1999/2000 Home Entertainment Catalog
New technology. New questions.
New solutions.
Your Guide to the Digital Age of Home Entertainment.
RCA P61300 HDTV
Changing Entertainment. Again.

America is looking to the
entertainment experts.
Introduction
Welcome to the RCA Home Electronics Catalog.
Our experts have set out to find out what you want
in home entertainment. They have listened to your likes and dislikes and
created products centered around the way you use home entertainment.
You can count on RCA products to deliver incredible pictures and sound
with highly advanced features, that are easy to use.
And our experts know that the electronics vocabulary can be complex.
There is Digital TV, HDTV, DVD, Divx1, Dolby Digital2, Dolby3Pro-Logic...the
list goes on and on. Which is which? What does what? We’ll explain the
differences because our experts believe, the more you know about home
electronics, the more likely you will come to insist on the RCA brand.
The RCA Catalog
is a solutions guide
to all of your home
electronics needs.
Changing Entertainment. Again.2

Introduction
HDTV/
Digital Products Pages 4-13
HDTV ushers in a new age in television
with theatre-like dimensions, vivid picture
and Dolby Digital2sound. With over
1 million pixels of resolution that is unlike
anything seen before.
Televisions Pages 14-29
RCA televisions offer great picture and
sound and are packed with convenience
features such as GUIDE Plus+4, that
make finding and recording your favorite
programs easier than ever.
TV/VCRs Pages 30-33
A TV/VCR combo offers many features in
a convenient package. There are sizes and
colors that can fit in any room of your home.
Satellite Systems Pages 34-37
RCA Satellite Systems featuring DIRECTV®
programming give you more sports,
more movies, more options. Plus,
DIRECTV®is your entry to the world of
HDTV programming.
DVD Players Pages 38-40
RCA DVD players deliver great digital
picture and sound. With DVD you get the
best picture possible for the life of the disc.
Digital Cable Modems Page 41
Experience immediate internet access—
with incredible speed—right through
your cable system!*
VCRs Pages 42-45
With features like Commercial Advance5
and Movie Advance5 , this year’s line
of VCRs combines convenience with
quality picture and sound.
Camcorders Pages 46-49
Capturing life’s precious moments is
made simple with the RCA AutoShot™
feature. Just point the camera and shoot.
Audio Products Pages 50-65
RCA Audio products give you theatre-
quality sound right in your own home.
And, with a wide assortment of audio
products you can have great sounds
wherever you go.
Accessories Pages 66-71
Enhance and protect your purchases with
our full-line of quality accessories. From
surge protectors to camera lenses, we
have accessories for all your needs.
*Monthly subscription fee applies.
The RCA line of home
electronics gives you
superior performance
with easy-to-use convenience.
3
Changing Entertainment. Again.
Simulated pictures.
DIRECTV is a trademark of DIRECTV, Inc., a unit of Hughes
Electronics Corp. and is used with permission.
(not available in Canada)

Not since RCA introduced
color television in 1954 has
the world of home entertainment undergone such
a major change. The new digital broadcast signals will
give you an amazingly lifelike picture and Dolby1Digital
sound. HDTV offers over 1 million pixels of resolution
that is unlike anything seen before. The 16:9 screen
ratio allows you to watch movies the way they were
meant to be seen without letter-boxing. Sports look
and sound so real, you would swear that you were
in the stadium. Home entertainment will never be the
same and an RCA HDTV is the best way to enjoy the
new age in television.
Nothing compares to the excitement of the silver screen.
Until now.
Digital Products | HDTV
HDTV ushers in a new age in television
with theater-like dimensions, vivid picture
and Dolby Digital1surround sound.
Changing Entertainment. Again.4Simulated picture.
digital
|
HDTV

