real living A109000605 User manual

TM
11X11 FT GREY POP UP SUN SHELTER
ASSEMBLY INSTRUCTIONS
ITEM#: A109000605
SKU#810416874
Need help? We are here for you! 1(866)578 – 6569 24/7 • Toll Free

2/
Safety Information
• Please read and understand this entire manual before attempting to assemble or install the product.
• Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
• The assembled gazebo should be located at least 6 feet from any obstruction such as fence, garage, house, overhanging
branches, laundry lines or electrical wires.
• Some parts may contain sharp edges. Wear protective gloves if necessary, during assembly.
• This unit is heavy. For safety, do not assemble this item alone. Two people are recommended for safe assembly.
• Check all nuts and bolts periodically for tightness and, when required, tighten them again.
• Pay attention to the parts orientation
• Install the gazebo on level ground.Stakes are provided to secure the gazebo to the ground.
• Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do not have enough anchorage in these types of
soil.
• If you wish to secure the gazebo to a wood deck or concrete surface, use anchors suited to these surfaces.
• Snow must be cleared off regularly during snowy days.Remove the snow at the roof top when it is thicker than 2 inches. In
order to avoid damage, use a plastic snow rake to remove excessive snow and ice buildup from roof and keep away from
falling debris.
• Do not leave the gazebo where there is a risk of high wind, as possible damage will occur to the structure.
• Any assembly or maintenance of the product must be carried out by adults only.
• Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for installation
and use. Some special procedures may be valid in your area.
• Keep all ame and heat sources away from the tent fabric. This tent is made with fabric that meets CPAI-84 speci cations
for ame resistance. It is not re proof. The fabric will burn if right in continuous contact with any ame source. The
application of any foreign substance to the tent fabric may render the ameresistant properties ineffective.
• If any scratch paint, please touch up to prevent rusting
• For outdoor use only.
• Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the
nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and
thus not covered by the warranty.
• To minimize this condition, it is recommended to use care when assembling and handling the product to prevent
scratching the paint. Should any scratching or damage occur, it is recommended to cover the scratch immediately with
rust inhibiting paint (not included).
• Surface rust can also be easily removed with a very light application of regular cooking oil or WD-40. If surface oxidation
(rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or patio and
caused damaging stains, which may be dif cult to remove. This can be prevented if the above-mentioned measures are
taken to keep the product from oxidizing.
• Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
• Keep instruction manual for future reference.
• Keep the original packaging to store the gazebo.
• Periodically check and ensure that all bolts are well-tighten during use
WARNINGS:
WARRANTY:
WHAT IS COVERED ?
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 1 Year
MAINTENANCE

3/
TOOLS NEEDED
IMPORTANT
How many people needed for the installation work

4/
EXPLODED DRAWING

5/
Parts List
Part ImageLabel Part Number Description Qty
A1 Gazebo Frame 1
B1 Connector 4
C1 Small Canopy 1
D1 Big Canopy 1
E1 Mosquito Netting 1

6/
Hardware Pack
Part ImageLabel Part Number Description Qty
AA ) Stake
Φ 5*230 8
BB ) Big Stake
Φ 7*230 4
CC 1 Rope
L=3000 4
DD 1 Netting Rope
L=3400 4
EE 1 Ring 32
Add
0
0
0
0
4
FF 1 Bag 1 0

7/
STEP 1

8/
STEP 2

9/
STEP 3

10/
STEP 4

11/
STEP 5

12/
STEP 6

13/
STEP 7

14/
STEP 8
