ‘Record’ to start creating a macro.
e. Type in the desired sequence of keystrokes.
f. Click ‘Stop’ to end the recording.
g. Right-click on the recorded keystroke to access more options.
h. You can also insert additional commands by clicking on the drop down menus.
i. Click ‘Apply’ when done.