digital
|
HDTV
Digital | HDTV
5
RCA High-Definition is the
new definition for television.
Movies will look like movies!
What is the HDTV picture difference?
The first time you see
HDTV, you might not
believe your eyes!
We could compare it to a movie screen,
but it’s actually better. Better because RCA
HDTV’s innovative technology puts you in
the heart of the action. In fact, it’s the
closest thing to being there. Speaking of
better, the RCA HDTV is not only the most
technologically advanced television we
have ever made, it is also easy to operate.
We have incorporated a navigational system
that operates with the touch of a button
on the remote control. We have also included
a tuner that automatically deciphers the
incoming video and audio information and
translates it into the lifelike pictures and
sounds of your favorite programs. With
these convenient features of an RCA HDTV,
you don’t have to be a technological
wonder to enjoy the wonders of technology.
For nearly 60 years, analog television has been the broadcast standard. This standard is now
being replaced by digital television, which uses a continuous stream of numbers to transmit
picture, sound, and information. This new method produces amazing results. The RCA HDTV
delivers its brilliantly clear picture on a rectangular 16:9 ratio screen. It also features the
incomparable Dolby1Digital audio system that makes the sound as lifelike as the picture.
This combination delivers an entertainment experience that is unmatchable.
Changing Entertainment. Again.
4:3 ratio
16:9 ratio
HDTV
Standard NTSC broadcast
The digital information of HDTV is translated into pixels. The higher the pixel number, the
better the picture. HDTV can receive up to ten times as many pixels as today’s TV—that’s
2,000,0000 pixels compared to 200,000 you get with normal analog technology. That
gives you the sharpest, clearest picture ever available with virtually no lines. The first time
you see the picture on RCA HDTV, you might not believe your eyes.
1920 X 1080 Lines =
2,073,600 pixels
200,000+ pixels
Most televisions have a
4:3 aspect ratio, but movie
aspect ratios are closer to
16:9. With RCA HDTV,
you’ll see more — the
whole picture, complete —
of every program broadcast
in the widescreen format.
Pixel Comparison
Today’s broadcast signal lights up about
200,000 pixels arranged in a 4:3 rectangle.
High-definition digital television is different.
At the very minimum, over-the-air digital
television offers a picture that’s 640 pixels
wide by 480 pixels high—that’s over 300,000
pixels (about 50% more than today’s TV).
Since we know that more pixels means more
visual information, we’re talking about a
sharper picture. In the past, a sharper picture
was just...sharper. But with digital television,
there’s a way to quantify just how sharp it is.
From the minimum of 300,000 pixels all the
way up to about a million pixels is called
standard definition digital television, or SDTV.
High-definition digital television, or HDTV,
starts at around a million pixels and can go
all the way up to 2 million—almost 10 times
the resolution of today’s TV.
digital
|
HDTV
Simulated pictures.

Color Coding
Legend
■HDTV signal gives improved
picture quality, even on
non-HDTV displays.
■DIRECTV®satellite delivers over
200 channels of digital quality
television.
■Cable Television signal
■Standard Television Broadcasts
(analog) from local stations.
■Digital Television and HDTV
broadcasts from local stations.
Digital | HDTV
6Changing Entertainment. Again.
When will I be able
to see HDTV?
With DIRECTV® , you will have HDTV program-
ming options wherever you live. Over-the-air
broadcasts of digital television begin in the
top ten U.S. television markets in late 1998,
expanding to the top 30 markets gradually
by the turn of the century. All over-the-air
stations must be broadcasting digital signals
by 2003. Current analog signals will be
available at least until 2006.
■Next 20 Digital TV Markets
by November, 1999
■First Ten Digital TV Markets by May, 1999
Atlanta
Boston
Chicago
Dallas/Ft. Worth
Detroit
New York
Philadelphia
Los Angeles
San Francisco
Washington, D.C.
Baltimore
Charlotte
Cincinnati
Cleveland
Denver
Hartford/New Haven
Houston
Indianapolis
Miami/Ft.
Lauderdale
Minneapolis/St. Paul
Orlando/Daytona
Beach/Melbourne
Phoenix
Pittsburgh
Portland {Ore.}
Raleigh/Durham
Sacramento/
Stockton/Modesto
St. Louis
San Diego
Seattle/Tacoma
Tampa/St.
Petersburg/Sarasota
DIRECTV®
HDTV
Satellite
DIRECTV®
Satellite
Local
Digital
HDTV Dish
Local
Analog
Standard TV
Antenna
HIt
Analog Cable TV
DIRECTV®
HDTV
Satellite
DIRECTV®
Satellite
Local
Digital
HDTV Dish
Local
Analog
Standard TV
Antenna
HIt
Analog Cable TV
RCA HDTV comes with the capability of receiving every broadcast
and DIRECTV®satellite signal currently available.
The RCA Advantage.
Movies will sound like movies!
Dolby1Digital
Surround Sound
System brings
true 5-channel
surround sound
into your home.
The sound system is
revolutionary as well,
with 5.1 channel Dolby1
Digital surround sound
capability and 50 watts2
of audio power that
deliver crisp, clear sound
with up to five full
channels and a sixth
low-frequency-effects
(subwoofer) channel.
Enjoy high-definition programming when
it becomes available.
Built-in DIRECTV receiver offers standard digital
and high-definition DIRECTV® programming.
That means more movies, sports, music, news
and information than you’ll find on cable or any
other digital TV service.
Simulated picture.
DIRECTV is a trademark of DIRECTV, Inc., a unit of Hughes Electronics Corp. and is used with permission.
®
How It Works
The RCA HDTV is a receiver/
monitor capable of processing
the highest resolution format
HDTV signal. This receiver gives
you the ability to receive a wide
array of programming options
including current local broadcast
and high-definition (HD) broad-
casts where available. In addi-
tion, the RCA HDTV will receive
and decode standard digital and
high-definition DIRECTV®pro-
gramming.
■
■
■
■
■

