rba RAFFAELLO RBA4600 Series Manual

INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
Australia 1300 788 778 www.rba.com.au | New Zealand 0800 722 111 www.rbagroup.co.nz1 of 4
RBA4600-001-Series RBA Designer Rails White
RBA4600-008-Series RBA Designer Rails Matte Black
RBA4600-009-Series RBA Designer Rails Chrome
RBA4600-SERIES
* RBA4600-019 shown
As improvements in the design and performance of RBA products are continuous, specications may be subject to change without notice.
The illustrations and descriptions herein are applicable to production as of the date of this Installation Instructions Sheet. Revised 10/23 © 2023 by RBA Group II/Model RBA4600-Series/0323
Sourced/ Supplied under QMS

INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
Australia 1300 788 778 www.rba.com.au | New Zealand 0800 722 111 www.rbagroup.co.nz2 of 4
You are responsible for the safe operation of this unit.
Attention
For optimum installation, use at least 3 suitable screws for each wall plate. Screws should be selected to suit the wall type. Grab Rails are
no stronger than the anchors or walls to which they are attached, and therefore, must be rmly secured in order to support the loads for
which they are intended.
Maintenance and Cleaning Instructions
Do not use detergents containing bleach, acids, alkalis, or chlorine or abrasive products. Do not use abrasive objects (e.g. scouring pads).
Do not use chemicals that can damage plastic. Clean the surface with water and a neutral detergent; rinse carefully and dry with a clean
cloth. If alternative cleaning methods and/or chemicals are used, warranty may become void.
Important Warnings
Exceeding the maximum load values may cause permanent product damage. If this happens, cease use until checked by a specialised
maintenance person. Improper use, such as for gymnastic exercises or as a step, may cause accidents with serious consequences. Reliable
operation and product safety depend on the way the products are installed and used.
Ensure installation is performed by qualied personnel. Incorrect installation can seriously compromise product functionality.
Tools Required
• Plumbers Tape
• Screw Driver
• Extended Driver Bit
• Spirit Level
Components Supplied
2x Flange Cover
2x Bracket Post 2x Bolt 6x Screw 6x Pin
1x Rail
2x Wall Plate 2x Flange Button

INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
Australia 1300 788 778 www.rba.com.au | New Zealand 0800 722 111 www.rbagroup.co.nz3 of 4
7. Straighten the rail.
1. Lay rail at with thread facing up.
8. Mark location to install.
2. Place bracket post onto
rail.
9. Ensure the rail is level.
3. Slide ange cover over post.
4. Insert bolt through wall plate. 5. Insert xing wall bracket and
assemble.
6. Tighten.

INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
Australia 1300 788 778 www.rba.com.au | New Zealand 0800 722 111 www.rbagroup.co.nz4 of 4
10. Position ange cover so the hole is
over the screw xing point. Secure the
rst screw.
11. Rotate the ange cover so the hole is
positioned over a new screw xing point.
12. Repeat until four screws are securing
the wall plate.
13. Fix horizontal rail to wall. Push ange cover over wall plate and insert ange button.