Digital | HDTV
RCA HDTV gives you the future
of television. Today.
P61300 61"diagonal
■HDTV Resolution
(Over 1 Million Pixels)
■16:9 Aspect Ratio
■Analog Video Bandwidth
(Over 30 MHz)
■Digital Up-Conversion
■All-Format RCA Satellite Receiver
■Line Doubler for NTSC Signals
●Dolby1Digital Surround Sound
Capability
●Optical Output AC-3 Dolby1Digital
●Five Independent Audio Power
Channels
●MPEG Audio Decoder
◆Auto Digital Focus
◆Twin Tuner™Picture-In-Picture
◆Format Control (4:3 Centered,
4:3 Expanded, Letterbox Expanded)
◆Audio Video Monitor Panel
with 3 S-Video Inputs
◆One Pair of Switchable
(Variable/Fixed) Audio Outputs
◆Master Touch®Glo-In-The-Dark
Remote
◆60"H, 561/2" W, 291/2"D
7
Breathtaking to see.
Amazing to hear.
Easy to operate.
RCA HDTV.
Picture Features
High-Definition Optical
System
This high-definition television offers
a 61"diagonal screen with a 16:9
aspect ratio (similar to a movie screen)
for a breathtaking, lifelike picture.
The high-definition optical system
provides rich, accurate color and
pinpoint detail. Each set incorporates
our latest in digital up-conversion
technology to ensure the cleanest,
most detailed picture possible from
existing signals, regardless of the source.
Sound Features
Dolby1Digital Surround
Sound
Up to six distinct and separate
channels. (Additional speakers
required).
Convenience Features
Backlit Universal Remote
With the touch of an extraordinary
backlit remote, you’ll be able to scroll
through some of the most simple-to-
use, yet technologically advanced,
menu screens ever offered, including
on-screen displays that can be
controlled by the touch of a button.
Auto Digital Focus
Allows you to automatically reset the
digital dynamic convergence via the
easy-to-navigate on-screen menu.
Easy-To-Navigate On-Screen
Menu System
Interactive menus allow immediate
access to all HDTV features, all without
missing your favorite program.
Simulated picture.

P55000
It says here that HDTV will
be the TV of the future...
What happens to the TV
I bought last year?
Digital | High-Definition Digital Receiver
The exciting new world of HDTV
provides new programming
options with digital picture and sound. Even though
the best way to enjoy this new programming is on an
RCA HDTV, the RCA High-Definition Digital Receiver
is a perfect way to transition into this new entertain-
ment with your current television. You will be able
to receive all current analog programming, local
HDTV transmissions, analog cable, and satellite
programming from DIRECTV® . With DIRECTV® , you
have access to HDTV programming as it becomes
available, even if the major stations in your area are
not broadcasting in this format. Even on an analog
television, HDTV can provide DVD quality picture3and
Dolby1Digital sound.
With the RCA Brand High Definition Digital
Receiver you can enjoy HDTV programming
on your current analog television.
Changing Entertainment. Again.8

Satellite
Digital High
Resolution
Monitor
Current
Television
High
Definition
Display
Digital | Features
9
Changing Entertainment. Again.
• Dolby1Digital Capability
• On-Screen Program Guides,
both 5 and 7 lines.
• Interactive Channel Banner
• Format Control (4:3 and 16:9)
• Allows you to use your current television
as well as full high-definition displays.
• The HD|Digital Receiver provides
easy-to-use on screen menu systems
for easy navigation.
This RCA HD|Digital Receiver is capable
of receiving most broadcast and DIRECTV®
satellite signals currently available.
The RCA HD|Digital Receiver lets you make the
transition to the future of television—TODAY!
Compatible with a wide variety of TVs and Display Monitors:
The RCA HD|Digital Receiver (DTC100) is capable of processing the highest resolution
format HDTV signal. This receiver gives you the ability to receive a wide array of
programming options including current local broadcasts and high-definition (HD)
broadcasts where available. In addition, the DTC100 will receive and decode standard
digital and high-definition DIRECTV®programming.
Satellite Dish
Local Analog
Receive all local
standard analog
broadcasts with
your current indoor
or outdoor antenna.
Local Digital
Receive local digital
broadcasts using
your current indoor
or outdoor antenna.
DIRECTV®Satellite
Receives DIRECTV®
programming using a
satellite dish antenna
(sold separately). With a
subscription to DIRECTV® ,
you will have access to
hundreds of channels
including HD and digital
programming.
Analog Cable
The DTC100 is also
cable ready—it will
accept the coaxial
cable from your local
service provider.
Full Seven-Line Program Guide
Provides channel and program title
information for seven different channels
covering a two-hour time window.
Full Five-Line Program Guide
Provides channel, program title and detailed
program description for five different channels
covering a two-hour time window.
Interactive Channel Banner
The translucent, see-through Interactive
Channel Banner makes access to the key
features of the System fast and easy.
Enjoy digital programming
now, and high-definition
programming as it becomes
available.
DIRECTV®currently provides access to over
200 channels of digital entertainment choices.
That means more movies, sports, music, news
and information than you’ll find on cable or
any other digital TV service. The DTC100
will also receive DIRECTV®high-definition
programming as it becomes available.
Dolby1Digital
Surround Sound Capability
The revolutionary sound system offers
5.1 channel Dolby1Digital surround sound
capability with up to five full channels
and a sixth low-frequency-effects
(subwoofer) channel.
Easy-To-Navigate On-Screen
Menu System
Simulated pictures.
DIRECTV is a trademark of DIRECTV, Inc., a unit of Hughes Electronics Corp. and is used with permission.
HD/Digital Receiver

Digital | HD|Digital
10
Do I have to buy
a new TV to begin
to enjoy HDTV
programming?
The innovative RCA DTC100
HD|Digital Receiver offers you
the ability to receive digital pro-
gramming and display it in
analog format on the television
you have now.
Receives:
• All off-air standard and all
18 ATSC digital formats,
including standard digital
(SDTV) and high-definition
digital (HDTV) channels
• All current standard
unscrambled analog cable
broadcast channels
• Current standard digital
satellite programming from
DIRECTV®
, and the capability
to receive high-definition
satellite programming as it
becomes available.
A high-definition digital receiver can be your
introduction to the world of HDTV programming.
DTC100
■Multi-Platform Capability
–DIRECTV®Programming
-Over 200 Channels of Digital
Programming
-High-Definition Programming
–Local Off-Air Reception
-Analog Broadcasts
-Digital Broadcasts
–High-Definition Output
●Dolby1Digital Surround Sound
Capability
◆One-Touch Record
◆On-Screen Menu System
◆Universal Remote Control
◆Coaxial RF Inputs (2)
◆A/V Outputs (2 Sets)
◆S-VHS Output
◆Satellite Input
◆Optical Dolby1Digital Output
◆HD Monitor Output
(VGA Connector–RGB)
DTC100
DIRECTV is a trademark of DIRECTV, Inc., a unit of Hughes Electronics Corp. and is used with permission.

ANTENNA/
CABLE
INPUT
INPUT
INPUT
VIDEO
POWER
LR
AUDIO S-VIDEO AUDIO
R
L
SELECTED OUTPUTS
DVD COMPONENT INPUT
PBPRY
STEREO INPUT
(S)VGA 1 (S)VGA 2
AUDIO INPUTS
LR
DIGITAL
TV
FIXED VARIABLE
LR LR
AUDIO OUTPUTS
RL
EXT SPEAKERS EXT
INT
DEVICE /
HUB
PC/
HUB
USB
VIDEO L R
AUDIO
+––+
➧
Digital High-Resolution Monitors
Enjoy the clarity of an HDTV-quality picture.
Digital High-Resolution | Features
Monitors
11
Picture Features
Dark-Tint Screen—
25% Improved Brightness
(on Projection Models)
New screen design improves brightness
by 25% while utilizing dark-tint double
lenticular and fresnel levels to enhance
picture contrast with blacker blacks,
brilliant whites, and deep rich color.
High Performance Video
Amplifier
Delivers high resolution and clarity by
extending the video frequency response.
Optimizes performance from high-resolution
sources such as the RCA Satellite System,
DVD players, and S-Video signals (S-VHS, Hi8).
3-Line Digital Comb Filter
Separates black-and-white detail from
color information to virtually eliminate edge
crawls and rainbow effects while extending
picture resolution.
Sound Features
Broadcast Stereo with dbx3
Noise Reduction
Improves the clarity and fidelity of stereo
broadcasts by restoring dynamic range and
suppressing unwanted noise.
SRS Sound Retrieval System4
Brings dimensional realism to television
audio without the need for additional
speakers. Restores the information used
to determine distance and direction turning
normal audio into a three-dimensional
sensation.
Pixel Comparison
From the minimum of 300,000 pixels all the
way up to about a million pixels is called
standard definition digital television, or SDTV.
High-definition digital television, or HDTV,
starts at around a million pixels and can go
all the way up to 2 million—almost 10 times
the resolution of today’s TV.
Changing Entertainment. Again.
Connect your world—
for today and tomorrow.
The RCA brand has always offered innovative
technologies to enhance your home entertainment
experience, and now the RCA Digital High-Resolution
Monitor lives up to this commitment by offering
outstanding picture performance and multiple
connectivity options. This is the perfect vehicle to
help you make the transition into the world of HDTV.
In addition, with its 40 audio and video inputs, the
RCA High-Resolution Monitor has much more to offer
outside the world of HDTV. It’s the perfect display for
your computer, VCR, standard TV broadcasts, video
games and your DVD player—and they can all be
connected at the same time!
Combining the Digital High-
Resolution Monitor with a
DTC100 High-Definition
Digital Receiver will provide
you an HDTV-quality picture.
Within the monitor’s 4:3 aspect ratio
viewing area, you receive the same pixel
resolution inch for inch as with an
HDTV picture. It is the 30% wider
16:9 aspect ratio screen that defines
HDTV resolution.
Computer Speaker System Stereo System
Terrestrial
(NTSC)
HDTV Digital
Receiver
Cable
Front Jack Panel
Satellite
System
VCR DVD Player
OR
4:3 ratio = 864,000 pixels
16:9 ratio = Over 1 million pixels
Simulated pictures.
Video Game
OR
Camcorder

MM61100
Digital | High-Resolution
Monitors
12
All Projection
Digital High-
Resolution
Monitors feature:
■Digital TV Compatible with:
–Up to 1.3 Million Pixels
–1280 Lines of Horizontal
Resolution
■SVGA Progressive Scan
Compatible (Multiscan/Multisync)
Picture Features
■Digital High Resolution
Optics Package
–Dark-Tint Screen—
25% Improved Brightness
–Custom-Designed Digital High-
Resolution Lens System
–Digital High Resolution
Projection Tubes
■Digital Focus
■3-Line Digital Comb Filter
■High Performance Video Amplifier
■Auto Color Control
■Auto Color Balance
■High Performance Scan Velocity
Modulation (SVM)
■Adjustable Color Warmth
Sound Features
●Broadcast Stereo with dbx3
Noise Reduction
●SRS Sound Retrieval System4
●Second Audio Program (SAP)
Convenience Features
◆Advanced Twin Tuner™
Picture-In-Picture
◆Picture Reset
◆Advanced Auto Channel Search
◆On-Screen Menu System
◆Interactive Setup Menu
◆V-Chip Parental Control
◆Master Touch®Universal
Glo-In-The-Dark Remote
◆40 Multiple Inputs/Outputs
Including:
–3 A/V, Each with Auto Detectible
S-Video
–2 SVGA / VGA
–Multiscan Component Video
Input (Y, Pr, Pb)
–Front A/V with USB Port
MM61100
Digital High-Resolution Projection System
MM52100 52"diagonal
◆Optional QuikFit Super Shield3
Available (SSH531)
◆521/2"H, 443/8" W, 25"D
MM61100 61"diagonal
◆Optional QuikFit Super Shield3
Available (SSH533)
◆611/4"H, 511/2" W, 253/4"D
Combining these sets
with an RCA brand
HD | Digital Receiver
gives you the sharpest
picture available.
The RCA Projection Digital High-Resolution Monitor has a dark-tint screen which gives a large,
crisp picture. This screen is 25% brighter than a conventional screen and delivers up to a stunning
1.3 million pixels.
Also Available:
Simulated picture.

MM36100
It’s what goes on behind the screen that makes
this picture incredible.
MM36100
MM27100
MM27100 27"diagonal
◆0.66 Digital Precision Pitch
Picture Tube
◆50 Watts of Picture Power
◆241/2"H, 251/2" W, 207/10"D
(Available late ‘99)
MM36100 36"diagonal
◆0.78 Digital Precision Pitch
Picture Tube
◆65 Watts of Picture Power
◆309/10"H, 333/5" W, 243/10"D
Digital | High-Resolution
Monitors
13
All Direct-View Digital
High-Resolution
Monitors feature:
■Digital TV Compatible with:
–Up to 864,000 Pixels
–820 (MM27100)/930 (MM36100) Lines
of Horizontal Resolution
■SVGA Progressive Scan Compatible
(Multiscan/Multisync)
Picture Features
■DPP-Digital Precision Pitch Picture Tube
■3-Line Digital Comb Filter
■High Performance Video Amplifier
■Dark-Tint, High-Contrast Picture Tube
■Auto Color Control
■Auto Color Balance
■High Performance Scan Velocity
Modulation (SVM)
■High Resolution Dynamic Focus
Electron Gun
Sound Features
●Broadcast Stereo with dbx3Noise
Reduction
●SRS Sound Retrieval System4
●Second Audio Program (SAP)
Convenience Features
◆Color Picture-In-Picture
◆Picture Reset
◆Advanced Auto Channel Search
◆On-Screen Menu System
◆Interactive Setup Menu
◆V-Chip Parental Control
◆Master Touch®Universal
Glo-In-The-Dark Remote
◆40 Multiple Inputs/Outputs Including:
–3 A/V, Each with Auto Detectible
S-Video
–2 SVGA / VGA
–Component Video Input
(Y, Pr, Pb)
–Front A/V with USB Port
Combining these sets
with an RCA brand
HD | Digital Receiver
gives you the sharpest
picture available.
The RCA Direct-View Digital High-Resolution Monitor delivers an incredible picture. It starts with
a Digital Precision Pitch Picture Tube which features a 0.66mm* center screen pitch that delivers crisp
focus and incredible color. An INVAR shadow mask is combined with 50* watts of concentrated
picture power to deliver a bright and sharp picture.
*On Model MM27100; Model MM36100 features a 0.78mm center screen dot pitch and 65 watts of picture power.
Simulated pictures.

With GUIDE Plus+ GOLD1 ,
finding your favorite show
just got easier, and it won’t
matter who has the remote.
Changing Entertainment. Again.14
TVs | GUIDE Plus+ GOLD
Program Listings and
One-Touch Record...
right through your remote control. Find out
what’s on. GUIDE Plus+ GOLD1is a built-in feature
that provides an instant summary of your favorite
TV shows at the touch of a button—yet requires
no monthly fee! The three-day Guide also allows
you to view listings up to 72 hours in advance and
delivers the capability for One-Touch Tuning and
VCR recording with the press of a button. And now
you can keep up-to-date on the world’s latest news
stories through the “NEWS” feature.
Introducing GUIDE Plus+ GOLD1
Interactive Program Guide Premiere Series.
Simulated picture.

15
How to find the show you want.
May we suggest something for you to watch?
Updated news at the press of a button.
Changing Entertainment. Again.
Finding your program
is now easy.
Watching it is amazing with
excellent picture and sound.
News
Review top national and world news stories,
updated daily, and accessed through the
NEWS menu item on the Guide bar.
Comprehensive coverage includes news,
weather, sports and entertainment stories.
The Grid Guide
Using the directional arrow pads on your
remote, you may scroll through up-to-the-
minute TV listings, or scroll to future programs.
As each channel grid is highlighted, the
current program appears in the preview
window, and a description is shown in the
information area to the right of the window.
Or if you can't tear yourself away from the
game, you can continue to watch your
programming in the preview window while
you scan through the program grids.
The Sort Guide
Want to relax and watch a movie?
SORT lists movies by theme that are on
for the next seven days. SORT can also
help you find your favorite game or
sports or children’s programs.
Picture Features
3-Line Digital Comb Filter
New digital separation technology
dramatically enhances picture resolution
by eliminating blurred edges between
colors and reducing dot crawl, producing
a new level of picture sharpness and detail.
Digital Focus
Computer-aligned 10-bit circuitry provides
precise and consistent picture performance
from the moment the TV is turned on.
When combined with Dynamic Focus, it
maximizes picture brightness with sharper
corner focus, ensuring a beautifully
detailed picture across the entire screen.
Dark-Tint, High-Contrast Picture
Tube (on Direct-View Models)
Dark glass picture tube delivers outstanding
picture contrast for blacker blacks, brilliant
whites, and deep, rich colors even in bright
room conditions.
High Performance Scan Velocity
Modulation (SVM)
Improved SVM circuitry automatically varies
the scanning speed of the picture tube’s
electron beam to improve sharpness and
detail, especially in high-contrast areas.
Custom Convergence
When the earth’s magnetic field interferes
with the Projection TV alignment, adjustable
convergence provides fine tuning for red,
blue and green Projection TV tubes. The
8-bit DA converter allows precise alignment,
restoring picture quality to its original setting.
Sound Features
SRS Sound Retrieval
System2
Delivers three-dimensional realism from the
television’s built-in speakers by restoring the
spatial information your ears use to determine
distance and direction. There are no additional
speakers, wires or equipment required.
Sound Logic™Audio Leveler
The leveler automatically reduces the
annoying “blast” in volume during
commercial breaks, and also amplifies
softer sounds in program material.
This feature eliminates the need to
constantly adjust the volume control.
TVs | Full-Size
Program and record with one touch.
Even if your VCR is flashing 12:00, GUIDE
Plus+ GOLD1can record your favorite show.
Simply highlight the program you would like
to record and press the Record button on the
remote. You can choose to record shows
once, daily, or weekly.
1
Simulated picture.

16
Viewing Area
PIX IN PIX
TWIN TUNER
46" 52"
28% more
viewing area
than a 46"
56"
49% more
viewing area
than a 46"
61"
76% more
viewing area
than a 46"
Screen sizes measured diagonally.
TVs | Home Theatre Premiere™
P56940 56"diagonal
◆Optional Quick Fit Super Shield3
Available (SSH532)
◆565/8" H, 471/2"W, 261/2"D
P61940 61"diagonal
◆Optional Quick Fit Super Shield3
Available (SSH533)
◆611/4" H, 511/2" W, 26" D
Our Home Theatre
Premiere™Series
comes with
everything except
the popcorn.
Simulated picture.
Also Available:

PIX IN PIX
TWIN TUNER
PIX IN PIX
TWIN TUNER
17
All Projection
Models on this
spread feature:
Picture Features
■Home Theatre™Premiere Video
Systems with 900 Lines of
Horizontal Resolution4
■Digital Focus
■3-Line Digital Comb Filter
■Custom-Designed Hybrid
Lens System
■Dark-Tint Screen—25%
Improved Brightness
■High-Performance Scan Velocity
Modulation (SVM)
■Adaptive Video Noise Reduction
■Auto Color Balance (also called
Auto Kine Bias–AKB)
■Deluxe Shielded Tuner with
181-Channel Tuning Capability5
■Wide Band Video Amplifier
■Dynamic BlackStretch Circuitry
Sound Features
●Broadcast Stereo with dbx6
Noise Reduction
●10-Watt7Stereo Amplifier
●SRS Sound Retrieval System2
●Sound Logic™Audio Leveler
●Matrix Surround Sound8with
External Speaker Terminals
Convenience Features/
Connections
◆GUIDE Plus+ GOLD1On-Screen
Program Guide
◆Advanced Twin Tuner™
Picture-In-Picture
◆Master Touch®Universal
Glo-In-The-Dark Remote
◆Advanced Auto Channel Search
◆Trilingual On-Screen Display
◆V-Chip Parental Control
◆Two Sets of Audio/Video Inputs
with Dual S-Video Inputs
◆One Pair of Switchable
(Variable/Fixed) Audio Outputs
◆Speaker Terminals
P52945 52"diagonal
◆Optional Quick Fit Super Shield3
Available (SSH531)
◆52" H, 441/4"W, 261/4"D
P52940 52"diagonal
◆Optional Quick Fit Super Shield3
Available (SSH531)
◆52" H, 441/4"W, 261/4"D
TVs | Home Theatre
Premiere™
1
Simulated pictures.

PIX IN PIX
TWIN TUNER
PIX IN PIX
TWIN TUNER
TVs | Home Theatre
Premiere™
18
Home Theatre Premiere™models with
Picture-In-Picture can put you in midfield
seats at two different games.
G36705 36"diagonal
■Home Theatre™Video System
with 790 lines of Horizontal
Resolution9
◆461/8"H, 39" W, 241/4"D
G32705 32"diagonal
■Home Theatre™Video System
with 765 lines of Horizontal
Resolution10
◆461/8"H, 361/2" W, 21"D
G32705
G36705
Simulated picture.

PIX IN PIX
TWIN TUNER
PIX IN PIX
TWIN TUNER
TVs | Home Theatre
Premiere™
19
All models
on this spread
feature:
Picture Features
■Direct-View Home Theatre™
Video System
■3-Line Digital Comb Filter
■High Performance Scan Velocity
Modulation (SVM)
■55 Watts of Picture Power
■Dark-Tint, High-Contrast
Picture Tube
■Adaptive Video Noise Reduction
■Auto Color Balance (also called
Auto Kine Bias–AKB)
■Deluxe Shielded Tuner with
181-Channel Tuning Capability5
■Wide Band Video Amplifier
■Dynamic BlackStretch Circuitry
Sound Features
●Broadcast Stereo with dbx6
Noise Reduction
●10-Watt7Stereo Amplifier
●SRS Sound Retrieval System2
●Sound Logic™Audio Leveler
●Matrix Surround Sound8with
External Speaker Terminals
Convenience Features/
Connections
◆GUIDE Plus+ GOLD1On-Screen
Program Guide
◆Advanced Twin Tuner™
Picture-In-Picture
◆Master Touch®Universal
Glo-In-The-Dark Remote
◆Advanced Auto Channel Search
◆Trilingual On-Screen Display
◆V-Chip Parental Control
◆Two Sets of Audio/Video Inputs
with Dual S-Video Inputs
◆One Pair of Switchable
(Variable/Fixed) Audio Outputs
◆Speaker Terminals
F32705 32"diagonal
■Home Theatre™Video System
with 765 lines of Horizontal
Resolution10
◆29"H, 301/8" W, 221/2"D
F36705 36"diagonal
■Home Theatre™Video System
with 790 lines of Horizontal
Resolution9
◆301/8"H, 335/8" W, 243/8"D
F36705
F32705
1
Simulated picture.

TVs | Home Theatre
20
Picture Features
■Home Theatre™Video System
with 900 Lines of Horizontal
Resolution4
■Digital Focus
■Custom-Designed Hybrid
Lens System
■3-Line Digital Comb Filter
■High Performance Scan Velocity
Modulation (SVM) (not available
on P46921)
■High Resolution, High Gain Screen
■Adaptive Video Noise Reduction
■Deluxe Shielded Tuner with
181-Channel Tuning Capability5
■Wide Band Video Amplifier
■Dynamic BlackStretch Circuitry
■Auto Color Balance (also called
Auto Kine Bias–AKB)
Sound Features
●10-Watt7Stereo Amplifier
●Broadcast Stereo with dbx6
Noise Reduction
●Sound Logic™Audio Leveler
Convenience Features/
Connections
◆GUIDE Plus+1On-Screen
Program Guide
◆Color Picture-In-Picture11
◆Master Touch®Universal
Glo-In-The-Dark Remote
◆Advanced Auto Channel Search
◆Trilingual On-Screen Display
◆V-Chip Parental Control
◆Two Sets of Audio/Video Inputs
with Dual S-Video Inputs
◆One Pair of Switchable
(Variable/Fixed) Audio Outputs
All models on this
spread feature:
PIX IN PIX
COLOR
1
RCA Projection models deliver a unique
Home Theatre experience.
P60921 60"diagonal
◆Optional Quick Fit Super Shield3
Available (SSH533)
◆611/4"H, 511/2" W, 26"D
◆Slim Cabinet Design
P60921
Only 26" deep
Simulated picture.
